Instruction
Manual
Lithium Series 48V 2.4 kWh Battery

2
Read this manual before installing the battery and follow the instructions
carefully during installation process.
Content
1. Scope ...................................................................................................................... 3
2. Specifications.......................................................................................................... 3
3. Features................................................................................................................... 4
4. Operation................................................................................................................4
4.1. Battery front .................................................................................................. 4
4.2. Battery Management System (BMS).............................................................. 6
4.2.1. Voltage Protection ...................................................................................6
4.2.2. Current Protection ....................................................................................6
4.2.3. Temperature Protection ........................................................................... 7
4.2.4. Other Protection ....................................................................................... 7
4.3. DIP switch ......................................................................................................7
4.4. Assembly and connection ..........................................................................9
4.4.1. Components list.....................................................................................9
4.4.2. Mechanical instalation ....................................................................... 10
4.4.3. Electrical installation............................................................................ 11
4.5. Battery parameter settings on the inverter .............................................. 13
5. Use, maintenance and problem solving ............................................................ 13
5.1. Commissioning and use of the equipment.............................................. 13
5.2. Alarm description and processing............................................................ 15
5.3. Common faults analysis and treatment ................................................... 16
6. Appendix............................................................................................................... 17
6.1. Safety instructions....................................................................................... 17
6.2. Safety warnings .......................................................................................... 17
6.3. Environmental protection .......................................................................... 18
6.4. Contact details........................................................................................... 18

3
1. Scope
This document describes the basic operation of the Turbo Energy brand lithium-
ion rechargeable battery (Lithium Series 48V 2.4 kWh model). This manual
contains all the necessary details for understanding the operation of the
equipment and for its correct application.
2. Specifications
Electrical
Nominal Energy
2.4 kWh
Nominal Capacity
50Ah
Depth of Discharge (DoD)
90%
Nominal Voltage
48V
Voltage operating range
40.5 - 54V
Cycle Life
>= 6000
Physical
Weight
22 kg
Dimensions
480 x 360 x 90 mm
Protection class
IP20
Battery type
LiFePO4
Operation
Charge/discharge current
25A (0.5 C)
Max. Charge current
45A
Max. Discharge current
55A
Temperature operating range (charge)
0ºC…50ºC
Temperature operating range (discharge)
-20ºC…50ºC
Humidity
5%...85%
Max. operating altitude
< 4000 m
BMS
Monitoring parameters
System voltage, Cell voltaje,
current and temperature
Communication
Compatible CAN and RS-485

4
3. Features
The Lithium Series 48V 2.4 kWh battery has the following features:
•Designed for use in photovoltaic applications.
•Battery Management System (BMS): The BMS system built into the battery
that monitors its operation and does not allow it to work outside the
bounds of the design regime (V, I).
•Expandability: The system's accumulation capacity can be expanded by
incorporating more batteries.
4. Operation
4.1. Battery front
Item
Name
Definition
1
Power switch
OFF/ON,
must be in the "ON" state when in use
2
Ground
connection point
Shell ground connection
3
Positive socket
Battery output positive or parallel positive line
4
Negative socket
Battery output negative or parallel negative
line
5
SW (battery
wake/sleep
switch)
When the "OFF/ON" switch button is in the ON
state, press and hold this button for 3 seconds
to put the battery into the power-on or sleep
state.
4
3
2
5
6
7
8
10
9
11
1

5
Item
Name
Definition
6
SOC
The number of green lights on shows the
remaining battery power. See table below for
details.
7
ALM
Red light flashing when an alarm occurs, red
light always on during protection status. After
the condition of trigger protection is released,
it can be automatically closed.
8
RUN
Green light flashing during standby and
charging mode.
Green light always on when discharging.
9
CAN/485
Communication cascade port, support CAN/
RS485 communication (factory default CAN
communication)
10
DRY CONTACT
/
11
ADD
DIP switch
Battery
Status
SOC
LED1
LED2
LED3
LED4
ALM
RUN
Shutdown
/
off
off
off
off
off
off
Standby
75%≤SOC≤100%
●
●
●
●
off
Flashing
50%≤SOC＜75%
●
●
●
off
off
Flashing
25%≤SOC＜50%
●
●
off
off
off
Flashing
5%＜SOC＜25%
●
off
off
off
off
Flashing
0%＜SOC≤5%
●
off
off
off
Flashing
Flashing
SOC=0
off
off
off
off
Flashing/●
Flashing
Charging
SOC=100%
●
●
●
●
off
Flashing
75%≤SOC＜
100%
●
●
●
Flashing
off
Flashing
50%≤SOC＜75%
●
●
Flashing
off
off
Flashing
25%≤SOC＜50%
●
Flashing
off
off
off
Flashing
0%＜SOC＜25%
Flashing
off
off
off
off
Flashing
Discharging
75%≤SOC≤100%
●
●
●
●
off
●
50%≤SOC＜75%
●
●
●
off
off
●
25%≤SOC＜50%
●
●
off
off
off
●

6
Battery
Status
SOC
LED1
LED2
LED3
LED4
ALM
RUN
5%＜SOC＜25%
●
off
off
off
off
●
0%＜SOC≤5%
●
off
off
off
Flashing
●
SOC=0
off
off
off
off
Flashing/●
Flashing
4.2. Battery Management System (BMS)
4.2.1. Voltage Protection
Low Voltage Protection in Discharging：
When any battery cell voltage or total voltage is lower than the protection value
during discharging, the over-discharging mode is activated, and the battery
buzzer makes an alarm sound. Then battery system stops supplying power to the
outside. When the voltage of each cell back to rated range, the protection is
over.
Over Voltage Protection in Charging：
Battery will stops charging when total voltage or any battery cell voltage reaches
the rated protection value during charging stage. When total voltage or all cell
back to rated range, the protection is over.
4.2.2. Current Protection
Over Current Protection in Charging：
When the charge current ＞45A, current limit protection mode is activated,
current will be limited to 5A，protection is removed after rated time delaying 10S.
Circulate like this until the current is lower than 45A.
Over Current Protection in Discharging：
When the discharging current is greater than the protection value 55A, the
battery buzzer alarms and the system stops discharging. Protection is removed
after rated time delaying 1min.
Caution:
The buzzer sound alarm setting can be manually turned off on the background
software, and the factory default is on.

7
4.2.3.Temperature Protection
Low/Over temperature protection in charging：
When battery’s temperature is beyond range of -5℃~+55℃during charging,
temperature protection is activated, device stops charging.
The protection is over when temperature back to rated working range.
Low/Over temperature protection in discharging：
When battery’s temperature is beyond range of -20℃~+55℃during discharging,
temperature protection is activated, device stops supplying power to the
outside.
The protection is over when temperature back to rated working range.
4.2.4.Other Protection
Short Circuit Protection：
When the battery is activated from the shutdown state, if a short circuit occurs,
the system starts short-circuit protection for 60 seconds.
Self-Shutdown：
When device connects no external loads and power supply and no external
communication for over 72 hours, device will dormant standby automatically.
Caution
Battery’s maximum discharging current should be more than load’s maximum
working current.
4.3. DIP switch
When the batteries are connected in parallel, the host communicates with the
slaves through the CAN interface. The host summarizes the information of the
entire battery system and communicates with the inverter through CAN or 485.
The connection mode is divided into the following two cases:
1- The communication cable from the host CAN IN to the inverter comm port
should be the correct one.
2- DIP configuration depending on Inverter type:

8
- Inverter: TURBO ENERGY HI, GOODWE, VICTRON, SOFARSOLAR, SMA, SOLIS,
LUX, IMEON, INFINISOLAR, SUNGROW, RENAC, DELIOS, GROWATT HVM
Master Slaves
- Inverter: VOLTRONIC Axpert-VMIII/Axpert King, Growatt SPH/SPA
Master Slaves
- Inverter: GROWATT SPH/SPA
Master Slaves
- Inverter: GROWATT SPF HVM
Master Slaves
3- If the energy storage system has only one Lithium Series 48V 2.4 kWh, it is
the host itself.
1=ON
0=OFF
1
3
2
4

9
4.4. Assembly and connection
4.4.1. Components list
Item
Specification
Quantity
Figure
Battery-B4850
48V/50Ah
480×360×90mm
1
Power cable-
positive
Red
/25mm2/L2050m
m
1
Power cable-
negative
Black
/25mm2/L2050m
m
1
Parallel
cable-
positive
Red
/25mm2/L215mm
1
Parallel
cable-
negative
Black
/25mm2/L215mm
1
Communicati
on parallel
cable
Black
/L250mm/Double
RJ45 plug
1

10
4.4.2. Mechanical instalation
Installation method 1: With rack installation
Communicati
on cable-to
inverter
Black
/L2000mm
/Double RJ45
plug
1
Ground wire
L500mm,4mm²
1
User Manual
LIS 24 User
manual
1
1. Place the Lithium Series 48V 2.4
kWh unit on the rack bracket as
shown in the figure and push the
device into the cabin at the
installation position. (The cabinet
structure in the figure is for
reference only)
2. Secure the Lithium Series 48V 2.4
kWh unit to the rack with a nut
through the mounting holes top on
the hanging ears of the unit.

11
Installation method 2: With simple bracket installation
4.4.3. Electrical installation
Before connecting the power cables, use multimeter to measure cable
continuity, short circuit, confirm positive and negative, and accurately mark the
cable labels.
Measuring methods：
•Power cable check: select the buzzer mode of multimeter and
detect both ends of the same color cable. If the buzzer calls, it
means the cable is in good condition.
•Short circuit judgment: choose multimeter resistor file, probe the
same end of positive and negative pole, if the resistor shows infinity,
means that the cable is available.
•After visual testing of power line is connection, the positive and
negative poles of the battery shall be connected respectively to
the positive and negative poles of the opposite terminal.
It is better to add a circuit breaker between the inverter and the battery system.
The selection of the circuit breaker requires:
1. Place the Lithium Series 48V
2.4 kWh and brackets as
shown in the figure and insert
it into the brackets. Use 4
screws to fix the module on
the front bracket.
2. Install another pair of
brackets on the first one,
fixed by buckles between
them.
3. Insert the second one
Lithium Series 48V 2.4 kWh
into the brackets and
repeat for more batteries.

12
Voltage: U>60V
Current: I =
𝐼𝑛𝑣𝑒𝑟𝑡𝑒𝑟 𝑃𝑜𝑤𝑒𝑟
45V
The circuit breaker is installed between the battery module and the inverter, as shown in
next figure:
Important:
Connect the specific communication cable supplied by the provider.
Connect the communication cable between batteries.
Negative
power cable
Positive
power cable
Positive
parallel
cable
Negative
parallel
cable
Communication cable to
Inverter
Communication
parallel cable
Circuit
breaker
Inverter
Master
battery

13
After the whole system connection, set the master DIP mode according to the
inverter model firstly, then start the battery.
The BAT-INV comms cable is from inverter comm port to master CAN IN port, BAT-
BAT cable is from master CAN OUT to slave1 CAN IN, slave1 CAN OUT to slave2
CAN IN…
Each pair of power cable, it is limited continuous current is 120A, so if the inverter
Max. work current more than 120A, please add power cable according to the
proportion.
4.5. Battery parameter settings on the inverter
The following parameters must be set into inverter settings:
•Max Charging (Bulk) Voltage: 53.5V
•Absorption Voltage: 53V
•Float Voltage: 52.5V
•Shut Down (cut off) Voltage: 47V
•Shut Down (cut off) SOC: 20%
•Restart Voltage: 49V
•Max Charge Current: 25A*battery QTY
•Max Discharge Current: 25A * battery QTY
•Capacity: 50Ah* battery QTY
5. Use, maintenance and problem solving
5.1. Commissioning and use of the equipment
After completing the electrical installation, follow these steps to start the battery
system:
1. Refer to the description of the DIP switch of 4.2. to prepare the battery
module before starting up, then press the ON/OFF button to the ON
position, next press and hold the SW button for 3 seconds.
2. After the indicator self-test, the RUN indicator will light and the SOC
indicator will be on (100% SOC status in the figure)

14
Caution
After pressing the power button, if the battery status indicator on the front panel
continues to be red, please refer to the "5.2 Alarm description and processing ".
If the failure cannot be eliminated, please contact the dealer timely.
3. Use a voltmeter to measure whether the voltage of the circuit breaker
battery access terminal is higher than 42V, and check whether the
voltage polarity is consistent with the inverter input polarity. If the circuit
breaker battery input terminal has a voltage output and is greater than
42V, then the battery begun to work normally.
4. After confirming that the battery output voltage and polarity are correct,
turn on the inverter, close the circuit breaker.
5. Check if the indicator of the inverter and battery connection
(communication indicator and battery access status indicator) is normal.
If it is normal, successfully complete the connection between the battery
and the inverter. If the indicator light is abnormal, please refer to the
inverter manual for the cause or contact the dealer.
6. Battery modules can be connected in parallel up to 40 units.

15
5.2. Alarm description and processing
When protection mode is activated or system failure occurred, the alarm signal
will be given through the working status indicator on the front panel of the LS 2,4
kWh. The network management can query the specific alarm categories.
If the fault such as single cell overvoltage, charging over-current, under-voltage
protection, high-temp protection and other abnormalities which affects the
output, please deal with it according to the following table.
Status
Alarm category
Alarm
indication
Processing
Charge state
Over-current
RED,
Buzzer start
Stop charging and find
out the cause of the
trouble
High temp
RED
Stop charging
Discharge
state
Over-current
RED
Buzzer start
Stop discharging and
find out the cause of
the trouble
High temp
RED
Stop discharging and
find out the cause of
the trouble
Total voltage
undervoltage
RED
Buzzer start
Start charging
Cell voltage
undervoltage
RED
Buzzer start
Start charging
Equipment
Use
Charging
a) The battery's long-term continuous charging
current should be ≤0.5C
b) If the battery capacity is empty, please
charge it within 18 hours after the battery is
empty.
Discharging
c) The long-term continuous discharge current
of the battery should be ≤0.5C
d) The recommend maximum depth of
discharge (DOD)of Battery PACK is no more
than 80%.

16
5.3. Common faults analysis and treatment
No
Fault
phenomenon
Reason analysis
Solution
1
The indicator
does not
respond after the
power on
Total voltage lower than 35V
Check the total
voltage
2
No DC output
Battery data status is abnormal.
Battery gets into over-discharged
protection
Read the
battery
information on
the monitor.
3
The DC power
supply time is too
short
Battery capacity become smaller
Storage
battery
replacement or
add more
modules
4
The battery
cannot be fully
charged to 100%
Charging voltage is too low
Adjust
charging
voltage at
53.5V or 54V
5
The power cable
sparks once
power on and
ALM light RED
Power connection short-circuit
Turn off the
battery, check
the cause of
the short circuit
6
Communication
fault
The DIP setting of the host is wrong/
the battery type of the inverter is
wrong/
Communication cable used
incorrectly/
communication cable is incorrectly
connected at the battery comm
port or the inverter comm port/
The battery firmware version is not
supporting the inverter
Check these
possible causes
one by one

17
6. Appendix
6.1. Safety instructions
1. Please read the battery instructions before use.
2. Keep the battery away from high voltage and out of reach of children.
3. In operation, the battery should be kept in the set temperature ranges
(between -20ºC and 50ºC) and a humidity less than 85%.
4. During handling, be very careful to avoid bumps/falls of the battery.
5. Be careful not to touch the contacts at the same time.
6. The battery, at the end of its useful life, requires a recovery process, not
disassemble it.
7. Avoid locating batteries in damp places to avoid danger.
8. When not in use for a long time, store the battery intact and let the battery
be half charged. Wrap the battery with non-conductive material to avoid
direct contact of the metal. Store the battery in a cool, dry place.
9. Never expose the battery to fire or water.
6.2. Safety warnings
1. Do not disassemble the batteries. The inside of the battery has a protective
mechanism and a protective circuit to avoid danger. Improper
disassembly will damage the protection function permanently, leaving
the battery without safety conditions.
2. Never short-circuit the poles of the battery. Avoid contact of positive and
negative poles with metals.
3. Keep the batteries away from fire and extreme temperatures. Monitor the
distance to thermal bulbs, stoves, etc.
4. Keep the battery away from the water. Always be careful that the battery
is not located in damp places where the dew point can be reached.
5. Do not use batteries that have physical damage that may be due to falls
or bumps.
6. Do not weld near the battery.
7. Overheating will result in the loss of the protective function of its life cycle,
even, it could render the battery useless and in extreme cases self-ignition
of the battery occurs.

18
8. Never connect this battery in series and connect it in parallel only with
identical batteries up to a maximum number of 6.
9. If the battery has liquid leakage, avoid contact with it completely. It can
be harmful to the skin, and if you touch the eyes, wash, and go to the
hospital immediately for treatment.
6.3. Environmental protection
Turbo Energy's batteries comply with EU ROHS regulations.
6.4. Contact details
For any incident with the battery write, indicating your contact details, an email
to the address: [e-mail] and we will contact you as soon as possible.
