Trueshopping SM206 User manual

Offering a wide selection of products at competitive prices
Steam Mop
SM206
Instruction Manual

Trueshopping
www.trueshopping.co.uk
Introduction
Thank you for choosing the Steam Mop. The Steam Mop is a new
way of cleaning that is effective and far more hygienic than
conventional methods. The Steam Mop achieves a high degree of
hygiene and increasing cleansing power by converting water into
steam using a microfiber floor cloth enhancing absorbency. When
contact is made with floor surfaces, dirt and grime can be eliminated
in a matter of seconds. Since the Steam Mop uses the active power
of steam without the use of detergents or soap, it is environmentally
friendly.
When used correctly the Steam Mop can kill dust mites and some
types of bacteria. To disinfect a specific area, position the steamer
over the area for a minimum of eight seconds. The steam
temperature will reach to approximately 90-100°C (194-212°F). Use
this procedure to disinfect floors in bathrooms, showers, around
kitchen counters, pet sleeping quarters, etc.
Please save these instructions.

Trueshopping
www.trueshopping.co.uk
Safety guidelines
Read all instructions before using this steam cleaner.
When using an electric appliance, basic precautions should always
be followed, including the following:
WARNING! To reduce the risk of fire, electric shock, or injury:
Connect to properly grounded outlets only.
Check that the main voltage corresponds to the voltage
indicated on the rating label, specifications is: 220-240V,
50Hz, 1500W.
This product is designed for domestic use only.
Do not use outdoors.
Do not leave the Steam Mop unattended while switched on.
Turn off the switch and unplug the electrical cord when not in
use and before servicing.
Never direct steam towards people, animals, plants, or
equipment containing components.
Do not immerse the Steam Mop into water or other liquids.
Do not use with damaged cord or plug. If the Steam Mop is
not working as it should, has been dropped, damaged, left
outdoors, or immersed into water, return it to the distributor.
If the supply cord is damaged, it must be replaced by the
manufacturer or a similarly qualified person to avoid a hazard.
Do not pull or carry by cord, use cord as a handle, close a
door on the cord, or pull cord around sharp edges or corners.
Keep cord away from heated surfaces.
Never force the plug into an outlet.

Trueshopping
www.trueshopping.co.uk
Do not use extension cords or outlets with inadequate current
carrying capacity.
Unplug after use. Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
Do not handle plug or Steam Mop with wet hands or operate
without shoes.
Do not insert any objects into openings. Do not use with any
opening blocked.
Do not use without floor cloth in place. Do not use without
water in the water tank.
When using on stairs use extra caution.
Store your Steam Mop indoors in a cool, dry area.
Keep your work area well lighted.
Never put cleaning detergents into the Steam Mop. This will
make the operation unsafe and damage the unit.
Never block the steam openings of the product or place it on a
soft surface, where the steam openings may be blocked.
Keep the steam openings free of lint, hair, and the like.
Use only as described in this manual. Use only
manufacturer's recommended accessories.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety.

Trueshopping
www.trueshopping.co.uk
Key features of Steam Mop
A) Handle
B) Trigger
C) Carry Handle
D) Water tank
E) Filter
F) Body
G) LED
H) Cord wrap
I) Power cord
J) Head
K) MIicrofibre cloth pad
L) Glider
M) Measuring cup
N) Large screw
O) Small screw
The following information is provided for service by a qualified
electrician only.
Rated voltage: 220-240V, 50Hz, 1500W
This appliance must be grounded. Use only the proper type
outlet when plugging in the appliance. Do not attempt to
override the ground wire feature.

Trueshopping
www.trueshopping.co.uk
Instructions for use
The Steam Mop is designed to thoroughly clean floor surfaces, such
as marble, ceramic, stone, linoleum, sealed hardwood floors and
parquet.
WARNING! On surfaces that have been treated with wax, the wax
may be removed by the heat and steam action. Do not use on
unsealed wood floors or let unit stand on any wood floor for an
extended period of time. This could cause the wood grain to rise.
When using on vinyl, linoleum or any other heat sensitive floors, use
extra caution. Too much heat can melt down glue in the flooring. It is
therefore recommended that a sample cleansing be carried out on
an isolated area of the floor. It is also recommended that you check
the use and care instructions of the surface from the floor
manufacturer to ensure suitability to steam cleaning.
Steam Mop uses tap water. Residents in areas with hard water,
should use distilled water for better performance.
How to assemble and use
1) Attach head to body.
2) Secure head with the small Philips Head Screw until it is fully
tightened.

Trueshopping
www.trueshopping.co.uk
3) Insert handle down into the body.
4) Once the handle is placed inside the body, please make sure it is
already located on the handle to the bottom.
5) Screw the Large Philips Head screw through the opening at the
back of the body into the rear of the handle, tighten with screwdriver
until secure.
6) Place the Microfiber Cloth Pad or disposable pad (optional item)
onto the mop head.
Note: Microfiber cloth is washable while the disposable pad (optional
item) is intended for one-time use.
7) Fasten the Microfiber Cloth Pad by pulling the cord while pressing
on Toggle.
Note: This step is not required if you are using disposable pad
(optional item). Disposable pad comes with built in elastic cord.

Trueshopping
www.trueshopping.co.uk
8) When using Steam Mop on carpets, place the mop head (with
microfiber cloth or disposable pad in place) over the carpet glider.
NOTE:Do not operate without either microfiber cloth or disposable
pad (optional item) in place.
9) To remove the water tank push it up and detach from the body as
shown below.
10) Pour two measuring cups of water into the water tank. The MAX
is 800ml.
11) To remove the water filter push it up and detach from the body.
12) Twist the quick release cord wrap clockwise to unwrap the power
cord completely and plug into a grounded outlet.

Trueshopping
www.trueshopping.co.uk
13) When plugged in, the LED light located on the front of the Steam
Mop body will be red. After 20-25 seconds, it means the mop is
ready to release steam. To release steam, press the trigger located
on the handle, and the unit will start releasing steam. To stop
releasing steam, press the trigger again.
14) Slowly pass over surface to be cleaned. It is recommended to
sweep or vacuum floor prior using the Steam Mop.
NOTE: It is recommended that another high wattage appliance is not
operated on the same circuit to avoid a circuit overload.
CAUTION: To sanitise an area of your floor, leave the Steam Mop
over area for a minimum of eight seconds, but no longer than 15
seconds. Leaving the Steam Mop in a stationary position for a longer
period than recommended may cause the build up of a pale residue.
This residue can be removed by using a decalcifying product or with
a few drops of vinegar. (See Troubleshooting Guide)
15) When the Steam Mop stops emitting steam, this will occur after
approximately 20 minutes of use, turn off the Steam Mop and simply
remove the water tank, refill, and then again turn on and continue
cleaning.
WARNING! Never use the Steam Mop without water. Never direct
steam at any person or animal. Use the Steam Mop on sealed hard
floor only.

Trueshopping
www.trueshopping.co.uk
16) When you finish your cleaning, unplug power cord from outlet,
empty the water tank, carefully remove the cloth pad from the head,
wind power cord around the cord wrap and store it upright in a dry
area or hang by the storage hook.
CAUTION: The cloth pad may be very hot.
Cleaning and maintenance
CAUTION: Prior to cleaning or maintenance isolate the unit by
removing the cord from the power socket. Do not immerse the unit in
water.
1) Microfiber Cloth Pad can be machine washed in hot water and
tumbled dried.
2) Wipe the steamer with a soft cloth.
The Steam Mop should only be used with its own specially
developed floor cloths and filter (spare cloth pads and filters are
available from retailer).

Trueshopping
www.trueshopping.co.uk
TROUBLESHOOTING GUIDE
CAUTION: Prior to troubleshooting isolate the unit by removing the
cord from the power socket.
Problem
LED is not on.
The Steam Mop will not produce steam.
Pale residue left on the floor.
Solution
Ensure the Steam Mop power cord is correctly
plugged into power outlet and power trigger is
turned on. Ensure circuit breaker is operational.
Try operating the Steam Mop from another power
outlet.
Ensure the water tank has correct level of water.
Caused by leaving the Steam Mop in the same
position for too long. Can be removed with
household white vinegar or a decalcifying
product. Alternatively reheat the area for one
minute and residue should be removed.
