True TSD-47G User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
S
A
V
I
N
G
S
E
N
E
R
G
Y
S
5
YEAR
COMPRESSOR
WARRANTY
USA
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
TSD-47G
TSD-47G
Model
Glass
Doors
Capacity
(Cu. Ft.)
(liters)
# of
Shelves
Cabinet Dimensions
(inches)
(mm)
LD†H*
HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TSD-47G 2 47
1331
654
1/8
1375
295/8
753
783/8
1991
1/2
1/2
115/60/1
230-240/50/1
10.6
5.4
5-15
▲
9
2.74
480
218
3/05
R
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility costs,
exceptional food safety and the
best value in today’s food service
marketplace.
Oversized, factory balanced,
refrigeration system holds 33°F
to 38°F (.5°C to 3.3°C) for the
best in food preservation.
Energy efficient, “Low-E”,
double pane thermal glass
doors.
“Low-E”, double pane thermal
glass insert with mitered plastic
channel frame.
Adjustable, heavy duty PVC
coated shelves.
NSF-7 compliant for open food
product .
Unique space saving design for
space tight kitchens.
Bottom mounted units feature:
”No stoop” lower shelf.
Storage on top of cabinet.
Compressor performs in coolest,
most grease free area of kitchen.
Easily accessible condenser coil
for cleaning.
TSD Series:
Reach-In Glass Slide Door Refrigerator
®
† Depth does not include 3/8 " (10 mm) for door handles. ▲Plug type varies by country.
* Height does not include 61/8 " (156 mm) for legs or 5 " (127 mm) for optional castors.

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
& labor and an additional 4 year
warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TSD-47G TFGY14E TFGY10S TFGY11P TFGY143
TSD-47G
DESIGN
• True’s sliding door reach-in’s are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered self-contained,
capillary tube system using
environmentally friendly
(CFC free) 134A refrigerant.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser; maintains 33°F to 38°F (.5°C to
3.3°C) for the best in food preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True reach-in’s a more
efficient low velocity, high volume airflow
design. This unique design insures
faster temperature recovery and shorter
run times in the busiest of food service
environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen. Allows for
storage area on top of unit.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel front
grill and shroud. Anodized quality
aluminum exterior ends and back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor
with coved corners.
• Insulation - entire cabinet structure is
foamed-in-place using high density, CFC
free, polyurethane insulation.
• Cabinet mounted on a welded, heavy
duty galvanized frame rail. Rail dipped in
rust inhibiting enamel paint for corrosion
protection inside and out.
• Frame rail fitted with 6" (153 mm) legs.
DOORS
• “Low-E”, double pane thermal glass inserts
with mitered plastic channel frames.
• Self-closing doors, efficient counter
balanced weight system for smooth, even,
positive closure. Sliding doors ride on
stainless steel V-Channel with stainless
steel bearings. Doors fit within plastic
channel frame.
• Each door is fitted with a 12" (305 mm)
long molded plastic handle.
SHELVING
• Six (6) adjustable, heavy duty PVC coated
wire shelves 247/16"L x 209/16"D (621 mm
x 523 mm). Four (4) chrome plated shelf
clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Safety shielded fluorescent interior
lighting.
MODEL FEATURES
• Exterior mounted temperature monitor.
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead time may apply.
❒230 - 240V / 50 Hz.
❒4" (102 mm) diameter castors.
❒Seismic/flanged legs.
❒Door locks.
❒Stainless steel interior.
❒Additional shelves.
❒11/4" (32 mm) pricing strips.
❒Wine racks.
❒Remote cabinets (condensing unit supplied
by others), consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
52"
(1321 mm)
785/16"
(1990 mm)
843/8"
(2144 mm)
61/16"
(154 mm)
541/8"
(1375 mm)
297/8"
(759 mm)
ELEVATION PLAN VIEW
299/16"
(751 mm)
TSD Series:
Reach-In Glass Slide Door Refrigerator
