Tuscany TU031 User manual

CLEANING
Always unplug from power outlet before cleaning.
Clean the Power Unit (6) with a soft and slightly damp cloth. Do not wash unit
under running water or submerge in water or any liquids.
All accessories can be washed by hand or in the dishwasher:
- for hand washing, use tepid water with dishwashing liquid, with extra care in
handling the blade as it is very sharp;
- for dishwashing, place accessories on the upper part of the dishwasher and make
sure the water never exceeds maximum temperature of 50℃
Do not use chemical or abrasive substances.
Note: After cleaning, make sure accessories/parts do not have waste/dirt residue
which may prevent the unit from functioning properly.If necessary use a soft brush
to clean residue.
The blades cannot be sharpened. Replace them if they are not cutting
properly or are worn. Contact an authorized service centre to purchase accessories/
parts liable to wear and for maintenance work on your appliance.
STORAGE
Make sure your appliance and all its accessories are completely dry before putting
them away.
Your food processor has a space-saving storage system where all accessories can
be put away in the bowl tidily.
WEEE
The WEEE directive requires that old or defective electrical and electronic
products must disposed off in environmentally sound way. The symbol means
that your product must be collected separately. Please contact your community
for the nearest collection center.
INSTRUCTION MANUAL
TU031

III. Slicing & Shredding Function
- Fix the slicing/shredding knife to the knife support (Diagram 9).
- Put the bowl on the power unit first and then turn the bowl clockwise until it
locks into place. Put the knife support on the axis in the middle of the bowl
(Diagram 10).
- Put the cover on the bowl and turn until it locks into place. Fix the plug to the
electric socket, press the power switch and then choose the right level. Slowly
insert your ingredients down the tube. You can use the measuring cup to help
push down the ingredients (Diagram 12).
-When the operation is finished, cut off the power supply by pressing the
LCD power switch button. After the blade stops completely, pour out the food.
ⅣJuicing Function
1. Put the bowl on the power unit first and then turn it clockwise until it locks to
place. Fix the filtrating plate and juice drill to the bowl (Diagrams 13 & 14).
2. Fix the plug to the electric socket, turn the switch to 1,
3. Cut fruit/s into halves, slowly push down the juice drill (Diagram15).
4. Pour out the juice.
B: Blender jug
-Put stuff into the blender jug and place the jug on the power unit and then turn it
clockwise.
-Make sure that the jug is covered tightly.
GENERAL INSTRUCTIONS
·Please read this handbook as it gives important instructions about safety, use and
maintenance of your appliance and keep it for future reference.
·Make sure the data on the appliance rating plate corresponds to that of the main
power supply and of your electrical system before plugging into the outlet. In
case of doubt, contact professionally qualified personnel.
·It is advisable not to use adaptors, multiple plugs and extensions. Use devices
certified and conforming to existing safety standards, making sure they are
compatible with your electrical system and with the appliance technical data.
·Any installation not conforming to instructions may endanger your safety
and forfeit the guarantee.
·The appliance must be used for the purpose for which it was designed only, i.e.
prepare food for domestic use.
·For safety’s sake be careful:
-not to use the appliance with bare feet or wet hands or feet
-not to leave the appliance exposed to sun or rain
-not to allow children or incapable individuals to use the appliance
-never tug on the lead or appliance itself to unplug from the outlet
-not to leave the appliance plugged into the main power supply unattended
-never submerge the appliance in water any liquids.
·Switch off and do not mishandle the appliance if it should breakdown and/or
work badly. Contact an authorized service centre for eventual repairs, asking
for original spares.
·Put the appliance out of service at the end or its service life by cutting off the
lead after unplugging from the outlet. Abide by local existing rules and
regulations for its disposal.
·Observe a maximum of 40s for continued operation of the appliance, then rest 30
min before restart.

TECHNICAL SPEC：
Voltage：220-240V 50Hz
Power：1000W
Structure:
-Connect the power plug of the machine and switch on the food processor. Turn the
knob to the required level (The speed is increased by levels. PULSE is the highest
level).
-You can add some liquid material (such as oil, cream if any) to the food when
mixing from tube entrance if necessary;
-Please cut off the power supply by pressing LCD power switch button after
working. Pour the mixed food out of the Blender jug.
INGREDIENTS LIST:
-Bowl:
FUNCTION INGREDIENT MAX QUANTITIES
MAXIMUMTIMES(s)
SLICING
SHREDDING
SLICING
MURPHY
500g
40s
40s
MELON
500g
40s
40s
CARROT
500g
40s
40s
CHOPPING
&
WHISKING
MEAT
500g(about 10g/piece)
40s
HAM
400g(about 15g/piece)
40s
ONIONS
500g(about 20g/piece)
40s
EGG
ten yolks
40s
STRAWBERRY
300g
40s
CHEESE
200g
40s
ALMONDS
200g
40s
HAZELNUTS 200g 40s
WALNUTS
200g
40s
-Blender jug:
material
MAX QUANTITIES
MAXIMUM TIMES (s)
apple
300g
40s
orange
300g
40s
grape
300g
40s
strawberry
300g
40s
material volume
：
20X20X20mm3 /pc
，
water
：
450ml.
⑴
Measuring Cup
⑵Blender Jug cover
⑶Blender Jug
⑷Switch Connecter
⑸LCD Power Switch
⑹LCD Display
⑺LCD Control Buttons
⑻Top Cover
⑼Measuring Cup
⑽Bowl Cover
⑾Bowl
⑿
Turn Axis
⒀Sredding Knife
⒁Slicing Knife
⒂Knife Support
⒃Plastic Blade
⒄Whisking Blade
⒅Blade Cover
⒆Protect Cover
⒇Spatula

USING IT FOR THE FIRST TIME
-Read this handbook to familiarize yourself with all the parts of your new food
processor.
-Clean all the parts and accessories before using the appliance for the first time (see
paragraph “Cleaning”).
Take note:
1. Blades should always be handled with care as they are very sharp.
2. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety.
3. Children should be supervised to ensure that they don’t play with the appliance.
4. If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
5. Switch off the appliance before changing or adjusting accessories or parts.
USAGE GUIDE
Your new food processor will help you to prepare a lot of basic mixtures that you
can use for your recipes.
Please abide by the following instructions to achieve the best results and to keep
your appliance in good working condition.
Warning: Never exceed the maximum quantity level and never pour liquids hotter
than 75℃into the bowl and/or blender.
Follow these instructions:
-Never leave the appliance unattended while it is on.
-Never make the appliance work while it is empty.
-Never touch moving parts.
-Never put your fingers inside the lid opening.
-Never use your bare hands to press down ingredients into the lid opening.
-Do not use the appliance for hard ingredients (e.g. frozen meat, ice), rubbery (e.g.
candied peel), or inedible stuff (e.g. bones).
-Do not remove the lid and never replace accessories without switching off the
appliance.
II. Chopping Function
-Put the plastic bowl on power unit and turn the handle clockwise (Diagrams 1
& 2).
- Put the blade support on the axis in the middle of the bowl and press it to the
bottom. Then fix the chopping blade to the blade support (Diagrams 3 & 4).
Warning: The blade is sharp so hold the plastic part while using.
- Put the food in the bowl (Diagram 5). Big chunks of food should be cut into
smaller pieces (approx 2 cm ×2 cm ×2 cm).
- Put the cover on the bowl and turn until it locks to place (Diagram 6 &7).
- Fix the plug to the electric socket then press the LCD power switch button. The
background light goes on.
- There are 8 different speeds in all so you can choose a suitable speed according to
need by pressing the button “+” or “-”.
- After selecting, press the LCD control button (“ON/OFF”). The appliance should
begin to operate (Diagram 8).
- In the process, you can adjust the speed by pressing “+” or “-” buttons. You can
also accelerate the speed by pushing the PULSE button. In addition, you can
suspend the motion of the appliance by pressing the “ON/OFF” button.
- When chopping is finished, cut off the power by pressing the LCD power switch
button. After the blade stops, pour out the food.
II. Whisking Function
Mixing function basically has the same operating steps as the chopping function.
Just change the chopping blade to the shredding blade. It is used for mixing and
whisking of food, e.g. eggs.
