Turbo Energy Lithium Series User manual

www.turbo-e.com
Instruction manual
Lithium Series Slim
48V 2.4 kWh

2
www.turbo-e.com
Read this manual before installing the battery and follow the instructions carefully during the
installation process.
Content
1. Scope............................................................................................................................................................................................3
2. Specifications ...........................................................................................................................................................................3
3. Battery Dimensions...............................................................................................................................................................4
4. Features......................................................................................................................................................................................4
5. Operation...................................................................................................................................................................................5
5.1. Battery front....................................................................................................................................................................5
5.2. Battery pack ....................................................................................................................................................................5
5.3. Assembly and connection .........................................................................................................................................6
5.3.1. Configuration without communications....................................................................................................8
5.3.2. Configuration with communications...........................................................................................................8
5.4. On and Off......................................................................................................................................................................11
5.5. LED display...................................................................................................................................................................11
5.6. Protection codes.........................................................................................................................................................12
5.7. Error codes............................................................................................................................................................12
6. Appendix.................................................................................................................................................................................13
6.1. Security instructions.........................................................................................................................................13
6.2. Safety warnings...................................................................................................................................................14
6.3. Contact details .....................................................................................................................................................14

3
www.turbo-e.com
1. Scope
This document describes the basic operation of the Turbo Energy brand lithium-ion rechargeable
battery (Lithium Series Slim 48V 2.4 kWh model). This manual contains all the necessary details for
understanding the operation of the equipment and for its correct application.
2. Specifications
Electrical
Nominal Capacity
2.4 kWh
Max. Output power
2.2 kWh
Depth of Discharge (DoD)
90%
Nominal Voltage
48 V
Voltage operating range
40.5 –54V
Cycle Life
>= 6000
Physical
Weight
23 kg
Dimensions
440 x 505 x 66.5 mm
Protection class
IP20
Battery type
LiFePO4
Operation
Maximum charge/discharge current
50A (1 C)
Standard charge/discharge current
25 A (0.5C)
Temperature operating range
0ºC…50ºC
Humidity
20% - 90%
Maximum operating altitude
< 4000 m
BMS
Power consumption (Off mode)
<100 µ A
Monitoring parameters
System voltage and current, Cell
voltage and temperature
Communication
Compatible CAN and RS-485
Inverters
Turbo, Victron, Voltronic, Goodwe,
Growat, Solis, Sofar, Sermatec, SMA,
Ingeteam, Darfon.
Max parallel units
15
Compatibility

4
www.turbo-e.com
3. Battery Dimensions
4. Features
The Lithium Series Slim 48V 2.4 kWh battery has the following features:
•Designed for use in photovoltaic applications.
•Battery Management System (BMS): The BMS system built into the battery that monitors its
operation and does not allow it to work outside the bounds of the design regime (V, I).
•Expandability: The system's accumulation capacity can be expanded by incorporating more
batteries.

5
www.turbo-e.com
5. Operation
5.1. Battery front
5.2. Battery pack
①: Positive and negative connector * 2 - for battery parallel connection and power output, model:
Anderson 120A
②: RS485-1 support the BMS monitor or customer's EMS device.
③: CAN-1 support Turbo, Goodwe, Solis, Sermatec, Sofar, Ingeteam lnverter.
④: CAN-2 support Victron inverter.
⑤: RS485-3 support Growatt inverter.
⑥: RS485-2 support Voltronic inverter and inner parallel communication between batteries.
⑦: RS485-2 support Voltronic inverter and inner parallel communication between
batteries.

6
www.turbo-e.com
⑧Handles
The standard packing list of Lithium Series Slim is as follows:
Item
Part Name
Description
Unit
Quantity
1
Battery
Lithium Series Slim
pcs
1
2
User Manual
Lithium Series Slim User Manual
pcs
1
3
RJ45 netting cable
RS485 parallel netting cable/0.2m
pcs
1
4
CANBUS communication cable with turbo
inverter /2m
pcs
1
5
CANBUS communication cable with Victron
inverter /2m
pcs
1
6
RS485 communication cable with Voltronic
inverter /2m
pcs
1
7
Grounding wire
Black/1.5m/10AWG
pcs
1
5.3. Assembly and connection
Batteries may be connected in parallel up to a maximum of 15. All batteries must be grounded. It is
suggested to connect the installation ground to the rack at the same point as all battery lands.
•Connection between batteries:
-Up to 15 batteries are allowed to be used in parallel.
-The batteries used in parallel must be the same batch of cases with the same SOC.
-The Voltage difference of batteries used in parallel must be within 0,5V.
-The dimensions of parallel cable must be the same.
-The batteries must be connected two by two with the same cable to the bus,
following next scheme.

7
www.turbo-e.com
•Connection between battery and inverter:
25 mm2 power cable section.
NOTE: Each power cord can carry a maximum of 120 A, so every two batteries would need to
connect a new cable to the inverter. However, if the inverter is 5 kW only with one cable it
would be enough to be at the limit of the maximum current recommended.
Battery connection
Inverter connection

8
www.turbo-e.com
Warning when doing a battery expansion: It is very important that in the case of connecting
batteries in parallel that are not new (for example, we add a new battery to an existing system), we
previously perform a voltage balancing (without load) between them to avoid overcurrents that
could damage the system. As an alternative to balancing voltages, balancing can be done by equalizing
the SOC of the batteries. In addition, when connecting new batteries, we must take into account that
the number of batteries at the time of connection must be similar to the number of batteries that are
already connected in the system. For example, if we have five batteries installed and we want to
connect a new one, we must first connect the new battery with two of the five that were already in
place to balance them, and then connect these three with the other three remaining batteries in the
system. Batteries should always be connected in groups of similar numbers so that a large group
cannot damage a smaller group of batteries at the time of connection.
5.3.1. Configuration without communications
For those cases where the battery is intended to operate connected to an inverter without
communications, it’s not necessary to select a specific configuration of the DIP switches and the
batteries do not need to be connected each other with the communication cable.
5.3.2. Configuration with communications
Communication cable: It will be configured one way or another depending on the inverter used.
Cable configuration Hybrid Inverter Turbo Energy/
Goodwe/Solis/Growatt
· It can be used a Straight-through cable
· Connect the cable to the CAN-2 port
· Growatt inverter is connected to the
RS485-3 port
Inverter
Battery
There must be installed a higher power of batteries than the inverter
power
The sum of batteries power must be higher than the sum of the inverters
power

9
www.turbo-e.com
Cable configuration Victron
Cable configuration Sofar
2
3
1
4
5
6
7
8
CAN H
CAN L
8
7
6
5
4
3
2
1
CAN H
CAN L
2
3
1
4
5
6
7
8
CAN H
CAN L
8
7
6
5
4
3
2
1
CAN H
CAN L
Cable configuration Voltronic
2
3
1
4
5
6
7
8
RS485A
RS48AB
8
7
6
5
4
3
2
1
RS485A
RS48AB
Connect the cable to the
CAN-2 port
Connect the cable to the
CAN-1 port
Inverter
Battery
Inverter
Battery
Inverter
Battery
Connect the cable to the
RS485-2 port

10
www.turbo-e.com
DIP switch
Each module has 4 DIP switches (Dual Inline Package) that will be configured differently according
to the number of batteries will be connected
Address
Dial switch position
Explain
#1
#2
#3
#4
1
ON
OFF
OFF
OFF
Pack1/Master
2
OFF
ON
OFF
OFF
Pack2
3
ON
ON
OFF
OFF
Pack3
4
OFF
OFF
ON
OFF
Pack4
5
ON
OFF
ON
OFF
Pack5
6
OFF
ON
ON
OFF
Pack6
7
ON
ON
ON
OFF
Pack7
8
OFF
OFF
OFF
ON
Pack8
9
ON
OFF
OFF
ON
Pack9
10
OFF
ON
OFF
ON
Pack10
11
ON
ON
OFF
ON
Pack11
12
OFF
OFF
ON
ON
Pack12
13
ON
OFF
ON
ON
Pack13
14
OFF
ON
ON
ON
Pack14
15
ON
ON
ON
ON
Pack15
1=ON
0=OFF
1
3
2
4
