TW Audio M8i User manual

Operation manual M8i

Operation manual M8i
2
Introduction
Thank you for choosing a high-quality product “MADEIN GERMANY” from TW AUDiO.
The M8i is the installation version of the M8, one of the most popular TW AUDiO products.
The M8i takes the same uncompromising acoustic design of the M8 (8“ LF-driver, 1“ com-
pression driver and rotatable 90° × 60° horn) and places it in the i-series installation specific
enclosure.
The phase-aligned and frequency corrected passive crossover allows the M8i to be driven
even by standard linear amplifier without DSPpresets. For extended fullrange use, or in com-
bination with TWAUDiO subwoofers, there are dedicated presets available for Powersoft and
Lab.gruppen amplifier platforms.
The M8i allows delivery of uncompromising audio in an architecturally discrete package.
If you lend your product to another party, inform that party of the safety-related operating pro-
cedures and hand over this assembly guide. If you require additional copies of this manual,
you can obtain them free of charge from TWAUDiO or download them from www.twaudio.de
Instructions in this user manual
Strictly adhere to the instructions contained in this operating manual that are marked as
follows:
This symbol in combination with the signal word “Caution” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to light or moderate injury.
This symbol in combination with the signal word “Note” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to product damage.
This symbol in combination with the signal word “Tip” identifies additional information or
notes that will simplify working with TW AUDiO products on the basis of practical experience.
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation. Failure to comply with this safety instruction can lead to serious injury or even death.
NOTE
TIP
CAUTION
WARNING
This symbol in combination with the signal word “Warning” identifies a potentially hazardous
situation for persons with a pacemaker. Failure to comply with this safety instruction can lead
to serious injury or even death.
WARNING

Operation manual M8i
3
Notes on the products
Read manual
before use!
Before using the device, carefully read the operating manual and keep it with the M8i loudspe-
aker.
General information
Operation manual: OM-M8i
Version 1.0 en, 11/2018
© by TW AUDiO 2018; all rights reserved.
All information contained in this operating manual was correct to the best of our knowledge
at the time of printing.
Quality warranties or assurance of suitability for a certain type of use based on the technical
specifications, dimensions and weights are not granted by TWAUDiO.
TW AUDiO also shall not assume liability for any secondary damage (property damage and/or
personal injury) nor for the failure to comply with this operating manual!
TW AUDiO reserves the right to update this document based on recent developments.
TW AUDiO GmbH
Osterholzallee 140
71636 Ludwigsburg
Germany
Phone : + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
E-Mail: [email protected]
WWW: www.twaudio.de

Operation manual M8i
4
Content
1. Safety | Intended use...................................................................................................... 5
2. Overview ........................................................................................................................ 7
2.1 Components ........................................................................................................... 7
3. Technical specifications .................................................................................................. 8
3.1 Data sheet............................................................................................................... 8
3.2 Connection diagram ................................................................................................ 8
4. Commissioning............................................................................................................... 9
4.1 Setup ...................................................................................................................... 9
4.2 M6 and M10 threaded inserts.................................................................................. 9
4.3 Rotating the HF horn ............................................................................................. 10
4.4 Connection options ............................................................................................... 10
4.5 Operation .............................................................................................................. 11
4.6 Connecting the cable............................................................................................. 11
5. Transport and Storage.................................................................................................. 12
6. CE Conformity Declaration............................................................................................ 12
7. Disposal ....................................................................................................................... 13

Operation manual M8i
5
1. Safety | Intended use
Please adhere to the following safety instructions to avoid risks when operating loudspeakers.
The M8i loudspeaker was developed for use in professional sound systems. The loudspeaker
may only be used by trained and qualified personnel.
Note the operating modes described in this operating manual. Other uses are not permis-
sible.
Damage caused by improper use is not covered by TW AUDiO.
Loudspeakers generate an electromagnetic field. Persons with pacemakers are not permit-
ted to remain in the immediate vicinity of loudspeakers as the electromagnetic fields can
cause pacemakers to malfunction.
Ensure that the units are in a stable position and are firmly attached. A falling loudspeaker can
result in serious personal injury and property damage.
When using and assembling TW AUDiO loudspeakers, only use materials specified by
TW AUDiO. These tasks must be performed by qualified personnel. Adhere to the applicable
safety regulations.
WARNING
When setting up loudspeakers, ensure that they are not exposed to the following ambient
conditions:
• direct sunlight
• Humidity
• Jolting
• Dust
Keep away from the immediate vicinity of loudspeakers that are operated at high sound pres-
sure levels. These loudspeaker systems are capable of endangering your health. Sound levels
beginning as low as approximately 90dBSPL can lead to long-term hearing impairment.
WARNING
Avoid:
• Feedback
• Distorted signals (clipping) and
• Peaks resulting from switching on devices, plugging in devices or unplugging devices during
operation.
Such signals can lead to loudspeaker overload and ultimately to loudspeaker failure.
WARNING
NOTE
NOTE

Operation manual M8i
6
Ensure that the loudspeaker is not exposed to permanent thermal overloads. Thermal over-
loads may cause a fire and result in serious personal injury and property damage.
WARNING
Note that TW AUDiO does not provide a warranty for damage that can be attributed to this
type of overload and therefore cannot be held liable for any secondary damage.
A permanent magnetic field is present in the immediate vicinity of loudspeakers. Ensure that
objects which react sensitively to magnetic fields are not located in the immediate vicinity of
the loudspeaker. In particular, this applies to magnetic storage media, magnetic stripe cards
such as debit cards and CRT displays. A distance of approximately one meter is sufficient to
avoid damage.
Check loudspeakers and accessory parts regularly for visible wear. This is essential to ensure
continuing fault-free operation. Worn parts should be replaced immediately. Spare parts are
available from TWAUDiO.
NOTE
NOTE

Operation manual M8i
7
2. Overview
2.1 Components
1. Front grill
2. 15 mm Multiplex enclosure - Warnex textured paint surface
3. M10 threaded insert for attaching accessories (4 pieces)
4. Rotatable horn with 1“ compression driver
5. 8“ cone driver
6. M6 threaded insert for attaching accessories (6 pieces)
7. Type label
8. Standard i-series screw terminal
Figure 2.1 - Overview
1
23
7
6
5
4
8

Operation manual M8i
8
3. Technical specifications
3.1 Data sheet
Drivers 1x 8“ LF / 1x 1,0“ HF
Frequency response 66 - 20000 Hz
Power handling (program/Peak) 400 / 800 W
Impedance 8 Ω
Coverage (h x v) 90° x 60° rotable
Max. SPL / 1m 124 dB
Dimensions (h x w x d) 440 x 240 x 240 mm [17,32 x 9,45 x 9,45 in]
Weight 10,3kg [22,708 lbs]
Surface Warnex textured paint
3.2 Connection diagram
Figure 3.2 - Connection diagram
red black

Operation manual M8i
9
4.1 Setup
The M8i loudspeaker is designed for hanging, vertical and horizontal operation. TW AUDiO
provides a wide range of accessories to securely attach the loudspeaker.
TW AUDiO recommends using only the accessories specified by TWAUDiO for securing and
mounting loudspeakers.
NOTE
Make sure the speakers are securely fastened to prevent personal injury and property damage.
WARNING
4. Commissioning
Make sure that all system structures are located on a firm, level surface and that the surface
can bear the total weight!
WARNING
4.2 M6 and M10 threaded inserts
Before fitting the accessories follow the subsequent steps:
4. For the M8i loudspeaker M6 and M10 threaded inserts, various TW AUDiO accessories
can be mounted. For each product refer to the instructions.
5. Note that the load capacity is limited to a single speaker.
3. Please note that once the countersunk screws are removed, water and moisture may
enter into the enclosure.
1. To remove the countersunk screws remove the texture paint by using a cutter knife. Avoid
damaging the surrounding paint to prevent chipping.
2. Remove for your application required countersunk screws. Use a hexalobular key with the
size of TX30 or TX50.
NOTE
WARNING

Operation manual M8i
10
4.4 Connection options
The M8i loudspeaker is equipped as standard with the i-series screw terminal.
As options there can be mounted a panel with cable gland (CG-option) or a panel with two
built-in speakON® jacks (SO-option).
Furthermore, a blind cover option is available.
All connection options are only available in black colour.
NOTE
More information about the different connection options can be found in the respective opera-
ting instructions in the download area on the homepage of TWAUDiO.
NOTE
4.3 Rotating the HF horn
With the factory default orientation of the M8i loudspeaker horn, the horizontal coverage is
90° and the vertical coverage is 60°. In some situations, it may be advantageous to change
the high frequency dispersion pattern. To adjust the dispersion pattern, the M8i loudspeaker’s
HF horn can be rotated. Proceed as follows:
1. Place the M8i loudspeaker on its back, with the speaker grille facing up. Make sure to place
the speaker on a clean, non-slippery surface.
2. To remove the front grill, a 3mm Allen key is required. Loosen the two mounting screws at
the top and bottom of the speaker cabinet.
3. Loosen the four screws on the horn using a 3mm Allen key. Pull the horn with the compres-
sion driver up and out of the speaker cabinet.
4. Check the seal between housing and horn for correct fit.
5. Carefully turn the horn by 90° and re-insert the horn with the driver back into the recess.
Screw it to the housing and apply medium-strength thread-locking fluid.
6. Attach the grill using the screws provided.

Operation manual M8i
11
4.5 Operation
M(i) series loudspeakers can be operated on standard linear amplifiers. For optimal perfor-
mance, we recommend using the system amplifiers and presets provided by TWAUDiO.
Make sure that the amplifier’s specifications meet the requirements. Using an amplifier that
doesn’t meet the specifications can destroy the loudspeaker.
Please note the technical data in section 3.1 on page 8.
NOTE
Before connecting the loudspeaker to the amplifier, ensure that the right preset has been
loaded.
Using the wrong preset or a preset not provided by TWAUDiO preset can destroy the speaker.
NOTE
4.6 Connecting the cable
To create a cable connection with an amplifier rack from TWAUDiO, proceed as follows.
Ensure that the cable cross sectional area is sufficient (at least 1.5 mm²) to avoid power losses.
TW AUDiO recommends using the loudspeaker cables available from TW AUDiO.
When connecting the cables to the loudspeaker, ensure that polarity (+/-) and pin assignment
(1/2) are correct. Incorrect connection can lead to a significant change in the loudspeaker’s
sound characteristics and may damage the driver.
The pin connections of the M8i loudspeaker can be found in section 3.2 (“Connection dia-
gram”) on page 8.
The internal wiring of the M8i loudspeaker allows for parallel connection of multiple loudspea-
ker units.
Please note that parallel connections will decrease the total impedance of your loudspeaker
configuration.
The total impedance and the resulting power of the speaker configuration must match the
output power of the amplifier.
NOTE

Operation manual M8i
12
5
Copy and translation of the original CE Conformity Declaration:
We hereby declare that the below-referenced components by virtue of their design and
construction, and in the configuration placed on the market by us, satisfy the safety and
health requirements of the applicable EC directives. This declaration becomes invalid in
case of modifications that have not been approved by us.
This declaration applies to the following components
• M8i
as well as all model variants based on these, provided that they correspond to the original
factory models and have not been technically modified in any way.
Applicable directives:
• 2001/95/EG
• 2011/65/EU
Applicable national standards and technical specifications:
• DIN EN 18 800
• DIN EN ISO 12 100
• DGUV Vorschrift 17 und 18
• EN 50581: 2013-02
Ludwigburg, Germany, April 1st, 2018
Tobias Wüstner
6. CE Conformity Declaration
5. Transport and Storage
Ensure that the front grill of the loudspeaker is not damaged during transport and storage.
Moisture can penetrate exposed wood surfaces and cause the wood to swell. A bent or bro-
ken front grill will no longer adequately protect the sensitive driver membranes.
In addition, larger dust deposits can significantly affect the functionality of a speaker mem-
brane. This is why the product should be transported and stored in a safe, careful, dry and
largely dust-free manner.
NOTE

Operation manual M8i
13
It is prohibited to dispose of used electrical equipment with household refuse.
All TW AUDiO GmbH products are so-called B2B-products. This means that they are sold by
a commercial business to a commercial business. TW AUDiO products that bear the trash
can symbol shown here may only be disposed of by TWAUDiO.
The loudspeaker owner is legally responsible for proper disposal of used devices that do not
bear this symbol. This pertains to all products delivered prior to March 29, 2010. Nevertheless,
TW AUDiO will also be happy to assist you in this case.
If you have any question regarding the disposal of used devices, please contact us under the
following telephone number:
+49 (0) 71 41 - 48 89 89 0
Thus, TW AUDiO is in strict compliance with the Waste Electrical and Electronic Equipment
Directive (2012/19/EU) for the protection of our environment.
TW AUDiO is registered under the following WEEE-reg.-no. with the German National Register
EAR as a B2B-manufacturer and distributor of electrical devices:
DE54488702
In countries outside of the European Union, comply with local regulations.
7. Disposal

Operation manual M8i
14
TW AUDiO GmbH
Osterholzallee 140
71636 Ludwigsburg
Germany
Phone : + 49 (0) 71 41-48 89 89 0
Fax: + 49 (0) 71 41-48 89 89 99
E-Mail: [email protected]
WWW: www.twaudio.de
