TurboChef TORNADO User manual

©2007 Doctor's Associates Inc. All rights reserved. December 2007
This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.
Preventive Maintenance Guide PREP PAGE 2.48
PREP/SERVICE AREA Tornado Oven – TurboChe
Clean ven Interior and Exterior
12/07
What You Will Need:
• SUBWAY®Oven Cleaner
• SuperSanTM sanitizer
• Nylon scrub pad
• Cleaning towel
Speed oven should be cleaned each morning
before it is turned on to avoid having to wait
for it to cool down
Prepare the ven for Cleaning
1. Turn off the oven by pressing the “BACK”
key on the control pad – the control panel
will display the message “ VEN FF
C LING D WN”. The cooling process will
take approximately 90 minutes.
✓TASK QUICK STEPS
✓Turn off the oven – press the “BACK”
key on the control panel, and wait 90
minutes for the oven to cool
completely
✓Clean food particles from lower access
panel – remove panel, wipe out with
damp cloth, reattach panel
✓Clean wire rack – remove; wash, rinse,
sanitize and let dry; reinstall
✓Clean interior – under bottom heating
element, with damp towel; remove
stains; wipe heating element;
thoroughly dry cooking cavity –
especially bottom of cook cavity and
wave guide covers
✓Clean exterior – where access panel is
connected and all other finished
surfaces
Do not attempt to clean the
Tornado oven during the cool
down cycle, as indicated by the
“COOLING DOWN” message
displayed on the control panel – the oven
operates at 500° /260°C and may cause
injury if not allowed to cool completely
before cleaning
CAUTION
1

©2007 Doctor's Associates Inc. All rights reserved. December 2007
This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.
Preventive Maintenance GuidePREP PAGE 2.49
PREP/SERVICE AREA Tornado Oven – TurboChe
Clean ven Interior and Exterior continued
12/07
Clean Food Particles from Lower Access Panel
1. Remove the lower access panel, below the
oven door – grip the panel on both ends and
pull to disengage the four clips that secure
the panel to the oven
2. Wipe out any food particles and crumbs that
have collected inside the access panel and
around the oven base with a towel
Clean the Wire Rack
1. Remove the wire rack from inside the oven
2. Wash and rinse the wire rack, and then sanitize
using SuperSan™ sanitizer; let dry
Clean the ven Interior
1. Lift the bottom heating element, and while
holding it up, use a damp towel to remove any
large food particles from the bottom of the oven
2. If stubborn stains are present, sparingly spray
SUBWAY®Oven Cleaner into the oven cavity
and on the inside of the door, and allow the
cleaner to penetrate for five minutes
•
Only use SUBWAY®Oven Cleaner – using any
other cleaning products can damage critical
parts and may void the warranty on those parts
• Never saturate the bottom of the oven
with water or oven cleaner – doing so will
damage vital components and result in a
non-warranty service call
• Never spray the top of the cavity
Do not touch the heating
element until the cool down
cycle has completed and the
element has cooled completely
– the heating element operates at
1000° /538°C and can cause burns if not
completely cooled
CAUTION

©2007 Doctor's Associates Inc. All rights reserved. December 2007
This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.
Preventive Maintenance Guide PREP PAGE 2.50
PREP/SERVICE AREA Tornado Oven – TurboChe
Clean ven Interior and Exterior continued
12/07
3. Using a nylon scrub pad, clean the oven
interior and door, being careful not to apply
pressure to the Wave Guide Caps – breaking
the caps will result in a non-warranty service
call
4. Cracked wave guide covers must be replaced
immediately
5. Wipe the oven interior, heating element,
and door using a clean damp towel. Repeat
as necessary until all oven cleaner residue is
removed
Clean ven Exterior
1. Wipe the area beneath the oven door –
Do NOT spray any chemical in this area!
2. Wipe the oven exterior with a clean, damp
cloth

©2007 Doctor's Associates Inc. All rights reserved. December 2007
This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.
Preventive Maintenance GuidePREP PAGE 2.51
PREP/SERVICE AREA Tornado Oven – TurboChe
Clean ven Interior and Exterior continued
12/07
Prepare the ven for peration
1. Lower the bottom heating element and
reinstall the wire rack
2. Reinstall the lower access panel
3. Power up the oven – Press the “ VEN N”
soft key, and the control panel will display
“WARMING UP”. It will take approximately
15 minutes for the oven to warm up, and
the oven will sound a tone when the oven is
ready to use.
