Turboair SAK-50 User manual

1250 Victoria Street
CARSON, CA 90746
T E L : 310-900-1000
FAX : [phone]
Toll Free : 1-800-627-0032
(U.S.A and Canada)
http://www.turboairinc.com

Turbo air Speeds UP the Pace of Innovation
COMMERCIAL REFRIGERATOR
Installation and Operation Manual
Please read this manual completely before attempting
to install or operate this equipment!
SAK-50󳢬
SAK-60󳢬
SAK-70󳢬

Turbo air Speeds UP the Pace of Innovation
CONTENTS
INTRODUCTION 1
SPECIFICATION 3
INSTALLATION INSTRUCTIONS 3~4
Inspection for damage
Location of Display
Leveling of Display
OPERATING INSTRUCTIONS 5
Power input/output
Thermometer
How to place product
MAINTENANCE & CLEANING 6~8
Interior/Exterior cleaning
Drain pipe cleaning
Condenser coil
TROUBLE SHOOTING 8
Display not working
Display case warm
WIRING DIAGRAM 9
WARRANTY STATEMENT 9~13

1
Turbo air Speeds UP the Pace of Innovation
INTRODUCTION
This owner’s manual has important information. Please read the entire manual before
installing your new Turbo Air Open Display Merchandiser. After reading manual if you
have any questions, please fill free to call:
““RR”” oorr ““LL”” oonn tthhee mmooddeell nnaammee ddeessiiggnnaatteess tthhee llooccaattiioonn ooff tthhee ccoommpprreessssoorr iinn tthhee uunniitt..
CUSTOMER SERVICE DEPARTMENT
TURBO AIR
1250 VICTORIA ST.
CARSON, CA 90746
1-800-381-7770
Please write down model and serial number for making any reference to this unit.
MODEL NUMBER
SERIAL NUMBER

2
Turbo air Speeds UP the Pace of Innovation
WARNING!
Failure to read this manual completely can result in personal injury or damage to the
unit. Keep manual in a safe place to refer to in the future.
Display should be on dedicated outlet for proper operation.
This equipment is for the storage and display of packaged foods only
Do not put above 120mm heigh
Thank you for purchasing Turbo Air!

3
SPECIFICATION
INSTALLATION INSTRUCTIONS
INSPECTION FOR DAMAGE
Customer is responsible for checking for damage. First inspect crate as soon as it
arrives. Prior to signing if crate is damaged make sure you note that on bill of lading.
If after uncrating there is concealed damage and crate was in good condition you must
call Customer Service at Turbo Air. Concealed damage must be reported within 24
hours of receiving unit. Bill of lading will be requested faxed to claim department.
Pictures may be requested of unit and crating.
Model
Dimension
(W×D×H)in
Electricity
Power Input
Compressor
Refrigerant
Weight of Case
48.8×14.2×11.5 60.3×14.2×11.5 71.8×14.2×11.5
3A 3A 3A
76.06 lbs 87.08 lbs 98.01 lbs
120V/1Ph/60Hz
SD152C-L1U2
R-134a
SAK-50* SAK-60* SAK-70*
Turbo air Speeds UP the Pace of Innovation

4
Turbo air Speeds UP the Pace of Innovation
LOCATION OF DISPLAY CASE MERCHANDISER
Display is designed to be in an ambient 75 degrees Fahrenheit (dry bulb) or colder and
55 percent relative humidity. If unit is installed in a warm ambient Display will not cool
effectively. Move the display to the final location before removing shipping skid. Allow
3 inches from back of Display to wall. Condenser is located in beside of Display. Do
not block inlet /outlet.
LEVELING OF DISPLAY CASE MERCHANDISER
aa.. DDiissppllaayy ccaassee sshhoouulldd bbee iinnssttaalllleedd oonn wweellll lleevveelleedd ttaabbllee oorr ffllaatttteedd llooccaattiioonn..
bb.. IIff uunniitt iiss nnoott lleevveelleedd,, ddrraaiinnaaggee ooff wwaatteerr wwiillll nnoott ddrraaiinn pprrooppeerrllyy.. LLeevveelliinngg lleeggss ccaann bbee
aaddjjuusstteedd aaccccoorrddiinnggllyy

5
OPERATING INSTRUCTIONS
POWER INPUT/OUTPUT
aa.. AAfftteerr iinnssttaalllliinngg uunniitt aanndd aallll eelleeccttrriiccaall ttoo tthhee DDiissppllaayy,, DDiissppllaayy iiss rreeaaddyy ttoo ssttaarrtt uupp..
bb.. IInnppuutt iiss ccoonnttrroolllleedd bbyy ppuusshhiinngg tthhee bbuuttttoonn..
iiiiii
Apporx 30min interval is needed to reactivate display case after power off.
THERMOMETER :
Thermometer showing temperature is located on opposite side of machine room.
NOTE:
Before placing products to Display wait for unit to reach desired temperature.
Do not place hot product in unit.
HOW TO PLACE PRODUCT:
Do not overload product on shelves.
Turbo air Speeds UP the Pace of Innovation

6
Turbo air Speeds UP the Pace of Innovation
MAINTENANCE & CLEANING
INTERIOR/EXTERIOR CLEANING
aa.. AAllwwaayyss bbeeffoorree cclleeaanniinngg DDiissppllaayy,, RReemmoovvee pprroodduuccttss aanndd uunniitt sshhoouulldd bbee ttuurrnneedd ooffff aatt
ppoowweerr sswwiittcchh
bb.. DDoo nnoott wweett eelleeccttrriiccaall ccoommppoonneennttss..
cc.. DDoo nnoott uussee wwaatteerr jjeett ttoo cclleeaann tthhee eexxtteerriioorr..
DRAIN PIPE CLEAINING
aa.. EEiitthheerr mmiixx 00..2266 ggaall((11lliitteerr)) ooff wwaatteerr wwiitthh 00..1133ffll..OOzz((33..77mmll)) ooff 55..2255%% ssooddiiuumm
hhyyppoocchhlloorriittee iinn aa ssuuiittaabbllee ccoonnttaaiinneerr..
bb.. JJooiinn tthhee ddrraaiinn hhoossee aanndd ttuurrnn uupp tthhee eenndd ooff hhoossee aabboovvee ddiissppllaayy ccaassee
cc.. SSlloowwllyy ppoouurr tthhee ssaanniittiizziinngg ssoolluuttiioonn iinnttoo tthhee ddrraaiinn iinnssiiddee ooff ddiissppllaayy aanndd ffuullll iitt uupp ttoo
tthhee eenndd ooff hhoossee..
dd.. WWaaiitt ffoorr 55 mmiinnuutteess,, aanndd ttuurrnn ddoowwnn tthhee eenndd ooff tthhee ddrraaiinn hhoossee ttoo ddrraaiinn tthhee ssoolluuttiioonn..

7
Turbo air Speeds UP the Pace of Innovation
DISPLAY CASE SHOULD BE CLEANED THOROUGHLY
BEFORE FIRST USE.
aa.. DDoo nnoott cclleeaann wwiitthh hhaarrsshh ddeetteerrggeennttss.. UUssee aa mmiilldd ssooaapp
bb.. RReemmoovvee aallll pprroodduuccttss..
cc.. RReemmoovvee bboottttoomm ttrraayyss..
dd.. CClleeaann iinntteerriioorr wwiitthh wwaarrmm wwaatteerr aanndd mmiilldd ddeetteerrggeenntt..
ee.. WWiippee wwiitthh ssoofftt ccllootthh ssooaakkeedd iinn wwaarrmm wwaatteerr.. DDoo nnoott lleeaavvee rreessiidduuee ooff ssooaapp..
CONDENSER COIL
1. Disconnect the electrical power to the unit
2. Lift up the Louver to release the Louver from the body.(①)
! How to remove Louver

8
Turbo air Speeds UP the Pace of Innovation
3. Pull the Louver toward you.(②)
4. Pull on the downward. (③)
5. Brush the dirt, lint, etc from the finned condenser coil.
6. When finished, Louver installed by reverse way of removing
7. Reconnect the electrical power to the unit.
8. Condenser should be cleaned every 1 months or as needed.
EVAPORATOR COIL
1. Remove the glass door and Boottom shelf.(①)
2. Join the drain hose.(②)
3. Sweep evaporator pins with warm water and brush.
4. Clean up with soft cloth the evaporator pins.
5. When finished cleaning off properly, remove the drain hose.
6. Reconnect the Glass door and Bottom shelf.
TROUBLE SHOOTING
For any problems with Display, please refer to following check list. If still having a
problem or need to ask a question please call Customer service at 1-800-381-7770.
DISPLAY NOT WORKING
aa.. CChheecckk ppoowweerr ggooiinngg ttoo uunniitt..
bb.. CChheecckk ppoowweerr sswwiittcchh iiss oonn..
DISPLAY CASE WARM
aa.. CChheecckk ccoonnddeennsseerr ttoo sseeee iiff cclleeaann..

9
Turbo air Speeds UP the Pace of Innovation
WARRANTY STATEMENT
Warranty claims
All claims for labor or parts must be made directly through Turbo Air.
All claims should include:model number of the unit, the serial number of the cabinet,
proof of purchase, date of installation, and all pertinent information supporting the
alleged defect.
In case of compressor replacement under warranty, either compressor or compressor
tag must be returned to Turbo Air along with above listed infomation.
Failure to comply with warranty policies will result in voiding claims.
WIRING DIAGRAM

10
Turbo air Speeds UP the Pace of Innovation
One Year Parts & Labor Warranty
Turbo Air warrants all new refrigerated components, the cabinet and all parts, to be
free from defects in materials or workmanship, under normal and proper use and
maintenance service as specified by Turbo Air and upon proper installation annd start-
up in accordance with the instruuction packet supplied with each Turbo Air unit.
Turbo Air’s obligation under this warranty is limited to a period of one(1) year from
the date of original installation or 15 months after shipment date from Turbo Air,
whichever occurs first.
Any part. covered under this warranty, that are by Turbo Air to have been defective
within one(1) year of original installation or fifteen(15) months after shipment date
from manufacturer, whichever occurs first, is limited to the repair or replacement,
including labor charges, of defective parts or assemblies. The labor warranty shall
include standard straight time labor charges only and reasonable travel time, as
determined by Turbo Air.
Additional Four Year Compressor Warranty..
In addition to the one(1) year warranty stated adove, Turbo Air warrants its
hermetically sealed compressor to be free from defects in both material and
workmanship under normal and proper use and maintenance service for a period of
four (4) additional years from the date of original installation, but not to exceed five (5)
years and three (3) months after shipment from the manufacturer.
Compressor determined by Turbo Air to have been defective within this extended
period will, at Turbo Air’s discretion, be either repaired or replaced with a compressor
or compressor parts of similar design and capacity.
The four (4) year extended compressor warranty applies only to hermetically sealed
parts of the compressor and does not apply to any other parts or components,
including, but not limited to, cabinet, paint finish, temperature control, refrigerant,

11
Turbo air Speeds UP the Pace of Innovation
metering device,m driers, motoir starting equipment, fan assembly or and other
electrical components, etcetera.
404A / 134A Compressor warranty
The four-year compressor warranty detailed above will be void if the following
Procedure is not carefully adhered to:
1. This system contains R404A or R134A refrigerant and polyol ester lubricant. The
polyol ester lubricant has rapid moisture absorbing qualities.
2. Drier replacement is very important and must be changed when a system is opened
for servicing. A 620 dopper drier or better is highly recommended.
3. Micron level vacuums must be achieved to insure low moisture levels in the system.
500 microns or lower must be obtained.
4. When compressor is grounded, suction filter drier and 620 drier or better must be
replaced.
5. Compressor must be obtained through Turbo Air, unless otherwise specified in
writing, through Turbo Air’s warranty department.
What is not covered by this warranty
Turbo Air’s sole obligation under this warranty is limited to either repair or
replacement of parts, subject to the additional limitations below. This warranty neither
assumes nor authorizes any person to assume obligations other than those expressly
covered by this warranty.
NO CONSEQUENTIAL DAMAGES. TURBO AIR IS NOT RESPONSIBLE FOR
ECONOMIC LOSS;PROFIT LOSS;OR SPECIAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, INCLUDING WITHOUT LIMITATION, LOSSES, OR DAMAGES ARISING
FROM FOOD OR PRODUCT SPOILAGE REGARDLESS OF WHETHER OR NOT THEY

12
Turbo air Speeds UP the Pace of Innovation
RESULT FROM REFRIGERATION FAILURE. WARRANTY IS NOT TRANSFERABLE. This
warranty is not assignable and applies only in favor of the original purchaser / user to
whom delivered. ANY SUCH ASSIGNMENT OR TRANSFER SHALL VOID THE
WARRANTIES HEREIN AND SHALL VOID ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR LABOR COVERAGE FOR
COMPONENT FAILURE OR OTHER THE WARRANTY PACKET PROVIDED WITH
THE UNIT.
ALTERATION, NEGLECT, ABUSE, MISUSE, ACCIDENT, DAMAGE DURING TRANSIT
OR INSTALLATION, FIRE, FOOD, ACTS OF GOD, Turbo Air is not responsible for the
repair or replacement of any parts that Turbo Air determines have been subjected after
the date of manufacture to alteration, neglect, abuse, misuse, addcident, damage
during transit or installation, fire, flood, or act of GOD.
IMPROPER ELECTRICAL CONNECTIONS. TURBO AIR IS NOT RESPONSIBLE FOR
THE REPAIR OR REPLACEMENT OF FAILED OR DAMAGED COMPONENTS
RESULTING FROM ELECTRICAL POWER FAILURE, THE USE OF EXTENSION CORDS,
LOW VOLTAGE, OR VOLTAGE DROPS TO THE UNIT. NO IMPLIED WARRANTY OF
MERCHANTABILIT OR FITNESS FOR A PARTICULAR PURPOSE:THERE ARE NO
OTHER WARRANTIES, EXPRESSED, IMPLIED OR STATUTORY, EXCEPT THE ONE(1)
YEAR PARTS & LABOR WARRANTY AND THE ADDITIONAL FOUR(4) YEAR
COMPRESSOR WARRANTY AS DESCRIBED ABOVE. THESE WARRANTIES ARE
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, INCLUDING IMPLIED
WARRANTY AND MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
THERE ARE NO WARRANTIES, WHICH EXTEND BEYOND THE DESCRIPTIO ON
THE FACE HEREOF.
Outside U.S. and Canada:This warranty does not apply to, and Turbo Air is not

13
responsible for, any warranty claims made on products sold or used ouutside the
continent of the United States and Canada.failure to clean and/ or maintain product as
set forth in the warranty packet provided with the unit
Turbo air Speeds UP the Pace of Innovation
