TVT Digital TD-3000H1-B1 User manual

Network Video Recorder
Quick Start Guide
1. Notes
● Please read this instruction carefully for correct use of the product and
preserve it for reference purposes.
● All the examples and pictures used here are for reference only.
● There may be several technically incorrect places or printing errors in
this manual. The updates will be added into the new version of this manual.
The contents of this manual are subject to change without notice.
● This device should be operated only from the type of power source indicated
on the marking label. The voltage of the power must be verified before using
the same.
3. HDD Installation
The interfaces of the rear panel are for reference only.
4. Rear Panel Instruction
This series of the product supports 1 SATA hard drive. Please make sure that the
device is powered off before the installation. The pictures of the installation are only
for reference, please take the real object as the standard.
① Loosen the screws to open the cover.
② Put the HDD on the bottom of the device.
③ Turn over the machine and secure the HDD with the screws.
④ Connect the power and data cables.
Tips: Please check the inside structure of the device and make sure the cables
connected well before installing the cover back. Please format the HDD before
using.
⑤ Install back the cover and secure it with the screws.
2. Packing Check
Please check the device and the accessories after getting the device. If there
are any damages, shortages or defects, please contact your dealer immediately.
Connect to high definition display device
Connect to monitor
Network port
Connect to USB storage device or USB mouse
Power input
Name Description
VGA
HDMI
LAN
USB
DC12V
Rear Panel for 4/8CH
5 Startup & Shutdown.
►Startup
① Connect the monitor and the power.
② The device will boot. Please wait for a while.
③ A wizard window will pop up.
►Shutdown
Click “Start” and then select “Shutdown” icon. This will bring up a shutdown
window. The device will shut down after entering the username and password.
Then follow the direction to disconnect the power.
6. System Login
You must configure the wizard if you start the NVR for the first time. Choose
the language and read the privacy statement. Then set the data, time and zone
as needed. After that, set the login password.
The default username is admin. Set your own password when you use the
wizard for the first time. Enable pattern lock and click “Edit” to set the pattern
lock. Then set security questions and answers. It is important for you to
remember these answers, or you will not be able to reset your password. Click
“Next” to continue.
Username
Admin Password Setup
New Password
Confirm Password
Pattern Lock
admin
Wizard
xxxxxx
xxxxxx
Display Password
Enable
Log In Automatically
NextPrevious
Edit
7. Disk Settings
You can view the disk number, disk capacity of the NVR and serial number,
Read/Write status of the disk. Click “Format” to format the disk. Click
“Next” to continue.
8. Network Configuration & Add IP Camera
① Enter IP address, subnet mask, gateway, etc. If using DHCP, please enable
DHCP in both the NVR and the router.
② Enter HTTP port (the default value is 80) and server port (the default port is
6036).
Add Camera. ③ Click “Next” to go to the following interface.
Wizard
Obtain an IP address automatically
Address 192 . 168 . 1 . 2
. . . 255 255 255 0
192 . 168 . 1 . 1
Subnet Mask
Gateway
Ethernet Port 1 ( Online )
Obtain DNS automatically
HTTP Port HTTPS Port
Sever Port
. . .
. . .
Preferred DNS
Alternate DNS
Next
Previous Cancel
80 443
6036
Network Settings
Port
Next
Previous Cancel
3.4.2
3.4.2
4.0.0.1.beta1
Version Add
+_
_
_
+
+
80
80
80
No. Address Edit Port Protocol Model
1
2
3
192.168.1.20
192.168.1.38
192.168.2.45
XXX
XXX
XXX
XXX
XXX
XXX
Wizard
Network Settings Add Camera
Delete
No. Address
IP Camera Name EditProtocol Status
1 192.168.1.20
IPC Online
Add All
Refresh
Remain Bandwidth: 64 / 64 Mb Delete All
XXX
Inte rne t

12. Manual Recording
11. Cloud Upgrade
9. Record Settings
10. NAT
13. Playback
④lick to edit an IP camera as shown on the above left. Enter the new IP
address, subnet mask, gateway, username and password of the camera. Click
“OK” to save the settings.
Click to edit the added camera as shown on the above right. Enter the new
camera name, IP address, port, username and the password of the camera.
You can click “Test” to test the effectiveness of the input information. Click
“OK” to save the settings. You can change the IP camera name only when the
added camera is online. Click “Next” to continue.
C
►Web Browser Access Through NAT Function
① o
NAT Server Address. Click “Apply” to save the parameters.
G to Start → Settings → Network → NAT tab. Enable NAT and select the
NAT2.0(d2020.autonat.com:7968)
Enable
Access Type
Apply
enter to go to the following interface. If you are the first time to access the
NAT, you shall download and install the plug-in according to the popup
tips. After that, re-open your web browser and enter the above-mentioned
address. Then the login box will appear. Enter the device serial number,
username and password.
Enter www.autonat.com in the address bar of your browser and then press
Before recording, please install a HDD. In the live interface you can see
the menu toolbar. Click button to start recording. Click it again to
stop recording. You can also click to check the status of the recording.
►
Click “Instant Playback” in the right-click menu of the camera’s preview
window to select or drag the playback progress bar to change the playback
time to play back the record.
Instant playback
Click on the tool bar at the bottom of the live view interface or click Start
→ Playback to go to the playback interface as shown below. You can also add
the playback cameras manually. Click in the playback window to pop up the
“Add Camera” window. Check the cameras in the window and then click “Add”
to add playback camera. The record files of the added playback camera will be
played in the playback interface.
►General playback
NAT
Device Serial Number
interface and then click next to the admin icon to view the serial number.
Username: The username of the NVR. The default username is admin.
Password: The password of the NVR. The password is set by yourself when
you configure the wizard for the first time.
: Click on the menu bar at the bottom of the live
Enter Password
Enter Username
Enter device serial number
Login
Camera Name
IP v4
Model
Edit Camera
XXX
192 168 1 . 58 . .
9008
admin
XXX
Port
Username
Protocol
Password
IP Camera 1
OKTest Cancel
Sync to IPC
Mac Address
Address
Edit IP
192 168 1 . 45 . .
255 255 255 . 0 . .
admin
192 168 1 . 1 . .
Subnet Mask
Username
Gateway
Password
OK Cancel
CE :98 :23 :75 :35 : 22
NAT Status Success
Two record modes: auto and customization.
Auto Mode: Select one auto mode in the interface as shown below and then
click “Next” to save the settings. Click “Advanced” to self-define a record
mode.
Wizard
Mode
Motion Record
Sensor Record
Motion Record+S ens or Re cor d
Always(24x7)R eco rd+ Mot ion R eco rd
Always(24x7)R eco rd+ Sen sor R eco rd
Always(24x7)R eco rd+ Mot ion R eco rd+ Sen sor R ecord
Always(24x7)R eco rd+ Mot ion R eco rd+ Sen sor R ecord+AI Record
Next
Advanced
Previous Cancel
Record Settings
Network Settings Add Camera Disk Settings
Auto
Customization Mode: Set the “Sensor Record”, “Motion Record”, “AI
Record”, “POS Record” and “Schedule Record” of each camera. Please
enable the record as needed. Click “Next” to continue.
You can enable the NAT function in the interface or set it in the network
configuration after exiting the wizard. You can scan the QR code through the
mobile surveillance APP available for iOS or Android to easily view your
cameras. Please see the user manual of NVR for more details.
Click “Refresh” to refresh the list of online IP cameras which are in the same
local network with the NVR. Click + to add the searched camera. Click “Add
All” to add all the cameras in the list. Click to delete the added camera.
Click “Delete All” to delete all the added cameras.
8002001476 A0
Before using this function, please enable NAT2.0. Then click “Cloud
Upgrade” in the wizard interface. Go to Start →Settings →Network
→ Cloud Upgrade interface and click “Upgrade” to upgrade your device
if it is not the latest version.
Visit Address www.autonat.com
