TurboChef ENCORE User manual

TM
©2012-2014 TurboChef Technologies, Inc.
Service Manual
   TM   TM   

The information contained in this manual is important for the proper installation, use, maintenance,
and repair of this oven. Follow these procedures and instructions to help ensure satisfactory baking
results and years of trouble-free service.
Errors – descriptive, typographic, or pictorial – are subject to correction. Specifications are subject to
change without notice.
Please carefully read this manual and retain it for future reference.
For further information, call
800.90TURBO
or
+1 214.379.6000

Important Safety Instructions
General Safety Information i
Reducing Fire Risk i
Grounding Instructions ii
Power Cord Replacement ii
Precautions to be Observed Before and During Servicing to Avoid Possible Exposure to
Excessive Microwave Energy ii
RF Interference Considerations ii
Specifications and Installation
Theory of Operation 1
Dimensions 1
Certifications 2
Oven Construction 2
Electrical Specifications 2
Installation 2
Unpacking Instructions 2
Installation Warnings - Read Before Lifting Oven 2
Installing the Oven 3
Installation Near Open Heat Source 3
Oven Restraint Kit 4
ChefComm Pro® 4
ChefComm LimitedTM 4
Oven ConnectTM 4
Voltage Selection 4
Ventilation 4
Oven Maintenance
Daily Maintenance 5
Quarterly Maintenance 7
Oven Controls and Cooking
Oven Controls 9
Cooking 10
Info Mode
Last Temperature Selected 13
Serial Number 13
Menu Version 13
Firmware Version 13
Cook Counters/Time Logs 13
Voltage - View Incoming 13
Fault Log 13
Service Numbers 13
Test Mode 13
Continued on next page...
Table of Contents

Set Options 13
Cook More / 13
Edit Mode / 13
Load Menu / 14
Network Setup 14
Auto Off / 14
Auto On / 14
Demo Mode / 14
Light Ring / 14
Set Date and Time 14
Load Menu from USB or Smart Card 15
Save Menu to USB or Smart Card 15
Sound Volume 15
Electrical Temperature 15
Reset the Oven 15
Firmware Update 16
Edit Mode
Set Temperature Edit 17
Baking Stone Use YES/NO 17
Bottom Temperature Offset 17
Select Groups and Items to Edit 17
Recipe Edit 18
Test Mode
Status Indicators 19
Magnetron Test 19
Blower Motor Test 19
Top Heater Test 20
Bottom Heater Test 20
Electrical Compartment (Ctl) Fan Test 20
Diagnostic Mode 20
Manufacturing Mode 20
Microwave Leakage Test 21
Burn in 21
Serial Number Edit 21
Self Test 21
Volt On 22
Erase/Default Oven Settings 22
Changing Temperature Measurement: F or C 22
Oven Systems
Impingement System 23
Blower Motor 23
Blower Motor Speed Controller (BMSC) 23
Heater - Top 23
Heater - Bottom 23
High Limit Thermostat 23
Jetplate - Bottom 23
RTD - Top and Bottom 23
Solid State Relay - K4/K5 Heaters 23
Troubleshooting 23

Oven Door 24
Removing/Reinstalling the Oven Door 24
Adjusting the Oven Door 24
Interlock Switches 25
Relay - K3 Monitor 25
Adjusting the Primary, Secondary, and Monitor Switches 25
Measuring RF Leakage for Microwave Safety 26
Troubleshooting 26
Microwave System 27
Capacitors 27
Testing a Capacitor 27
Filament Transformers 27
Wiring the Filament Transformers 27
High-Voltage Transformers 28
Wiring the High-Voltage Transformers 28
Testing a Filament or High-Voltage Transformer 28
High-Voltage Diodes 28
Testing a High-Voltage Diode 29
Magnetrons 29
Magnetron Cooling Fans 29
Magnetron Thermostats 30
Testing a Magnetron for an Open/Shorted Filament 30
Relay - K1 Filament 30
Relay - K2 Anode 30
Relay - K7 Encore: Magnetron Cooling Fans / Encore 2: All Cooling Fans 30
Waveguides 30
Troubleshooting 30
Control System 31
Control Board 31
Display 31
Ethernet Extension Cable 31
Keypad 31
LED Light Ring 31
Speaker 31
USB/Smart Card Reader 31
Troubleshooting 31
Power Components 32
Electrical Compartment Cooling Fan 32
Electrical Compartment Thermostat 32
Electrical Compartment Thermocouple 32
EMI Filter 32
Fuses 32
Power Supply 32
Relay - K6 Voltage 32
Relay - K7 Encore: Magnetron Cooling Fans / Encore 2: All Cooling Fans 32
Relay - K8 EC Cooling Fan 32
Voltage Sensor 32
Wire Harnesses 32
Troubleshooting 33
Continued on next page...

Filtering System 34
Catalytic Converter 34
Air Filter 34
Vent Catalyst 34
Troubleshooting 34
Troubleshooting
Overview of Troubleshooting 35
Fault Code Descriptions 35
F1 Blower Running Status Bad 37
F2 Cook Temperature Low 38
F3 Magnetron Current Low 39
F4 Door Monitor Defective 40
F5 Magnetron Over Temperature 40
F6 Electrical Compartment Temperature High 41
F7 RTD Open 41
F8 Heat Low 42
F9 Cook Cavity Temperature High 42
No Keypad Input 43
“Cook Door Open” Message when Door is Closed 43
No Display (Screen is Blank) 44
Food Not Cooking Properly 45
Troubleshooting: “Failed 240,” “No Card,” or “Write Fail” Message when Loading or Saving a Menu 46
Steam Present During or After Cooking 46
Encore Oven Schematic and Wire Harnesses
Relay Schematic 47
Oven Schematic 48
Wire Harness: HV Microwave Circuit 1 50
Wire Harness: HV Microwave Circuit 2 50
Wire Harness: Low Voltage 52
Wire Harness: Heater 52
Wire Harness: Cooling Fans 54
Wire Harness: Main Line Voltage 56-59
Encore 2 Oven Schematic and Wire Harnesses
Relay Schematic 61
Oven Schematic 62
Wire Harness: Heater 64
Wire Harness: HV Microwave Circuit 1 66
Wire Harness: HV Microwave Circuit 2 66
Wire Harness: Low Voltage 66
Wire Harness: Main Line Voltage 68-71
Wire Harness: Cooling Fans 72

Encore Appendix - Replacing Oven Components
Replacing Oven Components A-1
Oven Exterior A-2
Impingement System A-4
Microwave System A-6
Oven Door and Related Parts A-8
Control System A-10
Power Components A-12 – A-15
Encore 2 Appendix - Replacing Oven Components
Replacing Oven Components A-17
Oven Exterior A-18
Impingement System A-20
Microwave System A-22
Oven Door and Related Parts A-24
Control System A-26
Power Components A-28 – A-31

i
SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When operating this oven, strictly adhere to the following safety precautions to
reduce the risk of burns, electric shock, fire, injury, damage to oven or property near oven, or
possible exposure to excessive microwave energy.
GENERAL SAFETY INFORMATION
a Read all instructions before using this appliance.
a Read and follow the specific “Precautions to be Observed to Avoid Possible Exposure to Excessive
Microwave Energy” found on page ii.
a This appliance must be grounded. Connect only to a properly grounded outlet. See “Grounding
Instructions” on page ii.
a Install or locate this appliance only in accordance with the provided installation instructions.
a This appliance should be serviced by qualified service personnel only. Contact the nearest authorized
service facility for examination, repair, or adjustment.
a Keep the cord away from heated surfaces.
a Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave
oven is not always present.           
           .
a : The contents of feeding bottles and baby food jars must be stirred or shaken and the
temperature checked before consumption, in order to avoid burns (IEC 60335-2-90).
a Use this appliance only for its intended uses as described in this manual.
a Only use utensils that are suitable for use in microwave ovens (IEC 60335-2-90).
X   use corrosive chemicals or vapors in this appliance; it is not designed for industrial/laboratory use.
X :   heat liquids or other foods in sealed containers (e.g., jars, whole eggs, etc.) since
they are liable to explode.
X   allow children to use this appliance.
X   operate this appliance if it has a damaged cord or plug, is not working properly, or has been
damaged or dropped. See “Power Cord Replacement” found on page ii.
X   cover or block any openings on this appliance.
X   store this appliance outdoors.
X   use this product near water (e.g., near a kitchen sink, in a wet basement, near a swimming pool).
X   immerse the cord or plug in water.
X   let the cord hang over the edge of a table or counter.
X   use a water jet for cleaning. See pages 5-7 in this manual for proper cleaning procedures.
X   use this product without the bottom jetplate installed. The oven will not cook properly and
damage to the oven may occur.
X This appliance is not to be used by children or persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
REDUCING FIRE RISK
a Remove wire twist-ties from paper or plastic bags used to facilitate cooking in the oven.
a If materials inside the oven ignite, keep the oven door closed, turn the oven off, and disconnect the
power cord or shut off power at the fuse or circuit breaker panel.
a If smoke is observed, switch off or unplug the oven. Keep the door closed to stifle any flames.
X   use the cook cavity for storage purposes.
X   overcook food. Carefully attend to the oven if paper, plastic, or other combustible materials are
placed inside the oven to facilitate cooking.
X   leave paper products, cooking utensils, or food in the cavity when the oven is not in use.

ii SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current. This oven is equipped with a cord that has
a grounding wire with a grounding plug, which must be plugged into an outlet that is properly installed and
grounded. Consult a qualified electrician or serviceman if uncertain about the ability to follow grounding
instructions or if in doubt as to whether the appliance is properly grounded.
X   use an extension cord. If the power cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
WARNING:Improper grounding can result in risk of electric shock.
POWER CORD REPLACEMENT
If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly
qualified person.
PRECAUTIONS TO BE OBSERVED BEFORE
AND DURING SERVICING TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other
microwave source, and make repairs as necessary: (1) interlock operation, (2) proper door closing,
(3) seal and sealing surfaces (arcing, wear, and other damage), (4) damage to or loosening of hinges and
latches, (5) evidence of dropping or abuse.
(c) Before turning on microwave power for any service test or inspection within the microwave
generating compartments, check the magnetron, wave guide or transmission line, and cavity for
proper alignment, integrity, and connections.
(d) Any defective or misadjusted components in the interlock, monitor, door seal, and microwave
generation and transmission systems shall be repaired, replaced, or adjusted by procedures described
in this manual before the oven is released to the owner.
(e) A microwave leakage check to verify compliance with the Federal Performance Standard should be
performed on each oven prior to release to the owner. Refer to page 26 for leakage test procedures.
RF INTERFERENCE CONSIDERATIONS
The oven generates radio frequency signals. This device has been tested and was determined to be in compli-
ance with applicable portions of FCC part 18 requirements and to the protection requirements of Council
Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic
compatibility at the time of manufacture. However, some equipment with sensitivity to signals below these
limits may experience interference.
If your equipment experiences interference:
a Increase the physical separation between this oven and the sensitive equipment.
a If the sensitive device can be grounded, do so following accepted grounding practices.
a If battery-powered microphones are being affected, ensure that the batteries are fully charged.
a Keep sensitive equipment on separate electrical circuits if possible.
a Route intercom wires, microphone wires, speaker cables, etc. away from the oven.
SAVE THESE INSTRUCTIONS

Specifications and
Installation

1
SPECIFICATIONS AND INSTALLATION
Encore 2 Depth
Encore Depth
Theory of Operation
The TurboChef Encore/Encore 2 oven uses radiant
heat in combination with high-speed air impinge-
ment and side-launched microwave to cook food
rapidly without compromising quality. Performance
and menu versatility are maximized due to flexible
top and bottom temperature settings and the ability
to set the amount of microwave and air in different
phases of each recipe.
This manual includes instructions for installing,
cleaning, and operating the oven. If you have
questions that are not addressed in this
manual, contact Customer Support at
800.90TURBO (USA) or +1 214.379.6000
(International), or your Authorized Distributor.
Dimensions
Oven Dimensions
Height - Single Oven
with legs: 23” (584 mm)
without legs: 19” (483 mm)
Height - Stacked Ovens
lower oven with legs: 42” (1,067 mm)
lower oven without legs: 38” (965 mm)
Width: 21.4” (544 mm)
Depth (Encore)
footprint: 28.6” (726 mm)
door closed: 32.7” (831 mm)
door open: 39.4” (1,000 mm)
Depth (Encore 2)
footprint: 25.85” (657 mm)
door closed: 29.95” (761 mm)
door open: 36.31” (922 mm)
Weight: 185 lb. (84 kg)
Cook Cavity Dimensions
Height: 6.0” (152 mm)
Width: 15.5” (394 mm)
Depth: 14.5” (368 mm)
Volume: 0.78 ft3(22.1 liters)
Clearances
Top: 5” (127 mm)
Sides: 2” (51 mm)
Figure 1: Encore and Encore 2 Oven Dimensions
Encore 2 Depth
Encore Depth
21.4” (544 mm)
19”
(483 mm)
Encore 2 Depth
Encore Depth
32.7” (831 mm)
30.2” (767 mm)
28.6” (726 mm)
21.4” (544 mm)
19”
(483 mm)
Encore 2 Depth
Encore Depth
29.95” (761 mm)
27.45” (697 mm)
25.85” (657 mm)
Encore Oven Dimensions Encore 2 Oven Dimensions
23”
(584 mm)
23”
(584 mm)

2SPECIFICATIONS AND INSTALLATION
Certifications
cULus, UL EPH, TÜV, CE, FDA
Oven Construction
Exterior
- Powder coated, corrosion-resistant steel
outer wrap
- Powder-coated aluminum steel front panels
and door
- Cool-to-touch exterior; all surfaces below
122°F (50°C)
- Ergonomic door handle
Interior
- 201 stainless steel
- Fully welded and insulated cook chamber
- Removable rack and lower jetplate for cleaning
Electrical Specifications
TurboChef recommends a Type D circuit breaker
for all installations outside the United States.
Single Phase (6200 watts)
US/Canada: 208/240 VAC*, 60 Hz, 30 A
Europe/Asia (UK): 230 VAC, 50 Hz, 30 A
Brazil (BK): 220 VAC, 60 Hz, 30 A
Latin America (LA): 220 VAC, 60 Hz, 30 A
Japan (JK): 200 VAC, 50 or 60 Hz, 30 A
Multiphase (6200 watts)
Europe/Asia Wye (EW): 400 VAC, 50 Hz, 16 A
Europe/Asia Delta (ED): 230 VAC, 50 Hz, 30 A
Japan Delta (JD): 200 VAC, 50 or 60 Hz, 30 A
Korea/Middle East Wye (KW): 400 VAC, 60 Hz, 16 A
Korea/Middle East Delta (SD): 230 VAC, 60 Hz, 30 A
* US/Canada models include a voltage sensor
that detects 208 or 240 VAC, but does not
compensate for lack-of or over-voltage installations.
Installation
Install or locate this appliance only in accordance
with the instructions below.
Unpacking Instructions
1. Remove the oven from its packaging.
2. Before throwing the packaging away, check it
thoroughly for accessories and literature.
NOTE: Keeping the packaging is recommended in
case the oven may be shipped to another location.
3. Check the cook cavity thoroughly for
packaging, accessories, and literature.
4. Discard any packaging in the cook cavity.
Installation Warnings - Read Before Lifting Oven
WARNING: The oven weighs approximately
185 lb. (84 kg). Never lift with fewer than
two people.
WARNING: Never lift the oven by the door
handle. Doing so will cause the door to mis-
align, resulting in a non-warranty service call.
WARNING: The oven must be properly
placed on a food station at all times.
TurboChef will not recognize a fallen oven as
a warrantable claim and is not liable for any
injuries that may result.
WARNING: This oven is not intended for
built-in installation (i.e., installing the oven in
any structure that surrounds the oven by five
or more sides). Be sure to provide a minimum
of 2” (51 mm) clearance for all sides and 5”
(127 mm) clearance for the top.
WARNING: This oven is not intended to be
stacked without appropriate hardware.
Contact TurboChef for details.
WARNING: Never stack ovens more than
two high.

3
SPECIFICATIONS AND INSTALLATION
Installing the Oven
1. Prepare a surface capable of supporting
190 lb. (86 kg) or 380 lb. (172 kg) if stacking.
The surface must be this deep:
 • Encore:30.2”(767mm)
 • Encore2:27.45”(697mm)
2. If installing onto an oven cart:
a. Ensure the oven cart casters are locked.
b. Ensure the oven legs are removed.
c. Drilling additional holes in the counter
surface/cart for stability is required if the
existing holes in the cart/surface do not
align with the leg holes of the oven. For
details, contact customer support at
800.90TURBO or +1 214.379.6000.
3. Position one or more persons at the front and
back of the oven.
4. Place hands under the oven and lift.
5. Place the oven on the prepared surface,
ensuring no edges are hanging off the sides.
6. If stacking two ovens:
a. See page 1 for dimensions.
b. Install the stacking bracket (part number
ENC-3001) to the lower oven.
NOTE: If stacking an Encore and Encore 2,
the Encore oven must be placed on the bottom.
c. Place the upper oven on top of the lower
oven.
d. Secure the bracket to the top oven.
7. Ensure the oven rack is properly installed
(attached to the bottom jetplate).
8. Plug in the oven.
NOTE: The oven is primarily serviced through
its sides and top. Shelving installed directly over
the unit may delay servicing. The owner will be
responsible for paying service costs for added time
spent clearing access to the oven.
Installation Near Open Heat Source
When placing a TurboChef oven near an open
heat source (Figure 2 below), strictly adhere to the
following:
- If the oven is being placed near a grill or stove,
a divider must exist between the oven and the
open heat source, with a minimum of 6”
(152 mm) between the oven and the divider.
- If the oven is being placed near a fryer, a
divider must exist between the oven and fryer,
with a minimum of 12” (305 mm) between
the oven and the divider.
- The height of the divider must be greater than
or equal to the height of the oven (see page 1).
- Verify the oven location has a minimum 5”
(127 mm) clearance on top and a minimum 2”
(51 mm) clearance on each side.
Figure 2: Installation Near Open Heat Source

4SPECIFICATIONS AND INSTALLATION
Oven Restraint Kit
Part Number: TC3-0242
WARNING: The Oven Restraint Kit will
not prevent the oven from falling off a
countertop if the oven is pulled off or
allowed to slide off the edge. Installation
instructions are included with the kit.
ChefComm Pro®
ChefComm Limited™
Part Number: CON-7016
ChefComm LimitedTM is a “read-and-upload only”
version of ChefComm Pro® that helps ensure menu
settings are easy to distribute, while preventing
them from being changed at the store level.
Oven Connect™
Oven ConnectTM allows you to update menu
settings for multiple ovens at once, from one
central location via LAN. Oven ConnectTM can also
download oven diagnostics and counters from the
oven to your computer. For more information
on how to network ovens, see page 14. For
information on Oven Connect, contact
TurboChef Customer Support at 800.90TURBO
or +1 214.379.6000.
Voltage Selection
For North America oven models, the oven will
detect 208 or 240 incoming voltage.
If incoming voltage for the store is different than
the factory-preset voltage, the operator will be
required to select either 208 or 240 after pressing
the On/Off key to turn on the oven. The correct
voltage will be enlarged on the screen, identifying
which option to select (see below).
Ventilation
The TurboChef Encore/Encore 2 oven has been
approved by Underwriter’s Laboratory® for ventless
operation (UL 710B, KNLZ listing) for all food
items except for foods classified as “fatty raw
proteins.” Such foods include bone-in, skin-on
chicken, raw hamburger meat, raw bacon, raw
sausage, steaks, etc. If cooking these types of foods,
consult local HVAC codes and authorities to ensure
compliance with ventilation requirements.
NOTE: In no event shall the manufacturer assume
any liability for damages or injuries resulting from
installations which are not in compliance with the
instructions and codes previously listed.
Part Number: CON-7006
ChefComm Pro® lets you easily create menu
settings on a computer and upload them to
an oven via smart card or USB. For more
information, call TurboChef Customer Support
at 800.90TURBO or +1 214.379.6000.
Figure 3: Select Voltage

Daily and Quarterly
Maintenance

5
DAILY MAINTENANCE
Daily Maintenance
Follow the steps below when cleaning your oven.
Use only TurboChef®-approved cleaning chemicals.
Failure to adhere to these procedures or the use of
any other cleaning products may damage critical oven
components, resulting in a non-warranty service call.
Supplies and Equipment
TurboChef® Oven Cleaner (Product Number: 103180),
TurboChef® Oven Guard (Product Number: 103181),
Kay ClickSan® sanitizer, nylon scrub pad, clean damp
and dry towels, disposable gloves, protective eyewear,
dust mask (optional)
Step 1
Tab Location
Step 2
Step 4
Step 3
Step 5
Step 1: Cool the Oven
WARNING: e oven operates at approximately 500°F (260°C) and may cause
injury if not allowed to cool properly.
•Turn o the oven by pressing the On/O key.
•Slightly open the oven door.
•Cooling takes approximately 30 minutes.
DO NOT proceed to Step 2 until the oven displays “ready to clean.”
Step 2: Clean the Wire Rack
•ewirerackisheldinplacebytabsthatarepositionedunderneatheitherside
of the jetplate.
•Lifttherearofthewirerack.
•Pullthewirerackforwarduntilthetabsarefree.
•Wash,rinse,sanitize,anddrythewirerack.
Step 3: Clean the Jetplate
•Liftthefrontofthejetplate.
•Pullthejetplateforwardandremoveitfromtheoven.
CAUTION: Handle the jetplate with care to avoid chipping the porcelain coating.
•Wash,rinse,sanitize,anddrythejetplate.
DO NOT clean the jetplate with a wire brush.
Step 4: Clean the Cavity Filter (if present)
e lter must remain in place during oven operation, and it must be cleaned
regularly or replaced if damaged.
•Removethecavitylterfromthebackcavitywallbyliftingthetabandpullingthe
lter towards you.
•Rinsethelterwithhotwater.
•Allowtheltertodrycompletely.
DO NOT scrub or pull apart the mesh in the lter frame.
Step 5: Clean the Air Filter
e lter must remain in place during oven operation, and it must be cleaned
regularly or replaced if damaged.
•Removetheairlterfromthebackoftheoven.
•Rinsetheairlterwithhotwater.
•Allowtheairltertodrycompletely.
!
!

6DAILY MAINTENANCE
A
Step 7
Step 8
Step 10
Step 9
Step 11
Step 12
Step 6: Remove Large Food Particles
•eheatingelementcanbeliftedforcleaningunderneath.
DO NOT attempt to clean the heating element.
•Useafoodvacuumordamptoweltoremovelargeparticles from the oven cavity.
Step 7: Clean the Oven Cavity
DO NOT spray TurboChef® Oven Cleaner into the holes in the oven cavity.
•ApplyOvenCleanertoatowelornylonscrubpadandcleanthetop,sides,and
bottom of the cavity.
DO NOT apply excessive pressure to the waveguide covers (A), located on
each side of the cavity.
•Forstubbornstains,sparinglysprayOvenCleaneronthestain.
•AllowtheOvenCleanertopenetratethestainforveminutes,thenwipeclean.
DO NOT use a hose or water jet for cleaning.
Step 8: Wipe Down the Oven Cavity
•Wipedowntheovencavitywithadamptowel.
•Drytheovencavitywithadrytowel.
Step 9: Clean and Dry the Oven Door
•CleantheovendoorwithOvenCleanerandanylonscrubpad.
•Wipetheovendoorwithadamptowel.
•Drytheovendoorwithadrytowel.
Step 10: Apply TurboChef ®Oven Guard
•SprayTurboChef®OvenGuardontoadrytowel.
•Wipethecavitywallsandtheinsideoftheovendoor.
DO NOT spray Oven Guard into the oven or apply to the heating element.
Step 11: Reinstall Components
•Reinstallthecavitylter(ifpresent).Besuretoalignthetop-leftpostonthe 
back of the lter with the top-left hole on the back cavity wall. is will ensure the
other posts on the back of the lter t into the wall.
•Reinstallthejetplateandthewirerack.
DO NOT operate the oven without the bottom jetplate installed. Doing so may
damage the oven.
•Closetheovendoor.
•Reinstallthelter,orreplaceitwithanewoneifthemeshisdeteriorated,has 
large openings, or has started to dislodge from the frame.
Step 12: Clean the Oven Exterior
•Wipetheovenexteriorwithadamptowel.
•Removethepanelbeneaththedoor,removeanylargefoodparticlesfromthepanel,
and wipe it with a damp towel.
•Reinstallthepanelbeneaththedoor.
DO NOT spray chemicals into any openings, such as the louvers on the side
panels or the rear vent catalyst housing.
•eovenisreadytoturnon.
Step 6
