Tuuci BAY MASTER MAX User manual

Assembly Instructions
BAY MASTER MAX

ASSSEMBLY AND OPERATING INSTRUCTIONS BAY MASTER MAX
Global headquarters
2900 NW 35th Street t 305.634.5116 [email protected]
Miami, Fl 33142 USA f 305.634.5119 www.tuuci.com
Note: This operation may require 2 people
1. Remove all packaging from umbrella, Remove Deck Mount from mast and install in desired location.
2. Once deck mount is installed place umbrella in it and tighten star-knob.
Make sure lock spring pin is in base slot which secures umbrella in place (see FIG A).
INSA1010-Rev.A page 1
lock spring pin in-place
FIG A
tighten star knob
deck mount base
deck mount

ASSSEMBLY AND OPERATING INSTRUCTIONS BAY MASTER MAX
Global headquarters
2900 NW 35th Street t 305.634.5116 [email protected]
Miami, Fl 33142 USA f 305.634.5119 www.tuuci.com
3. Gently separate each rib individually from center post, approximately 11 inches.
If rib does not move easily, do not force. Inspect product for additional packaging.
4. Gently slide main hub handle up center pole until clip bracket engages to slot (see FIG C).
5. To close umbrella press down clip bracket (see FIG D) to unlock from slot, then
slide down gently.
6. Close umbrella during wind conditions that exceed manufacturer's specifications.
7. To remove umbrella from base press lock spring pin inward (see FIG E) and turn pole so that the spring
pin recess under base surface, then pull umbrella upward.
separate ribs by
hand approx. 11"
before using hub
handle to lift
rib
rib
clip braket
main hub handle
before closing
push down clip bracket,
while holding down clip bracket
slide handle downward
slot, where clip
braket engages
(see FIG C)
FIG C
FIG D
press lock spring pin inward
and turn pole at same time
FIG E
once spring pin is beneath
base surface, pull umbrella out
INSA1010-Rev.A page 2
