TYAN GT20 B7002 User manual

TYAN®GT20
B7002
Service Engineer’s Manual

http://www.tyan.com
2

http://www.tyan.com
3
PREFACE
Copyright
This publication, including all photographs, illustrations, and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any material contained herein, may be reproduced
without written consent of manufacturer.
Copyright 2009 MiTAC International Corporation. All rights reserved.
TYAN®is a registered trademark of MiTAC International Corporation.
Version 1.10
Disclaimer
Information contained in this document is furnished by MiTAC Computer
Corporation and has been reviewed for accuracy and reliability prior to
printing. TYAN®assumes no liability whatsoever, and disclaims any
express or implied warranty, relating to sale and/or use of TYAN®products
including liability or warranties relating to fitness for a particular purpose or
merchantability. TYAN®retains the right to make changes to produce
descriptions and/or specifications at any time, without notice. In no event
will TYAN®be held liable for any direct or indirect, incidental or
consequential damage, loss of use, loss of data or other malady resulting
from errors or inaccuracies of information contained in this document.
Trademark Recognition
All registered and unregistered trademarks and company names contain-
-ed in this manual are property of their respective owners including, but not
limited to the following.
TYAN®is a trademark of MiTAC Computer Corporation
Intel®is a trademark of Intel®Corporation.
AMI®, AMIBIOS® and combinations thereof are trademarks of AMI
Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
IBM®, PC®, AT®and PS/2®are trademarks of IBM Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.

http://www.tyan.com
4
Federal Communication Commission (FCC)
Notice for the USA
Compliance Information Statement (Declaration of
Conformity Procedure) DoC FCC Part 15: This
device complies with part 15 of the FCC Rules
Operation is subject to the following conditions:
1) This device may not cause harmful interference;
2) This device must accept any interference received including
interference that may cause undesired operation. If this equipment
does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the
user is encouraged to try one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and the receiver.
– Plug the equipment into an outlet on a circuit different from that of
the receiver.
Consult the dealer on an experienced radio/television technician for
help.
Notice for Canada
This apparatus complies with the Class A limits for radio interference as
specified in the Canadian Department of Communications Radio
Interference Regulations. (Cet appareil est conforme aux norms de
Classe A d’interference radio tel que specifie par le Ministere Canadien
des Communications dans les reglements d’ineteference radio.)
Notice for Europe (CE Mark)
This product is in conformity with the Council
Directive 89/336/EEC, 92/31/EEC (EMC).
CAUTION: Lithium battery included with this board. Do not puncture,
mutilate, or dispose of battery in fire. There will be danger of explosion if
battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by manufacturer. Dispose of used battery according
to manufacturer instructions and in accordance with your local regulatio-
-ns.

http://www.tyan.com
5
About this Manual
This manual provides you with instructions on installing your
TYAN®GT20. This Manual is intended for experienced users and
integrators with hardware knowledge of personal computers.
This manual consists of the following parts:
Chapter1: Provides an introduction to the GT20-B7002 bare-
-bones, standard parts list, describes the external
components, gives a table of key components,
and provides block diagram of the system.
Chapter2: Covers procedures on installing the CPU, memory
modules and hard drives.
Chapter3:
Covers removal and replacement procedures for
pre-installed components.
Appendix:
List the BIOS differences, cable connection and FRU
part tables for reference of system setup, and
technical support in case a problem arises with your
system.
For information on the motherboard, please refer to the attached
motherboard user’s manual. You can find the detailed descripti-
-on about jumper and BIOS settings from the motherboard man-
-ual.

http://www.tyan.com
6
SAFETY INFORMATION
Before installing and using GT20-B7002, take note of the following
precautions:
·Read all instructions carefully.
·Do not place the unit on an unstable surface, cart, or stand.
·Do not block the slots and opening on the unit, which are provided for
ventilation.
·Only use the power source indicated on the marking label. If you are not
sure, contact the power company.
·The unit uses a three-wire ground cable, which is equipped with a third
pin to ground the unit and prevent electric shock. Do not defeat the pur-
-pose of this pin. If you outlet does not support this kind of plug, contact
your electrician to replace your obsolete outlet.
·Do not place anything on the power cord. Place the power cord where it
will not be in the way of foot traffic.
·Follow all warnings and cautions in this manual and on the unit case.
·Do not push objects in the ventilation slots as they may touch high volta-
-ge components and result in shock and damage to the components.
·When replacing parts, ensure that you use parts specified by the manuf-
-acturer.
·When service or repairs have been done, perform routine safety checks
to verify that the system is operating correctly.
·Avoid using the system near water, in direct sunlight, or near a heating
device.
·Cover the unit when not in use.

http://www.tyan.com
7
Table of Contents
Chapter 1: Overview.........................................................................9
1.1 About the TYAN GT20-B7002.................................................... 9
1.2 Product Models......................................................................... 10
1.3 Features ................................................................................... 11
1.4 Standard Parts List ................................................................... 15
1.4.1 Box Contents ..................................................................... 15
1.4.2 Accessories ....................................................................... 16
1.5 Optional Parts........................................................................... 17
1.6 About the Product..................................................................... 18
1.6.1 System Front View ............................................................ 18
1.6.2 System Rear View ............................................................. 18
1.6.3 LED Definitions.................................................................. 19
1.6.4 Motherboard (S7002) Layout ............................................ 21
1.6.5 Jumpers & Connectors ...................................................... 22
1.6.6 System Block Diagram ...................................................... 23
1.6.7 Internal View...................................................................... 24
Chapter 2: Setting Up..................................................................... 25
2.0.1 Before you Begin ............................................................... 25
2.0.2 Work Area.......................................................................... 25
2.0.3 Tools.................................................................................. 25
2.0.4 Precautions........................................................................ 26
2.1 Installing Motherboard Components ........................................ 27
2.1.1 Removing the Chassis Cover............................................ 27
2.1.2 Installing the CPU and Heatsink........................................ 28
2.1.3 Installing the Memory ........................................................ 31
2.1.4 Installing Hard Drives ........................................................ 35
2.2 Rack Mounting.......................................................................... 38
2.2.1 Installing the Server in a Rack........................................... 38

http://www.tyan.com
8
2.2.2 Installing the inner Rails to the Chassis ............................ 39
2.2.3 Installing the Outer Rails to the Rack ................................ 40
2.2.4 Rack mounting the Server................................................. 42
Chapter 3: Replacing Pre-Installed Components ........................ 45
3.1 Introduction ............................................................................. 45
3.2 Disassembly Flowchart........................................................... 45
3.3 Removing the Cover ............................................................... 46
3.3 Removing the Cover ............................................................... 47
3.4 Replacing Motherboard Components..................................... 47
3.4.1 Replacing Expansion Card................................................ 47
3.4.2 Disconnecting All Motherboard Cables ............................. 49
3.4.3 Removing the Motherboard............................................... 50
3.5 Replacing the LED Control Board .......................................... 51
3.5.1 M1008 LED Control Board Features ................................. 53
3.5.2 M1008 LED Control Board Connector Pin Definition ........ 53
3.6 Replacing the System Fan ..................................................... 54
3.7 Replacing the M1232 HDD/FAN Board .................................. 57
3.7.1 M1232 HDD/FAN Board Features..................................... 59
3.7.2 M1232 HDD/FAN Board Connector Pin Definitions .......... 61
Appendix I: BIOS Differences........................................................65
Appendix II: Replacing Slim DVD-ROM (Optional) ...................... 67
Appendix III: Cable Connection Tables ........................................69
Appendix IV: FRU Parts Table....................................................... 71
Appendix V: Technical Support ....................................................73

http://www.tyan.com
9
Chapter 1: Overview
1.1 About the TYAN GT20-B7002
Congratulations on your purchase of the TYAN®GT20-B7002, a highly-
-optimized rack-mountable barebone system. GT20-B7002 is designed to
support up to two Intel® “Nehalem-EP 2S” processors and up to 64GB
DDR3-800/1066/1333 memory, providing a rich feature set and incredible
performance. Leveraging advanced technology from Intel®, GT20-B7002
server system is capable of offering scalable 32 and 64-bit computing,
high bandwidth memory design, and lightning-fast PCI-E bus implementa-
-tion.GT20-B7002 not only empowers your company in nowadays IT
demand but also offers a smooth path for future application usage.
TYAN®is also proud to deliver GT20-B7002 in flavor while supporting up
to four hot-swap hard drives and one optional slim DVD ROM.
GT20-B7002 uses TYAN®’s latest chassis featuring a robust structure and
a solid mechanical enclosure. All of this provides GT20-B7002 the power
and flexibility to meet the needs of nowadays server application.

http://www.tyan.com
10
1.2 Product Models
Model HDD Bays Power supply
B7002G20V4H Removable,
4HDDs 400W single

http://www.tyan.com
11
1.3 Features
TYAN GT20-B7002 (B7002G20V4H)
Form Factor 1U Rackmount
Chassis Name GT20
Dimension (D x W x H) 22.4" x 17.2" x 1.72" (568 x 436 x 43.6mm)
Motherboard S7002GM2NR-LE
System
Gross Weight 17.7kg
Buttons (1) PWR / (1) RST / (1) NMI / (1) ID
LEDs
(1) PWR / (1) HDD / (2) LAN / (1) ID / (1)
Warning
Front Panel
I/O Ports (2) USB
Type / QTY 3.5" Hot-Swap / (4)
External Drive
Bay Supported HDD
Interface
1st priority: SATA
System Cooling
Configuration
FAN (5) 4cm fans
Type EPS1U
Input Range Full-range AC(100-240V)
Frequency 60 Hertz
Output Watts 400 Watts
Power Supply
Efficiency 80-plus
Supported CPU
Series
Intel Xeon 5500 series QC/DC processors
Socket Type / QTY LGA1366 / (2)
Processor
Thermal Design
Power (TDP) wattage
95W

http://www.tyan.com
12
Processor System Bus (MHz) 1333/1066/800
IOH / ICH Intel 5500 / ICH10R
Chipset
Super I/O Winbond W83627
Supported DIMM Qty (8) DIMM sockets
DIMM Type / Speed DDR3 800/1066/1333 RDIMM, UDIMM ECC
Capacity Up to 64GB
Memory channel 3-Channel
Memory
Memory voltage 1.5V
PCI-E (1) PCI-E x16 slot
Expansion
Slots Pre-install TYAN Riser
Card
M2083-RS, PCI-E x16 1U riser card (left)
Port QTY (2)
LAN
Controller Intel 82574
Connector type D-Sub 15pin
Resolution 1600x1200@60Hz
Graphic
Chipset Aspeed AST2050
USB 6 ports ( 2 at front, 4 at rear)
COM 1 port
VGA 1 port
I/O Ports
RJ-45 2 ports
Chipset Winbond W83793G
Voltage
Monitors voltage for CPU, memory, chipset &
power supply
System
Monitoring
Temperature
Monitors temperature for CPU & system
environment

http://www.tyan.com
13
LED
Fan fail LED indicator / Over temperature
warning indicator
System
Monitoring
Others Watch Dog timer support
Brand / ROM size 16MB / AMI
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0
/SMBIOS2.3 /PXE Boot / ACPI 2.0 power
management /Power on mode after power
recovery / User-configurable H/W monitoring /
Multiple boot options
Operation
System
OS supported list Please refer to our OS supported list.
FCC (Doc) Class A
CE (Doc) Yes
C-Tick Yes
Regulation
VCCI Yes
Operating Temp 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment In/Non-operating
Humidity
90%, non-condensing at 35° C
RoHS RoHS 6/6 Complaint Yes
Motherboard (1) S7002GM2NR-LE
Manual (1) User's manual / (1) Quick Ref. Guide
Installation CD (1) TYAN installation CD
I/O Shield (1) I/O Shield
Package
Contains
Chassis Unit
(1) CCHA-0350, GT20 1U chassis unit (for
B7002)

http://www.tyan.com
14
Cover (1) CCCV-0140, Top cover for GT20 (B7002)
HDD Tray (4) CHDT-0051, Removable 3.5" HDD Tray
Heatsink / Cooler
(5) CFAN-0241, 4 cm fans / (1) CHSK-0370,
LGA1366 CPU heatsinks / (1) M1232, fan/ HDD
adapter board
Riser Card (1) M2083-RS, PCI-E x16 riser card
Front Panel board (1) M1008, front panel board
Power Supply (1) CPSU-0281, 400W 1U (80 plus) single PSU
SATA (1) CCBL-067N, Mini SAS cable
USB (1) CCBL-035B, USB cable
FAN (1) CCBL-0391, Fan cable
Front Panel (1) CCBL-072N, front panel cable
Package
Contains
Cable
Power Cord
(1) CCBL-0310, US type power cord / (1)
CCBL-0300, EU type power cord
Front Bezel
(1) CFBZ-0070, Front bezel for GT series 1U
chassis
Rack Mounting Part
(1) CRAL-0032, Rail kit / (1) CEAR-0050,
mounting ear kit
Optional
accessories for
future upgrade
Peripheral
(1) CDVD-0060, slim type DVD-ROM / (1)
CCBL-0422, slim ODD SATA cable(1)
CCBL-0326,SATA cable

http://www.tyan.com
15
1.4 Standard Parts List
This section describes GT20-B7002 package contents and accessories.
Open the box carefully and ensure that all components are present and
undamaged. The product should arrive packaged as illustrated below.
1.4.1 Box Contents
Component Description
1U chassis,(4) hot swap HDDbays
TYAN®S7002 system board
(pre-installed)
400W single Power Supply
(5) System FAN
M1008：
LED control board (pre-installed)
M1232 HDD/Fan Board
M2083-RS PCI-E riser card

http://www.tyan.com
16
1.4.2 Accessories
If any items are missing or appear damaged, contact your retailer or
browse to TYAN®’s website for service: http://www.tyan.com
The web site also provides information of other TYAN®products, as
well as FAQs, compatibility lists, BIOS settings, etc.
1 x TYAN®
Motherboard
Drive CD
1 x Heatsink
HDD Screws Power Cables
Left to right: Europe, US
Mounting Ears &
Screws
Barebone Manual &
Mainboard Manual

http://www.tyan.com
17
Rail Kit
Rail with Bracket x 2 Screw Sack
1.5 Optional Parts
Item
Model
Number
Picture Quantity Description
DVD-ROM CDVD-0060 1 Slim DVD drive, SATA
Chassis
Front-Bezel CFBZ-0070 1 Front Bezel for GT series 1U
chassis

http://www.tyan.com
18
1.6 About the Product
The following views show you the product.
1.6.1 System Front View
LED control board
DVD-Rom drive (Optional)
USB ports ID button Reset button
NMI button
1.6.2 System Rear View
Power supply
USB ports
Serial port & VGA port
LAN1
USB ports
HDD LED
(
NIC3
)
Hot SWAP HDD Ba
y
s
ID LED
Warnin
g
LED
Power Status LED(PSMI)
Power button
(
with LED
)
NIC2
NIC1
LAN2

http://www.tyan.com
19
1.6.3 LED Definitions
Front Panel
LED State Color Description
On Green System is turned on
Blink Green System is under S1 or S3 state
Power
LED
Off Off Power off
Off Off HDD not active
HDD
LED(NIC3) Blinking Green HDD active
Blinking Green LAN active
On Green LAN linked
NIC1
off off LAN not linked
Blinking Green LAN active
On Green LAN linked
NIC2
off off LAN not linked
On Red Fan fail /Over temperature
/Over voltage
Warning
LED Off Off No failure
On Blue System identified
ID LED Off Off System not identified
Rear I/O
LAN1
LED State Color Description
On Green 10Mb/100Mb/1000Mb linked
Blinking Green 10Mb/100Mb/1000Mb activity
RJ-45
Linkage/
Activity(left) Off Off No LAN linked
On Amber 1000Mb linked/activity
On Green 100Mb linked/activity
RJ-45
Linkage/
Activity(Right) Off Off 10Mb mode or No LAN linked
NOTE: “Left” and “Right” are viewed from the rear panel.

http://www.tyan.com
20
LAN2 (shared by BMC)
LED State Color Description
On Green 10Mb/100Mb/1000Mb linked
Blinking Green 10Mb/100Mb/1000Mb activity
RJ-45 Linkage/
Activity(left) Off Off No LAN linked
On Amber 1000Mb linked/activity
On Green 100Mb linked/activity
RJ-45 Linkage/
Activity(Right) Off Off 10Mb mode or No LAN linked
ID LED
LED State Color Description
On Blue System identified
ID LED Off Off System not identified
Note: Press ID button when the system is AC (Alternating Current) on, then ID
LED will show the system is identified with emitting blue light. Users from
remote site could also activate ID LED by input a few commands in IPMI,
detailed software support please visit http://www.tyan.com for lastest
AST2050 user guide.
