TSL AMU2-8HD+ User manual

AMU2-8HD+ & 3G
Audio Monitoring
Units
Handbook
TSL
Vanwall Road, Maidenhead, Berkshire, SL6 4UB
Telephone [phone], FAX [phone]
USO RESTRITO

AMU2-8HD+/3G 1 Issue 1
USO RESTRITO

AMU2-8HD+/3G 2 Issue 1
SAFETY
Installation.
Unless otherwise stated TSL equipment may be installed at any angle or position within
an operating temperature range of 5°- 30°C .
All TSL equipment conforms to the EC Low Voltage Directive:
EC Low Voltage Directive (73/23/EEC)(OJ L76 26.3.73)(LVD).
Amendment: (93/68/EEC) (OJ L220 30.8.93).
The earth pin on the IEC mains inlet connector is connected to the metal frame of the
equipment, to 0 volts on the internal DC PSU and to signal ground, unless otherwise
stated. All metal panels are bonded together.
In all cases, the frame of the equipment must be earthed on installation.
Due consideration for cooling requirements must be given when mounting the equipment.
Ideally 1RU of rack space should be left above and below the unit.
Check that the fuse rating is correct for the local power (mains) supply. Replacement
fuses must be of the same rating and type for continued protection against fire risk.
Do not switch on until all connections are made.
WARRANTY, MAINTENANCE AND REPAIR
All TSL equipment is guaranteed for one year from the date of delivery to the customer’s
premises. If the equipment is to be stored for a significant period, please contact TSL
concerning a possible extended warranty period.
Failure during warranty
If any TSL product should fail or become faulty within the warranty period, first please
check the PSU fuses.
All maintenance work must be carried out by trained and competent personnel.
Technical support information
E-Mail address: [e-mail]
Telephone Support Number for the UK and Europe: [phone]
Telephone Support Number for the USA only: 1 877 591 2108
USO RESTRITO

AMU2-8HD+/3G 3 Issue 1
TSL Returns Procedure
Please telephone [phone] (Fax: [phone]) and ask for Production
Sales who will provide a Returns Number. This will enable us to track the unit effectively
and will provide some information prior to the unit arriving.
For each item, this unique Returns Number must be included with the Fault Report sent
with the unit.
A contact name and telephone number are also required with the Fault Report sent with
the unit.
Fault report details required.
•Company:
•Name:
•Address:
•Contact Name:
•Telephone No:
•Returns Number:
•Symptoms of the fault (to include switch setting positions, input signals etc):
Packing
Please ensure that the unit is well packed as all mechanical damage is chargeable. TSL
recommends that you insure your equipment for transit damage.
The original packaging, when available, should always be used when returning
equipment..
If returned equipment is received in a damaged condition, the damage should be
reported both to TSL and the carrier immediately.
USO RESTRITO

AMU2-8HD+/3G 4 Issue 1
Contents
1.0 Introduction
2.0 Front Panel Controls
2.1 Input and Meter Selection Buttons
2.2 Output Switching and monitoring
3.0 Pin-out Details
3.1 Line output
3.2 Analogue Output Connector – D25 Socket Pinout
3.3 AES Input/Output connector – D25 Socket Pinout
3.4 Control Connector - D9 Socket
3.5 External Connector - D15 Plug
3.6 S/HD BNC connectors
3.7 Re clocked BNC connector
3.8 Down converted BNC connector
3.9 Remote Control Connector/ RS 422 - D9 Socket
3.10 Aux (Dolby Metadata) - D9 Socket
4.0 LS Output
5.0 Configuration Switch Functions
6.0 General Notes
7.0 Specification
8.0 Block schematic diagram
9.0 Front and Rear panel layout drawings.
USO RESTRITO

AMU2-8HD+/3G 5 Issue 1
AMU2-8HD+/3G AUDIO MONITORING UNIT
1.0 Introduction
This handbook covers the AMU2-8HD+ and AMU2-8HD-3G Audio Monitoring Units.
The AMU2-8HD+/3G are full rack 2RU x 310mm deep Audio Monitoring Units with eight
TSL 53 segment bargraphs.
The following features are standard:
•Four AES/EBU inputs.
•Two HD/SDV auto sensing inputs.
•Re clocked output of input.
•Two Stereo analogue inputs.
•Phase reverse switch.
•Out-of-phase error indication.
•Down converted video or SDV output
•Additive output switch selection.
•Composite output.
•Headphone outputs with LS muting.
•Fixed and variable stereo line outputs of selected pair.
•Four simultaneous line outputs.
•Dolby compatible D and E.
•Metadata display.
•EBU digital, UK PPM and EBU PPM scales available.
•Internal amplifier.
•1080p50 / 1080p/60 capable (3G units only)
USO RESTRITO

AMU2-8HD+/3G 6 Issue 1
2.0 Front Panel Controls
2.1 Input and Meter Selection Buttons
AES1, 2, 3 & 4 AES input. This is selected by first pressing the AES select
button, then selecting A(1/2),B(3/4), C(5/6), D(7/8) respectively
on the LS monitoring panel.
Analogue 1 & 2 These inputs are selected by pressing the Phase
Reverse/function button and then the AES/ANLG button on the
input select panel. The signals are displayed on bargraph A
(1/2) and B (3/4).
S/HD (Auto sensing) This is selected by pressing the S/HD button 1 or 2 and then
selecting GP1 to GP4. The de-embedded SDV or HD is then
displayed on the bargraphs A(1/2),B(3/4), C(5/6), D(7/8)
respectively. Selecting e.g. group 1 and 2 together allows all
eight channels to be monitored.
Dolby Encoded Dolby can either be carried on an AES bit stream or
as embedded HD or SD. To select the Dolby function press the
DOLBY button after selecting either AES or S/HD buttons. If a
valid Dolby signal is present the Dolby button will illuminate
steady red. If a Dolby signal is not present or is lost the button
will flash. To select one pair from one group containing two
Dolby signals on each pair, select the group (1, 2, 3 or 4) from
the H/SDV input and then either A, B, C, or D from the input
selector to choose the pair.
Letterbox Shows the composite output as 16:9 aspect ratio on a 4:3
monitor.
Ø Rev (Function) Momentary phase reverse between A1 and A2 outputs.
Brightness To increase the brightness of the bargraph display
Press phase reverse and monitoring select A. To
decrease the Brightness press phase reverse and
monitoring select B.
Reference Marker To turn the reference marker on and off press phase
Reverse and the CUT button.
USO RESTRITO

AMU2-8HD+/3G 7 Issue 1
Meta Data Display This window indicates:
Channel coding (Rate/non PCM/Dolby D/Dolby)
Channel format (e.g. 8x1/2+2+2+2 etc)
Digital peak read out of selected pair.
Dialogue normalisation value where set
N.B. To reset/refresh display press Phase Reverse then Dolby select
switches simultaneously.
2.2 Output Switching and monitoring
A, B, C & D These buttons select the audio from pairs 1/2 (A) through to 7/8
(D)
The buttons toggle. Additive mixing is possible if two or more
buttons are selected together and are fed only to the variable
line outputs.
ALL Enables multi-channel listening on variable outputs. When
selected, multichannel variable outputs are enabled and full
surround can be monitored.
Selecting ALL, holding down and pressing output selection A
or B will toggle between using ABC for discrete 5.1 or BCD for
discrete 5.1.
LEnables the left hand channel to be monitored by both outputs.
R Enables the right hand channel to be monitored by both
outputs.
M A mono signal of the left and right hand channels is applied to
both outputs.
Lt Rt Allows a multi channel signal to be monitored and is a stereo
‘down mix ‘of a Dolby decoded signal. (Mutes multi channel
outputs)
5.1 Enables/Disables 5.1 metadata dynamic range control.
Dim Approximately 16dB of attenuation is switched into the audio
path.
Cut/Mute The front panel button Cut(s) the signal to all Variable O/Ps.
Volume The loudspeaker, headphone and variable O/P’s may be
varied.
USO RESTRITO

AMU2-8HD+/3G 8 Issue 1
3.0 Pin-out Details
3.1 Line output
XLRS PIN FUNCTION
ANALOG 1 1 GND
ANALOG 1 2 1 IN+
ANALOG 1 3 1 IN-
ANALOG 2 1 GND
ANALOG 2 2 2 IN+
ANALOG 2 3 2 IN-
3.2 D25 Socket, Analogue output connector
D 25 SOCKET
ON AMU AUDIO OUTPUTS
PIN NO FUNCTION
1 A8+ (7.1)
14 A8- (7.1)
2 Ground
15 A7+ (7.1)
3 A7- (7.1)
16 Ground
4 A6+ (RS)
17 A6- (RS)
5 Ground
18 A5+ (LS)
6 A5- (LS)
19 Ground
7 A4+ (LFE)
20 A4- (LFE)
8 Ground
21 A3+ (Centre)
9 A3- (Centre)
22 Ground
10 A2+ (FR)
23 A2- (FR)
11 Ground
24 A1+ (FL)
12 A1- (FL)
25 Ground
13 N/C
USO RESTRITO

AMU2-8HD+/3G 9 Issue 1
3.3 D25 Socket, AES Input/Output connector
D 25 SOCKET
ON AMU AES INPUTS/OUTPUTS
PIN NO FUNCTION
1 Ch1&2 Input 1+
14 Ch1&2 Input 1-
2 Ch3&4 Input 2+
15 Ch3&4 Input 2-
3 Ch5&6 Input 3+
16 Ch5&6 Input 3-
4 Ch7&8 Input 4+
17 Ch7&8 Input 4-
5 Ch1&2 Output 1+
18 Ch1&2 Output 1-
6 Ch3&4 Output 2+
19 Ch3&4 Output 2-
7 Ch5&6 Output 3+
20 Ch5&6 Output 3-
8 Ch7&8 Output 4+
21 Ch7&8 Output 4-
9 N/C
22 Ground
10 Ground
23 Ground
11 N/C
24 Ground
12 Ground
25 Ground
13 Ground
3.4 Control Connector - D9 Socket
This is wired for RS422.
D9 CONTROL
1 0V
6 0V
2 TX-
7 TX+
3 RX+
8 RX-
4 0V
9 0V
5 N/C
USO RESTRITO

AMU2-8HD+/3G 10 Issue 1
3.5 External Connector – D15 Plug
D15 EXTERNAL
PIN FUNCTION
1 Dim
2 Cut
3 GPI
4 Cut
5 Lt Rt enable
6 GPI
7 N/C
8 N/C
9 N/C
10 N/C
11 N/C
12 N/C
13 N/C
14 +5V
15 0V
3.6 S/HD connectors
This input auto detects HD or SDV signals.
3.7 Re clocked connector
This connector gives a re clocked output of the selected H/SDI input signal.
3.8 Video output connector
This gives a down converted output of HD (Vision only) or a composite PAL/NTSC
video. N.B. This is dependant on the switch selection detailed in section 5.
USO RESTRITO

AMU2-8HD+/3G 11 Issue 1
3.9 Remote Control Connector/ RS 422 - D9 Socket
This is wired for RS422.
D9 CONTROL
1 0V
6 0V
2 TX-
7 TX+
3 RX+
8 RX-
4 0V
9 0V
5 N/C
3.10 Aux (Dolby Metadata) - D9 Socket
This is wired for RS422.
D9 CONTROL
1 0V
6 0V
2 TX-
7 TX+
3 RX+
8 RX-
4 0V
9 0V
5 N/C
4.0 LS Output
This is a single ended amplifier therefore one side may be connected to ground.
USO RESTRITO

AMU2-8HD+/3G 12 Issue 1
5.0 Configuration Switch Functions (z12a.hex/z13.mcs FPGA)
ACI code 7.03 (Note:Subject to change)
SWITCH
SECTION FUNCTION
1 N/U
2 N/U
3 Loudspeaker O/P mute - UP
4 D25 Anlg variable – Up/Fixed - Dwn
5 AES variable –Up/Fixed -Dwn
6** XLR line O/P’s fixed – Up/variable-Dwn
7 Lo Ro-Up/Lt Rt-Dwn
8 Comp out-Up/ SDI - Dwn
** This output on the first pair of the D25 – Analogue output connector.
Note: The calibration, Frame delay (In Dolby mode) and scale type are factory set.
USO RESTRITO

AMU2-8HD+/3G 13 Issue 1
6.0 Notes
0 dBm = 0.775V into 600Ωi.e. 1mW power dissipation.
0 dBu = 0.775V rms = PPM 4.
Nominally, -18 dB ref 0FS = 0 dBu output.
European line up: -18 dBu
American lineup: -20 dBu
Please note that some American equipment has the function of the XLR pins 2 & 3
reversed.
TSL product is wired to the European standard
The Dolby (CAT552) card can be reset by pressing the phase reverse and the
Dolby select buttons simultaneously.
The screw locks on the D25 connectors use UNC 4-40 standard threads.
6.1 One frame Delay in Dolby mode option.
This operates on the down converted output only.
USO RESTRITO

AMU2-8HD+/3G 14 Issue 1
7.0 AMU2-8HD+/3G Technical Specifications
Power Supply
Supply Voltage 100 -240V AC @ 50Hz/60Hz +/- 10%
Power Consumption 60 Watts.
Or
Supply Voltage 12V DC
Physical Dimensions
Height 88mm (2RU)
Width 483mm (19”)
Depth 280mm
Weight 3500gm
Input 1 and 2
Connector Type XLR 3 pin. Pin 1 Gnd, Pin 2 hot, Pin 3 cold.
Signal Balanced line level audio.
Frequency Response 30Hz to 25kHz
Impedance >20kΩ
Inputs AES 1, AES 2
Connector Type XLR (F) 3 pin. Pin 1 Gnd,Pin 2 hot,Pin 3co
Standard AES3 (1994) 32, 44.1, 48, 96 KHz
Impedance Balanced110 Ohm.
Inputs AES 1, 2, 3 and 4
Connector type D25
Standard AES3 (1994) 32, 44.1, 48, 96 KHz
Impedance Balanced110 Ohm.
Inputs, HD/SDV (auto sensing)
Connector Type BNC.
Standard SMPTE 259M 4:2:2 component 525/60
or 625/50 with embedded 48kHz audio.
HDSDI (SMPTE 292M) – 720P & 1080i @ 50, 59.94 & 60Hz
(1080p @ 50/59.94/60Hz where
applicable)
Impedance 75ohm
Return Loss <-20dB to 1.5GHz (3GHz TBA)
AUX (Metadata Output)
Connector D9 (RS422)
Remote Control
Connector D9 (RS 422)
USO RESTRITO

AMU2-8HD+/3G 15 Issue 1
Setup Flash card port. (Factory use only)
Dolby Dolby Digital or Dolby E decoding from selected
AES input or selected embedded audio.
Note: The Dolby (CAT522) card can be reset by
pressing the phase reverse and the Dolby select
buttons simultaneously.
Display indicates: Channel coding
(rate/non pcm/dolby D/dolby)
Channel format (e.g. 8x1/2+2+2+2 etc)
Digital peak readout of selected pair.
Dial norm value where set
Down converted Output
Return Loss Better than -16.5dB to 1.5GHz
Connector BNC
Note: This is a video monitoring point only.
This connector also gives re clocked
SDV out when SDV is applied to the input.
Re clocked Output
Return Loss < -15dB up to 1.5GHz (3GHz TBA)
Connector BNC
Line Output.
Connector XLR 3 pin Male (variable line out A1 &A2)
Impedance 50Ω
Output Levels Through level control with 12dB gain.
Connector D25
Impedance >20kΩ
Output Levels Fixed (+ and – 1dB) and Variable (12dB gain).
Noise Better than -70 dB (22Hz to 22 KHz)
Headphone Output.
Connector Stereo Jack socket type A
Impedance 50Ω
Output Levels Through level control with 0dB gain.
Loudspeaker Outputs.
Connectors 4mm Binding Posts
Output rating Max 15W /Ch into 4Ω,
USO RESTRITO

AMU2-8HD+/3G 16 Issue 1
HD Standards Supported
1080p/50/59.94/60Hz (3G units only)
1080i/50
1080i/59.94
1080i/60
720p/50
720p/59.94
720p/60
8.0 Block schematic Diagram
USO RESTRITO

AMU2-8HD+/3G 17 Issue 1
USO RESTRITO

AMU2-8HD+/3G 18 Issue 1
USO RESTRITO

AMU2-8HD+/3G 19 Issue 1
9.0 Front and rear Panel layouts
SLT
ON
87654321
SLT
USO RESTRITO
