turck TX-LTE-WLAN User manual

TX-LTE-WLAN
© Hans Turck GmbH & Co. KG | 100028823 2021-06 DE EN FR
EU Declaration of Conformity
Hiermit erklärt die Hans Turck GmbH & Co. KG, dass der Funkanlagentyp
TX-LTE-WLAN der Richtlinie 2014/53/EU entspricht. Der vollständige Text der
EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar:
www.turck.com
Le soussigné, Hans Turck GmbH & Co. KG, déclare que l‘équipement radioélec-
trique du type TX-LTE-WLAN est conforme à la directive 2014/53/UE. Le texte
complet de la déclaration UE de conformité est disponible à l‘adresse internet
suivante: www.turck.com
Hereby, Hans Turck GmbH & Co. KG declares that the radio equipment type
TX-LTE-WLAN is in compliance with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available at the following internet address:
www.turck.com
Technical Data
Device
Type TX-LTE-WLAN
Ident-No. 100025179
Power supply
The plug-in module is supplied via the backplane bus connector from the HMI
(TX700).
Interfaces
Main Antenna/RX Diversity Antenna
– Impedance 50 Ω
– Frequency 700…960 MHz/1700…2700 MHz
– Gain Max. 4.0 dBi
– Connector SMA plug
Wi-Fi Antenna
– Impedance 50 Ω
– Frequency 2400…2500 MHz
– Gain Max. 2.2 dBi
– Connector RP-SMA plug
Digital inputs 2, optoisolated (industrial standard), source
active high (+ 24 VDC)
– Input voltage range 12…30 VDC, 35 VDC max. for 500 ms
Digital outputs 2, SSR, optical isolation, 2 contacts each
– Max. load voltage 30 VDC
– Max. load current 0.5 A
Connector I/Os DFMC 0,5/ 4-ST-2,54-RF Phoenix Contact
LED indicators 4
SIM slot microSIM
Plug-in extender yes
GNSS function GPS, GLONASS, BeiDou/Compass, Galileo,
QZSS
Wi-Fi IEEE 802.11a/b/g
Environmental conditions
Operating temperature -20…+60 °C
Storage temperature -20…+70 °C
Operating and storage humidity 5…85 % relative humidity, non-condensing
Protection class IP20
Dimensions and weights
W × H × L 20.60 × 23.80 × 90.50 mm
Weight 0.2 kg
Approvals
For installation in industrial environments:
– emission EN 61000-6-4,
– immunity EN 61000-6-2
UL cULus (UL File No. E484727)
ANSI/UL 508
CAN/CSA C22.2 No. 142
FCC/IC Digital Device Limitations
This device complies with Part 15 of the FCC Rules and Industry Canada
license-exempt RSS -210 standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux condi-
tions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonc
tionnement.
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct
the interference at his own expense.

TX-LTE-WLAN
DE Kurzbetriebsanleitung
TX-LTE-WLAN – Erweiterungsmodul
Zu Ihrer Sicherheit
Bestimmungsgemäße Verwendung
Das Erweiterungsmodul TX-LTE-WLAN ist ein drahtloses Modem-Plug-in für die
HMIs der TX700-Serie und ermöglicht dem TX7…, mit Maschinen und Systemen
über das Internet zu kommunizieren. Das Gerät darf nur wie in dieser Anleitung
beschrieben verwendet werden.
Jede andere Verwendung gilt als nicht bestimmungsgemäß. Für daraus resultie-
rende Schäden übernimmt Turck keine Haftung.
Allgemeine Sicherheitshinweise
■Nur fachlich geschultes Personal darf das Gerät montieren, installieren, betrei-
ben, parametrieren, programmieren und instand halten.
■Das Gerät erfüllt ausschließlich die EMV-Anforderungen für den industriellen
Bereich und ist nicht zum Einsatz in Wohngebieten geeignet.
■Das Gerät nur in Übereinstimmung mit den geltenden nationalen und inter-
nationalen Bestimmungen, Normen und Gesetzen einsetzen.
■Das Gerät nur in Bereichen betreiben, in denen der Betrieb von Funkanlagen
erlaubt ist.
■Ein längerer Aufenthalt im Strahlungsbereich der WLAN-Antenne kann ge-
sundheitsschädlich sein. Strahlungsgrenzwerte und Mindestabstände bei der
Auswahl des Montageorts der Antenne einhalten.
■Die Strahlung der WLAN-Antenne kann medizinische Hilfsmittel beeinflus-
sen. Erhöhten Abstand zu aktiven Strahlungsquellen bis hin zur maximalen
Sendereichweite einhalten.
■Bei der Installation der Antenne im Freien: Blitzschutz z. B. gemäß EN62305
beachten.
■Das Gerät bei Arbeiten an der Antenne ausschalten.
Produktbeschreibung
Geräteübersicht
Siehe Abb. 1
Funktionen und Betriebsarten
TX-LTE-WLAN ist ein 4G-Funkmodem für LTE-Cat.4-Mobilfunknetze. Das Erweite-
rungsmodul verfügt über vier LED-Anzeigen für den Modul- und Netzwerksta-
tus und einen microSIM-Steckplatz. Darüber hinaus stellt das TX-LTE-WLAN zwei
digitale Eingänge und zwei digitale Ausgänge zur Verfügung.
Anschlüsse und Steckplätze
Siehe Abb. 1
Anschluss/Steckplatz Funktion
1 LTE-Hauptantenne
2 GNSS-Antenne
3 LTE-RX-Diversity-Antenne
4 Wi-Fi-Antenne
5 Erweiterungssteckplatz für Plug-in-Module
6 SIM-Karten-Steckplatz
7 LED-Anzeigen 1…4
8 I/O-Kanäle
HINWEIS
Die Antennen gehören nicht zum Lieferumfang. Geeignete Antennen finden
Sie als Zubehör im Internet unter www.turck.com.
Die I/O-Kanäle sind SELV (Safety Extra Low Voltage) gemäß den europäischen
Normen.
Montieren
WARNUNG
Beeinflussung des Blitzschutzzonenkonzepts
Personen - und Sachschäden durch Blitzeinschlag
➤Bei der Installation der Antenne im Freien: Blitzschutzmaßnahmen z. B.
gemäß EN62305 einhalten.
➤Blitzschutzzonenkonzept durch die Antenne und ihre Zuleitung nicht
aufheben.
➤ Schutzabdeckung vor der Installation entfernen.
➤ Modul gemäß Abb. 2 montieren.
➤ Antenne anschließen (siehe Abb. 1).
ACHTUNG
Kurzschlussgefahr
Zerstörung der Elektronik!
➤Gerät nicht unter Spannung montieren oder demontieren.
WARNUNG
Einflüsse von Funksignalen auf den Körper
Personenschäden durch Funksignale!
➤Mindestabstand von 20 cm zu Personen beachten.
Anschließen
Siehe Abb. 3
➤ Geeignete Antenne direkt oder über eine Antennenleitung anschließen.
➤ Maximale Länge der Antennenleitung (3 m) beachten.
➤ Antenne nicht erden.
GEFAHR
Beeinflussung elektrisch gesteuerter medizinischer Hilfsmittel wie
Herzschrittmacher
Lebensgefahr durch Störung oder Ausfall medizinischer Hilfsmittel
➤Erhöhten Abstand zu aktiven Strahlungsquellen bis hin zur maximalen
Sendereichweite der Strahlungsquelle einhalten.
Spannungsversorgung
Die Versorgung des Gerätes erfolgt über die Steckverbindung zum TX700.
Digitale Sensoren und Aktuatoren
➤ Sensoren und Aktuatoren gemäß der folgenden Anschlussbelegung mit Hilfe
des mitgelieferten Steckverbinders anschließen.
Pin Signal Pin Signal
1 OUT 1A 5 IN 1+
2 OUT 1B 6 IN 1-
3 OUT 2A 7 IN 2+
4 OUT 2B 8 IN 2-
Betreiben
LED-Beschreibung
Siehe Abb. 4
LED Beschreibung
1 konfigurierbar
2 konfigurierbar
3 Modem-Status AN/AUS
4 Netlight (Netzwerk-Status-LED)
Instand halten
➤ Geräte in regelmäßigen Abständen mit einem feuchten Tuch reinigen.
Reparieren
Das Gerät ist nicht zur Reparatur durch den Benutzer vorgesehen. Sollte das
Gerät defekt sein, nehmen Sie es außer Betrieb. Bei Rücksendung an Turck
beachten Sie bitte unsere Rücknahmebedingungen.
Entsorgen
Das Gerät muss fachgerecht entsorgt werden und gehört nicht in den
normalen Hausmüll.
Hans Turck GmbH & Co. KG | Witzlebenstraße 7 | 45472 Mülheim an der Ruhr | Germany | Tel. +49 208 4952-0 | Fax +49 208 4952-264 | more@turck.com | www.turck.com

EN Quick Start Guide
TX-LTE-WLAN – Extension module
For your safety
Intended use
The extension module TX-LTE-WLAN is a wireless modem plug in for the HMIs
of the TX700 series and enables the TX7… to communicate with machines and
systems via the internet. The device may only be used as described in these
instructions.
Any other use is not in accordance with the intended use. Turck accepts no li-
ability for any resulting damage.
General safety instructions
■The device may only be assembled, installed, operated, parameterized and
maintained by professionally-trained personnel.
■The device only meets the EMC requirements for industrial areas and is not
suitable for use in residential areas.
■The device may only be used in accordance with applicable national and
international regulations, standards and laws.
■Only operate the devices in areas where the operation of wireless equipment
is allowed.
■Any extended stay within the area the WLAN antenna may be harmful to
health. Maintain radiation limits and minimum distances when selecting the
installation location for the antenna.
■The radiation WLAN antenna may impair the operation of medical equip-
ment. Maintain an additional distance from active radiation sources up to the
maximum transmission distance.
■When installing the antenna outside: Observe lightning protection e.g. ac-
cording to EN 62305.
■Switch off the device when working on the antenna.
Product description
Device overview
See fig. 1
Functions and operating modes
TX-LTE-WLAN is a is a 4G radio modem for LTE Cat.4 mobile networks. The
extension module provides four LED indicators for module and network status
and a microSIM slot. In addition, the TX-LTE-WLAN provides two digital inputs
and two digital outputs.
Connectors and slots
See fig. 1
Connector/slot Function
1 LTE main antenna
2 GNSS antenna
3 LTE RX diversity antenna
4 Wi-Fi antenna
5 Expansion slot for plug-in modules
6 SIM card slot
7 LED displays 1…4
8 I/O channels
NOTE
The antennas are not included in the scope of delivery. Suitable antennas can
be found as accessories on the Internet at www.turck.com.
The I/O channels are SELV (Safety Extra Low Voltage) according to European
standards.
Installing
WARNING
Influences on lightning protection zone concept
Personal injury and material damage due to lightning strikes
➤When installing the antenna outside: Observe lightning protection e.g.
according to EN 62305.
➤Do not override lightning protection zone concept by the antenna and its
feed line.
➤ Remove the protective cover before installation.
➤ Mount the module according to fig. 2.
➤ Connect the supplied antenna (see Fig. 1).
ATTENTION
Risk of short circuits
Destruction of electronics!
➤Do not connect or disconnect the device when energized.
WARNING
Influences of radio signals on the body
Personal injury due to radio signals
➤Keep a minimum distance of 20 cm to persons.
Connecting
See fig. 3
➤ Connect a suitable antenna directly or via an antenna line.
➤ Observe the maximum length of the antenna cable (3 m).
➤ Do not ground the antenna.
DANGER
Effect on electrically controlled medical devices such as pacemakers
Danger to life due to malfunction or failure of medical equipment
➤Maintain an additional distance from active radiation sources up to the
maximum transmission distance.
Power supply
The device is supplied via the plug in connection at the TX700.
Digital sensors and actuators
➤ Connect sensors and actuators according to the following pin assignment
using the supplied plug connector.
Pin Signal Pin Signal
1 OUT 1A 5 IN 1+
2 OUT 1B 6 IN 1-
3 OUT 2A 7 IN 2+
4 OUT 2B 8 IN 2-
Operating
LED description
See fig. 4
LED Description
1 Configurable
2 Configurable
3 Modem status ON/OFF
4 Netlight (network status LED)
Maintenance
➤ The devices must be cleaned at regular intervals with a damp cloth.
Repair
The device must not be repaired by the user. The device must be decommis-
sioned if it is faulty. Refer to our return acceptance conditions when returning
the device to Turck.
Disposal
The device must be disposed of correctly and must not be included in
normal household garbage.
TX-LTE-WLAN
© Hans Turck GmbH & Co. KG | 100028823 2021-06 DE EN FR

FR Mode d’emploi simplifié
TX-LTE-WLAN – Mdule d'extension
Pour votre sécurité
Utilisation conforme
Le module d'extension TX-LTE-WLAN et un modem sans fil pour la série TX700
qui permet au TX7... de communiquer avec des machines et des systèmes via
Internet. L'appareil doit être utilisé conformément aux indications du manuel.
Toute autre utilisation est considérée comme non conforme. La société Turck
décline toute responsabilité en cas de dommages causés par une utilisation non
conforme.
Consignes générales de sécurité
■Seul un personnel qualifié est habilité à monter, installer, utiliser, paramétrer,
programmer et entretenir l’appareil.
■Les appareils répondent exclusivement aux exigences de la directive CEM
pour le secteur industriel et ne sont pas destinés à être mis en œuvre dans les
zones d’habitation.
■L’appareil doit uniquement être utilisé conformément aux dispositions,
normes et lois nationales et internationales en vigueur.
■L'appareil doit uniquement être utilisé dans les zones où l'utilisation d'appa-
reils radio est autorisée.
■Une exposition prolongée dans la zone de rayonnement de l'antenne UMTS
peut avoir des conséquences néfastes sur la santé. Il est impératif de respec-
ter les limites de rayonnement et les distances minimales lors de la sélection
du lieu de montage de l'antenne.
■Le rayonnement de l'antenne UMTS peut avoir un impact sur certains dispo-
sitifs médicaux. Maintenir une distance supérieure par rapport aux sources de
rayonnement actives jusqu'à la portée d'émission maximale.
■Lors de l'installation de l'antenne en extérieur: respecter les dispositions de
protection contre la foudre, par exemple selon la norme EN62305.
■Éteindre l'appareil lorsque vous travaillez sur l'antenne.
Description du produit
Aperçu de l’appareil
Voir fig. 1
Fonctions et modes de fonctionnement
TX-LTE-WLAN est un modem radio 4G pour les réseaux mobiles LTE Cat.4. Le
module d'extension dispose de quatrevoyants LED indiquant l'état du module
et du réseau, ainsi que d'un emplacement microSIM. De plus, le TX-LTE-WLAN
dispose de deux entrées et deux sorties numériques.
Connecteurs et emplacements
Voir fig. 1
Connecteur/emplacement Fonction
1 Antenne principale LTE
2 Antenne GNSS
3 Antenne LTE Rx Diversity
4Antenne Wi-Fi
5 Emplacement pour modules plug-in
6 Emplacement SIM
7 Affichages LED 1…4
8 Canaux d'entrée/sortie
NOTE
Les antennes ne sont pas incluses dans l'étendue de la livraison. Vous trouverez
des antennes appropriées sous forme d'accessoires sur Internet à l'adresse
www.turck.com.
Les canaux d'entrée/sortie sont de type SELV (Safety Extra - Low Voltage),
conformément aux normes européennes.
Montage
AVERTISSEMENT
Influence du concept de zones de protection contre la foudre
Dommages corporels et matériels causés par la foudre
➤Lors de l'installation de l'antenne en extérieur: respecter les mesures de
protection contre la foudre, par exemple selon la norme EN62305.
➤Ne pas supprimer le concept de zones de protection contre la foudre via
l'antenne et sa ligne d'alimentation.
➤ Retirer le couvercle de protection avant l'installation.
➤ Monter le module comme indiqué sur la figure 2.
➤ Connecter l'antenne (voir fig. 1).
ATTENTION
Risque de court-circuits
Destruction de l'électronique!
➤Ne pas monter ni démonter l'appareil sous tension.
AVERTISSEMENT
Influences des signaux radio sur le corps
Dommages corporels causés par les signaux radio!
➤Respecter une distance minimale de 20 cm par rapport aux personnes.
Raccordement
Voir fig. 3
➤ Connecter l'antenne appropriée directement ou via une ligne d'antenne.
➤ Respecter la longueur maximale du câble d'antenne (3 m).
➤ Ne pas mettre l'antenne à la terre.
DANGER
Impact potentiel sur les dispositifs médicaux électriques tels que les stimula-
teurs cardiaques
Risque mortel en cas de perturbation ou de panne des dispositifs médicaux
➤Maintenir une distance supérieure par rapport aux sources actives de
rayonnement jusqu'à la portée d'émission maximale de la source de
rayonnement.
Alimentation
L'alimentation de l'appareil est fournie par le connecteur du TX700.
Capteurs et actionneurs numériques
➤ Brancher les capteurs et les actionneurs selon l'affectation des broches sui-
vante en utilisant le connecteur fourni.
Pin Signal Pin Signal
1 OUT 1A 5 IN 1+
2 OUT 1B 6 IN 1-
3 OUT 2A 7 IN 2+
4 OUT 2B 8 IN 2-
Opération
Description des LED
Voir fig. 4
LED Description
1 Configurable
2 Configurable
3 État du modem activé/désactivé
4 Netlight (voyant LED d'état du réseau)
Maintenance
➤ Nettoyer l'appareil à intervalles réguliers avec un chiffon humide.
Réparation
L’appareil ne peut pas être réparé par l’utilisateur. En cas de dysfonctionnement,
mettez l’appareil hors tension. Veuillez tenir compte de nos conditions de
reprise lorsque vous souhaitez renvoyer l’appareil à Turck.
Mise au rebut
Les appareils doivent être mis au rebut convenablement et ne doivent
pas être jetés dans les poubelles traditionnelles.
TX-LTE-WLAN
Hans Turck GmbH & Co. KG | Witzlebenstraße 7 | 45472 Mülheim an der Ruhr | Germany | Tel. +49 208 4952-0 | Fax +49 208 4952-264 | more@turck.com | www.turck.com
This manual suits for next models
1
Table of contents
Languages:
