Turn Key TK-12-5L User manual

Thermo Pot
INSTRUCTION MANUAL
Model Nos.
TK-12-5L & TK-13-35L
Before operating this appliance, please read these
instructions carefully.

CONTENTS
Title
Page
Parts Introduction
1
Technical Specifications
2
Before Using
2 - 3
How To Operate Thermo Pot
4 - 8
Cleaning and Maintenance
8 - 11
Important Guidelines
12
Disposal/Food Safety
Compliance
13
Guarantee 14
EU Declaration of Conformity 15
Returns Policy 16
Troubleshooting Guide 17
Thank you for choosing a Turnkey appliance. We hope you have
an enjoyable experience using this product.
操作面板
1
Parts Introduction
Function panel

Model
TK-12-5L & TK-13-35L
Voltage
230V~50Hz
Power
680W Boil;
2W &100W Keep Warm.
Capacity
5 L & 3.5L
Specifications are subject to change without prior notice due
to the development of technology.
1. Please read these instructions carefully before using the Thermo
Pot for the first time, and keep them for future reference.
2. This appliance should only be used to boil and dispense
water. It is not intended for use with any other liquids.
3. Check your local mains voltage to ensure it is the same as stated
on the appliance.
4. Handle the power cord carefully. Do not bend or pull the cord.
Unplug the appliance from the wall socket when it is not in use.
5. Always use the Thermo Pot in a vertical upright position, and
never cover the steam vent.
6. Allow the Thermo Pot to cool before cleaning.
7. The Thermo Pot may be damaged if exposed to heat or used in
unstable surroundings (excess water or humidity).
8. Boiling without water in the Thermo Pot will damage the appliance.
9. The outer body of the Thermo Pot becomes warm during
operation. Always allow the unit to cool before handling.
10. Do not wash the power cord or immerse the Thermo Pot in any
water or liquid.
11. Close supervision is necessary when the Thermo Pot is used by
or near to children. Never leave the appliance unattended
when children are nearby.
12. Do not operate the appliance with a damaged cord or plug.
13. Do not attempt to repair the Thermo Pot. Always return it to the
supplier in the event of a fault.
14. The Thermo Pot must NOT be modified in any way.
2
15. The appliance is not intended for outdoor use or in damp
areas.
16. The power cord should not be knotted, left on hot surfaces or left
hanging over worktop edges etc.
17. The Thermo Pot should be given ample air circulation on all sides.
18. The Thermo Pot should be placed on a level heat resistant
surface.
19. Do not use the appliance for other than its intended use.
20. When opening the lid beware of steam which is released.
21. Place Steam vent of lid away from the power switch and furniture.
22. Do not place flammable material near the Thermo Pot.
23. There may be an odour emitted during the first use. This is normal
and will stop after a short period of usage. Fill and boil the
Thermo Pot twice and pump the water through the auto-dispense
option both times to ensure the system is clean before first use.
When the water level is too low to allow the auto-dispense
function to work, tip the remaining water from the second boil
away manually before filling with fresh water to commence normal
use.
24. Be careful if moving the Thermo Pot when it is filled with hot water.
Make full use of the handle when moving the Thermo Pot when it
contains any hot water.
25. Do NOT fill the Thermo Pot above the “Full”water indicator scale
(on the inside of the boiler) as this may cause it to overflow when
it boils.
26. Always ensure that the Thermo Pot lid is closed properly.
27. To get the optimum benefit from your Thermo Pot DO NOT turn it
off at night. When in regular domestic use the appliance can be
left on at all times to ensure that you always have instant hot
water when you need it.
28. The unit must be unplugged to be re-filled (as per the instructions)
but apart from that it does not need to be turned off.
29. When not being used for an extended period then the unit should
be switched off, emptied totally until no water runs out of the
dispensing outlet, and then left open to air (see instructions).
30. If the unit is not used for 72 hours it will automatically turn itself off
(see instructions).
31. It is recommended that the original packaging is retained so
that the Thermo Pot can be adequately protected if further
transportation (or return) is required. Damage arising from
inadequate protection during any such further movement is
NOT covered by the guarantee.
3
Technical Specifications
Before Using

OPENING THE TOP LID
Push down front edge of TOP COVER LOCK FLAP located on the lid.
Lift up back portion by pulling upwards to open the top cover.
Beware as water may still be hot and hot steam may escape.
REMOVE LID (when required)
Lift top lid to about a 45º angle, press the UNLOCK button located at
the rear of the top cover and pull upwards at 45º.
FILLING
1. Open the Top Cover as per the above instruction (no need to
remove it), and using another container (such as a jug) pour cold
water into the inner pot until the FULL mark is reached (on the
inside of the boiler). Do not overfill as hot water may splash out
during boiling. As with a kettle this appliance should never be
filled directly from the tap when it is connected to the mains
supply. The power input socket on the Thermo Pot must NEVER
come into contact with any water or other liquid.
2. Close the top cover and ensure that the lid is secured by
pressing firmly down until a “click”sound is heard.
3. When filling the Thermo Pot always keep the lid away from you as
there is hot steam trapped under the lid.
4. The Thermo Pot has a 360º rotating base to assist with ease of
access.
4
TO BOIL WATER
1. After the power is switched on, the water will start to boil
automatically.
Do not open the top cover when the water is boiling.
Do not add water when appliance is still boiling.
Do not obstruct the top lid steam vent.
4
KEEP WARM
A beeper will sound 5 times when the water is boiled. The keep
warm LED will then be lit and the water will keep warm at the
chosen temperature.
USING THE KEEP WARM TEMP SETTING
Press the “SELECT”button to select your ideal temperature. The
default setting is 98º
Press “SELECT”button once to change
Temperature.
98º℃85º℃60º℃50º℃40º℃
5
How To Operate The Thermo Pot
Boiling LED
is lit
LCD indicates
water temperature
progress
Keep warm
temperature selection
Keep warm LED lit
LCD
indicates
water
temperature
Keep warm
temperature
selection

When the keep warm settings are set
at 98º; 85º; 60º; 50º; 40º;℃the keep warm LED with be lit after
boiling. When the water temperature drops below the selected
settings by more than 3º, the water will be reheated to the desired
temperature automatically.
The temperature can be reset at any time during keep warm
phase.
After the Thermo Pot has been disconnected from the mains it is
important to check that your chosen temperature setting has been
re-selected when it is reconnected to the power supply. The
Thermo Pot will default to the 98º setting.
AUTO CUT-OFF
In the event that the Thermo Pot runs dry, the auto CUT-OFF function
will be activated. The power source will be CUT-OFF and at the same
time, the beeper will sound and a sign will be displayed on the
LCD panel. The “REFILL LED”will be lit.
Causes of AUTO CUT-OFF
The power is on, but the Thermo Pot is not filled.
Water level is below “add water”indicator but water is still boiling.
If no water is added when the water is used up.
The top cover is not secured properly.
Solution
Switch off the power supply, allow the unit to cool, add water, and
then turn on appliance again.
Care should be taken to ensure that the Thermo Pot does not run
dry as this can damage the appliance.
The Thermo Pot is designed to remain switched on at all times during
normal domestic use.
If the Thermo Pot is not used for 72 hours it will automatically turn
itself off and the following flashing symbol will appear in the green
LCD display.
6
To use the appliance again touch any key. It is however essential
that if the water has been standing for this length of time, it is
discarded completely and the Thermo Pot filled with fresh water,
and flushed through before normal use is resumed.
If the Thermo Pot is not being used for an extended period of time (in
excess of 72 hours) then it is recommended that the appliance is
disconnected from the mains, emptied and left open to air in the
upright position. Ensure that water is cleared from all outlets by
gently inverting the appliance until there is no water flowing from the
spout. When it is used again it should be filled and boiled once
flushing the water through to rinse the pipes. Empty the residual
water at the bottom of the boiler when the auto-dispensing is finished,
rinse the internal pot to remove any loose lime scale, and commence
normal use.
RE-BOIL FUNCTION
Additional water can be added to the Thermo Pot to top it up at
anytime (though NOT when the boil function is active) and this will
trigger the automatic boil function to operate. If however the
added water is not sufficient to start the automatic boiling function
then it may be necessary to press the RE-BOIL button.
1. Press “RE-BOIL”button once. The re-boiling indicator light will
light up.
2. After RE-BOIL is completed, the KEEP WARM indicator light will
be lit.
Re-boil will not function if there is insufficient water in the
appliance..
Pressing the RE-BOIL button immediately after the water has just
reached boiling point will have no effect as the water is already at
100℃. The temperature needs to cool to 94º before the RE-BOIL
button can be pushed to achieve a rolling boil again. If a rolling
boil is needed again when the temperature is between 95º –
98º this can be achieved by moving the temperature selector
down through the temperature settings and re-selecting 98º.
DISPENSING WATER
1. AUTO DISPENSE WATER OUTLET
a) Press the “UNLOCK”key ONCE. The “UNLOCK”indicator light will
come on.
b) Push the “AUTO DISPENSE”button to dispense hot water.
7

2. CUP WATER OUTLET
a) Press the “UNLOCK”key ONCE. The “UNLOCK”indicator light will
come on.
b) Use cup touch dispenser water outlet by placing cup under the
outlet and raise the cup slightly upwards.
If the dispense button or cup switch dispense button is not
selected within 10 seconds after selecting the UNLOCK key, the
appliance will automatically revert back to the LOCK position.
Do not press the dispensing button when the inner water reservoir
is empty. (Doing so can cause damage.)
The “Auto” and “Cup Water Outlet” dispensing functions will NOT
operate if the electric Thermo Pot is not connected to the mains
supply. (Use Air Pump dispensing as No. 3 below)
3. MANUAL AIR PUMP WATER OUTLET (can be used without
power connection)
Put the cup under the water outlet. Depress the centre section of
the lid manually ensuring that the “unlock” position has been
selected. Ensure that the manual air pump is locked again after use.
Before cleaning the appliance, always ensure that the power cord is
disconnected from the mains supply, and that residue water is poured
out and the device is cooled.
It is recommended that the water is emptied every few days and any
loose lime scale rinsed out before re-filling the Thermo Pot with fresh
water. Always disconnect the Thermo Pot from the mains before
emptying it manually.
Inner pot & Inner cover
Clean the device with a soft sponge and wash it with water.
Lime scale should be remove every month as a minimum. It may be
necessary to do this more frequently according to the hardness of the
water in your area. Citric acid is required (see instructions below). An
80g supply of citric acid is provided with the appliance. Further
supplies are easily obtained via amazon.co.uk.
Do not scrub the inner lining with any metal objects, nylon brush,
scourer, toothbrush etc., or the inner pot lining may peel off.
Clean the INNER POT with a soft damp cloth only.
Never use any chemical or abrasive solution or cleaning materials
to clean your electric water boiler.
The exterior surfaces of the water boiler should also be cleaned
with a soft damp cloth. No chemicals are needed.
Do not immerse the unit in water or allow the operating panel to
become wet.
Do not place the unit upside down to dry it. Leave it in an upright
position.
Cleaning with citric acid.
Fill the Thermo Pot with water to the full level.
Add 15g approx (three heaped teaspoons) of citric acid (in
very hard water areas this may need to be increased to an
amount that is found to be effective).
Close the lid and connect to the power supply.
Press the “Cleaning Button” and hold for 3 seconds (approx)
to start cleaning function.
The water will then heat to 100º.
The water will then keep warm at 98 –99 degrees, and the
water boiler will count down from 70 minutes.
During the cleaning phase the green LCD will be lit.
9
Cleaning and Maintenance
LED flashes boiling to 100ºC
70 mins.
LCD stops flashing
Ihr 10 Mins later

During the cleaning process no keys/buttons will function.
If you want to stop the cleaning process then press the
“cleaning button” again and hold for 3 seconds.
At the end of the cleaning cycle the Thermo Pots beeps
frequently. Ensure that you are present at the end of the
cleaning process to respond to the bleep alerts.
At the end of the cleaning process it is necessary to
disconnect the Thermo Pot from the mains supply and re-
connect it to the power supply again to enable the
keys/buttons to function again. (If the water has cooled it may
initially re-boil and the LCD will be red during which time the
dispense button will continue to remain inactive. When the
green LCD is lit again normal dispensing can again be
undertaken)
Using the “Auto Dispense” function flush the water through
the unit to clean the pump/dispense outlet. When there is
insufficient water left to use this function, allow to cool,
remove the lid, and tip the remaining water away manually.
Rinse the inner pot with cold water and refill. Replace lid and
boil. Flush through the first half a pint of the new water to
ensure that there is no residue from the citric acid left in the
pump or dispensing outlets.
Wipe Thermo Pot with soft cloth and it is ready for use again.
Failure to keep the Thermo Pot free from excessive lime
scale may result in the stain becoming difficult to remove,
and may damage the unit.
If the Thermo Pot is not clear of lime scale after the first
cleaning cycle it may be necessary to repeat the cleaning
process again before proceeding to the second boil/rinse
instruction above. The unit should be completely clear of
lime scale before normal use is resumed.
DO NOT USE THE FOLLOWING ITEMS TO CLEAN THE
THERMO POT:
Volatile oil or thinner.
Abrasive cleaning powder, nylon brushes etc.
The electric Thermo Pot is NOT dishwasher safe.
STORAGE:
Clean as above and dry the Thermo Pot thoroughly before
prolonged storage as previously described.
10
Quick Clean
Use of the cleaning cycle is recommended as above, but a
quick clean can be used in between the full clean if required.
Fill the Thermo Pot as previously described, and add two
heaped dessertspoons (or amount as required) of citric acid
to the water and boil.
Leave for half an hour at 98º.
Use the auto-dispense to flush through the water to clean the
pump and outlets.
Allow to cool, remove the lid and tip out the residue from the
bottom.
Rinse with cold water and re-fill.
Replace lid and boil again. Dispense half a pint of water to
clear any citric acid from the pump and water outlets.
Use as normal.
It is important to ensure that nobody uses the Thermo
Pot whilst it is being cleaned using this method, as unlike
the full cleaning programme the Thermo Pot will still
dispense water.
11

A short power cord is provided to minimise hazards involving longer
cords. The Thermo Pot should be situated so that the power lead
does not hang over the edge of a counter top etc. and does not touch
any hot surfaces. The power lead and plug must NEVER come into
contact with any water etc.
Do not place the appliance on a metal surface when it is
connected to the mains supply.
Extension cables should NOT be used with the Thermo Pot
The Thermo Pot must NOT be modified in any way.
The Thermo Pot is supplied with a 13 amp plug. If the fuse needs
changing it must be replaced with a 13 amp BS 1362 cartridge fuse.
Do not use the power cable if it becomes damaged. Consult an
electrician or replace the entire cable.
WARNING: THIS APPLIANCE MUST BE EARTHED
WARNING: This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
WARNING: The use of any electrical appliance requires both
common sense and the adherence to the safety guidelines within
this instruction manual, to avoid risk of injury to a person and of
damage to the Thermo Pot.
12
European Directive 2002/96/EC
Correct Disposal of this product
This appliance is marked according to the European
Directive above on Waste Electrical and Electronic
Equipment (WEEE). This symbol indicates that this
appliance may NOT be treated as household waste.
To prevent possible harm to the environment or
human health from uncontrolled waste, disposal must
be carried out in accordance with local environmental
regulations for waste disposal.
By ensuring that this appliance is disposed of
correctly, you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this item.
.
The Turnkey Thermo Pots comply with Regulation (EC) no.
1935/2004 on materials and articles intended to come onto
contact with food.
13
Important Guidelines

Guarantee
This Electric Thermo Pot is covered by a one year guarantee from
the date of purchase, which covers manufacturing defects that occur
under normal use only, and where the original purchaser still owns the
appliance. Turnkey Domestic will during the guarantee period replace
or repair the appliance, or part found to be not working properly free
of charge. Beyond the guarantee period repair and carriage charges
will apply. The receipt including date of purchase must be provided in
the event of any claim within the guarantee period. The Thermo Pot
should be returned in the original packaging to avoid damage
during transit. If this is not available then equivalent protection must
be used. This guarantee does not cover damage caused as a result
of inadequate protection during carriage.
Exclusions:
1. Failure to carry out the maintenance as described above with
regard to the cleaning to prevent lime scale build up may
cause damage to the unit which will not be covered by the
guarantee.
2. Where the fault has been caused by misuse, neglect or used
contrary to the manufacturer’s instructions.
3. Where repairs have been attempted by anyone other than the
manufacturer.
4. Where the appliance has been used for hire.
5. The appliance is second hand.
This guarantee does not confer any rights other than those expressly
set out above and does not cover any claims for consequential loss or
damage. This guarantee is offered as an additional benefit and does
not affect your statutory rights as a consumer.
After Sales Service:
If you have any queries regarding this appliance please contact the
Sales Team (during normal office hours).
Email: [e-mail]
Phone: [phone]
Turnkey Domestic Ltd www.turnkeydomestic.co.uk
EC DECLARATION OF CONFORMITY
We the importers certify that the Turnkey Thermo Pots TK-12-5L &
TK-13-35L conform with the protection requirements of Council
Directive 2004/108/EC, relating to Electromagnetic Compatibility, and
Council Directive 2006/95/EC, relating to the Low Voltage Directive,
by the application of the following Test Standards:
EN 55014-1:2006+A1:2009+A2:2011
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-3:2008
EN 55014-1: Electromagnetic Compatibility –Requirements for household
appliances, electric tools and similar apparatus –Part 1: Emission
EN 55014-2: Electromagnetic Compatibility –Requirements for household
appliances electric tools and similar apparatus –Part 2: Immunity product
family standard
EN 61000-3-2: Electromagnetic Compatibility (EMC) Part 3-2: Limits for
harmonic current emissions (Equipment input current up to and including 16A
per phase)
EN61000-3-3: Electromagnetic Compatibility (EMC) Part 3-3: Limitations of
voltage supply systems for equipment with rated current ≤ 16A
EN60335-
1:2002+A11:2004+A1:2004+A12:2006+A2:2006+A13:2008+A14:2010+A15:2
011
EN 60335-2-15:2002+A1:2005+A2:2008
EN 62233:2008
Household and Similar Electrical Appliances –Safety
Part 1: General Requirements
Part 2-15: Particular Requirements For Appliances For Heating
Liquids
Measurement Methods For Electromagnetic Fields Of Household
Appliances And Similar Apparatus With Regards To Human Exposure
Registered in England VAT No: 851 486 613 Company Reg: No: 8426307
15

Returns Policy
In the event that you wish to return the Thermo Pot please contact your
supplier directly.
Where the purchase has been made directly from Turnkey Domestic Ltd we
will accept return of the item if the customer changes their mind within 14
days of the customer receiving the Thermo Pot. The customer will in this
instance pay the cost of the return carriage. A refund less the cost of the
original carriage) will be made upon safe receipt of the unused Thermo Pot
which must be returned in all of the original packing.
If the item develops a fault due to a manufacturing defect within the first six
months of the guarantee Turnkey Domestic will pay for the cost of returning
the Thermo Pot to us. The item will then be repaired or replaced at our cost
assuming that the fault is not due to misuse or general “wear and tear”.
If the Thermo Pot is more than six months old then the cost of returning the
item to us will be paid by the customer. The return postage (as above) will
be paid by Turnkey Domestic Ltd.
Returns should be sent to:
Turnkey Domestic Ltd
Access Storage
Unit F
Dolphin Industrial Estate
Windmill Road
Sunbury on Thames
TW16 7HT
In all cases the Thermo Pot must be returned in ALL of the original packing,
or equivalent protection used.
In the event that damage occurs during transit due to inadequate packing
then if the unit is repaired the cost of replacing the damaged casing would
be subject to a charge.
Please fill in the enclosed “Returns Note” and include
with the return.
Troubleshooting
Fault
Possible Cause
Solution
Unit doesn’t work
Not plugged into
power supply
Plug in unit and
switch on power
supply
Any malfunction
Power lead not
inserted into
back of unit
properly
Ensure that power
lead is fully
plugged into the
back of the unit
Doesn’t dispense
water after boiling
or running
cleaning cycle
Air in the pipes
Depress the Auto
Dispense button
several times until
water flows freely
Any other fault
contact supplier
17 v6 15.20.14
