Turbo E7T Operation instructions

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S equencer E7T 16 Output Channels
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
1
Sequencer E7T 16 Output Channels
U s e a n d M a i n t e n a n c e I n s t r u c t i o n s

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
2 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Description ____________________________________________________________________ 3
Technical Specifications ________________________________________________________ 4
Dimensions And Measurements ________________________________________________ 5
Warning Symbols Used n This Manual _________________________________________ 6
nstallation Rules Notes and Warnings _________________________________________ 6
Electrical Connections __________________________________________________________ 8
Jumper Configuration Power nput _____________________________________________ 9
Jumper Configuration Output Voltage __________________________________________ 9
Keyboard And Monitor ________________________________________________________ 10
Menu Layout ___________________________________________________________________ 11
Basic Settings ________________________________________________________________________ 11
Advanced Settings __________________________________________________________________ 12
Alarms ______________________________________________________________________________ 13
Calibration / Test ___________________________________________________________________ 13
Counters ____________________________________________________________________________ 14
Tribo Electric Probe _________________________________________________________________ 15
Operation Description_________________________________________________________ 16
Manual Operating Mode ____________________________________________________________ 16
Special Manual Operating Mode ____________________________________________________ 16
Other Function Descriptions___________________________________________________ 16
Alarms ______________________________________________________________________________ 16
Cleaning Function With Fan Off Post-Cleaning ______________________________________ 17
Selecting The Number Of Outputs __________________________________________________ 17
Cleaning Function From Remote Control ____________________________________________ 17
4-20mA N Function _________________________________________________________________ 17
Trouble Shooting FAQ ________________________________________________________ 18
Maintenance __________________________________________________________________ 19
Scrapping _____________________________________________________________________ 19
Default Settings _______________________________________________________________ 19
Warranty ______________________________________________________________________ 19
Warranty Exclusions ___________________________________________________________ 19
Declaration Of Conformity Of The Manufacturer ______________________________ 20

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
Description
Sequencer for the control of industrial dust collector system pneumatic cleaning.
Voltage free contact digital inputs, input and output relay contacts.
LCD backlit monochromatic graphic monitor where the following can be read at any
time:
running solenoid valves
time remaining for next air jet start
the signalling of any alarms
Interface menu available in five languages.
 Operating modes
manual, special manual.
 Solenoid valve not working alarm.
 Filter element maintenance alarm (with the possibility of inclusion / exclusion).
 Manual solenoid valve activation.
 Cleaning start from external contact.
 Hour counter and impulse counter.
 Cleaning function with fan off (post-cleaning) by contact in manual / special
manual modes, with selectable number of cycles.
 Compressed air consent input.
 Operating time expressed in seconds and minutes with selectable values for any
application.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
4 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Technical Specifications
Power Voltage 115 Vac 50-60 Hz ± 10 %
2 0 Vac 50-60 Hz ± 10 %
Alternative Power Voltage
Upon Request
24 Vac ± 10 %
24 Vdc ± 10 %
Output Voltage For Solenoid 115 Vac 50-60 Hz ± 10 %
2 0 Vac 50-60 Hz ± 10 %
24 Vac ± 10 %
24 Vdc ± 10 %
Inputs from 4 to 20mA x 1
Power Consumption 28 Watts Maximum Load
Alarm Relays Normally Closed
Display Graphic LCD Backlit Monochromatic
B/W 128 x 64 Pixel
Glass Fuse 5 x 20 mm 115 or 2 0 Vac 1 x 1 A
24 Vac or 24 Vdc 1 x A
Operating Temperature -10 °C - 55 °C
Storage Temperature -20 °C - 60 °C
Environmental Humidity 0 ÷ 95% Relative
Non Condensing
Valve Opening Impulse Time 50 ms - 10 s
Interval Pause Time Between
Valve Opening 1 sec. - 7200sec.
Casing ABS Base
Polycarbonate Cover
Protection Degree From Water And Dust IP65 DIN EN 60529
Shock Resistance IK07 2 Joule (EN62262).

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
5
Dimensions And Measurements
Fastening
Weight 2.1 Kg
To open the transparent cover, press on the right side
and lift.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
6 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Warning Symbols Used In This Manual
The information regarding safety are highlighted using the symbols:
Warning-Danger Generic - Warning-
Risk – Danger Electric Current
Dispose according to the standards for electrical
and electronic equipment RAAE
Installation Rules Notes and Warnings
 Protect the device from direct exposure to sunlight.
 Do not position the device near or directly in contact with sources of heat
or electromagnetic fields.
 Fix the device of a height of at least 60 cm from the ground.
In a clearly visible place easily accessible.
 Connect the device to power lines other than those for operating motors or other
large power devices which could generate network interference or instability.
 The electrical supply of the unit must be protected by a differential switch
2 0Vac~ 0mA and a bipolar magneto thermic 2 0Vac~ 10A, positioned in a
place easily accessible.
 Before working on the equipment to perform any operation switch off the
magneto thermic differential switch.
 For electric operations, always remove voltage, wait 0 seconds for the
inside capacitors to discharge before opening. At the end of the
operations, close the device to restore the correct degree of protection before
powering up.
 For the connection of the supply voltage, use anti-flame wires with a minimum
section of 0.75mm² certified and conform to the standard IEC60227 or IEC60245.
 Use flame-retardant cables with a minimum cross-section area of 0.75 mm² for all
control signals.
 Use flame-retardant cables with a minimum cross-section area of 0.75 mm² to
connect to the indicating relays.
 Use flame-retardant cables with a minimum cross-section area of 0.5 mm² for
electro valves control signals.
 The wire ground conductor of protection must be yellow/green.
 The wire ground conductor of protection must be connected first.
 The wire which is colored yellow/green must only be used for the ground
conductor.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
7
 The cable glands must be chosen according to the diameter of the cable to be
used.
 The sealing of the press cable is guaranteed by the compression of the rubber
gasket that tightens on the outer diameter of the cable.
 The tightness of the cable gland is guaranteed by the compression of the rubber
seal that tightens on the outer diameter of the cable.
 The size of cable and cable gland must ensure that a power cord traction is not
acting on the terminals.
 The terminal block must not be the point of mechanical anchoring of the
conductors.
 The cable gland PG9 supplied on request, has cable diameter minimum of 4mm
and a maximum of 8mm, with clamping nut by 19mm.
 Any use not described in this user instruction manual or incorrect use of the
device may cause damage to the device or to the devices connected to it.
 Furthermore, incorrect use or tampering with the device may cause injury.
 Waterproofness of the casing is guaranteed when the flap is closed.
 Make sure that rigid or flexible ducts used for wiring, if any, do not fill up with
water or other liquids.
 Do not make holes not protected on the container or protected by accessories with
protection degree lower than that of the housing of the control unit.
 Cut off power supply immediately if water is found in the casing.
 If the control unit is used in ways not specified by the manufacturer, the
protection provided by the device may be impaired.
 The E7T Control Unit does not release potentially toxic or harmful substances to
the health and the environment.
 No part with dangerous voltage is normally accessible.
Do not use the control unit if you have not read or do not understand this manual.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
8 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
lectrical Connections
To connect the wires to the E7T control unit, remove
the cover panel to access the terminal board,
unscrewing the two screws.
If the economiser is in G2 version with reinforced transformer, connect two solenoid valves in
parallel to each terminal.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
9
Jumper Configuration Power Input
115 VAC ~ 230 VAC ~
Jumper Configuration Output Voltage
24 VAC ~ 115 VAC ~
230 VAC ~ 24 VDC

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
1 0 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Keyboard And Monitor
There are 5 round keys on the front panel to control the intrument and select
functions.
At power on, during the verification of initialization,
the first screen that is shown is the firmware
version.
The next screen is always displayed during normal
operations:
 Menu
provides access to settings it is used as RESET
in the event of alarms
 Keys
Increase and decrease the values, manually start valves in Test mode, used to
scroll any alarms.
 The S key allows to start / stop the activation of the solenoid valves.
 Use the L key to select one of the 5 available languages: Italian, English, French,
German, Spanish.
On the main screen, when an alarm is active, the letter L changes state becomes A ,
pressing scrolls through the alarms, pressing A returns to the screen with
the operating mode.
In the versions with tribo electric probe, the black box between the two
keys indicates that the probe is installed.
With the probe installed the – key changes the screen to display the readings of the
emissions.
Without the probe installed is available only the screen with the operating mode.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
1 1
Menu Layout
Basic Settings
Press the Menu key in the main screen.
Use the arrows to select Main Set Up
Press OK key.
Use the arrows to select the item to be set.
Use keys to increase or decrease the value and change the item
conditions. Press exit to save and exit.
Set Operation Selectable arameters
Operativo Mode Manual
Special
Pulse Time Opening Valve 50 mSeconds ÷ 10 Seconds
Cycle Time Interval Openings 1 Second ÷ 7200 Seconds
Number of Valves 1 ÷ 16

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
1 2 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Advanced Settings
Press the Menu key in the home page.
Use the arrows to select Advanced Set Up.
Press OK key.
Use the arrows to select the item to be set.
Use keys to increase or decrease the value and change the item
conditions. Press exit to save and exit.
Set Operation Selectable arameters
Cleaning Fan off Number of complete cleans with fan off for
the number of connected solenoid valves.
Pulse Time Valve opening time in cycles with fan off
50 mSeconds ÷ 10 Seconds
Cycle Time Interval between valve opening in cycles
with fan off
1 Second ÷ 7200 Seconds
Cycles Manual Special If Special operating mode was selected in
basic set up, enter the number of complete
cycles for the number of connected solenoid
valves to be completed
Pause Cycles Manual Special If Special operating mode was selected in
basic set up, enter the pause between the
number of cycles

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
1
Alarms
Press the Menu key in the home page.
Use the arrows to select Advanced Set Up.
Press OK key.
Use the arrows to select the item to be set.
Use keys to increase or decrease the value and change the item
conditions. Press exit to save and exit.
Set Operation Selectable arameters
Hourmeter Fan Enabling the fan hour meter.
Connect the fan filter remote switch to
terminals 18_19 connector P9, to count
actual suction working hours
Replace Filters Enter the number of working hours desired
to trigger the filtering element replacement
alarm (sleeves/cartridges), the alarm is
only generated if the fan hour meter is
enabled and the fan remote switch
connected to terminals 18_19
on connector
P9 on the electronic board.
Calibration / Test
Press the Menu key in the home page.
Use the arrows to select Calibration / Test.
Press OK key.
Use the arrows to select the item to be set.
Use keys to increase or decrease the value and change the item
conditions. Press exit to save and exit.
Set Operation Selectable arameters
No. Valve (+/- = ON) Activation Press the keys to manually start
the solenoid valves connected to the
electronic board in sequence.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
1 4 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Counters
Press the Menu key in the home page.
Use the arrows to select Counters.
Press OK key.
Use the arrows to select the item to be set.
Use keys to increase or decrease the value and change the item
conditions. Press exit to save and exit.
Set Operation Selectable arameters
Hours Power
Counting the operating hours of the
electronic control unit.
Pulse count
Number of times the valves
connected
to the electronic board were started.
Hours Fan
Hours the filter fan is on.
The counter is only on if the filter fan
remote switch is connected to terminals
18_19 on connector P9
and the fan hour
counter function enabled in the Alarm
menu.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
1 5
Tribo lectric Probe
For the E8T versions were is provided.
Press the Menu key in the home page.
Use the arrows to select Counters.
Press OK key.
Use the arrows to select the item to be set.
Use keys to increase or decrease the value and change the item
conditions. Press exit to save and exit.
Tribo Electric robe
Alarms
arameters Factory Setting
Pre-Alarm Threshold 0.01 mg/m³ 800
Pre-Alarm Time
Recognition Multiple of 0.5 Sec. 00
Threshold Alarm 0.01 mg/m³ 1500
Time Alarm Recognition Multiple of 0.5 Sec. 60
Threshold Peak 0.01 mg/m³ 000
Time Recognition Peak Multiple of 0.5 Sec. 10
Reference Emissions 0.01 mg/m³ 5000
Reference µ Ampere 0.001 mA 20000
The alarms generated by the tribo electric probe activate the K relay at the 8_9
terminals of the P4 connector.
The relay is normally closed, opens in case of alarm, and opens to the control
unit off in the absence of power.
The Pre-Alarm and Alarm parameters are understood as:
Pre-Alarm Sets a value that indicates that the quantity of emissions tolerated
was exceeded.
Time of
Pre-Alarm
Sets the time interval duration in which emissions above the critical
threshold should remain before being reported.
In the same way you set the alarm, so doing a peak of moments is not reported
as a warning, but the warning only occurs if a value is high and permanent over
time.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
1 6 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Operation Description
The displayed information are:
the operating mode, active outputs and the time
necessary to activate the next output.
Manual Operating Mode
When manual operating mode is set, the economizer
works as a programmable cycle sequencer. The connected outputs will be
activated at programmed time intervals. Manual operating mode can be selected
in the Main Set Up menu under the first menu item.
Intervals are programmed in the same menu where activation time, pause time
and the number of solenoid valves connected to the device are set.
Special Manual Operating Mode
In the basic set up men, first menu item, select Special mode, enter the pulse
time and pause time. Open the advanced set up menu, second menu item, enter
the number of complete cycles and pause time between these cycles for the
connected solenoid valves.
With this mode, unlike manual mode, the device only runs the solenoid valves for
the set number of cycles and will remain in stand-by until an operator presses S
(start / stop) in the main menu to repeat the cycles. This mode is especially
suited for small filters or filters where the dP has low values or the inverter
keeps pressure constant.
Other Function Descriptions
Alarms
This function allows an alarm device to be connected. The alarm device can be
connected to two alarm relays (see wiring diagram) which are opened when the
threshold set in the ALARMS menu is exceeded. For details, see the third menu
item and the description in the Accessing the Alarm menu section.
When an alarm is triggered, it is signaled on the display by a blinking row that is
normally occupied by the operating mode. The menu key is used for Reset and
keys can be used to scroll any alarm items that may have triggered for
relay no. 1: Replace Filters (if enabled in the menu) while failed valve activation
is signaled with relay no. 2.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
1 7
Cleaning Function With Fan Off Post-Cleaning
This function allows a cleaning cycle to be run with the fan off.
In Manual or Special Manual modes, it occurs through a contact connecting the
fan to terminals 12_1 on connector P9, see wiring diagram.
In the advanced set up menu, the following post-cleaning settings can be set:
Start cleaning with fan off (Enable / Disable)
Number of cycles (cycles completed)
Pause time (pause duration between one solenoid valve start and the next during
post-cleaning).
Pulse time (cleaning pulse duration regardless of the fan on operating time).
Selecting The Number Of Outputs
The number of outputs, solenoid valves on which the economizer runs the
cleaning cycle can be selected. Cleaning is run in order from the first solenoid
valve to the last. Valve regulation is possible in the basic set up menu.
Cleaning Function From Remote Control
This function lets you pneumatically clean only after an external consent is
received. The external consent can be connected to prevent cleaning without
pressure in the high pressure circuit or in the compressed air tank.
The external contact must be voltage free, normally open and connected to
terminals 14_15 connector P9.
4-20mA IN Function
Terminals 22_2 on connector P7 can be connected to a tribo electric probe that
generates a signal in current that varies from 4 - 20 mA.
In the signal relays, alarms are broken down as follows:
 Relay No. 1 to contacts 4_5 connector P4, replacement filters.
 Relay No. 2 to contacts 6_7 connector P4, failure to activate the valve.
 Relay No. to contacts 8_9 connector P4, alarms tribo electric probe.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
1 8 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Trouble Shooting FAQ
F a u l t P o s s i b l e C a u s e S o l u t i o n
The display does not
light up.
Burnt fuse.
Power voltage.
Check the protection fuse on the power voltage.
Check that the power voltage is present and
compliant with that required for the device
(terminals 1 and 2).
The outputs do not
light up.
Output voltage.
Wiring to solenoid
valves.
Check that the timer and solenoid vale output
voltage agree.
Check wiring between timer and solenoid valves.
Does the economizer
occasionally reset?
Check that there are no unfiltered pulse loads on
the power line (spot welding machines, welding
machines, plasma cutters etc.). Install a filter on
the economizer power line, if needed.
Does post-cleaning
start during normal
cleaning?
Change the post-cleaning start-up threshold by
lowering it.
Do the alarms fail to
activate signaling
devices?
The alarm devices must be powered by voltage
external to the economizer. A relay opening is
needed to activate them.
Do alarm messages
appear? Check the Alarms menu.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
I n M n S E 7 T
e n R e v . 0 0
T U R B O S r l D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
1 9
Maintenance
The only parts which may be replaced are fuses.
All other operations must be carried out by the manufacturer.
Scrapping
Dispose of properly after use. Dispose of the product according to laws in force for
electronic equipment.
This device is for use in a dust collection system and is therefore part of a fixed
installation.
Default Settings
The default settings are:
S e t t i n g V a l u e
Operating Mode Manual
Pulse Time Valves 200 m.sec.
Pause Time Valves Cycle 20 sec.
Number Of Connected Valves 1
Cleanings When Fan Is Off 2
Pulse Time V. Cleaning Fan Off 200 m.sec.
Pause Time V. Cleaning Fan Off 20 sec.
Language Italian
Warranty
The warranty lasts for two years. The manufacturer will replace any faulty electronic
component exclusively at their own facilities only, unless otherwise authorized in
advance by the manufacturer.
Warranty xclusions
The warranty will be cancelled in case of:
Signs of unauthorized tampering or repairs.
Incorrect use of the device not respecting technical data.
Incorrect electric connections.
Failure to respect system standards.
Use not in accordance with EC standards.
Atmospheric events (lightening, electrostatic discharges,), power surges.

U s e A n d M a i n t e n a n c e I n s t r u c t i o n s
S eq u e n c e r E 7 T 1 6 O u t p u t C h a n n e l s
2 0 T U R B O S r l
D u s t F i l t e r C o m p o n e n t s
V i a P o / 5 2 0 8 1 1 C e s a n o M a d e r n o ( M B ) I t a l y T e l + + 9 0 6 2 5 7 4 0 2 4 F a x + + 9 0 6 2 5 7 4 0 9 2
I n M n S E 7 T
R e v . 0 0 e n
Declaration Of Conformity Of The Manufacturer
The manufacturer:
T U R B O S R L
The manufacturer's address:
V i a P o 3 3 / 3 5 2 0 8 1 1 C e s a n o M a d e r n o , I t a l y
Declares that the product:
S e q u e n c e r
Model:
7 T
Complies with the following directives:
Directive 2014/ 0/EU Electromagnetic Compatibility compliant with Harmonised
European standards EN61000-6-2:2005 class B of EN61000-6-4:2001
Directive 2014/ 5/EU Low Voltage compliant with Harmonised European
Standards EN 60947-1:2004
This product was tested using standard settings.
Cesano Maderno, 15 July 2017
F . M e s s i n a ( C . . O . )
T U R B O s . r . l .
Code And Serial Num er
