TRP-C08
User’s Manual
USB to RS-232/422/485 Isolated Converter
Printed Feb. 2007 Rev 1.2
Trycom Technology Co., Ltd
1F, No.2-11, Sihu street, Yingge Township, Taipei, Taiwan ROC
Tel: [phone], Fax: [phone]
Web: www.trycom.com.tw
Copyright
Copyright Notice: The information in this manual is subject to change without prior notice in order to improve
reliability, design and function and dosed not represent a commitment on the part of the manufacturer. No part of this
manual may be reproduced, copied, or transmitted in any form without the prior written permission of manufacturer.
Acknowledgment Products mentioned in this manual are mentioned for identification purpose only. Products manes
appearing in this manual may or may not be registered trademarks or copyright of their respective companies.

ECHIPAMENTE PENTRU AUTOMATIZĂRI
Electric Film S.R.L. — Aleea Scarisoara 3, Apt.42 ▪ Cluj Napoca, Cluj ▪ 400445 ▪ www.electricfilm.eu
VÂNZĂRI ▪ 0364 710319 ▪ [e-mail] ▪ SUPORT TEHNIC ▪ 0788 250583
cele mai sensibile
2
1. Introduction
The TRP-C08 allows you to connect your serial devices to systems by using a USB
interface. With auto configuration in data format, baud rate and RS485 data flow direction control.
TRP-C08 is able to automatically configure RS-232, RS-422 or RS-485 signals to baud rate
without external switch setting. TRP-C08 is equipped with 3000V DC of isolation and internal
surge-protection on each data lines to protect the host computer and converter against high
voltage spikes, as well as ground potential difference. TRP-C08 also features a high-speed 256
Kb/s transmission rate, and supports various O.S. The industry DIN rail and panel mounting
design enable user a fast and professional installation.
1-1. Features
¾Full compliance with the USB V1.0 and 2.0 specification.
¾System gets 1 COM port when the converter is connected.
¾Auto data format detecting.
¾Auto direction flow control on RS-485.
¾Auto baud rate switching from 300bps to 115.2 Kbps.
¾256 byte buffer for upstream and downstream data flow.
¾Direct power from USB port , no external power necessary.
¾3000V DC isolated protection.
¾Surge protection on RS-422/485 data lines.
¾Power/TX/RX mode LED indicator.
¾DIN rail or panel mount support.
¾Driver support: Windows 98/ME/2000/XP/CE3.0, and Linux, and Mac OS.
1-2. Specifications
¾USB interface: Fully compliant with V1.0, 2.0 specification.
¾USB to serial bridge controller; Prolific PL2303HX.
¾RS-232 signal: 5 full-duplex (TXD, RXD, CTS, RTS, GND).
¾RS-422 signal: Differential 4 full-duplex wires (TX+, RX+, TX-, RX-).
¾RS-485 signal: Differential 2 half-duplex wires (D+, D-).
¾Data Format:Asynchronous data with all common combination of bits, parity, stop.
¾Parity type: None, odd, even mark, space.
¾Data bit: 5, 6, 7, 8.
¾Stop bits: 1, 1.5, 2.
¾Cable: USB type A to type B.
¾Communication speed: form 300bps to 256Kbps.
¾RS-422/485 line protection: Against surge, short circuit, and voltage peak.
¾Transmission distance: RS422/485 Up to 4000ft (1200M).
¾Connection type: Screw terminal accepts AWG #12~30 wires.
¾Signal LED: Power on, TX, RX.
¾Direct power from USB port.
¾Power consumption: 1.2W.
