TYAN S8253 User manual

http://www.tyan.com
1
S8253
Version 1.0a
Copyright
Copyright © 2020 MiTAC International Corporation. All rights reserved. No part of
this manual may be reproduced or translated without prior written consent from
MiTAC International Corporation.
Trademark
All registered and unregistered trademarks and company names contained in this
manual are property of their respective owners including, but not limited to the
following.
TYAN®is a trademark of MiTAC International Corporation.
AMD®is a trademark of AMD®Corporation.
AMI, AMI BIOS are trademarks of AMI Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.
Notice
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN®products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to product descriptions and/or specifications at
any time, without notice. In no event will MiTAC be held liable for any direct or
indirect, incidental or consequential damage, loss of use, loss of data or other
malady resulting from errors or inaccuracies of information contained in this
document.

http://www.tyan.com
2
Contents
S8253............................................................................................................1
Before you begin…....................................................................................3
Chapter 1: Instruction ................................................................................4
1.1 Congratulations .................................................................................4
1.2 Hardware Specifications....................................................................4
1.3 Software Specifications.....................................................................9
Chapter 2: Board Installation...................................................................10
2.1 Board Image....................................................................................11
2.2 Block Diagram.................................................................................12
2.3 Motherboard Mechanical Drawing...................................................13
2.4Board Parts, Jumpers and Connectors...........................................14
2.5 LED Definitions................................................................................23
2.6Installing the Processor and Heatsink.............................................24
2.7Thermal Interface Material ..............................................................28
2.8Tips on Installing Motherboard in Chassis......................................29
2.9Installing the Memory ......................................................................31
2.10 Attaching Drive Cables..................................................................34
2.11 Installing Add-In Cards..................................................................35
2.12 Connecting External Devices........................................................36
2.13 Installing the Power Supply...........................................................38
2.14 Finishing Up...................................................................................38
Chapter 3: BIOS Setup.............................................................................39
3.1 About the BIOS................................................................................39
3.2 Main Menu.......................................................................................41
3.3 Advanced Menu...............................................................................43
3.4 Chipset Menu ..................................................................................95
3.5AMD CBS Menu..............................................................................99
3.6 Server Management......................................................................119
3.7Security..........................................................................................128
3.8Boot ...............................................................................................133
3.9Save & Exit....................................................................................136
Chapter 4: Diagnostics...........................................................................138
4.1 Flash Utility....................................................................................138
4.2 AMIBIOS Post Code (Aptio)..........................................................139
Appendix I: Fan and Temp Sensors .....................................................146
Glossary...................................................................................................151
Technical Support ..................................................................................157

http://www.tyan.com
3
Before you begin…
Check the box contents!
The retail motherboard package should contain the following:
S8253 Motherboard x 1
SATA Single Cable x 2
Rear IO shielding x 1
S8253 Quick Installation Guide x 1
IMPORTANT NOTE:
Sales samples may not come with any of the accessories listed above.
If you have ordered a sales sample and you are missing any of the above items,
please contact your sales representative to help order accessories.

http://www.tyan.com
4
Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN® S8253 motherboard, based on the
Aspeed®AST2500 chipset. The S8253 is designed to support dual AMD®EPYC™
7002/7003 series Processor, and Up to 1,024GB RDIMM, 4,096GB LRDIMM 3DS
DDR4 3200 MHz memory. Leveraging advanced technology from AMD®, the
S8253 is capable of offering scalable 32 and 64-bit computing, high-bandwidth
memory design, and lightning-fast PCI-E bus implementation.
The S8253 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S8253 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN® website at http://www.tyan.com. There you can find
all the information on all TYAN®products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S8253GM2NE Specifications
Processor
Q'ty / Socket Type
(2) AMD Socket SP3
Supported CPU Series
(2) AMD EPYC™ 7002/7003
Series Processors
Configurable Thermal
Design Power (cTDP)
Wattage
Max up to 280W
Memory
Supported DIMM
Qty
(8)+(8) DIMM slots
DIMM Type / Speed
DDR4 ECC RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 3200
Capacity
Up to 1,024GB RDIMM, 4,096GB
LRDIMM 3DS
Memory channel
8 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCIe
(1) PCIe Gen.4 x32 slot, (3) PCIe
Gen.4 x16 slot, (1) PCIe Gen.4 x8
slot
Recommended TYAN
M8253T65-R32-3F, 2U riser card

http://www.tyan.com
5
Riser Card
(PCIe Gen.4)
for slot #6.5 w/ (3) PCIe slots
(right)
LAN
Q'ty / Port
(2) GbE ports + (1) GbE dedicated
for IPMI
Controller
Intel I210
PHY
Realtek RTL8211E
Storage
SATA
Connector
(3) Mini-SAS HD (12
ports), (2) 7-pin White
SATA 6G ports w/
Power conn. support
SATA-DOM,, (2) 7-pin
SATA 6G ports
Controller
Direct from AMD EPYC
CPU
Speed
6Gb/s
RAID
N/A
NVMe
Connector (U.2)
(2) SFF-8654 for (4)
NVMe ports
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input /Output
USB
(2) USB3.1 Gen.1 ports (@ rear),
(1) USB3.1 Gen.1 port (Type-A),
(1) USB3.1 Gen.1 ports (via Cable)
COM
(1) DB-9 COM Connector (@ rear)
VGA
(1) D-Sub 15-pin VGA port (@ rear)
RJ-45
(2) GbE ports, (1) GbE dedicated for
IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(4) SATA/SATA-DOM connectors +
(3) Mini-SAS (4-in-1) connectors
Power
(4) 2x4 Power input connectors, (1)
2x12 Power input connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,

http://www.tyan.com
6
chipset & power supply
LED
Fan fail LED indicator, Over
temperature warning indicator, Fan
& PSU fail LED indicator
Others
Watchdog timer support
Server Management
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
Console Redirection, ACPI 6.1, ACPI
sleeping states S0, S5, FAN speed
control automatic
Physical Dimension
Form Factor
EATX
Board Dimension
12" x 13.4" (304.8 x 340.36mm)
Regulation
FCC (SDoC)
Class A
CE (DoC)
Class A
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Operating System
OS supported list
Please refer to our AVL support
lists.
Package Contains
Motherboard
(1) S8253 Motherboard
Manual
(1) Quick Installation Guide
Cable
(2) SATA signal cables
Installation CD
(1) TYAN Device Driver CD
I/O Shield
(1) I/O Shield
Optional accessories
Riser Card
M8253T65-R32-3F

http://www.tyan.com
7
S8253GM4NE-2T Specifications
Processor
Q'ty / Socket Type
(2) AMD Socket SP3
Supported CPU Series
(2) AMD EPYC™ 7002/7003
Series Processors
Configurable Thermal
Design Power (cTDP)
Wattage
Max up to 280W
Memory
Supported DIMM
Qty
(8)+(8) DIMM slots
DIMM Type / Speed
DDR4 ECC RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 3200
Capacity
Up to 1,024GB RDIMM, 4,096GB
LRDIMM 3DS
Memory channel
8 Channels per CPU
Memory voltage
1.2V
Expansion Slots
PCIe
(1) PCIe Gen.4 x32 slot, (3) PCIe
Gen.4 x16 slot, (1) PCIe Gen.4 x8
slot
Recommended TYAN
Riser Card
(PCIe Gen.4)
M8253T65-R32-3F, 2U riser card
for slot #6.5 w/ (3) PCIe slots
(right)
LAN
Q'ty / Port
(2) 10GbE ports, (2) GbE ports,
(1) GbE dedicated for IPMI
Controller
Intel I210, Intel X550
PHY
Realtek RTL8211E
Storage
SATA
Connector
(3) Mini-SAS HD (12
ports), (2) 7-pin White
SATA 6G ports w/ Power
conn. support SATA-
DOM,, (2) 7-pin SATA
6G ports
Controller
Direct from AMD EPYC
CPU
Speed
6Gb/s
RAID
N/A
NVMe
Connector (U.2)
(2) SFF-8654 for (4)
NVMe ports
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500

http://www.tyan.com
8
Input /Output
USB
(2) USB3.1 Gen.1 ports (@ rear),
(1) USB3.1 Gen.1 port (Type-A),
(1) USB3.1 Gen.1 ports (via Cable)
COM
(1) DB-9 COM Connector (@ rear)
VGA
(1) D-Sub 15-pin VGA port (@ rear)
RJ-45
(2) GbE ports, (2) 10GbE ports,
(1) GbE dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(4) SATA/SATA-DOM connectors +
(3) Mini-SAS (4-in-1) connectors
Power
(4) 2x4 Power input connectors,
(1) 2x12 Power input connectors
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Fan fail LED indicator, Over
temperature warning indicator, Fan
& PSU fail LED indicator
Others
Watchdog timer support
Server Management
AST2500 iKVM
Feature
24-bit high quality video
compression, Supports storage over
IP and remote platform-flash, USB
2.0 virtual hub
AST2500 IPMI
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
Console Redirection, ACPI 6.1, ACPI
sleeping states S0, S5, FAN speed
control automatic
Physical Dimension
Form Factor
EATX
Board Dimension
12" x 13.4" (304.8 x 340.36mm)
Regulation
FCC (SDoC)
Class A

http://www.tyan.com
9
CE (DoC)
Class A
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Operating System
OS supported list
Please refer to our AVL support
lists.
Package Contains
Motherboard
(1) S8253 Motherboard
Cable
(2) SATA signal cables
Manual
(1) Quick Installation Guide
Installation CD
(1) TYAN Device Driver CD
I/O Shield
(1) I/O Shield
Optional accessories
Riser Card
M8253T65-R32-3F
1.3 Software Specifications
For the latest AST2500 User’s Guide and OS (operation system) support, please
visit the Tyan’s Web site at http://www.tyan.com for the latest information

http://www.tyan.com
10
Chapter 2: Board Installation
You are now ready to install your motherboard.
How to install our products right… the first time
The first thing you should do is read this user’s manual. It contains important
information that will make configuration and setup much easier. Here are some
precautions you should take when installing your motherboard:
(1) Ground yourself properly before removing your motherboard from the
antistatic bag. Unplug the power from your computer power supply and
then touch a safely grounded object to release static charge (i.e. power
supply case). For the safest conditions, MiTAC recommends wearing a
static safety wrist strap.
(2) Hold the motherboard by its edges and do not touch the bottom of the
board, or flex the board in any way.
(3) Avoid touching the motherboard components, IC chips, connectors,
memory modules, and leads.
(4) Place the motherboard on a grounded antistatic surface or on the antistatic
bag that the board was shipped in.
(5) Inspect the board for damage.
The following pages include details on how to install your motherboard into your
chassis, as well as installing the processor, memory, disk drives and cables.
Caution!
1. To avoid damaging the motherboard and associated
components, do not use torque force greater than
5~7kgf/cm (4.35~6.09 lb/in) on each mounting screw
for motherboard installation.
2. Do not apply power to the board if it has been
damaged.

http://www.tyan.com
11
2.1 Board Image
S8253GM4NE-2T
This picture is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above picture.

http://www.tyan.com
12
2.2 Block Diagram
S8253 Block Diagram

http://www.tyan.com
13
2.3 Motherboard Mechanical Drawing

http://www.tyan.com
14
2.4Board Parts, Jumpers and Connectors
This diagram is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above diagram. The
DIMM slot numbers shown above can be used as a reference when reviewing the
DIMM population guidelines shown later in the manual. For the latest board
revision, please visit our web site at http://www.tyan.com.

http://www.tyan.com
15
Motherboard Components
Connectors
1. System Fan Board Header (J42)
22. USB3.1 TYPEA Connector(J31)
2. IPMB Connector (J67)
23. PWR2 (J63)
3. HDT Header (J37)
24. PWR4 (J64)
4. NVME2_3 (CN5)
25. SATA8_11 (J26)
5. SATADOM1 (J104)
26. PWR1 (J60)
6. NVME0_1 (CN6)
27. SYS_FAN_5 (J190)
7. SATA0_3 (J27)
28. Front Panel Header (J38)
8. Internal USB3.1 Header (J32)
29. USB3.1/IPMI_LAN (J29)
9. NVME hot plug (J118)
30. COM+VGA (J50)
10. SATADOM2 (J202)
31. LAN4 (J8001)
11. CPU1_FAN (J20)
32. PSMI Header(J61)
12. SATA13 (J49)
33. LAN3 (J8002)
13. SATA12 (J48)
34. LAN2 (U9)
14. PWR5 (J65)
35. LAN1 (U8)
15. PWR3 (J62)
36. Micro SD Card Connector (J19)
16. SYS_FAN_4 (J180)
37. FPGA JTAG Connector (J59)
17. SYS_FAN_3 (J404)
38. TYAN Module Header (J40)
18. SYS_FAN_2 (J45)
39. RESET Button (SW2)
19. SYS_FAN_1 (J44)
40. POWER Button (SW4)
20. CPU0_FAN (J18)
41. NMI Button (SW3)
21. SATA4_7 (J25)
Jumpers
a. ID_BTN_SW (J46)
e. BMC_DEBUG (J52)
b. FPGA_JTAG_SW (J39)
f. COM_SEL2 (J55)
c. RESET_SEL (J41)
g. COM_SEL1 (J53)
d. COM_SEL3 (J56)
h. BYPASS_BMC (J43)
I. CMOS_CLR (J36)
PCIE Slots
A PCIE#2 (J301)
D. PCIE#5 (J6001)
B. PCIE#3 (J4100)
E. PCIE#6.5 (J7001)
C. PCIE#4 (J5001)
LEDs
iBMC_HBLED (D33)
II ID_LED (D770)

http://www.tyan.com
16
J42: System FAN Board Pin Header
Signal
Pin
Pin
Signal
BMC_TACH_SYS_FAN2
1
2
BMC_TACH_SYS_FAN7
BMC_TACH_SYS_FAN3
3
4
BMC_TACH_SYS_FAN8
BMC_TACH_SYS_FAN4
5
6
BMC_TACH_SYS_FAN9
BMC_TACH_SYS_FAN5
7
8
BMC_TACH_SYS_FAN10
BMC_TACH_SYS_FAN6
9
10
BMC_TACH_SYS_FAN11
GND
11
12
GND
BMC_PWM_BUF_FAN3
13
14
BMC_PWM_BUF_FAN2
BMC_TACH_SYS_FAN12
15
16
BMC_SDA3
BMC_TACH_SYS_FAN13
17
18
BMC_SCL3
3.3V
19
20
BMC_PWM_BUF_FAN4
3.3V
21
22
GND
BMC_TACH_SYS_FAN14
23
24
BMC_TACH_SYS_FAN1
BMC_TACH_SYS_FAN15
25
26
BMC_TACH_SYS_FAN0
BMC_PWM_BUF_FAN5
27
28
BMC_PWM_BUF_FAN6
BMC_PWM_BUF_FAN0
29
30
GND
J67: IPMB Connector
Signal
Pin
Pin
Signal
IPMB_DATA
1
2
IPMB_CLK
GND
3
4
VCC
J37: HDT Header
Signal
Pin
Pin
Signal
P1V8_AUX
1
2
TCK
GND
3
4
TMS
GND
5
6
TDI
GND
7
8
TDO
TRST_N
9
10
PEROK
NC
11
12
RESET_N
NC
13
14
NC
NC
15
16
DBREQ_N
GND
17
18
NC
P1V8_AUX
19
20
NC

http://www.tyan.com
17
J104, J202: SATA DOM Connector
Name
TYPE
1
GND
2
TXP
3
TXN
4
GND
5
RXN
6
RXP
7
GND
P1
VCC
P2
GND
Connects to the Serial ATA ready drives via the Serial ATA cable.
SATA12 (J48)/ SATA13 (J49): 7-pin SATA 3.0 Connector
Name
TYPE
1
GND
2
SATA TX DP
3
SATA TX DN
4
GND
5
SATA RX DN
6
SATA RX DP
7
GND
J18, J20, J44, J45, J404, J180, J190: 4-pin Fan Connector
Pin
1
2
3
4
Signal
GND
VCC12
TACH
PWM
Use this header to connect the cooling fan to your motherboard to
keep the system stable and reliable.
Note: A 4-pin fan is required for fan support 4pin Control
J20: CPU1_FAN J18: CPU0_FAN
J44: SYS_FAN_1 J45: SYS_FAN_2
J180: SYS_FAN_4 J404: SYS_FAN_3

http://www.tyan.com
18
J38: Front Panel Connector
Signal
Pin
Pin
Signal
PW_LED+
1
2
FP_PWR
3
4
ID_LED+
PWR_LED-
5
6
ID_LED-
HDD_LED+
7
8
FAULT_LED1-
HDD_LED-
9
10
FAULT_LED2-
PWR_SW#
11
12
LAN1 ACTLED+
GND
13
14
LAN1 ACTLED-
RST_SW#
15
16
SMBus SDA
GND
17
18
SMBus SCL
SYS_ID_SW#
19
20
INTRUSION#
TEMP SENSOR
21
22
LAN2 ACTLED+
NMI_SW#
23
24
LAN2 ACTLED-
DBG_HD1: TYAN Module Header
Signal
Pin
Pin
Signal
VDD_33_RUN
1
2
FRAME_N
LAD0
3
4
KEY
LAD1
5
6
RESET#
LAD2
7
8
GND
LAD3
9
10
CLK
DBG_SERIRQ
11
12
GND
DBG_PRES_N
13
14
3VSB
NA
15
16
TPM_PP_EN
J61: PSMI Connector
Pin
1
2
3
4
5
Signal
PSMI_CLK
PSMI_DAT
PSMI_ALERT
GND
VCC
J32: Internal USB3.1 Header
Signal
Pin
Pin
Signal
USB3_VCC_FPB
1
2
USB31_PCH_P4_RX_ESD_DN
USB31_PCH_P4_RX_ESD_DP
3
4
GND
USB31_PCH_P4_TX_ESD_DN
5
6
USB31_PCH_P4_TX_ESD_DP
GND
7
8
USB2_PCH_P9_ESD_DN
USB2_PCH_P9_ESD_DP
9
10
USB31_FPB_OC2_N_R
USB2_PCH_P6_ESD_DP
11
12
USB31_PCH_P3_TX_ESD_DN
GND
13
14
USB31_PCH_P3_TX_ESD_DP
USB31_PCH_P3_TX_ESD_DN
15
16
GND
USB31_PCH_P3_RX_ESD_DP
17
18
USB31_PCH_P3_RX_ESD_DN
USB3_VCC_FPB
19
20
Key

http://www.tyan.com
19
J31: Vertical (Type_A) USB3.1 Connector
Signal
Pin
Pin
Signal
P5V_AUX
1
2
USB2.0_DATA_N
USB2.0_DATA_P
3
4
GND
STAD_SSRX-1
5
6
STAD_SSRX+1
GND
7
8
STAD_SSTX-1
STAD_SSTX+1
9
CN6 and CN5: NVME2_3/ NVME0_1
pin
net
pin
net
A1
GND
B1
GND
A2
NVME[1,3,5,7]_RX_P3
B2
NVME[1,3,5,7]_TX_P3
A3
NVME[1,3,5,7]_RX_N3
B3
NVME[1,3,5,7]_TX_N3
A4
GND
B4
GND
A5
NVME[1,3,5,7]_RX_P2
B5
NVME[1,3,5,7]_TX_P2
A6
NVME[1,3,5,7]_RX_N2
B6
NVME[1,3,5,7]_TX_N2
A7
GND
B7
GND
A8
NC
B8
CPU_NVME_SCL
A9
NC
B9
CPU_NVME_SDA
A10
GND
B10
GND
A11
NVME_CLK_DP
B11
NVME_PERST_N
A12
NVME_CLK_DN
B12
NVME_HP_ALERT_N
A13
GND
B13
GND
A14
NVME[1,3,5,7]_RX_P1
B14
NVME[1,3,5,7]_TX_P1
A15
NVME[1,3,5,7]_RX_N1
B15
NVME[1,3,5,7]_TX_N1
A16
GND
B16
GND
A17
NVME[1,3,5,7]_RX_P0
B17
NVME[1,3,5,7]_TX_P0
A18
NVME[1,3,5,7]_RX_N0
B18
NVME[1,3,5,7]_TX_N0
A19
GND
B19
GND
A20
NVME[0,2,4,6]_RX_P3
B20
NVME[0,2,4,6]_TX_P3
A21
NVME[0,2,4,6]_RX_N3
B21
NVME[0,2,4,6]_TX_N3
A22
GND
B22
GND
A23
NVME[0,2,4,6]_RX_P2
B23
NVME[0,2,4,6]_TX_P2
A24
NVME[0,2,4,6]_RX_N2
B24
NVME[0,2,4,6]_TX_N2
A25
GND
B25
GND
A26
BMC_SMBus_SCL
B26
SMB_SW_BIT0
A27
BMC_SMBus_SDA
B27
SMB_SW_BIT1
A28
GND
B28
GND
A29
NC
B29
PERST_N
A30
NC
B30
NC
A31
GND
B31
GND
A32
NVME[0,2,4,6]_RX_P1
B32
NVME[0,2,4,6]_TX_P1
A33
NVME[0,2,4,6]_RX_N1
B33
NVME[0,2,4,6]_TX_N1
A34
GND
B34
GND
A35
NVME[0,2,4,6]_RX_P0
B35
NVME[0,2,4,6]_TX_P0
A36
NVME[0,2,4,6]_RX_N0
B36
NVME[0,2,4,6]_TX_N0
A37
GND
B37
GND

http://www.tyan.com
20
J27/ J25/ J26: SATA0_3/SATA4_7 /SATA8_11
pin
net
pin
net
A1
SIDEBAND0
B1
SIDEBAND1
A2
SIDEBAND7
B2
SIDEBAND3
A3
GND
B3
GND
A4
RXA1_DP
B4
RXA0_DP
A5
RXA1_DN
B5
RXA0_DN
A6
GND
B6
GND
A7
RXA3_DP
B7
RXA2_DP
A8
RXA3_DN
B8
RXA2_DN
A9
GND
B9
GND
C1
SIDEBAND2
D1
SIDEBAND6
C2
SIDEBAND4
D2
SIDEBAND5
C3
GND
D3
GND
C4
TXA1_DP
D4
TXA0_DP
C5
TXA1_DN
D5
TXA0_DN
C6
GND
D6
GND
C7
TXA3_DP
D7
TXA2_DP
C8
TXA3_DN
D8
TXA2_DN
C9
GND
D9
GND
J46: Rear IO ID LED Button
Signal
Pin
Pin
Signal
FP_IDLED_BTN_N
1
2
GND
SW4: POWER Button
Pin
1
2
3
4
Signal
GND
GND
PWR_BTN1
PWR_BTN1
SW2: COLD Reset Button
Pin
1
2
3
4
Signal
GND
GND
FP_RST_BTN_N
FP_RST_BTN_N
SW3: NMI Button
Pin
1
2
3
4
5
Signal
NC
FP_NMI_BTN_N
GND
NMI_BTN_L 52
VCC
