Tuuci MAX TILT CANTILEVER Quick reference guide

INSA2025
1
|tuuci
ASSEMBLY & OPERATING INSTRUCTIONS MAX TILT CANTILEVER
step 4
lock umbrella down by pushing the cam lock handle in the
down position and lock with pin
step 1
remove all packaging from in and around umbrella
step 2
pull pin from cam lock and lift the handle to unlock umbrella
step 3
once you have Installed and leveled the stem using the base
installation instructions, slide the beauty cover and umbrella
over the security stem (security stem is included with umbrella)
umbrella mast
pin
beauty cover
unlock cam lock handle
lock cam lock handle
security stem
step 5
gently separate each rib individually from center hub approx. 10 inches.
if rib does not move easily do not force. inspect product for additional packaging
OPENING UMBRELLA
center hub

INSA2025
2
|tuuci
ASSEMBLY & OPERATING INSTRUCTIONS MAX TILT CANTILEVER
step 6
lift both (2) cart levers to release tension and to unlock canopy frame
unlock cart lever
unlock cart lever
step 7
crank lock must be in the top/unlock position before turning crank handle
step 8
insert crank handle and rotate clockwise to open umbrella canopy,
stop cranking when rotation comes to a stop (do not force cranking)
unlock crank lock
crank handle
OPENING UMBRELLA (cont’d)

INSA2025
3
|tuuci
ASSEMBLY & OPERATING INSTRUCTIONS MAX TILT CANTILEVER
OPENING UMBRELLA (cont’d)
step 9
once umbrella canopy is open hold both (2) wind
stabilizers to adjust tensioned and lock canopy position
wind
stabilizers wind
stabilizers
lower lock
cart lever
lock 2nd
top lock
cart lever
lock 1st
step 11
Once umbrella is fully opened and cart levers locked, crank lock must be in down
position to lock. Remove crank handle and store in a safe place.
step 10
lock umbrella position by locking both(2) cart levers down
top lock must be locked rst followed by the lower cart
crank lock
crank handle

INSA2025
4
|tuuci
ASSEMBLY & OPERATING INSTRUCTIONS MAX TILT CANTILEVER
TILT/ANGLE ADJUSTMENT
unlock
cart lever
unlock
cart lever
step 2
to tilt/angle canopy hold both (2) wind stabilizers and move the lower cart up or down to adjust
step 3
lock tilt/angle position by locking both cart levers down
top lock must be locked rst followed by the lower cart
step 1
must unlock both (2) cart levers before adjusting tilt/angle
lower cart
wind
stabilizers wind
stabilizers
wind stabilizers
lower cart
lower lock
cart lever
lock 2nd
top lock
cart lever
lock 1st

INSA2025
5
|tuuci
ASSEMBLY & OPERATING INSTRUCTIONS MAX TILT CANTILEVER
CLOSING UMBRELLA
step 2
the crank lock must be in the top/unlock position before turning crank handle
step 3
insert crank handle and rotate counterclockwise, until it stops
step 4
use wind stabilizers to lower cart to bottom
step 1
lift both (2) cart levers to release tension and to unlock canopy frame
unlock
cart lever
unlock
cart lever
crank handle
unlock
crank lock

INSA2025
6
|tuuci
ASSEMBLY & OPERATING INSTRUCTIONS MAX TILT CANTILEVER
step 5
collapse umbrella frame
step 6
lock both(2) cart levers down
CLOSING UMBRELLA (cont’d)
step 7
when not in use the canopy should be carefully
folded and secured with the tie-strap
Note:
close umbrella during wind conditions that
exceed manufacturer’s specications
lock
cart lever
lock
cart lever
