Assembly
Instructions
BI135F
Cement Mixer

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 1 | P a g e
BI135F cement mixer’s part’s name, part number, bolts, nuts, and washer
information with assembly drawing
Reference
Description
Figures
650349
Frame Upper Part
1
650350
Mixing Drum Compl.
Without Bearing
29+31+ 6 sets of M6x16mm Hex Bolts,
M6.0mm Nuts and washer dia. 6.0 mm
650351
Mixing Blade Compl.
30(2) + 4 sets of M8x25mm Oval bolts
M8mm Nuts and washer dia. 8.0 mm
650352
Foot (Spring side Leg)
3+ 2 sets of M8x70 mm Hex Bolts, M8.0
Nuts and washer dia. 8.0 mm
650353
Foot (Leg with Wheels)
2+4(2) +5(2) + 4 sets of M8x25mm Hex
Bolts. M8.0 mm Nuts and Washer dia.
8.0mm
650354
Mixing Drum bearing
Compl.
24+25+26(2) +27(2) +28+ 4 sets of
0.75x1inch Hex bolts with 2 washers of
0.65 & 0.9inch dia.
650355
Motor Shaft Compl.
13(2) +14+15+16(2) +17+18(2) +20+21+
8+43+44
650356
Pinion Guard Compl.
19+9+ 2 sets of 0.75x1 inch Hex bolts,
0.75inch Nuts and washer dia. 0.75
inch.
650357
Cover Support
6+ 4 sets of 0.5x1 inch Hex bolts
2.75inch Nuts and washer dia. 0.75
inch.
650358
Casing Lid
40+ 7 sets of Screws, 0.75inch long
square drive pan head screws
650359
Cover Motor Compl.
Without Motor
33+34+40+ 0.75-inch-long square drive
pan head screw
650360
Plug
35
650443
Interrupter
36
650444
Motor 115V/60Hz
39
650363
Bracket Compl.
8
650364
Steering Wheel Compl.
10+11+32+ 1 set of M12x45mm Hex
Bolts with M12.0 mm Nuts
650365
Locking System Compl.
7+22+23+ 1 set of M8x25mm Oval bolt,
M8.0mm Nut and Washer dia. 8.0mm
401694
Belt PJ711
37
401636
Wheel diameter Ø200mm
4+5
Retrieved from Tufx-Fort Manufacturing Inc. (2021, March 11). BI135F concrete mixer operation & parts
manual Rev.D110228 page-13.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 2| P a g e
Retrieved from Tufx-Fort Manufacturing Inc. (2021, March 11). BI135F concrete mixer operation & parts
manual Rev.D110228 page-13.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 3| P a g e
Steps to assemble BI135F Cement Mixer
Step-1 Build leg(2) with wheel(4) of the BI135F Cement mixer, remove 2 sets of bolts
provided from wheel axle. Check the picture given below.
Step–2 Insert wheels(4) on both sides of the legs(2) and fix it with bolts(5) which were
removed from the wheel axle as shown in image below.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 4| P a g e
Step-3 Take the other leg(3) of cement mixer and insert it in upper frame part(1) of the
mixer as following.
Step–4 Fix the leg(3) using 2 sets of M8X70mm HEX bolts and M8.0mm nuts with
Washer of diameter 8.0mm as shown in picture below.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 5| P a g e
Step–5Assemble leg(2) with wheels(4) to upper frame part(1) as following picture.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 6| P a g e
Step-6 Fix the leg(2) with wheels(4) using 4 sets of M8X25 mm HEX bolts and M8.0 mm
nuts with washer diameter 8.0mm to the upper frame part(1) as shown in image
below.
Step-7 After assembling the wheeled leg(2), attach the locking bar(7) to the spring(23)
by 1 set of M8x25mm oval bolts and M8.0mm nuts with washer diameter 8.0mm.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 7| P a g e
Step–8Place Electric motor panel(33 to 39 & 42) on the wheeled leg(2) side of the frame.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 8| P a g e
Step–9Fix the electric motor panel(33 to 39 & 42) with 2 sets of M8X100mm HEX bolts
and M8.0mm nuts with washer diameter 8.0mm as shown in image below.
Step–10 Attach the black cover(40) of the electric motor panel with the provided 0.75
inches long square drive pan head 7 screws.

TUFX - FORT MANUFACTURING INC.
DESIGNED TO WORK 9| P a g e
Step-11 After attaching black cover(40), place and align the bottom of drum(31) on gear
side first. Then place it on the spring lock(23) side as shown in image.
