True TUC-27F-D-2 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TUC-27F-D-2
TUC-27F-D-2
†Depth does not include 1"(26 mm) for rear bumpers. ▲Plug type varies by country.
* Height does not include 61/4"(159 mm) for castors or 6"(153 mm) for optional legs.
8/07
True’s undercounter units are
designed with enduring quality
that protects your long term
investment.
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility
costs, exceptional food safety
and the best value in today’s
food service marketplace.
Oversized, environmentally
friendly (R404A) forced-air
refrigeration system holds
-10°F (-23.3°C). Ideally suited
for both frozen foods and ice
cream.
All stainless steel front, top
and ends. Matching aluminum
finished back.
Front breathing.
Each drawer accommodates
one (1) full size 12"L x 20"W
x 6"D (305 mm x 508 mm x
153 mm) food pan (sold
separately).
Automatic defrost system time-
initiated, time-terminated.
Foamed-in-place, high density
polyurethane insulation (CFC
free).
Undercounter:
Drawered Freezer
®
Model Drawers
Capacity
(Cu. Ft.)
(liters)
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TUC-27F-D-2 2 6.5
185
275/8
702
301/8
766
293/4
756
1/3
1/3
115/60/1
230-240/50/1
7.4
3.3
5-15P
▲
7
2.13
215
98

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TUC-27F-D-2 TFQY05E TFQY05S TFQY05P TFQY053
TUC-27F-D-2
DESIGN
• True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder product
temperatures, lower utility costs, exceptional
food safety and the best value in today’s
food service marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly
(CFC free) R404A refrigerant.
• Oversized, factory balanced refrigeration
system with guided airflow to provide
uniform product temperatures.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser; maintains -10°F (-23.3°C) cabinet
temperatures. Ideally suited for both frozen
foods and ice cream.
• Sealed, cast iron, self-lubricating evaporator
fan motor(s) and larger fan blades give True
undercounter units a more efficient low
velocity, high volume airflow design. This
unique design ensures faster temperature
recovery and shorter run times in the busiest
of food service environments.
• Condensing unit access in back of cabinet,
slides out for easy maintenance.
• Automatic defrost system time-initiated,
time-terminated.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and ends.
Matching aluminum finished back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless steel
floor with coved corners.
• Insulation - entire cabinet structure and
drawer facings are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• 5" (127 mm) diameter stem castors - locks
provided on front set. 36" (915 mm) work
surface height.
DRAWERS
• Stainless steel exterior drawer facings and
liners. Stainless steel drawer frames.
• Each drawer fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to ensure permanent
attachment.
• Heavy-duty stainless steel drawer slides and
rollers. Removable without tools for easy
cleaning.
• Magnetic drawer gaskets of one piece
construction, removable without tools for
ease of cleaning.
PAN CAPACITY
• Each drawer accommodates one (1) full size
12"L x 20"W x 6"D (305 mm x 508 mm x 153
mm) food pan (sold separately). Drawers will
support varying size pan configurations with
pan divider bars (drawer pans and divider
bars optional).
MODEL FEATURES
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase, 15 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230 - 240V / 50 Hz.
❒ 6" (153 mm) standard legs.
❒ 6" (153 mm) siesmic/flanged legs.
❒ 2
1/2" (64 mm) diameter castors.
❒ Basic overshelf.
❒ Sandwich/salad service shelf.
❒ Single utility shelf.
❒ Double utility shelf.
❒ Stacking collar.
❒ 30" (762 mm) deep, 1/2" (13 mm) thick, white
polyethylene cutting board. Requires “L”
brackets.
❒ 30" (762 mm) deep, 1/2" (13 mm) thick,
composite cutting board. Requires “L”
brackets.
❒ Heavy duty, 16 gauge tops.
❒ Exterior rectangular digital temperature
display (factory installed).
❒ ADA compliant models with 34" (864 mm)
work surface height.
❒ Low profile models with 317/8" (810 mm)
work surface height.
❒ Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant). Consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
Undercounter:
Drawered Freezer
25/16"
(59 mm)
37/8"
(99 mm)
125/8"
(321 mm) 75/16"
(186 mm)
293/4"
(756 mm)
3515/16"
(913 mm)
63/16"
(158 mm)
ELEVATION RIGHT VIEW
279/16"
(701 mm)
4615/16"
(1193 mm)
301/16"
(764 mm)
157/8"
(404 mm) 1"
(26 mm)
1711/16"
(450 mm)
1911/16"
(501 mm)
5"
(127 mm)
