TurboChef NGC-3069 Reference manual

FSB10062A
3/29/07
Page 1 of 2
Reference
New Power Supply Implementation Kit (NGC-3069)
Distribution
Field ser ice personnel.
Application
All domestic and international NGC o ens requiring power supply replacement.
Kit Components
•Power supply (101211)
•Bracket, power supply (NGC-1391)
•Screw, #8 x ½ SS, Phillips truss type 17 with serrations (101688) x2
•Screw, M3 (GB818-9) x3
•Washer, split lock, M3 (GB93-1) x3
•Field ser ice bulletin (FSB-10062)
Required Parts
•Phillips screwdri er
Step 1—Ensure the oven is removed from power source
Step 2—Remove the right side panel
Step 3—Remove the top panel
Step 4—Remove and discard the old power supply and hardware
a. The old power supply is attached to the top of the electrical compartment frame ia three screws and three
standoffs.
b. Remo e and discard the power supply, screws, and standoffs.

FSB10062A
3/29/07
Page 2 of 2
Step 5
—
Attach the new power supply to the bracket
a. Using the three M3 screws and split-lock washers pro ided, attach the power supply to the bracket as shown
in Figure 1.
Step 6—Install the new power supply
a. Using the two truss-head screws pro ided, install the power supply to the top of the electrical compartment
frame as shown in Figure 1.
Step 7—Reinstall the top panel
Step 8—Reinstall the right side panel
Step 9—Plug in the oven and verify that the control board display turns on
Figure 1: Power Supply Installation
Pro ided
truss-head screws
Pro ided M3
screws and washers
Bracket
Power Supply
- End of Procedure -
