DUSTTRAK™
EXTERNAL PUMP MODULE
PUMP REPLACEMENT KIT
MODELS 8530EP/8533EP
EXTERNAL PUMP REPLACEMENT PROCEDURE
SEE MANUAL 6008408 MNL 8540 ENV DUSTTRAK PHOTOMETER FOR
ENVIRONMENTAL PUMP REPLACEMENT PROCEDURE
Thank you for purchasing a TSI®DustTrak™
Model 8530EP/8533EP dust monitor. This guide will help
you quickly replace the Thomas Rotary Vane Pump
Model #BL-G 085 M in the DustTrak™External Pump
Module that comes with the DustTrak™Model
8530EP/8533EP.
More detailed information is in the user manual provided
with the instrument in the carry case. Please refer to the
manual if you have questions on the operation of your
dust monitor.
Setup Instructions
The DustTrak External Pump Module has a user-
replaceable long-life rotary vane pump. To replace the
pump in the External Pump Module, carefully follow the
detailed procedures in this document. The following parts
come with the pump replacement kit:
Qt
y.
Part
Number
Description
Item
1
854043
DustTrak
External Pump
Replacement
Kit
1
6006603
DustTrak
External Pump
Module Pump
Replacement
Kit Models
8530EP /
8533EP Pump
Replacement
Procedure
The following tools are required but NOT included in
the kit:
Qty.
Part
Number
Description
Item
1
N/A
2 mm HEX
Ball Driver
1
N/A
2.5 mm HEX
Ball Driver
1
N/A
3/16” Wrench
1
N/A
#2 Phillips
Head
Screwdriver
Disassembly
1. Observe ESD
precautions.
2. Fully loosen four (4)
screws on module
cover. Screws
DO NOT need to be
removed from cover.
Set cover aside.
3. Disconnect tubing
from ports on pump.

TSI Incorporated –Visit our website www.tsi.com for more information.
USA Tel: [phone]
UK Tel: [phone]
France Tel: [phone]
Germany Tel: [phone]
India Tel: [phone]
China Tel: [phone]
Singapore Tel: [phone]
P/N 6006603 Rev. B ©2021 TSI Incorporated Printed in U.S.A.
4. Lift filters out of way
and disconnect cable
from PC board.
(Remove and replace
filters if needed.)
5. Remove four (4)
screws that attach
pump to box. Set
screws aside.
6. Remove pump
assembly from case.
Reassembly
1. Observe ESD
precautions.
2. Remove pump
assembly from
packaging.
3. Verify ribbon cable is
connected.
4. Place pump
assembly in case.
5. Connect cable to
PC board.
6. Install four (4) screws
to secure pump.
7. Connect filter tubing
to pump.
8. Install cover.
NOTE
The external pump is completely powered by the
DustTrak™monitor. DO NOT attempt to power the pump
module using an external power source.
