HY-LINE CP-292 User manual

CP-292 DVI-I to
Component (HD)
Scaler Box
Operation Manual
CP-292

1. Introduction................................................................................
2. Features......................................................................................
3. Operation Controls and Functions..........................................
3.1 Front Panel...........................................................................
3.2 Rear Panel............................................................................
4. OSD Operation...........................................................................
5. Connection and Installation.....................................................
6. Specifications.............................................................................
7. Supports Resolution....................................................................
TABLE OF CONTENTS
1
1
1
2
2
3
4
4
4

1.Introduction
This Scaler Box is designed to upscale DVI-I input sources to HD output of
wide-range HDTV resolutions; the resolution is up to 1080p. This unit has a
comprehensive OSD menu that allows user to select a variety of output
resolutions and adjust for best picture quality.
2. Features
 DVI 1.0 compliant.
 Scales any PC/HD resolutions to HD (480i ~ 1080p) resolutions.
 Provides output picture adjustment on contrast, brightness, hue, saturation,
sharpness, RGB (color tone) level and aspect ratio size.
 Supports high resolution output:
SD/HD: 480i, 576i, 480p, 576p, 720p, 1080i and 1080p
1

1 Component output: Connect the component output port to the
component input port of your display.
2 Menu Button: Press the MENU button to bring up OSD operation menu.
(See section “4. OSD Operation” for reference.)
3 +/- Button:
•On the first tier of OSD menu, use + and – buttons to move up/down the
highlight item for selection.
•Once the desired option is selected, use + and – buttons to toggle
between setting values.
Note: Outside of the OSD menu, Press [MENU] and then [ - ] to switch to
480p mode.
1 2 3
3.2 Rear Panel
2
1 DVI-input: Connect the DVI-I input port to the output port of your source
equipment.
2 Power: Plug the 5VDC power supply into the unit and connect the
adaptor to AC wall outlet.
3.1 Front Panel
1 2
3. Operation Controls and Functions
INPUT
DVI-I
DC 5V
MENU
-
+
Cr / Pr Cb / Pb Y / HD
OUTPUT

4. OSD Operation
3
Adjustment
CONTRAST - 0 ~ 100 of Contrast Level
BRIGHTNESS - 0 ~ 100 of Brightness Level
- HUE 0 ~ 100 of Hue Level
- SATURATION 0 ~ 100 of Saturation Level
- SHARPNESS 0 ~ 100 of Sharpness Level
FINETUNE
- EXIT
- RED 0 ~ 100 of Red Color Level
- GREEN 0 ~ 100 of Green Color Level
- BLUE 0 ~ 100 of Blue Color Level
COLOR
- EXIT
SIZE -
OUTPUT -
- HPOSITION 0 ~ 100 of OSD Horizontal Position
- VPOSITION 0 ~ 100 of OSD Vertical Position
- TIMER 0 ~ 100 of OSD Existing Time (sec.)
- BACKGROUND 0 ~ 100 of OSD Transparent Level
OSD
- EXIT
INFORMATION -
Mirror
FULL / OVERSCAN / UNDERSCAN /
LETTERBOX / PANSCAN
1st Tier Option 2
nd
Tier Option
Back to 1st Tier
Back
to 1st Tier
Back to 1st Tier
Back
to 1st Tier
SOURCE (Input Interface)
INPUT (Input Resolution)
OUTPUT (Output Resolution)
VERSION (Firmware Version)
NATIVE / VGA / SVGA / XGA /
SXGA /UXGA / WXGA / WSXGA /
WUXGA / 480i / 480p /720p@60Hz
/ 1080i@60Hz /
1080p@60Hz / 576i / 576p /
720p@50Hz / 1080i@50Hz /
1080p@50Hz
EXIT - Close OSD Menu
ON/OFF
Note: Finetune function works differently under component and
VGA input therefore, Hue, Saturation and Sharpness are only
adjustable when input signal is component.
- PHASE (PC)
0 ~ 100 of Phase Level
- CLOCK (PC)
0 ~ 100 of Clock Level
- H-POSITION (PC)
0 ~ 100 of H-Position Level
- V-POSITION (PC)
0 ~ 100 of V-Position Level
- EXIT (PC)

5. Connection and Installation
4
6. Specifications
Input port
Output port
Power Supply
Dimensions (mm)
Weight(g)
Chassis Material
Silkscreen Color
Operating Temperature
1 x DVI-I (DVI-D,PC)
1 x Component (Y/Pb/Pr)
5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
157(D) x 102(W) x 25(H)
320
Aluminum
Silver
0°C ~ 40°C
480I/576I (NTSC/PAL)
480P/576P
720P@(50/60)
1080I@(50/60)
1080P@(50/60)
VGA@(60/72/75/85)
SVGA@(56/60/72/75/85)
XGA@(60/70/75/85)
SXGA@(60/75/85)
UXGA@60
WXGA@60(1280x800)
WSXGA@60(1680x1050)
WUXGA@60(1920x1200)
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
PC/HD SD/HD
7. Supports Resolution
DVI-I INPUT
Component OUTPUT
TV
Component
DVD Player DVI-I

20080806 MPM-CP292
