USER INSTRUCTIONS
TRIKE KIT
This product complies with the following toy safety requirements: AS/NZS ISO 8124, EN 71 and
FRONT WHEEL HEIGHT
The front fork has 2 opons for posioning the wheel. Hole
1 makes the bike lower. If your child is small or starng
with the tricycle opon, this is the best posion. If your
child is taller, the wheel can be in hole 2. This will put the
Trybike in the highest posion.
HEIGHT AND POSITION REAR WHEEL
The rear fork has 9 opons for posioning the rear wheel.
This feature allows you to shorten, extend, lower or raise
the wheelbase. Hole 1 puts the bike in the lowest posion,
hole 5 in the highest posion, hole 3 provides the longest
wheelbase and is ideal for the tricycle posion and hole 7
provides the shortest wheelbase, making the Trybike even
more manoeuvrable.
For use as a tricycle:
• Starter: Front, use hole 1. Rear, use hole 1. (the lowest posion)
• Advanced: Front, use hole 1. Rear, use hole 3.
(this gives more room for the feet relave to the long axle)
For use as a two-wheeler:
• Starter: Front, use hole 1. Rear, use hole 1 or 9. (depending on child size)
• Advanced: Front, use hole 1. Rear, use hole 9. (regular distance between wheels)
• Very skilful: Front, use hole 1. Rear, use hole 7. (shorter distance between wheels and
as a result more manoeuvrable)
• Advanced and large: Front, use hole 2. Rear, use hole 5. (extra high posion)
TRYBIKE FOLLOW YOUR FEET
HOLE1
1-3 years
HOLE2
4-6 years
FRONT
FRONT
Posion of holes +
numbers

TRYBIKE DISCOVERTHEWORLD
WHAT IS IN THE BOX?
• Bag with long rear axle, three aluminium pipes, four short black nylon bushings and two
long nuts of which one nut is sealed to the axle.
• Allen keys
• 1 wheel
TRYBIKE THEGROWBIKE
ASSEMBLY OF THE LONG REAR AXLE AND THE TWO REAR WHEELS
Remove the parts of the long axle, please note: one nut is sealed and only one nut can be
unscrewed. Insert the short aluminium pipe in between the rear forks. Insert the short black
bushings into the wheels, with the narrow part of the bushings into the wheel bearings. Then
slide one wheel with the bushings over the rear axle up to the sealed nut at the end of the axle.
Push the long aluminium pipe over the axle up to the wheel and slide the axle, from the le
side of the rider, into the holes of the rear forks and through the aluminium pipe. Important,
keep the sealed nut on the le side of the rider. This way the nut on the other side won’t turn
loose when the Trybike is ridden. Slide the remaining long aluminium pipe and the wheel with
the bushings onto the right side of the rear axle and fasten the wheel with the nut. Finally,
 ghten the nut properly (not too  ght but also not too loose) and check that the wheels rotate
smoothly and the nuts don’t turn. Put the short axle in the supplied bag and store it, so you can
convert the tricycle to a bicycle in the future.
