Turbo Professional Series User manual

Model
T90040
T90040
TOUGH AND RELIABLE
SEWAGE PUMP
REPAIR PARTS
Professional Series
• Water cooled
• Cast iron and stainless steel construction
• 2’’solid handling capabilities
• Vortex impellers, clog-free type, made of
cast iron
• Heavy duty motors
• Automatic adjustable vertical switches
115V 60Hz 7A, (14A at start)
Discharge: 2’’ NPT
Electric cables: 19’ piggyback type
1/2HP
(each pump)
Head of
25’ (7.5m)
1 400353 Power cable
2 300487 Handle
3 400355 Stator
4 400356 Motor upper plate
5 400357 Motor cover
6 400358 Seal plate
7 400359 Motor base plate
8 400360 Pump casing
9 400361 Impeller
10 400362 Bottom plate
11 400363 Oil seal
12 400364 Mechanical seal
13 350335 Upper bearing
14 506031 Lower bearing
15 400367 Rotor & shaft
16 400368 Capacitor
17 400369 Motor casing
18 400370 Top gasket
19 400371 Seal plate "O"ring
20 400374 Oil seal bushing
21 450447AG Vertical switch
22 400375 "O"ring motor base (2)
23 450700 Cable & screw of handle (4)
24 450701 Bolts housing & cover (8)
25 450702 Screws (4)
26 450703 Base plate screws (3)
27 300485 Discharge adaptor
28 450704 Capacitor clamp
29 450705 Long bolts (4)
©2013 TURBO Printed in Canada TI027
US GPH LPH
5’ 9550 36150
10’ 7600 28750
15’ 5800 21950
20’ 4200 15900
25’ 1000 3785
US GPH LPH
5’ 4900 18550
10’ 3900 14765
15’ 3000 11350
20’ 2200 8325
25’ 600 2275
REF. PART DESCRIPTION
2YEAR WARRANTY
23
24
25
26
28
29
2
8
3
51
6
4
910
11
12
13
14
15
18
17
16
20
19
22
27
7
22
4900 GPH
(One pump running)
9550 GPH
(Two pump running)
Friction loss not included
One pump running Two pumps running
21

1
2012 TURBO Printed in Canada TI902
TO THE PROFESSIONAL OR INSTALLER:
Instructions must remain with installation.
GENERAL SEWAGE PUMP INSTALLATION
GENERAL SEWAGE PUMP INSTALLATION
Please read these instructions carefully.
Note before you proceed with the
installation of this product that the
manufacturer’s guideline has to be
respected. Failure to comply to instructions
and designed operation of this product,
may void the warranty.
Your product has been carefully packaged
at the factory to prevent damage during
shipping. However, occasional damage
may occur due to rough handling. Carefully
inspect your product for damages that could
cause failures. Report any damage to your
carrier or your point of purchase.
INITIAL START UP PROCEDURES:
1- Inspect the pump and the sewage tank for
any obvious condition that may necessitates
cleaning, correction, adjustement or repair.
2- Assure that the pump is secure and vertical
for proper operation.
3- Assure that there is adequate clearance
from any combustible materials or structure.
Stored materials must be kept away from the
pump. Shelves or cabinet structures must
not be in close proximity over the pump.
4- Assure that the motor is securely plugged
into a proper‘GFCI’electrical outlet.
5- Test the ‘GFCI’ outlet by pressing its test
switch. This should prove that the outlet
is energized and will trip o to protect
against a ground fault. Be sure to reset
the ‘GFCI’ by pressing its reset switch.
(Repeat this step monthly)
6- Lift the oat to assure that the pump will
start when required. (Step 7 below will test
submersible pumps with enclosed oats).
7- Pour pails of water in the sewage tank to
turn the pump on. Assure that any check
valve present will permit the sewage to ow.
8- Observe that the plumbing can pump the
sewage safely out of the residence. (Repeat
this step monthly)
SAFETY INTRUCTIONS:
Before installation and operation, follow these
procedures:
A- Check with your local electrical and
plumbing codes to ensure you comply with
the regulations. These codes have been
designed with your safety in mind. Be sure
you comply with them.
B- A separate circuit must be lead from the
home electrical distribution panel properly
protected with a fuse or a circuit breaker. We
also required that a ground fault circuit be
used as well as a ‘GFCI’ receptacle. Consult a
licensed electrician for all wiring.
C- The ground terminal on the three prong
plugs should never be removed. They are
supplied and designed for your protection.
D- Never make adjustments to any electrical
appliance or product with the power
connected. Do not only unscrew the fuse
or trip the breaker, remove the power plug
from the receptacle.
IMPORTANT
ELECTRICAL CONNECTION:
For pumping systems using more than one
pump, each pump needs to be connected to a
separate dedicated circuit protected by a fuse
or breaker. This way, the power supply of one
pump will not stop operating if the fuse of one
of the pumps burns or if the breaker of one of
the pumps trips.
IMPORTANT NOTICE:
The following are minimum requirements in
order to protect your residence from ooding.
It is a small investment but it is your personal
responsibility to protect your home, family and
valuables. Failure to comply with the following
requirements will also void your warranty:
- Two (2) pumps have to be installed in the
sewage pit. The rst pump as a primary pump
and the second pump as the backup unit.
-An Alarm system model T50454 has to be
installed to advise you of any malfunctions.
Pump selection, proper and adequate
installation are a must to comply with local
by-laws and need to be adhered to.

INSTALLATION STEPS:
STEP 1
We recommend that you install your pump
and basin in a clean location where there is
adequate room for servicing at a later date.
Protection from freezing temperatures and
good ventilation should be considered as well,
to provide the pump an environment for long
life. Friction losses in the discharge pipe must
be taken into consideration when many elbows
and ttings are installed in the discharge line.
Each elbows and ttings must be considered
as 1 feet of head. Never run the pump dry.
Damage to the seal may occur. The run of the
pipes from the check valve(s) to the existing
waste or drain line must never be slooping
downward except when connecting to same.
For a new installation, install your sewage
basin in the excavation you have provided in
the basement oor of your home. Connect the
necessary piping from your shower trap, toilet,
etc., to the inlet of your sewage basin, with the
proper pipe and ttings (see diagram).
STEP 2
Cut a length of 40” to 42” of 2” ABS/DWV pipe.
Cement the 2”ABS/DWV male adaptor to 2”slip
to one end of this pipe.
STEP 3
With your drill, make a 1/2” hole in the adaptor
previously glued. This hole will prevent any air
locking which might occur. Note: Check that
this might have been done in factory when
discharge pipe is supplied.
STEP 4
Lower pump(s) with piping attached into the
sewage basin. Make sure that the pump is as
close as possible to the centre of the basin.
Adjusting the pump(s) in centre of basin and
keep oat switch(es) from rubbing on side of
basin.
STEP 5
When you are pumping raw sewage, you must
have a gas tight cover on the basin and a vent
pipe from basin, connecting to home’s vent
system (see diagram). Feed the 2” riser pipe
from pump’s discharge, through the 2”opening
in the cover. Secure a 3” vent pipe to the vent
opening and bring the switch(es) and pump
motor power cables through the opening in
the cover provided.
STEP 6
Cut a piece of 2’’ ABS/DV pipe to the desired
length to start the discharge line. Run the
discharge line as short as possible to the
home’s waste sewer line.
STEP 7
Connect the 3 prong plug of the switch in a
receptacle. Insert the motor 3 prong plug into
female receptacle on exposed piggy-back
of switch plug. Repeat this operation for the
second pump.
STEP 8
Fill the sewage basin with water to test
the operation of the sewage pump(s) and
switch(es) operation. Allow the pump to go
several “on-o” cycles to assure satisfactory
operation.
STEP 9
Secure the gas tight cover and the plug for
electrical cords with the gaskets and screws
provided with the cover. Make vent connection
to home’s vent system.
22
Raw sewage
discharge line
Home’s
vent system
Sewage
basin inlet
From bath
or shower
Pump’s
discharge line
Basin
vent line
From
toilet
From
sink
SEWAGE SYSTEM TYPICAL PIPING:

SEWAGE PUMP APPLICATION:
* Picture shown is an example only,
it may vary from your pump model.
‘GFCI’ plug type
STEP 9
Vent connection
and cover sealing.
STEP 2
Install sewage basin.
STEP 5
Secure cover.
STEP 3
Air lock preventor hole
drilling. (each pump)
STEP 7
Connect oat and motor power
cable. One receptacle per pump,
on a dedicated circuit.
STEP 4
Install your pump in
center of pit.
STEP 8
Verify the operation.
STEP 6
Discharge line.
NOTES:
3
NOTICE:
This unit have been designed to pump water only. This unit is not designed for applications
involving salt water, brine or any other liquids including petroleum products. Use with salt,
brine or any other liquids including petroleum products will void the warranty.

NOTES:
4
Motor does not run
Motor runs but no
water is delivered
Pump does not deliver
to full capacity
Pump does not shut o
TROUBLE SHOOTING GUIDE CHECK LIST
PROBABLE CAUSE ACTION
Switch is o position
Blown fuse
Tripped breaker
Disconnected plug
Corroded plug
Float stuck
Defective switch
Defective motor
Improper voltage
Pump may be airlocked
Pump discharge head too high
Clogged inlet/impeller
Improper voltage
Pump may be airlocked
Pump discharge head too high
Clogged inlet/impeller
Defective switch
Missing check valve
Clogged check valve
in open position
Float obstruction
Turn switch to on position
Replace
Reset
Re-install
Clean
Check movement
Replace
Replace
Check voltage
Check drilled hole in
discharge pipe
Wrong pump selection (over15’)
Clean
Check voltage
Check drilled hole in
discharge pipe
Wrong pump selection (over15’)
Clean
Replace
Install valve
Clean debris
Check for movement
TO THE END CONSUMER:
If you have any problem with the product, before advising the store, where you’ve purchased
the pump, please contact us at 514 337-4415, and ask for our customer service desk. They will
be pleased to help you with any questions you might have, concerning your installation.
