TS-market EMM Tiny Stereo 1120 User manual

EMM Tiny Stereo Model
1120/2240/4480/8960/17920
- Board;
- dimensions: 27.5x14.5x6 mm;
- weight;
(without miniSD ash card and power source): <2 g;
- recording mode: mono/stereo;
- current consumption in recording mode
(sampling rate 8 K Hz, without compression): <2 mA;
- current consumption in VAS mode
(audio signal below threshold): 350 mA;
- current consumption in stand-by mode: 25 mA;
- supply voltage: 3 V.

2
Package Content
- Module;
- USB cable;
- CD with drivers and programs;
- user manual.
Description
AINL
AINR
GND
FUCC
LED
UCC
GND
K
LED
Switch
USB
connector
RECORD STOP Power
supply

3
Contact Assignments
Label Assignment Parameters Notes
AINR Right channel
input
2.9 Vpp voltage
audio source with
1.5 V constant
component
AINL Left channel input
GND Ground
FUCC +power supply
of external audio
source (micro-
phone)
voltage is 3+/-
0.2V, maximum
load current is
10 mA
The connector
is alive while
recording
LED Indicator signal For external light
diode connection
Red LED is rec-
ommended
UCC + module’s power
supply
3+/-0.2 V voltage
GND Ground
K External control
input
When it is con-
nected with ground
– recording if
disconnected - stop
The module’s
switch has to
be in the STOP
position

4
Connection of the Module
The UCC (+) and GND (-) connectors are used for power
supply connection.
Attention! Check polarity while connecting the module to a
power source! Otherwise, the module could be damaged.
The AINL and AINR connectors serve for connecting to the
2.9 Vpp voltage audio source with a 1.5 V constant compo-
nent. If the audio source provides mono audio signal, the
source should be connected to the AINR connector.
The FUCC connector serves to provide power supply for ex-
ternal audio sources. As recording is turned on, the connec-
tor becomes alive: the voltage is 3+/- 0.2 V, maximum load
current is 10 mA.
As audio signal sources the Telesystems’ microphones for
the USB Recorder Mini can be used.
The LED and K connectors serve for connecting an external
indicator and external control. It is recommended to use LED
as an external indicator. An external control has to provide

5
connection between The K and GND connectors to start re-
cording and should be disconnected to stop recording. Pay
attention that the module’s switch has to be in the STOP posi-
tion if the external control is used.
When you turn on the module, set the switch in the RECORD
position for 2-3 seconds and then back to the STOP position.
The indicator will ash 3 times showing that the module start-
ed self-testing. If this does not occurred, check the module’s
power supply.
After 5-10 seconds the module will ash for the fourth time
and will be ready to start recording. The length of this ash
depends on memory capacity and can be dozens of sec-
onds.
Attention!
The module is sensitive to static electricity. Use an antistatic
bracelet while soldering. The soldering equipment has to be
grounded.

6
To estimate the module’s operation in different modes, use
the table below:
Current Consumption (mA) in Different Recording Modes
with 3 V Voltage Supply
5,5 kHz 8 kHz 11 kHz 16 kHz 22 kHz
Mono St. Mono St. Mono St. Mono St. Mono St.
Without
compres-
sion
1,7 2,3 23 2,7 3,6 3,6 4,5 3,5 5,9
u-Law 1,9 3 2,3 3,5 2,9 53,8 6,1 5 -
4-bit
ADPCM 2,1 3,2 2,8 4,1 3,2 5,4 4,4 6,7 5,4 -
2-bit
ADPCM 23 2,5 3,7 3,1 5,3 46,4 5,4 -
Start/Stop Recording
To start recording, set the switch into the “START” position.
The voice recorders’ LED will ash ve times and then start
blinking in a sequence while the recording is in progress. To
stop recording, set the switch into the “STOP” position.
Blinking sequences indicate the supply voltage level and

7
available memory space. The rst sequence indicates that
the supply voltage level is: 1 ash –maximum, 2 ashes –
enough for work, 3 ashes –not enough for work. The second
blinking sequence indicates the amount of memory available:
1 ash – 76-100%, 2 ashes -51-75%, 3 ashes – 25-50%, 4
ashes – 1-25%.
