True TUC-44D-2 User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • FAX [phone] • [phone] • www.truemfg.com
Parts Dept. (800)424-TRUE • Parts Dept. FAX# [phone]
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
TM
AVAILABLE AT:
TUC-44D-2
TUC-44D-2
Model Drawers
Capacity
(Cu. Ft.)
(liters)
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TUC-44D-2 2 11.4
323
441/2
1131
321/4
820
293/4
756
1/5
1/3
115/60/1
230-240/50/1
5.1
3.8
5-15P
▲
7
2.13
285
130
†Depth does not include 1
" (26 mm) for rear and 1/4 " (7 mm) for front bumpers. ▲Plug type varies by country.
*Height does not include 61/4
" (159 mm) for castors or 6 " (153 mm) for optional legs.
1/06
R
Designed using the highest
quality materials and
components to provide the
user with colder product
temperatures, lower utility
costs, exceptional food safety
and the best value in today’s
food service marketplace.
Oversized, environmentally
friendly (134A) forced-air
refrigeration system holds
33°F to 38°F (.5°C to 3.3°C).
All stainless steel front, top
and cabinet ends. Matching
aluminum finished back.
NSF approved, white
aluminum interior liner.
300 series stainless floor with
coved corners.
Foamed-in-place, high
density polyurethane
insulation (CFC free).
Each drawer accommodates
two (2) full size 12"L x 20"D
x 8"H (305 mm x 508 mm
x 204 mm) food pans (sold
separately).
Deep Undercounter:
Drawered Refrigerator
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • FAX [phone] • [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TUC-44D-2 TFPY65E TFPY65S TFPY65P TFPY653
TUC-44D-2
DESIGN
• True’s deep undercounter units are designed
with enduring quality that protects your long
term investment.
• True’s commitment to using the highest
quality materials and oversized refrigeration
systems provides the user with colder product
temperatures, lower utility costs, exceptional
food safety and the best value in today’s food
service marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained capillary
tube system using environmentally friendly
(CFC free) 134A refrigerant.
• Oversized, factory balanced refrigeration
system with guided airflow to provide
uniform product temperatures in cabinet
interior.
• Extra large evaporator coil balanced with
higher horsepower compressor and large
condenser; maintains cabinet temperatures
of 33°F to 38°F (.5°C to 3.3°C) for the best in
food preservation.
• Sealed, cast iron, self-lubricating evaporator
fan motor and larger fan blades give True
undercounter units a more efficient low
velocity, high volume airflow design. This
unique design insures faster temperature
recovery and shorter run times in the busiest
of food service environments.
• Condensing unit is accessed from behind
front grill; slides out for easy maintenance.
CABINET CONSTRUCTION
• Exterior - stainless steel front, top and
cabinet ends. Matching aluminum finished
back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor with
coved corners.
• Insulation - entire cabinet structure and
drawer facings are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• 5" (127 mm) diameter stem castors - locks
provided on front set. 36" (915 mm) work
surface height.
DRAWERS
• Stainless steel exterior with white aluminum
liner to match cabinet interior.
• Each drawer fitted with 12" (305 mm) long
recessed handle that is foamed-in-place with
a sheet metal interlock to insure permanent
attachment.
• Heavy-duty stainless steel drawer slides and
rollers. Removable without tools for easy
cleaning.
• Magnetic drawer gaskets of one piece
construction, removable without tools for
ease of cleaning.
PAN CAPACITY
• Each drawer accommodates (2) 12"L x 20"W x
8"D (305 mm x 508 mm x 204 mm) food pans
(sold separately).
MODEL FEATURES
• Evaporator is epoxy coated to eliminate the
potential of corrosion.
• Drawers will support a wide variety of
incremental pan size configurations; divider
bars available.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1 phase
- 15 amp dedicated outlet. Cord and plug set
included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230 - 240V / 50 Hz.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒
21/2 " (64 mm) diameter castors.
❒ Single utility shelf.
❒ Double utility shelf.
❒
321/8 " (816 mm) deep, 1/2 " (13 mm) thick,
white polyethylene cutting board. Requires
“L” brackets.
❒ 321/8 " (816 mm) deep, 1/2 " (13 mm) thick,
composite cutting board. Requires “L”
brackets.
❒ Heavy duty 16 gauge tops.
❒ Heavy duty package - 16 gauge tops,
20 gauge drawers, sides and back with
stainless interior.
❒ Remote cabinets (condensing units supplied
by others; system comes standard with
404A expansion valve and requires R404A
refrigerant). Consult factory technical service
department for BTU information.
115/60/1
NEMA-5-15R
Deep Undercounter:
Drawered Refrigerator
2511/16"
(653 mm)
587/8"
(1496 mm)
123/4"
(324 mm) 81/4"
(210 mm)
1/4"
(7 mm)
ELEVATION RIGHT VIEW
441/2"
(1131 mm)
293/4"
(756 mm)
3515/16"
(913 mm)
63/16"
(158 mm)
323/16"
(818 mm)
1"
(26 mm)
39/16"
(91 mm)
25/8"
(67 mm)
