TYAN FT77B-B7059 Quick start guide

1
http://www.tyan.com
FT77B-B7059
Service Engineer’s Manual

2
http://www.tyan.com

3
http://www.tyan.com
PREFACE
Copyright
This publication, including all photographs, illustrations, and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any material contained herein, may be reproduced
without written consent of manufacturer.
Copyright 2015 MiTAC International Corporation. All rights reserved. TYAN®is
a registered trademark of MiTAC International Corporation.
Version 1.0b
Disclaimer
Information contained in this document is furnished by MiTAC International
Corporation and has been reviewed for accuracy and reliability prior to printing.
MiTAC assumes no liability whatsoever, and disclaims any express or implied
warranty, relating to sale and/or use of TYAN®products including liability or
warranties relating to fitness for a particular purpose or merchantability. MiTAC
retains the right to make changes to produce descriptions and/or specifications
at any time, without notice. In no event will MiTAC be held liable for any direct
or indirect, incidental or consequential damage, loss of use, loss of data or
other malady resulting from errors or inaccuracies of information contained in
this document.
Trademark Recognition
All registered and unregistered trademarks and company names contained in
this manual are property of their respective owners including, but not limited to
the following.
TYAN®is a trademark of MiTAC International Corporation.
Intel®is a trademark of Intel®Corporation.
AMI®, AMIBIOS® and combinations thereof are trademarks of AMI
Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
IBM®, PC®, AT®and PS/2®are trademarks of IBM Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.

4
http://www.tyan.com
FCC Declaration
Notice for the US
A
Compliance Information Statement (Declaration of
Conformity Procedure) DoC FCC Part 15: This
device complies with part 15 of the FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following conditions:
This device must not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Notice for Canada
This Class A digital apparatus complies with Canadian ICES-003. Cet
appareil numérique de la Classe A est conforme à la norme NMB-003 du
Canada.
Notice for Europe (CE Mark)
This product is in conformity with the Council
Directive 2004/108/EC.
CAUTION: Lithium battery included with this board. Do not puncture,
mutilate, or dispose of battery in fire. There will be danger of explosion if
battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by manufacturer. Dispose of used battery according to
manufacturer instructions and in accordance with your local regulations.

5
http://www.tyan.com
About this Manual
This manual is intended for experienced users and integrators with hardware
knowledge of personal computers.
It is aimed to provide you with instructions on installing your TYAN FT77B-B7059.
How this guide is organized
This guide contains the following parts:
Chapter 1: Overview
This chapter provides an introduction to the TYAN FT77B-B7059 barebones and
standard parts list, describes the external components, gives an overview of the
product from different angles.
Chapter 2: Setting Up
This chapter covers procedures on installing the processors, memory modules, hard
drivers and other optional parts.
Chapter 3: Replacing the Pre-installed Components
This chapter covers the removal and replacement procedures for pre-installed
components.
Chapter 4: Motherboard Information
This chapter lists the hardware setup procedures that you need to abide by when
installing system components. It includes description of the jumpers and connectors
on the motherboard.
Chapter5: BIOS Setup
This chapter tells how to change system settings through the BIOS setup menu.
Detailed descriptions of the BIOS parameters are also provided.
Chapter 6: Diagnostics
This chapter introduces some BIOS codes and technical terms to provide better
service for the customers.
Appendix:
This chapter provides the cable connection table, the FRU parts list for reference of
system setup, and technical support in case a problem arises with your system.

6
http://www.tyan.com
Safety and Compliance Information
Before installing and using TYAN FT77B-B7059, take note of the following
precautions:
·Read all instructions carefully.
·Do not place the unit on an unstable surface, cart, or stand.
·Do not block the slots and opening on the unit, which are provided for
ventilation.
·Only use the power source indicated on the marking label. If you are not
sure, contact the power company.
·The unit uses a three-wire ground cable, which is equipped with a third pin to
ground the unit and prevent electric shock. Do not defeat the purpose of this
pin. If your outlet does not support this kind of plug, contact your electrician
to replace your obsolete outlet.
·Do not place anything on the power cord. Place the power cord where it will
not be in the way of foot traffic.
·Follow all warnings and cautions in this manual and on the unit case.
·Do not push objects in the ventilation slots as they may touch high voltage
components and result in shock and damage to the components.
·When replacing parts, ensure that you use parts specified by the
manufacturer.
·When service or repairs have been done, perform routine safety checks to
verify that the system is operating correctly.
·Avoid using the system near water, in direct sunlight, or near a heating
device.
·Cover the unit when not in use.

7
http://www.tyan.com
Safety Information
Retain and follow all product safety and operating instructions provided
with your equipment. In the event of a conflict between the instructions in
this guide and the instructions in equipment documentation, follow the
guidelines in the equipment documentation.
Observe all warnings on the product and in the operating instructions. To
reduce the risk of bodily injury, electric shock, fire and damage to the
equipment, observe all precautions included in this guide.
You must become familiar with the safety information in this guide before
you install, operate, or service TYAN products.
Symbols on Equipment
Caution. This symbol indicates a potential hazard.
The potential for injury exists if cautions are not
observed. Consult equipment documentation for
specific details.
Caution. Slide-mounted equipment is not to be
used as a shelf or a work space.
Warning. This symbol indicates the presence of
hazardous energy circuits or electric shock
hazards. Refer all servicing to qualified personnel.
Warning. This symbol indicates the presence of a
hot surface or hot component. If this surface is
contacted, the potential for injury exists.
To reduce risk of injury from a hot component,
allow the surface to cool before touching.
General Precautions
· Follow all caution and warning instructions marked on the equipment and
explained in the accompanying equipment documentation.
Machine Room Environment
· This device is for use only in a machine room or IT room.
 · Make sure that the area in which you install the system is properly
ventilated and climate-controlled.

8
http://www.tyan.com
· Ensure that the voltage and frequency of your power source match the
voltage and frequency inscribed on the electrical rating label of the
equipment.
·Do not install the system in or near a plenum, air duct, radiator, or heat
register.
·Never use the product in a wet location.
Equipment Chassis
· Do not block or cover the openings to the system.
·Never push objects of any kind through openings in the equipment.
Dangerous voltages might be present.
·Conductive foreign objects can produce a short circuit and cause fire,
electric shock, or damage to your equipment.
·Lift equipment using both hands and with your knees bent.
Equipment Racks
To avoid injury or damage to the equipment:
·Observe local occupational health and safety requirements and guidelines
for manual materials handling.
·Do not attempt to move a rack by yourself; a minimum of two people are
needed to move a rack.
·Do not attempt to move a fully loaded rack. Remove equipment from the
rack before moving it.
·Do not attempt to move a rack on an incline that is greater than 10 degrees
from the horizontal.
·Make sure the rack is properly secured to the floor or ceiling.
·Make sure the stabilizing feet are attached to the rack if it is a single-rack
installation.
·Make sure racks are coupled together if it is a multiple-rack installation.
·Make sure the rack is level and stable before installing an appliance in the
rack.
·Make sure the leveling jacks are extended to the floor.

9
http://www.tyan.com
·Make sure the full weight of the rack rests on the leveling jacks.
·Always load the rack from the bottom up. Load the heaviest component in
the rack first.
·Make sure the rack is level and stable before pulling a component out of the
rack.
·Make sure only one component is extended at a time. A rack might become
unstable if more than one component is extended.
To avoid damage to the equipment:
· The rack width and depth must allow for proper serviceability and cable
management.
· Ensure that there is adequate airflow in the rack. Improper installation or
restricted airflow can damage the equipment.
·The rack cannot have solid or restricted airflow doors. You must use a
mesh door on the front and back of the rack or remove the doors to ensure
adequate air flow to the system.
·If you install the Model in a rack, do not place equipment on top of the unit.
It will cause restricted airflow and might cause damage to the equipment.
·Make sure the product is properly matted with the rails. Products that are
improperly matted with the rails might be unstable.
·Verify that the AC power supply branch circuit that provides power to the
rack is not overloaded. This will reduce the risk of personal injury, fire, or
damage to the equipment. The total rack load should not exceed 80 percent
of the branch circuit rating. Consult the electrical authority having jurisdiction
over your facility wiring and installation requirements.
·Verify that the AC power supply branch circuit that provides power to the
rack is not overloaded. This will reduce the risk of personal injury, fire, or
damage to the equipment. The total rack load should not exceed 80 percent
of the branch circuit rating. Consult the electrical authority having jurisdiction
over your facility wiring and installation requirements.
·Verify that the AC power supply branch circuit that provides power to the
rack is not overloaded. This will reduce the risk of personal injury, fire, or
damage to the equipment. The total rack load should not exceed 80 percent
of the branch circuit rating. Consult the electrical authority having jurisdiction
over your facility wiring and installation requirements.
·When use 100V-127VAC input: The system does not support redundant
PSU operation if the total system load exceeds 20A.

10
http://www.tyan.com
Equipment Power Cords
· Use only the power cords and power supply units provided with your
system. The system might have one or more power cords.
·Plug the power cord into a grounded (earthed) electrical outlet that is easily
accessible at all times.
·In all European electrical environments, you must ground the Green/Yellow
tab on the power cord. If you do not ground the Green/Yellow tab, it can
cause an electrical shock due to high leakage currents.
·
Do not place objects on AC power cords or cables. Arrange them so that no
one might accidentally step on or trip over them.
·Do not pull on a cord or cable. When unplugging from the electrical outlet,
grasp the cord by the plug.
·To reduce the risk of electrical shock, disconnect all power cords before
servicing the appliance.
Equipment Batteries
· The system battery contains lithium manganese dioxide. If the battery pack
is not handled properly, there is risk of fire and burns.
·Do not disassemble, crush, puncture, short external contacts, or dispose of
the battery in fire or water.
·Do not expose the battery to temperatures higher than 60°C (140°F).
·The system battery is not replaceable. If the battery is replaced by an
incorrect type, there is danger of explosion. Replace the battery only with a
spare designated for your product.
·Do not attempt to recharge the battery.
·Dispose of used batteries according to the instructions of the manufacturer.
Do not dispose of batteries with the general household waste. To forward
them to recycling or proper disposal, use the public collection system or return
them to TYAN, your authorized TYAN partner, or their agents.

11
http://www.tyan.com
Equipment Modifications
· Do not make mechanical modifications to the system. TYAN is not
responsible for the regulatory compliance of TYAN equipment that has been
modified.
Equipment Repairs and Servicing
· The installation of internal options and routine maintenance and service of
this product should be performed by individuals who are knowledgeable about
the procedures, precautions, and hazards associated with equipment
containing hazardous energy levels.
·Do not exceed the level of repair specified in the procedures in the product
documentation. Improper repairs can create a safety hazard.
·Allow the product to cool before removing covers and touching internal
components.
·Remove all watches, rings, or loose jewelry when working before removing
covers and touching internal components.
·Do not use conductive tools that could bridge live parts.
·Use gloves when you remove or replace system components; they can
become hot to the touch.
·If the product sustains damage requiring service, disconnect the product
from the AC electrical outlet and refer servicing to an authorized service
provider. Examples of damage requiring service include:
– The power cord, extension cord, or plug has been damaged.
– Liquid has been spilled on the product or an object has fallen into the
product.
–The product has been exposed to rain or water.
– The product has been dropped or damaged.
– The product does not operate normally when you follow the operating
instructions.

http://www.tyan.com
12

http://www.tyan.com
13
Table of Contents
Chapter 1: Overview....................................................................... 17
1.1 About the TYAN FT77B-B7059.............................................. 17
1.2 Product Models....................................................................... 17
1.3 Features.................................................................................. 18
1.4 Standard Parts List................................................................. 22
1.4.1Box Contents.................................................................... 22
1.4.2 Accessories ..................................................................... 22
1.5 About the Product................................................................... 24
1.5.1System Front View........................................................... 24
1.5.2System Rear View ........................................................... 26
1.5.3LED Definitions ................................................................ 27
1.5.4 System Top View............................................................. 29
Chapter 2: Setting Up..................................................................... 31
2.0.1 Before you Begin............................................................. 31
2.0.2 Work Area........................................................................ 31
2.0.3 Tools................................................................................ 31
2.0.4 Precautions...................................................................... 32
2.1 Installing Motherboard Components ...................................... 33
2.1.1 Removing the Chassis Cover and Air Duct..................... 33
2.1.2 Installing the CPU and Heatsink...................................... 35
2.1.3 Installing the Memory ...................................................... 38
2.1.4 Installing the Expansion Cards........................................ 39
2.1.6 Installing the Mezzanine Card......................................... 41
2.1.7 Installing Hard Drives ...................................................... 43
2.2 Rack Mounting........................................................................ 47
2.2.1 Installing the Server in a Rack......................................... 47
2.2.2 Installing the inner Rails to the Chassis .......................... 48
2.2.3 Installing the Outer Rails to the Rack.............................. 49
2.2.4 Rack mounting the Server............................................... 49
Chapter 3: Replacing Pre-Installed Components ........................ 51
3.0.1 Introduction...................................................................... 51
3.0.2 Disassembly Flowchart.................................................... 51
3.1 Removing the Cover............................................................... 52
3.2 Replacing the Power Supply .................................................. 52
3.3 Replacing the Power Distribution Board................................. 53
3.3.1 Power Distribution Board Features ................................. 54
3.3.2 Pin Definitions.................................................................. 55
3.4 Replacing the Power Backplane Board.................................. 56
3.4.1 Power Backplane Board Features................................... 57

http://www.tyan.com
14
3.4.2 Pin Definitions.................................................................. 58
3.5 Replacing the Riser Card ....................................................... 59
3.5.1 Riser Card Features ........................................................ 61
3.6 Replacing the System Fan ..................................................... 62
3.6.1 Fan Board Features......................................................... 64
3.6.2 Pin Definitions.................................................................. 65
3.7 Replacing the Front Panel Board...........................................66
3.7.1 Front Panel Board Features............................................ 67
3.7.2 Pin Definitions.................................................................. 68
3.8 Replacing the Motherboard.................................................... 69
Chapter 4: Motherboard Information ............................................ 71
4.1 Board Image........................................................................... 72
4.2 Block Diagram ........................................................................ 73
4.3 Motherboard Mechanical Drawing.......................................... 74
4.4 Board Parts, Jumpers and Connectors .................................. 75
4.5 Thermal Interface Material...................................................... 85
4.6 Tips on Installing Motherboard in Chassis ............................. 86
4.7 Installing the Memory ............................................................. 88
4.8 PLXPXE8747 and PCIE LED Definition................................. 93
4.9 Finishing Up............................................................................ 94
Chapter 5: BIOS Setup................................................................... 95
5.1 About the BIOS....................................................................... 95
5.1.1 Setup Basics.................................................................... 95
5.1.2 Getting Help..................................................................... 96
5.1.3 In Case of Problems........................................................ 96
5.1.4 Setup Variations .............................................................. 96
5.2 Main Menu.............................................................................. 97
5.3 Advanced Menu...................................................................... 98
5.3.1 PCI Subsystem Settings................................................100
5.3.2 ACPI Settings................................................................ 102
5.3.3 Trusted Computing........................................................ 103
5.3.4 CPU Configuration......................................................... 104
5.3.5 Runtime Error Logging ..................................................109
5.3.6 SATA Configuration....................................................... 110
5.3.7 SAS Configuration.........................................................111
5.3.8 Onboard Device Configuration......................................112
5.3.9 PCIe Slot Configuration................................................. 113
5.3.10 USB Configuration......................................................... 114
5.3.11 Info Report Configuration.............................................. 115
5.3.12 Hardware Health Configuration.....................................116
5.3.13 Super IO Configuration.................................................. 118
5.3.14 Serial Port Console Redirection.................................... 120

http://www.tyan.com
15
5.4 Chipset Menu ....................................................................... 125
5.4.1 North Bridge .................................................................. 126
5.4.2 South Bridge.................................................................. 133
5.4.3 WatchDog Timer Configuration.....................................134
5.5 Boot..................................................................................... 135
5.5.1 Network Device BBS Priorities......................................137
3.5.2CSM Parameters ........................................................... 138
5.5.3 Delete Boot Option........................................................140
5.6 Security................................................................................. 141
5.7 Server Management............................................................. 142
5.7.1 System Event Log .........................................................143
5.7.2 BMC Network Configuration..........................................144
5.8 Event Logs............................................................................ 145
5.9 Save & Exit...........................................................................146
Chapter 6: Diagnostics ................................................................ 149
6.1 Flash Utility...........................................................................149
6.2 AMIBIOS Post Code (Aptio)................................................. 150
Appendix I: Cable Connection Tables ........................................ 159
Appendix II: Fan and Temp Sensors .......................................... 161
Appendix III: FRU Parts Table ..................................................... 167
Appendix IV: Technical Support ................................................. 169

http://www.tyan.com
16
NOTE

http://www.tyan.com
17
Chapter 1: Overview
1.1 About the TYAN FT77B-B7059
Congratulations on your purchase of the TYAN®FT77B-B7059, a highly optimized
4U rack-mountable barebone system. The FT77B-B7059 is designed to support dual
Intel®Xeon E5-2600 Series Processors and up to 192GB UDIMM and 384GB
RDIMM, providing a rich feature set and incredible performance. Leveraging
advanced technology from Intel®, the FT77B-B7059 server system is capable of
offering scalable 32 and 64-bit computing, high bandwidth memory design, and
lightning-fast PCI-E bus implementation. The FT77B-B7059 not only empowers your
company in nowadays IT demand but also offers a smooth path for future application
usage.
TYAN®also offers the FT77B-B7059 in a version that can support up to ten 2.5” or
3.5” hard drives. The FT77B-B7059 uses TYAN’s latest chassis featuring a robust
structure and a solid mechanical enclosure. All of this provides FT77B-B7059 the
power and flexibility to meet the needs of nowadays server application.
1.2 Product Models
The system boards within the Tyan MicroServer blades contain different features
and chipsets, which are defined by the following models:
B7059F77BV10R-2T: Intel-based platform
B7059F77BV10R: Intel-based platform

http://www.tyan.com
18
1.3 Features
TYAN FT77BB7059 (B7059F77BV10R-2T)
System
Form Factor 4U Rackmount
Gross Weight 35 kg
Chassis Model FT77B
Dimension (D x W x
H) 30.31" x 17.24" x 6.93" (770 x 438 x 176mm)
Motherboard S7059GM2NR-2T
Front Panel
Buttons (1) RST / (1) ID / (1) PWR w/ LED
LEDs (1) HDD / (2) LAN / (1) ID / (1) IPMI/Warning
I/O Ports (2) USB ports
External Drive
Bay
Type / Q'ty (10) 3.5"/2.5" HDDs
Supported HDD
Interface (2) SATA 6Gb/s / (4) SATA 3Gb/s / (1) Mini-SAS (4port w/ SATA 3Gb/s)
System Cooling
Configuration FAN (5+1) hot-swap 12cm fans
Power Supply
Efficiency 80 plus Platinum
Redundancy 2+1
Serviceability Hot-swap
Input Range 100-127V AC / 200-240V AC
Output Watts 3,200 Watts
Processor
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 series processors
Socket Type / Q'ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 150W
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602
Memory
Supported DIMM
Qty (12)+(12) DIMM slots
DIMM Type / Speed RDIMM ECC 1866/1600/1333/1066 /
UDIMM/LRDIMM ECC 1866/1600/1333/1066
Capacity up to 192GB UDIMM / 384GB RDIMM / 768GB
LRDIMM
Memory channel 4 Channels per CPU
Memory voltage 1.5V or 1.35V
Expansion Slots
PCI-E (8) PCI-E Gen3 x16 slots / (2) PCI-E Gen3 x8 slots(one for mezzanine card) / (3) PCI-E Gen2 x1
slots
PCI (1) PCI 32-bit slot
Recommended M7059F77-QDR-2, Dual QSFP IB mezzanie card

http://www.tyan.com
19
TYAN Mezzanie
Card (40Gb/s) / M7059F77-FDR-2, Dual QSFP IB mezzanie card (56Gb/s)
LAN Port Q'ty (2) 10GbE ports (1 port shared with IPMI)
Controller Intel X540-AT2
Storage SATA
Connector (2) Mini-SAS (4-ports) + (2) SATA (totally support 10
ports)
Controller Intel C602
Speed (2) 6.0 Gb/s, (8) 3.0 Gb/s
RAID RAID 0/1/10/5 (Intel RST)
Graphic Connector type D-Sub 15-pin
Chipset Aspeed AST2300
I/O Ports
USB (2) ports (via a dongle cable)
VGA (1) D-Sub 15-pin port (via a dongle cable)
RJ-45 (2) ports (1 port shared with IPMI)
System
Monitoring
Chipset Aspeed AST2300
Voltage Monitors voltage for CPU, memory, chipset & power
supply
Temperature Monitors temperature for CPU & memory
LED Fan fail LED indicator / Over temperature warning
indicator / Fan & PSU fail LED indicator
Others Watchdog timer support
Server
Management
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management controller
(BMC) / Supports storage over IP and remote
platform-flash / USB 2.0 virtual hub
AST2300 iKVM
Feature 24-bit high quality video compression / 10/100 Mb/s MAC interface
BIOS
Brand / ROM size AMI / 8MB
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power on
mode after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk types
Operating
System OS supported list Please refer to our Intel OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating
Environment
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Compliant Yes
Package
Contains
Barebone (1) FT77B-B7059 Barebone
Manual (1) Quick Installation Guide

http://www.tyan.com
20
Installation CD (1) TYAN installation CD
Cable Others (1) via a dongle cable
TYAN FT77BB7059 (B7059F77BV10R)
System
Form Factor 4U Rackmount
Gross Weight 35 kg
Chassis Model FT77B
Dimension (D x W x
H) 30.31" x 17.24" x 6.93" (770 x 438 x 176mm)
Motherboard S7059GM2NR
Front Panel
Buttons (1) RST / (1) ID / (1) PWR w/ LED
LEDs (1) HDD / (2) LAN / (1) ID / (1) IPMI/Warning
I/O Ports (2) USB ports
External Drive
Bay
Type / Q'ty (10) 3.5"/2.5" HDDs
Supported HDD
Interface (2) SATA 6Gb/s / (4) SATA 3Gb/s / (1) Mini-SAS (4port w/ SATA 3Gb/s)
System Cooling
Configuration FAN (5+1) hot-swap 12cm fans
Power Supply
Efficiency 80 plus Platinum
Redundancy 2+1
Serviceability Hot-swap
Input Range 100-127V AC / 200-240V AC
Output Watts 3,200 Watts
Processor
Supported CPU
Series Intel Xeon Processor E5-2600/E5-2600 v2 series processors
Socket Type / Q'ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage Max up to 150W
System Bus Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
Chipset PCH Intel C602
Memory
Supported DIMM
Qty (12)+(12) DIMM slots
DIMM Type / Speed RDIMM ECC 1866/1600/1333/1066 /
UDIMM/LRDIMM ECC 1866/1600/1333/1066
Capacity up to 192GB UDIMM / 384GB RDIMM / 768GB
LRDIMM
Memory channel 4 Channels per CPU
Memory voltage 1.5V or 1.35V
Expansion Slots PCI-E (8) PCI-E Gen3 x16 slots / (2) PCI-E Gen3 x8 slots(one for mezzanine card) / (3) PCI-E Gen2 x1
slots
