True TR3F-6HS User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
(636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# (636)272-9471
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T
RUE
R
EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
AVAILABLE AT:
TR3F-6HS
TR3F-6HS
Model Doors
Capacity
(Cu. Ft.)
(liters)
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TR3F-6HS 6 85
2407
761/2
1944
345/8
880
781/4
1988
11/2115/208-230/60 11.8 14-20P 9
2.74
790
359
†Depth does not include 23/8
"
(61 mm) for rear condensate enclosure.
*Height does not include 5
"
(127 mm) for castors, 6
"
(153 mm)
for optional legs,
and 1
"
(26 mm) for system mechanical components.
Requires 115/208-230/60 Hz, singel phase, 3 pole, 4 wire circuit.
12/05
Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower
utility costs and exceptional food
safety.
Oversized, factory balanced,
refrigeration system holds -10°F
(-23.3°C) for the best in food
preservation.
300 series stainless steel exterior
and interior. The very finest
stainless with higher tensile
strength for fewer dents and
scratches.
Equipped with (1) interior kit
option per full section, factory
installed. Four (4) different
interior kits available.
Positive seal self-closing doors
with 120° stay open feature.
Lifetime guaranteed door hinges.
Entire cabinet structure and
solid doors are foamed-in-place
using high density, CFC free,
polyurethane insulation.
Automatic defrost system
time-initiated, temperature-
terminated. Saves energy
consumption and provides
shortest possible defrost cycle.
TR Series:
Reach-In Solid Half Door Freezer
R
®
STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TR3F-6HS TFQX75E TFQX59S TFQY57P TFQX753
TR3F-6HS
DESIGN
• True’s solid door reach-in’s are designed with
enduring quality that protects your long term
investment.
• Designed using the highest quality materials
and components to provide the user with colder
product temperatures, lower utility costs and
exceptional food safety.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly (CFC
free) 404A refrigerant.
• Extra large evaporator coil balanced with higher
horsepower compressor and large condenser
maintains -10°F (-23.3°C) cabinet temperature.
Ideal for both frozen foods and ice cream.
• Sealed, cast iron, self-lubricating evaporator fan
motors and larger fan blades give True reach-
in’s a more efficient low velocity, high volume
airflow design. This unique design insures faster
temperature recovery and shorter run times in
the busiest of foodservice environments.
• Top mounted refrigeration system with
evaporator positioned out of food zone to
maximize capacity.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest possible
defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors, front,
sides, back and bottom.
• Interior- 300 series stainless steel liner and floor.
• Insulation - entire cabinet structure and solid
doors are foamed-in-place using high density,
CFC free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4" (102 mm) diameter
stem castors - locks provided on front set.
DOORS
• 300 series stainless steel. Doors open within
cabinet dimension. Door locks standard.
• Lifetime guaranteed recessed door handles.
Each door fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to insure permanent
attachment.
• Positive seal self-closing doors with 120° stay
open feature. Lifetime guaranteed door hinges.
• Magnetic door gaskets of one piece
construction, removable without tools for ease
of cleaning.
SHELVING
• One (1) factory installed, interior kit option
per full section. Four (4) different interior kits
available (see Kit Options). Pilasters and tray
slides are factory installed at no charge.
LIGHTING
• Incandescent interior lighting - safety shielded.
Lights activated by rocker switch mounted
above top doors.
MODEL FEATURES
• Exterior mounted temperature monitor.
Available with either °F or °C display.
• Evaporator epoxy coated to eliminate the
potential of corrosion.
• Backguard improves airflow.
• Minimum wattage heater in cabinet frame and
door.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and ready
for final connection to a 115/208-230/60/1 phase
- 20 amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒6" (153 mm) stainless steel legs.
❒Stainless steel rail skirt for use with legs
(field installed).
❒Metal door handles (factory installed).
❒Electronic temperature control (factory
installed).
❒Correctional Facilities Options.
❒Curb mountable units.
❒Remote cabinets (condensing unit supplied
by others; system comes standard with 404A
expansion valve and requires R404A refrigerant),
consult factory technical service department for
BTU information.
KIT OPTIONS
❒Kit #1: Nine (9) sets of #1 type tray slides and
pilasters (factory installed), bottom support of
one (1) 18"L x 26"D (458 mm x 661 mm) pan or
two (2) 14"L x 18"D (356 mm x 458 mm) pans
❒Kit #2: One (1) set half-section #2 steel rod
tray slides and pilasters (factory installed), rim
support of one (1) 18"L x 26"D (458 mm x
661 mm) pan.
❒Kit #3: Six (6) sets of universal type tray slides
and pilasters (factory installed), bottom support
of one (1) 18"L x 26"D (458 mm x 661 mm) pan,
two (2) 12"L x 20"D (305 mm x 508 mm) pans or
two (2) 14"L x 18"D (356 mm x 458 mm) pans.
❒Kit #4: Three (3) chrome shelves 25"L x 273/4"D
(635 mm x 705 mm). Four (4) shelf supports
included per shelf. Shelves adjustable on 6"
(153 mm) increments.
❒Additional kit option components available
individually.
115/208-230/1
NEMA-14-20R
TR Series:
Reach-In Solid Half Door Freezer
ELEVATION
843/16"
(2139 mm)
5"
(127 mm)
1"
(26 mm)
RIGHT VIEW
13/16"
(31 mm)
2317/32"
(598 mm)
585/32"
(1478 mm)
761/2"
(1944 mm)
345/8"
(880 mm)
PLAN VIEW
783/16"
(1986 mm)
6015/32"
(1536 mm)
441/4"
(1124 mm)
59/16"
(142 mm)
191/16"
(485 mm)
2823/32"
(730 mm)
3615/16"
(939 mm)
77"
(1956 mm)
25/16"
(59 mm)
