DustTrak™
External Pump
Models 8530EP/8533EP
Quick Start Guide
P/N 6006245, Revision F
April 2023
DustTrak™8530EP Monitor
DustTrak™8533EP Monitor

2
Thank you for purchasing a TSI®DustTrak™Model 8530EP/8533EP dust
monitor. This guide will help you quickly connect the external pump to the
DustTrak™Model 8530EP/8533EP dust monitor.
More detailed information is in the user manual provided with the
instrument in the carry case. Please refer to the manual if you have
questions on the operation of your new dust monitor.
Setup Instructions
DustTrak™8530EP/8533EP does not come with an internal pump. It must
be connected to an external pump module available from TSI®. The
following parts are needed to set up the DustTrak monitor with the external
pump. Contact TSI®immediately if any of the items are missing or broken.
Qty
Part
Number
Description
Item
1
801675
External Pump Kit
(replacement
available separately
from TSI®)
1
801797
External Pump
Power Cable (to
DustTrak monitor)
1
801798
External Pump
Flow Tube (to
DustTrak monitor)
1
Exhaust Adapter,
DustTrak Monitor
1
8530EP/
8533EP
DustTrak Monitor with
External Pump

Quick Start Guide 3
1. Carefully unpack the DustTrak™monitor from the shipping container.
2. Unpack the external pump from the shipping container.
3. Connect one end of the quick connect of the External Pump Flow Tube
to the pump module [1A to 1B].
4. Connect one end of the External Pump Power Cable (to DustTrak™
monitor) to the pump module as shown below [2A to 2B].
1A 1B 1A
2B
2A
5. Connect the exhaust adapter to the exhaust of the DustTrak™monitor
as shown below.
1D
6. Connect the other end of the quick connect of the External Pump Flow
Tube (to DustTrak monitor) to the exhaust adapter on the DustTrak
monitor [1C to 1D]. Likewise, connect the other end of the External
Pump Power Cable to the DustTrak monitor as shown below
[2C to 2D].
1C
1D
2D
2C

TSI Incorporated –Visit our website www.tsi.com for more information.
USA Tel: [phone]
UK Tel: [phone]
France Tel: [phone]
Germany Tel: [phone]
India Tel: [phone]
China Tel: [phone]
Singapore Tel: [phone]
P/N 6006245 Rev. F ©2023 TSI Incorporated Printed in U.S.A.
_____________________
TSI and TSI logo are registered trademarks of
TSI Incorporated in the United States and may
be protected under other country’s trademark
registrations. DustTrak is a trademark of
TSI Incorporated.
7. Setup of the DustTrak™monitor with the external pump is
now complete.
C AU TI O N
The external pump is completely powered by the DustTrak™
monitor. DO NOT attempt to power the pump module using an
external power source.
N O TICES
1. The power connector and the flow quick connect “click” when
securely connected. The power connector must be rotated
clockwise past the locking pin.
2. DO NOT hot-plug the External Pump Module when the
DustTrak™monitor is turned ON. Always connect the External
Pump module first and then turn the DustTrak monitor ON.
3. TSI®recommends that the DustTrak monitor with the external
pump be operated in the Model 8535 Environmental Enclosure.
4. TSI®recommends that the pump module be operated when
mounted on its feet and avoid operating at other orientations as
much as possible.
5. Pump module and the DustTrak monitor should be at the same
electrical potential.
6. The additional port on the external pump module is where the
pump exhausts the flow. For applications where the DustTrak
monitor is sampling from a chamber or a duct at pressures
significantly different from the ambient, TSI®recommends
plumbing the exhaust of the external pump back in to the
chamber/duct.
