True GEM-72FC User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
GEM-72FC
GEM-72FC
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†HHP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
GEM-72FC 3 72
2039
678
1/4
1988
293/8
747
791/8
2010
1/2
1/2
115/60/1
115/60/1
12.0
6.9
5-15P
▲
9
2.74
718
326
†Depth does not include 13/8" (35 mm) for door handle. ▲Plug type varies by country.
7/07
Glass end models offer greater product
visibility for more attractive floral
displays.
Oversized and balanced refrigeration
system, factory sealed and pre-lubricated
for long life. Designed to hold 35°F
(1.6°C) to accommodate a broad range
of floral arrangements.
Exterior - non-peel or chip black
laminated vinyl; durable and permanent.
Interior - attractive black aluminum
interior liner with 300 series stainless
steel floor.
Self closing doors. Positive seal, torsion
type closure system.
“Low-E”, double pane thermal insulated
glass side panel and door assemblies with
extruded aluminum frames. The latest in
energy efficient technology.
Patented integrated door light (IDL)
system for brighter, shadow free
illumination. Special interior agro
lighting designed for flowers to prevent
premature discoloration.
Illuminated exterior sign panel.
Entire cabinet structure is foamed-
in-place using high density, CFC free,
polyurethane insulation.
Bottom mounted units feature
”No stoop” lower shelf to maximize
product visibility.
Storage on top of cabinet.
Easily accessible condenser coil for
cleaning.
Glass Door Merchandisers:
Swing Door Glass End Floral Case Refrigerator
®
R

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
GEM-72FC TFBY07E TFBY07S TFBY07P TFBY073
GEM-72FC
DESIGN
• True’s commitment to using the highest
quality materials and refrigeration systems
provides the user with dependable product
temperatures, and lower utility costs in
an attractive merchandiser that brilliantly
displays high profit floral arrangements.
• True’s floral merchandisers offer interior
agro lighting combined with a baffled
airflow design which creates the ideal
environment to prolong fresh flower shelf
life.
• Brilliant black exterior and interior with
product accentuating black shelves further
entice customers to purchase high profit
floral arrangements.
REFRIGERATION SYSTEM
• Factory engineered, self-contained, capillary
tube system using environmentally friendly
(CFC free) 134A refrigerant.
• Oversized and balanced refrigeration
system, factory sealed and pre-lubricated
for long life. Designed to hold 35°F (1.6°C)
to accommodate a broad range of floral
arrangements.
• Sealed, cast iron, self-lubricating evaporator
fan motor(s) and larger fan blades give True
merchandisers a more efficient low velocity,
high volume airflow design. This unique
design ensures faster temperature pull
down, dependable holding temperatures
and faster recovery in high use situations.
• Baffled airflow provides even air distribution
for longer shelf life of fresh flowers.
• Bottom mounted condensing unit positioned
for easy maintenance; “no stoop” lower
shelf maximizes visibility by raising
merchandised product to higher level.
CABINET CONSTRUCTION
• Exterior - non-peel or chip black laminated
vinyl; durable and permanent.
• Glass ends - Low-E, double pane thermal
glass assemblies. The latest in energy
efficient technology.
• Interior - attractive aluminum liner with 300
series stainless steel floor.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with leg levelers.
• Illuminated exterior sign panel.
DOORS
• ”Low-E”, double pane thermal glass door
assemblies with extruded aluminum frames.
The latest in energy efficient technology.
• Each door fitted with 12" (305 mm) long
black PVC handle.
• Self closing doors. Positive seal, torsion type
closure system.
• Magnetic door gasket of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty, black PVC
coated wire shelves 249/16"L x 221/8"D
(624 mm x 562 mm). Four (4) chrome plated
shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Fluorescent interior lighting. Each door
utilizes full-length, patented, integrated
door light (IDL) system. Safety shielded.
• Special interior agro lighting designed for
flowers to prevent premature discoloration.
• Cabinet lighting utilizes electronic ballast
and T-8 bulbs for brighter illumination,
longer bulb life and increased energy
efficiency.
MODEL FEATURES
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase, 15 amp dedicated outlet. Cord and
plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230-240V / 50 Hz.
❒White exterior.
❒Rosewood exterior.
❒Mirrored back.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒21/2" (64 mm) diameter castors.
❒Additional shelves.
❒Remote cabinets (condensing unit supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant). Consult factory technical
service department for BTU information.
115/60/1
NEMA-5-15R
Glass Door Merchandiser:
Swing Door Glass End Floral Case Refrigerator
ELEVATION PLAN VIEW
781/8"
(1985 mm)
2913/16"
(758 mm)
3029/32"
(786 mm)
21/8"
(54 mm)
793/8"
(2017 mm)
13/8"
(35 mm)
535/8"
(1363 mm)
2313/16"
(605 mm)
7615/16"
(1955 mm)
5/16"
(8 mm)
