TurboChef NGO User manual

TM
Service Manual
   /TM   
©2009-2014 TurboChef Technologies, Inc.

For further information, call
800.90TURBO
or
+1 214.379.6000

The information contained in this manual is important for the proper installation, use, maintenance,
and repair of this oven. Follow these procedures and instructions to help ensure satisfactory baking
results and years of trouble-free service.
Errors – descriptive, typographic, or pictorial – are subject to correction. Specifications are subject to
change without notice.
Please carefully read this manual and retain it for future reference.

Safety Instructions
General Safety Information i
Reducing Fire Risk i
Grounding Instructions ii
Power Cord Replacement ii
Precautions to be Observed Before and During Servicing to Avoid
Possible Exposure to Excessive Microwave Energy ii
RF Interference Considerations ii
Specifications and Installation
Theory of Operation 1
Dimensions 1
Certifications 2
Oven Construction 2
Electrical Specifications 2
Installation 2
Unpacking Instructions 2
Installation Warnings - Read Before Lifting Oven 2
Lifting and Placing the Oven 3
Installation Near Open Heat Source 3
Oven Connect Suite 4
Oven Connect 4
ChefComm Pro 4
ChefComm Limited 4
Voltage Selection 4
Ventilation 4
Daily Maintenance 5-6
Oven Controls and Cooking
Oven Controls 7
Cooking 8
Step 1: Turn the Oven On 8
Step 2: Select Cook Temperature 8
Step 3: Warming Up 8
Step 4: Soaking 9
Step 5: Ready to Cook 9
Step 6: Adjusting the Time 9
Step 7: Cooking 9
Step 8: Check/Remove Food from Oven 10
Step 9: Additional Cooking Options 10
Step 10: Cooling Down 10
Table of Contents

Info, Test, and Edit Mode
Overview of the Info Mode 11
Viewing Cook Counter/Time Logs 11
Viewing the Fault Log 11
Viewing the Service Numbers 11
Setting the Language 11
F2 Bypass 12
Resetting the Oven 12
Set Options Screens 12
Network Setup 12
Auto On and Off: Setting the Time 13
Light Ring 13
Catalytic Recondition 13
Test Mode - Testing Oven Parts 14
Status Indicators 14
Turning Diagnostic Mode On/Off 14
Manufacturing Mode 15
Serial Number Edit 15
Changing Temperature Measurement Setting 15
Microwave Leakage Test (How to Use Oven for Testing) 15
Erase/Default Oven Settings 15
Updating the Oven Menu 16
Making a Copy of the Oven Menu 16
Updating the Oven Firmware 17
Menu Structure 17
Overview of the Edit Mode 17
Changing Set Temperatures 17
Edit Recipe Settings 18
Changing Group/Item/Quantity Name 18
Changing Cook Settings 18
Oven Systems
Convection System 19
Blower Motor (Bottom) 19
Blower Motor (Top) 19
Blower Motor Speed Controller (BMSC) 19
Heater Elements 19
Jetplate (Bottom) 19
Jetplate (Top) 19
Stirrer Motor and Assembly 19
Troubleshooting 19
Oven Door 20
Removing/Reinstalling the Oven Door 20
Adjusting the Oven Door 20
Interlock Switches 21
Adjusting the Primary, Secondary, and Monitor Switches 21
Measuring RF Leakage for Microwave Safety 22
Troubleshooting 22

Microwave System 23
Capacitors 23
Testing a Capacitor 23
Filament Transformers 23
Wiring the Filament Transformers 23
High-Voltage Transformers 24
Wiring the High-Voltage Transformers 24
Testing a Filament or High-Voltage Transformer 24
High-Voltage Diodes 24
Testing a High-Voltage Diode 25
Magnetrons 26
Testing a Magnetron for an Open/Shorted Filament 26
Stirrer Motor and Assembly 26
Waveguides 26
Troubleshooting 26
Control System 27
Control Board 27
Cooling Fans 27
Display 27
Electrical Compartment Cooling Fan Thermostat 27
Electrical Compartment Thermocouple 27
EMI Filter 27
Ethernet Extension Cable 28
Fuses 28
High-Limit Thermostat 28
Keypad 28
LED Light Ring (Sota only) 28
Magnetron Thermostats 28
Power Supply 28
Relay - K1 Filament 28
Relay - K2 Magnetron Cooling Fans 28
Relay - K3 Stirrer Motor 28
Relay - K6 Voltage 28
Relay - K7 Monitor 29
Relay - K8 Anode 29
RTD 29
Smart Card Reader 29
Solid State Relay - K4/K5 Heater 29
Speaker 29
Voltage Sensor 29
Wire Harness 29
Troubleshooting 29
Filtering System 30
Catalytic Converter 30
Air Filter 30
Vent Catalyst 30
Troubleshooting 30

Troubleshooting
Overview of Troubleshooting 31
Fault Code Descriptions 31
Fault Code Troubleshooting - F1 Blower Running Status Bad 33
Fault Code Troubleshooting - F2 Cook Temperature Low 34
Fault Code Troubleshooting - F3 Magnetron Current Low 35
Fault Code Troubleshooting - F4 Door Monitor Defective 36
Fault Code Troubleshooting - F5 Magnetron Over Temperature 36
Fault Code Troubleshooting - F6 Electrical Compartment Temperature High 37
Fault Code Troubleshooting - F7 RTD Open 37
Fault Code Troubleshooting - F8 Heat Low 38
Fault Code Troubleshooting - F9 Cook Cavity Temperature High 38
Non-Fault Code Troubleshooting - No Keypad Input 39
Non-Fault Code Troubleshooting - “Cook Door Open” Message when Door is Closed 39
Non-Fault Code Troubleshooting - No Display (Screen is Blank) 40
Non-Fault Code Troubleshooting - Food Not Cooking Properly 41
Non-Fault Code Troubleshooting - “Read Fail” Message when Loading a Menu 42
Non-Fault Code Troubleshooting - “Write Fail” Message when Loading a Menu 42
Non-Fault Code Troubleshooting - Menu Settings are Not Present 43
Non-Fault Code Troubleshooting - “Defective Media” Message When Oven is
Plugged in or Restarted 44
Oven Schematic 45
Appendix - Replacing Oven Components
Replacing Oven Components A-1
Replacing Items - No Cover Removal Required A-2
Replacing Items - Removing Outer Shell Required A-4
Replacing Items - Removing Outer Shell and Back Cover Required A-11
Replacing Items - Removing Outer Shell and Back Cover Required,
Single Magnetron Sota A-12

SAFETY INSTRUCTIONS
  
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When operating this oven, strictly adhere to the following safety precautions to reduce the risk
of burns, electric shock, fire, injury, damage to oven or property near oven, or possible exposure to excessive
microwave energy.
General Safety Information
D
Read all instructions before using this appliance.
D
Read and follow the specific “Precautions to be Observed Before and During Servicing to Avoid Possible
Exposure to Excessive Microwave Energy” found on page ii.
D
This appliance must be grounded. Connect only to a properly grounded outlet. See “Grounding
Instructions” on page ii.
D
Install or locate this appliance only in accordance with the provided installation instructions.
D
This appliance should be serviced by qualified service personnel only. Contact the nearest authorized
service facility for examination, repair, or adjustment.
D
Keep the cord away from heated surfaces.
D
Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave
oven is not always present.           
           .
D
: The contents of feeding bottles and baby food jars must be stirred or shaken and the
temperature checked before consumption, in order to avoid burns (IEC 60335-2-90)
D
Use this appliance only for its intended uses as described in this manual.
D
Only use utensils that are suitable for use in microwave ovens (IEC 60335-2-90)
X   use corrosive chemicals or vapors in this appliance; it is not designed for industrial/laboratory use.
X :   heat liquids or other foods in sealed containers (e.g., jars, whole eggs, etc.) since
they are liable to explode.
X   cook with metal lids or aluminum foil
X   cook without food in the cook cavity.
X   allow children to use this appliance.
X   operate this appliance if it has a damaged cord or plug, is not working properly, or has been
damaged or dropped. See “Power Cord Replacement” found on page ii.
X   cover or block any openings on this appliance.
X   store this appliance outdoors.
X   use this product near water (e.g., near a kitchen sink, in a wet basement, near a swimming pool).
X   immerse the cord or plug in water.
X   let the cord hang over the edge of a table or counter.
X   use a water jet for cleaning. See pages 5-6 in this manual for proper cleaning procedures.
X This appliance is not to be used by children or persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
Reducing Fire Risk
D
Remove wire twist-ties from paper or plastic bags used to facilitate cooking in the oven.
D
If materials inside the oven ignite, keep the oven door closed, turn the oven off, and disconnect the
power cord or shut off power at the fuse or circuit breaker panel.
D
If smoke is observed, switch off or unplug the oven. Keep the door closed to stifle any flames.
X   use the cook cavity for storage purposes.
X   overcook food. Carefully attend to the oven if paper, plastic, or other combustible materials are
placed inside the oven to facilitate cooking.
X   leave paper products, cooking utensils, or food in the cavity when the oven is not in use.
i

Grounding Instructions
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current. This oven is equipped with a cord that has
a grounding wire with a grounding plug, which must be plugged into an outlet that is properly installed and
grounded. Consult a qualified electrician or serviceman if uncertain about the ability to follow grounding
instructions or if doubt exists as to whether the appliance is properly grounded.
X   use an extension cord. If the power cord is too short, have a qualified electrician or
serviceman install an outlet near the appliance.
WARNING: Improper grounding can result in risk of electric shock.
Power Cord Replacement
If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly
qualified person.
Precautions to be Observed Before and During Servicing to Avoid Possible
Exposure to Excessive Microwave Energy
(a)   operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other
microwave source, and make repairs as necessary: (1) interlock operation, (2) proper door closing,
(3) seal and sealing surfaces (arcing, wear, and other damage), (4) damage to or loosening of hinges
and latches, (5) evidence of dropping or abuse.
(c) Before turning on microwave power for any service test or inspection within the microwave
generating compartments, check the magnetron, wave guide or transmission line, and cavity for
proper alignment, integrity, and connections.
(d) Any defective or misadjusted components in the interlock, monitor, door seal, and microwave
generation and transmission systems shall be repaired, replaced, or adjusted by procedures described
in this manual before the oven is released to the owner.
(e) A microwave leakage check to verify compliance with the Federal Performance Standard should be
performed on each oven prior to release to the owner.
Refer to page 22 for leakage test procedures.
RF Interference Considerations
The NGO oven generates radio frequency signals. This device has been tested and was determined to be in
compliance with applicable portions of FCC part 18 requirements and to the protection requirements of
Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electro-
magnetic compatibility at the time of manufacture. However, some equipment with sensitivity to signals
below these limits may experience interference.
If your equipment experiences interference:
D
Increase the physical separation between this oven and the sensitive equipment.
D
If the sensitive device can be grounded, do so following accepted grounding practices.
D
If battery-powered microphones are being affected, ensure that the batteries are fully charged.
D
Keep sensitive equipment on separate electrical circuits if possible.
D
Route intercom wires, microphone wires, speaker cables, etc. away from the oven.
ii SAFETY INSTRUCTIONS

SPECIFICATIONS AND INSTALLATION
1
Theory of Operation
Utilizing TurboChef’s patented technology to
rapidly cook food without compromising quality,
the NGO oven provides superior cooking
performance while requiring minimal space and
energy consumption. The control system precisely
coordinates independent top and bottom impinged
airflow with top-launched microwave to deliver
product-specific results, and integral catalytic
converters allow for UL®-certified ventless
operation (see page 4 for details).
This manual includes instructions for installing,
cleaning, operating, and servicing the NGO oven.
If you have questions that are not addressed in this
manual, contact Customer Support at
800.90TURBO (+1 214.379.6000) or your
Authorized Distributor.
Dimensions
Oven Dimensions
Height: 25.0” (635 mm)
Width: 16.0” (406 mm)
Depth (footprint): 18.5” (470 mm)
Depth (door closed): 29.8” (757 mm)
Depth (door open): 39.1” (993 mm)
Weight, Sota: 170 lb. (77 kg)
Weight, Single Magnetron Sota: 135 lb. (61.2 kg)
Cook Cavity Dimensions
Height: 7.2” (183 mm)
Width: 12.5” (318 mm)
Depth: 10.5” (267 mm)
Volume: 0.54 ft3(15.4 liters)
Clearances
Top: 5” (127 mm)
Sides: 2” (51 mm)
16.0”
(406 mm)
21.0”
(533 mm)
4.0”
(102 mm)
11.8”
(300 mm)
25.0”
(635 mm)
27.3”
(693 mm)
Approximate location
of cord and plug
2.5”
(64 mm)
18.5”
(470 mm) 4.2”
(107 mm)
10.7”
(272 mm)
25.9”
(658 mm)
2.5”
(64 mm)
39.1”
(993 mm)
Figure 1: NGO Oven Dimensions

Certifications
cULus, UL EPH, TÜV, CE, FDA
Oven Construction
Exterior
- Two-tone stainless steel front, top, and sides
- Ergonomic door handle
- 4” (102 mm) adjustable legs
- Cool-to-the-touch door with microwave seal
Interior
- 304 stainless steel interior
- Fully-insulated cook chamber
- Removable rack
- Top and bottom jetplates
Electrical Specifications
TurboChef recommends a Type D circuit breaker
for all installations outside the United States.
Single Phase (6200 watts)
US/Canada: 208/240 VAC*, 60 Hz, 30 A
Europe/Asia (UK): 230 VAC, 50 Hz, 27 A
Brazil (BK): 220 VAC, 60 Hz, 28 A
Latin America (LA): 220 VAC, 60 Hz, 28 A
Japan (JK): 200 VAC, 50 or 60 Hz, 30 A
Multiphase (6200 watts)
Europe/Asia Wye (EW): 400 VAC, 50 Hz, 16 A
Europe/Asia Delta (ED): 230 VAC, 50 Hz, 20 A
Japan Delta (JD): 200 VAC, 50 or 60 Hz, 20 A
Korea/Middle East Wye (KW): 400 VAC, 60 Hz, 16 A
Korea/Middle East Delta (SD): 230 VAC, 60 Hz, 20 A
Australia (AU): 400 VAC, 50 Hz, 16 A
Single Magnetron
US/Canada 1 Ph: 208/240 VAC*, 60 Hz, 20 A, 4.2/4.8 kW
Europe (UK) 1 Ph: 230 VAC, 50 Hz, 13 A, 3 kW
Europe (UK) 1 Ph: 230 VAC, 50 Hz, 16 A, 3.6 kW
* US/Canada models include a voltage sensor
that detects 208 or 240 VAC, but does not com-
pensate for lack-of or over-voltage installations.
Installation
Install or locate this appliance only in accordance
with the instructions below.
Unpacking Instructions
1. Remove the oven from its packaging.
2. Before discarding, check the packaging
thoroughly for accessories and literature.
NOTE: Packaging may also be retained in case the
oven may at some point be shipped somewhere
else or returned to the manufacturer.
3. Check the cook cavity thoroughly for
accessories and literature.
4. Discard any packaging in the cook cavity.
Installation Warnings - Read Before Lifting Oven
WARNING: The Sota oven weighs
approximately 170 lb. (77 kg). The Single
Magnetron Sota oven weighs approximately
135 lb. (61.2 kg). Never lift with fewer than
two people.
WARNING: Never lift the oven from the
front and rear or by the door handle. Doing so
will cause the door to misalign, resulting in a
non-warranty service call.
WARNING: The oven must be properly
placed on a food station at all times.
TurboChef will not recognize a fallen oven as
a warrantable claim and is not liable for any
injuries that may result.
WARNING: This oven is not intended for
built-in installation (i.e., installing the oven in
any structure that surrounds the oven by five
or more sides). Be sure to provide a minimum
of 2” (51 mm) clearance for all sides and 5”
(127 mm) clearance for the top.
WARNING: This oven is not intended to be
stacked without appropriate hardware.
Contact TurboChef for details.
2 SPECIFICATIONS AND INSTALLATION

SPECIFICATIONS AND INSTALLATION
3
Lifting and Placing the Oven
1. Prepare a surface at least 26” (660 mm) deep
and capable of supporting 175 lb. (79 kg).
NOTE: Do not remove the oven legs, as clearance
is required for the bottom cooling fan.
2. Position one or more persons at the left and
right sides of the oven.
3. Place hands under the oven and lift.
4. Place the oven on the prepared surface,
ensuring no edges are hanging off the sides.
5. Ensure the oven rack is properly installed
(attached to the bottom jetplate).
6. Plug in the oven.
NOTE: The oven is primarily serviced through its
top. DO NOT install shelving directly over the
unit. The operator will be responsible for service
charges incurred as a result of added time required
to access the top of the oven.
Installation Near Open Heat Source
When placing a TurboChef oven near an open
heat source (Figure 2), strictly adhere to the fol-
lowing:
- If the oven is being placed near a grill or stove,
a divider must exist between the oven and the
open heat source, with a minimum of 6” (152
mm) between the oven and the divider.
- If the oven is being placed near a fryer, a
divider must exist between the oven and fryer,
with a minimum of 12” (305 mm) between
the oven and the divider.
- The height of the divider must be greater than
or equal to the height of the oven (25.0” or
635 mm).
- Verify the oven location has a minimum 5”
(127 mm) clearance on top and a minimum 2”
(51 mm) clearance on each side.
Grill
Partition
25.0” (635 mm)
Above Counter Top
TurboChef
NGO Oven
6”
(152 mm)
Minimum
12”
(305 mm)
Minimum
Deep Fryer
Counter Top / Table
Partition
25.0” (635 mm)
Above Counter Top
Figure 2: Installation Near Open Heat Source

4 SPECIFICATIONS AND INSTALLATION
Figure 3: Selecting Voltage
Oven Connect Suite
Oven Connect
Oven ConnectTM allows you to update menu
settings for multiple ovens at once, from one
central location. Oven Connect can also download
oven diagnostics and counters. For more informa-
tion on how to network ovens, see page 12. For
information on obtaining Oven Connect, contact
TurboChef Customer Support at 800.90TURBO
or +1 214.379.6000.
If servicing a control board, follow the instructions
on page 27 to ensure proper connectivity.
ChefComm Pro
Part Number: CON-7006
ChefComm Pro® empowers any user of a
TurboChef oven to easily create menu settings
on a computer and transfer them to an oven via
smart card. For more information, call TurboChef
Customer Support at 800.90TURBO or
+1 214.379.6000.
ChefComm Limited
Part Number: CON-7016
ChefComm LimitedTM is a “read-and-transfer only”
version of ChefComm Pro that helps ensure
carefully-crafted settings are easy to distribute
globally, while providing the peace of mind that
they will not be altered.
Voltage Selection
For North America oven models, the oven will
detect 208 or 240 incoming voltage.
The initial voltage selection is typically completed
before the oven is used by the customer. However,
if incoming voltage for the store is different than
the preset voltage, the operator will be required to
select either 208 or 240 after pressing the On/Off
key to turn on the oven. The correct voltage will be
enlarged on the screen, identifying which option to
select (see Figure 3 below).
Ventilation
The TurboChef TurboChef Soˇta (model NGO)
oven has been approved by Underwriter’s
Laboratory for ventless operation (UL KNLZ list-
ing) for all food items except for foods classified as
“fatty raw proteins.” Such foods include bone-in,
skin-on chicken, raw ham¬burger meat, raw bacon,
raw sausage, steaks, etc. If cooking these types of
foods, consult local HVAC codes and authorities to
ensure compliance with ventilation requirements.
To ensure continued compliance with all health,
building, and fire codes, you are required to main-
tain clean and sanitary conditions around your
oven at all times.
NOTE: In no event shall the manufacturer assume
any liability for damages or injuries resulting from
installations which are not in compliance with the
instructions and codes previously listed. Failure to
comply with these instructions could result in the
issuance of a temporary cease and desist order from
the local health department until the environment
concerns are addressed.
208 VAC
SELECT VOLTAGE:
240 VAC

DAILY MAINTENANCE
5
Step 1: Prepare the Oven
WARNING: The oven operates at approximately 525°F (274°C) and may
cause injury if not allowed to cool properly.
t5VSOPGGUIFPWFOCZQSFTTJOHUIF0O0GGLFZ
t4MJHIUMZPQFOUIFPWFOEPPS
t$PPMJOHUBLFTBQQSPYJNBUFMZNJOVUFTDO NOT clean the oven until the
oven displays  :   .
Step 2: Remove the Wire Rack and Lower Jetplate
WARNING: Be sure the oven interior is cool before removing these items.
CAUTION: Do not force the rack out by pulling upward. Forcefully
dislodging the rack could cause the top ceramic jetplate to break.
t5IFXJSFSBDLBOEMPXFSKFUQMBUFBSFDPOOFDUFEBOEDBOCFSFNPWFEUPHFUIFS 
t1VTIUIFXJSFSBDLUPXBSETUIFSFBSDBWJUZXBMM'JH"BOEUIFOMJGUVQ'JH#
t.BOFVWFSUIFCPUUPNKFUQMBUFPVUGSPNVOEFSUIFUBCTPOUIFSFBSDBWJUZXBMM
CAUTION: DO NOT remove the top ceramic jetplate; breakage will result in
a non-warranty service call.
Step 3: Clean the Wire Rack and Lower Jetplate
t%FUBDIUIFXJSFSBDLGSPNUIFKFUQMBUFBOEXBTISJOTFTBOJUJ[FBOEESZFBDIQBSU
Step 4: Clean the Air Filter
CAUTION: TurboChef does not recognize blocked air vents as a warrantable
claim. The filter must be cleaned regularly or replaced if damaged. During oven
operation, the filter must remain in place at all times.
t3FNPWFUIFBJSGJMUFSGSPNUIFCBDLPGUIFPWFO
t3JOTFUIFBJSGJMUFSXJUIIPUXBUFS
t"MMPXUIFBJSGJMUFSUPESZDPNQMFUFMZ
CAUTION: DO NOT operate the oven without the air filter in place.
Step 5: Wipe the Oven Interior
t6TFBGPPEWBDVVNPSEBNQUPXFMUPSFNPWFMBSHFQBSUJDMFTGSPNUIFPWFODBWJUZ
Continued on page 6.
Daily Maintenance
Follow the steps below when cleaning your NGO
oven. Use only TurboChef ®-approved cleaning
chemicals. The use of any other cleaning products
may damage critical oven components, resulting in a
non-warranty service call.
Supplies and Equipment
TurboChef ® Oven Cleaner (Product Number:
103180), TurboChef ® Oven Guard (Product Number:
103181, optional for easier maintenance), Kay Click-
San® sanitizer, nylon scrub pad, cleaning towel, dispos-
able gloves, protective eyewear, dust mask (optional)
Step 1
Step 2 (Fig A)
Step 2 (Fig B)
Step 4
Step 5

6 DAILY MAINTENANCE
Step 6: Clean the Oven Interior
t4QSBZ5VSCP$IFG¥0WFO$MFBOFSPOUPUIFUPQCPUUPNBOETJEFTPGPWFOJOUFSJPS
CAUTION: DO NOT spray Oven Cleaner into the holes on the back oven
wall. Doing so can damage critical oven components, resulting in a non-
warranty service call.
t"MMPX0WFO$MFBOFSUPQFOFUSBUFTUBJOTGPSGJWFNJOVUFT
t$MFBOUIFPWFOJOUFSJPSXJUIBOZMPOTDSVCQBE
CAUTION: DO NOT attempt to scrub the upper jetplate (Fig B). If food is
stuck to the oven ceiling, gently remove it without applying pressure to the
ceramic plate. Breakage will result in a non-warranty service call.
CAUTION: DO NOT remove the top ceramic jetplate (A); breakage will result
in a non-warranty service call.
Step 7: Clean and Dry the Oven Door
t$MFBOUIFPWFOEPPSXJUI0WFO$MFBOFSBOEBOZMPOTDSVCQBE
t8JQFUIFPWFOEPPSXJUIBEBNQUPXFMBOEUIFOBESZUPXFM
Step 8: Rinse or Wipe the Oven Interior
CAUTION: DO NOT use a hose or water jet for cleaning. Doing so can damage
critical oven components, resulting in a non-warranty service call.
t8JQFEPXOUIFPWFOJOUFSJPSXJUIBDMFBOEBNQUPXFM
t%SZUIFPWFOJOUFSJPSXJUIBDMFBOUPXFM
Step 9: Apply TurboChef® Oven Guard - Optional for Easier Maintenance
t4QSBZ5VSCP$IFG¥0WFO(VBSEPOUPBDMFBOUPXFM
t8JQFUIFJOUFSJPSXBMMTBOEUIFJOTJEFPGUIFPWFOEPPS
CAUTION: DO NOT spray Oven Guard into the cavity, especially around the
holes on the back oven wall. Doing so can damage critical oven components,
resulting in a non-warranty service call.
Step 10: Reinstall Components
t3FDPOOFDUUIFXJSFSBDLUPUIFMPXFSKFUQMBUFBOESFJOTUBMMCPUIJUFNT
t$MPTFUIFPWFOEPPS
t3FJOTUBMMUIFGJMUFSPSSFQMBDFJUXJUIBOFXPOFJGUIFNFTIJTEFUFSJPSBUFEIBT
large openings, or has started to dislodge from the frame.
Step 11: Clean the Oven Exterior
t8JQFUIFPWFOFYUFSJPSXJUIBDMFBOEBNQUPXFM
t3FNPWFUIFMPXFSQBOFMBOESFNPWFMBSHFGPPEQBSUJDMFT
t8JQFUIFQBOFMXJUIBDMFBOEBNQUPXFM
CAUTION: DO NOT spray chemicals into any openings, such as the louvers on
the side panels or the rear vent catalyst housing. Doing so can damage critical
oven components, resulting in a non-warranty service call.
t5IFPWFOJTSFBEZUPUVSOPO
Upper
jetplate
Step 6 (Fig B)
Step 7
Step 8
Step 9
Step 10
Step 11
Step 6 (Fig A)

OVEN CONTROLS AND COOKING
7
Oven Controls
1. On/Off Key
Press to turn the oven on (begin warmup) or off
(cool down), or to exit Info Mode (page 11).
2. Info Key
When the oven is off or cooling down, press to
access the Info Mode (page 11).
3. Up and Down Keys
When the oven is ready to cook (i.e., warmed up
and waiting for a cook command), press the Up or
Down key to view additional food groups or items.
When the oven is in the Info Mode (page 11),
press to navigate between screens 1 and 2.
When editing a food item, press to navigate
between editable fields (Figure 26, page 18).
4. Display
The display shows information relevant to the
current oven operation and/or user options.
5. Back/Stop Key
When the oven is cooking, press the Back/Stop key
to immediately terminate a cook cycle.
When the oven is ready to cook (i.e., warmed up
and waiting for a cook command), or in the Info
Mode (page 11), press the Back/Stop key to return
to the previous screen.
6. Enter Key
Press the Enter key when saving changes to food
item settings (Figure 26, page 18), or whenever
instructed by the oven screen.
7. Soft Keys
There are eight soft keys - four to the left and right
of the display. Press a soft key to select an option
adjacent to that key on the display.
NOTE: Soft keys are labeled L1-L4 and R1-R4 in
this manual (where applicable) for easier identifica-
tion and reference.
8. Numeric Keypad
Use the numeric keypad to enter access passwords
or modify cook settings (Figure 26, page 18). The
numeric keypad also contains a Back/Stop key and
an Enter key, which are functionally identical to
Items 5 and 6.
8
Figure 4: Oven Controls
77
13
2 5 6
4

8 OVEN CONTROLS AND COOKING
Step 3: Warming Up
During this step, the oven warms to the selected or pre-set
temperature.
Step 2: Select Cook Temperature
The oven stores two different cook temperature settings (see
page 17 for more information). Only items associated with
the selected temperature setting can be cooked without
re-specifying the temperature setting.
To select a temperature, press the adjacent soft key.
NOTE: If both temperature settings are the same, this screen will be bypassed and access to all food items will
be allowed.
Step 1: Turn the Oven On
When the oven is off (Figure 5), the oven temperature has
receded below 150°F (66°C), but the display and keypad
remain on.
Press the On/Off key to turn the oven on.
TURBOCHEF NGO
OVEN OFF
READY TO CLEAN
Figure 5: Oven Off
Cooking
The oven is preprogrammed with recipe settings at the time of manufacture and is ready to operate out of the
box. If these settings are erased, new menu settings must be either loaded via Oven Connect (page 4), smart
card (page 16), or programmed manually (pages 17-18). The oven will not cook unless settings are present.
Note that the steps below are not always sequential. Typically, multiple items are cooked before cooling the
oven (Step 10).
Figure 6: Select Cook Temperature
Figure 7: Warming Up
TEMP 2: 350F
TEMP 1: 500F
SELECT COOK TEMPERATURE
WARMING UP
OVEN CC = 433F
OVEN SP = 500F

OVEN CONTROLS AND COOKING
9
Step 6: Adjusting the Time
The Adjust Time option is turned off by default. If you want the ability to modify the cook time before each
cook cycle, this feature can be turned on from the Set Options screen (see page 12).
1. If the Adjust Time screen appears, change the cook
time (if required) using the number keys.
2. Press the bottom-right soft key to confirm and start
cooking.
Step 5: Ready to Cook
WARNING: Inside of oven and oven door are hot!
1. Place the food into the oven.
2. Select a food group by pressing its adjacent soft key, or press the Up or Down key for additional food groups.
3. Select an item to cook by pressing its adjacent soft key, or press the Up or Down key for additional items.
4. If applicable, select a quantity to cook by pressing its adjacent soft key.
NOTE: Quantities (if applicable) can be renamed (see page 18).
NOTE: See Figure 24, page 17 to determine which menu structure your oven is equipped with.
Step 4: Soaking
Once the oven temperature reaches the set point, the oven will continue to warm for eight minutes to ensure
the cook cavity surfaces absorb enough heat so as to not affect cooking results. This process is called “soaking.”
NOTE: While the oven is soaking, the operator will be able to navigate through the menu, but will not be
allowed to cook until the timer reaches 0:00.
Figure 8: Adjust Time
Step 7: Cooking
NOTE: To immediately terminate a cook cycle, press the
Back/Stop key.
NOTE: If the oven door is opened during a cook cycle,
the cycle will pause until the door is closed and ENTER
is pressed to resume.
Figure 9: Cooking
ADJUST TIME
START COOK
01:28
WARMING
QTY 2
A
LUNCH
1:04

10 OVEN CONTROLS AND COOKING
Step 8: Check/Remove Food from Oven
WARNING: Dish and inside of oven/oven door are hot!
Open the oven door and check/remove food.
Figure 10: Cooking Done
Step 9: Additional Cooking Options
The Additional Cooking Options screen (Figure 11) is
turned off by default. If you want the ability to cook a
product beyond the original cook time, you can enable this
feature from the Set Options screen (see page 12).
If the Additional Cooking Options screen appears and the food product requires more cooking:
- Select “cook more” if the inside of the food item is undercooked
- Select “brown more” if the outside of the food item requires more browning or crisping.
- Select “cook and brown more” if both the inside and outside of the food item are not done.
- Select “save adjusted time” to save any change to the cook time made during Step . Note that this option
is not available if “Adjust Time” is disabled (page 12).
- Select “exit” to return to the food group selection screen.
Figure 11: Additional Cooking Options
Step 10: Cooling Down
When finished cooking for the day, press the On/Off key to turn the oven off and begin cooling down.
During this step, the oven blows cool air into the cook cavity to return it to approximately 150°F (66°C), at
which point the oven is safe to clean.
PLEASE CHECK FOOD
WARMING DONE
COOK MORE
ADDITIONAL COOKING OPTIONS
BROWN MORE
COOK AND BROWN MORE
SAVE ADJUSTED TIME EXIT
