Tuuci MAX CENTER POST Quick reference guide

MAX CENTER POST
NAUTICAL TEAK HARDWOOD
EASY DRIVE CRANK
TUUCI
ASSEMBLY & OPERATING INSTRUCTIONS
TO PROTECT YOUR PRODUCT, PLEASE READ THE OPERATING INSTRUCTIONS BEFORE OPENING THE PARASOL
1005205

1005205
2
|tuuci
security stem
beauty cover
NAUTICAL TEAK HARDWOOD
STEP 4
Insert crank handle and unlock crank-lock button by moving to up position.
crank-lock button
crank handle
STEP 3
Once you have leveled the security stem using the base installa-
tion instructions, slide the post beauty cover and umbrella over
the security stem (security stem is included with umbrella).
STEP 5
Gently separate each rib individually from the center hub
approximately 10 inches. If the rib does not move easily,
do not force. Inspect the product for additional packaging.
STEP 1
Remove all packaging from in and around umbrella.
STEP 2
Pull pin from cam lock and lift the handle to unlock.
pin
STEP 6
Open umbrella by turning crank handle clockwise until
top telescopic head makes contact with bottom pole.
top telescopic
bottom pole
STEP 7
Crank lock must be in down position to lock opened umbrella.
push handle
back to lock
lock umbrella
(down position)

1005205
3
|tuuci
NAUTICAL TEAK HARDWOOD
CLOSING UMBRELLA
STEP 2
Close umbrella by turning crank handle counter-clockwise
STEP 1
Crank lock must be in top position to unlock umbrella before closing.
STEP 3
When not in use the canopy must be carefully folded and secured with the tie-strap.
Note:
close umbrella during wind conditions that exceed manufacturer’s specifications
slide lock to the
open position (up)
