Newbealer NB316A User manual

HANDHELD GARMENT
STEAMER
NB316A
USER MANUAL
Please read this manual carefully before
using and keep this in a safe place for
future reference.

● This steamer should not be used by children. Only
allow dependents to use the steamer when under
proper supervision.
● The voltage of the power source must be compati-
ble with the voltage displayed on the rating plate of
this steamer (120V/60Hz).
● Never place heavy or sharp objects on the
steamer's power cable.
● All cables should be positioned so they cannot be
tripped over or become obstructions.
● It is recommended to not plug in any other
appliances into the same circuit when the garment
steamer is in use to avoid overload.
● If the supplied power cord is damaged, it should
be replaced by a qualified technician.
● Do not expose the steamer to humidity and or use
it outdoors.
● Only fill the water tank with de-mineralized or
distilled water. Other liquids may damage the
steamer.
● Do not put any additives in the water tank. These
can damage the steamer.
● Never leave the steamer unattended when it is
hot, switched on, or connected to power.
● Do not use the steamer if it has fallen from a high
place, or if there are visible signs of damage or
leakage.
● The garment steamer provides a thermal safety
fuse to protect it from over-heating. However, the
steamer should not be left unattended while it is
connected to power. Take care when there are
children in the vicinity of the steamer.
Safety Instructions
- 01 -

● Never use the steamer on clothes that are being
worn. Never direct the steamer towards people or
animals.
● There may be leakage from the steam head if the
steamer's temperature is not high enough to
vaporize water and generate steam. Therefore,
make sure the steamer is always preheated for 20s
before use.
● Always unplug the steamer before attaching or
detaching the attachment brush.
● Before store the appliance, please wait half an
hour for the appliance to completely cool down.
● Only use officially provided attachments and
accessories.
- 02 -

Included Items
1 x Garment Steamer 1 x Fabric brush
1 x User Manual
*Note: When unpacking the garment steamer, check if you
have received all the items listed.
Product Details
Product: Handheld Garment Steamer Rated Power: 1200W
Rated Voltage: AC 120V ~ 60Hz
Water Tank Capacity: 6oz (180ml)
Dimension:
7.9*3.5*6.9 (when unfolded)
6.1*3.5*3.5 (when folded)
Model: NB316A
Working Time: 10 min
Net Weight: 1.54lb (700g)
Specifications
Parts Identification:
1.Steam Head
2.Power Indicator Light
3.Power Button
4.Water Tank
(removable)
5.Water tank inlet cap
6.Handle
7.Cord exit
8.Fabric Brush
(removable)
1
234
6
7
8
5
- 03 -

It is recommended to use de-mineralized or distilled water.
Never use water containing additives (starch, perfume, aromatic
substances, softeners, etc.), or condensation water (for example
water from tumble dryers, water from refrigerators, water from air
conditioning units, rainwater). This water contains organic waste
materials or minerals that concentrate under the effect of heat
and cause spitting, brown coloring or premature ageing of your
steamer.
What Water To Use?
1. Open the water inlet cap. Fill the
water tank with water (See section
"what water to use"). Never exceed
the maximum level.
2. Close the water inlet cap.
3. Push the water tank back into the
steamer as shown until it clicks into
place. (an audible "click" will be heard
when correctly locked).
To remove: Push the water tank in the
arrow direction until a click is heard.
Take the detachable water tank out to
refill water easily.
Before Use
- 04 -

Note: As steam is very hot, never attempt to remove
creases from a garment while it is being worn, always hang
garments on a clothes hanger.
Accessories
The fabric brush allows removing
lint, pet hair, dust, dirt and dander
on overcoat and down jacket.
To attach: While the brush and
steamer are cool, align the fabric
brush to the steam head and lock it
into position.
To remove: Allow the steamer to
cool prior to removing the brush.
Put your finger under the pointed tip
and lift it up.
1. Plug in the appliance.
2. Wait at least 35 seconds before
pressing the steam button. The power
indicator light flashes red to indicate
that the heating element is working.
When the indicator light becomes
solid red, the steamer is ready to use.
Use
- 05 -
OK

3. Press the steam button with the
steam head facing away from you
holding it in a vertical position. Now
it steams in low mode.
4. Press the steam button again, the
indicator light becomes solid green,
now the appliance steams in high
mode.
5. For optimal use, move the steam
jets over your garment from top to
bottom.
6. Use your free hand to keep the
fabric taut and stretched. Steam the
garment with slow, downward strokes,
keeping the head of the steamer in
contact with the fabric.
7. This steamer is anti-dripping,
meaning it can be used horizontally
to steam garments on an ironing
board.
- 06 -

Warning: Never steam a
garment while it is being
worn.
Warning: Never touch the
soleplate of the steamer.
1. Long press the button for 2s to
switch the appliance off.
2. Unplug the appliance.
3. Push the water tank inward until
a click is heard. Now take out the
water tank.
- 07 -
After Use

1. Store it in a cool dry place.
2. DO NOT wrap the power cord around the unit, place it loosely.
NOTE: Water containing mineral levels will vary depending on
he place where you live in. To ensure the continuous operation
Storing Your Newbealer Steamer
4.To avoid mineral buildup, empty
the tank after each use.
5.Return the water tank to its place
on the appliance, make sure it is
completely in place.Wait for 30
minutes for your appliance to cool
before storing.
1. Wait half an hour for the appliance to
completely cool down.
2. Clean the plastic parts of the appliance
with a dry cloth.
3. Never wash or rinse appliance directly
over a sink.
4. The handle can be folded up easily as
shown in the picture.
Cleaning
- 08 -

of the steamer, never store it without cleaning and removing
excess water from the water container or tank.
If you fill your steamer with tap water, you may experience
mineral build-up due to the high mineral content in the water
supply in many cities. Mineral residue inside your steamer’s
internal heater may cause intermittent steaming or, in severe
cases no steaming at all.
To avoid the problem, only use de-mineralized or distilled water
in your steamer. If you are unable to use de-mineralized
ordistilled water, we recommend you to follow the cleaning
procedure below at least once a month to help avoid mineral
build-up.
● Anti-calc operation can be done if you notice your appliance
performance has decreased.
● Do this operation in a vented room.
Steps:
1. Remove the water tank.
2. Fill the water tank with 0.1oz citric acid (you can also use 50%
water and 50% white vinegar).
3. Return the water tank to its place on the appliance. Make sure
the water tank is fully set in place.
4. Switch on the appliance.
5. Wait at least 35 seconds before pressing the steam button.
6. Allow the appliance to run until the water tank has completely
emptied.
7. Fill the water tank with 100% water and repeat the operation
until the water tank is completely empty in order to rinse the
appliance.
Anti Calc
- 09 -

● To reduce the risk of contact with hot water coming from steam
vents, check the water level and the indicator light on your isteam
before each use. Use this appliance for its intended use only.
● To reduce the risk of electric shock, do not immerse your
steamer in water or other liquids.
● Never pull out the cord to disconnect from the outlet, instead,
grasp the plug and pull to disconnect completely before putting it
away. Place the cord loosely when storing.
● Always keep your steamer disconnected from any electrical
outlet when filling it with water, when emptying it, and when it is
not in use.
● Do not operate your steamer when the cord is damaged, or if
the appliance has been dropped or damaged.
● To reduce the risk of electric shock, do not disassemble or
attempt to repair your steamer if damaged. Return it to the
Service Center for repair. An incorrect reassembly or repair could
result into a fire, electric shock, or injury when the appliance is
used.
● Never drop or insert any object into the steam vents of the
nozzle.
● Do not use the steamer outdoors, operate it where aerosol
products are being used or where oxygen is being manipulated.
● The surface of your steamer may get hot when it will be in
use.Always use a handle to avoid burning your skin.
● Do not place the steam nozzle directly on any surface or on
the appliance power cord while it is not or plugged in.
● Unplug your steamer before filling or emptying the water tank.
Never fill water past the maximum level.
● To reduce the risk of a circuit overload, do not operate another
high-voltage appliance on the same circuit.
● Be careful when arranging the cord so it cannot be pulled or
tripped over.
Warning
- 10 -

If your Garment Steamer is not operating properly, please check if
it is related to any of the following problems or conditions. If you
are still unable to detect and solve the problem, please contact us
for help.
Problems
Not enough
steam coming
out.
Not enough
steam coming
out.
Water leaks.
Water spits.
Steam rate
decreases or
releases particles.
Possible Causes
The steamer is not plugged in. Check that your steamer is
correctly plugged in.
Unplug your steamer and refill it.
Ensure that cover is closed and
that the water tank snaps when
put into place.
Follow the instructions under the
“Before Use” section and fill to
Max level.
Always allow steamer to preheat
until the power indicator light
becomes solid.
Ensure that cover is closed and
that the water tank snaps when
put into place.
Fill the water tank to the Max
level, do not overfill.
Before steaming, always allow
steamer to preheat until the power
indicator light becomes solid.
After each use, empty the water
tank.
Refer to ‘ANTI CALC’ section in
instructions for use.
Never add any additive in the
water tank.
Read carefully the “What water
to use” section.
Read carefully the ‘ANTI
CALC’ section in instructions
for use.
The water level is too low.
The water tank is not fully in place.
There is not enough water in
the water tank.
The steamer is not heated to
full temperature..
The water tank is not fully in
place or the cover is not
closed properly.
There water tank is overfilled.
The steamer is not heated to
full temperature before use.
There is remaining water after last
use which became condensation
water and stored in the steam head.
Calcium build-up.
Calcium build-up.
You are using water with
additives.
The water is too hard.
The appliance has not been
rinsed enough after the descaling
operation.
Solutions
Troubleshooting
- 11 -

To Steam Garments
1. Place the fabric in a dry and ventilated place and at least 20
cm (8 inches) away from any walls (otherwise moisture may
cause mildew).
2. Empty garment pockets and straighten turn-ups such as cuffs
and hems.
3. Hang the garment from a hanger and stretch the fabric slightly
with one hand, making sure there is nothing behind the fabric
that could be damaged by the steam.
4. Put the steam head against the garment, moving your arm in
an up and down motion, targeting creases on the fabric.
NOTE: Do not steam over metal accessories. Use with caution
when steaming around metal accessories.
WARNING: When using the garment steamer, do not
touch the steam head. This garment steamer will generate a
large flow of high temperature air that can cause burns if not
handled carefully.
To Steam Curtains
1. Wash and dry the curtains.
2. Steam when they are hanging.
3. While steaming, stretch the curtains with one hand to help
remove creases more easily
To Steam Upholstery
1. The garment steamer can be used to kill bacteria, remove
odors and freshen up furniture upholstery, slip covers, and
cushions.
2. Move the garment steamer over the fabric, cushions should be
removed for steaming. Allow cushions to dry thoroughly before
placing back on furniture.
Steaming Tips
- 12 -

The appliance’s packaging is made from environmentally friendly
material and can be disposed of at your local recycling plant.
Thank you for purchasing your newbealer garment steamer, the
perfect tool to keep your wardrobe and household fabrics fresh
and wrinkle-free. Use it daily to easily and quickly revive all your
clothing. Enjoy a warranty for one year!
If you experience any issues with this product, or its performance
is not what you had expected, please contact us, we would like
to offer a replacement.
Warranty Details
- 13 -
