TYAN FT72 B7015 Quick start guide

http://www.tyan.com
1
TYAN®FT72
B7015
Service Engineer’s Manual

http://www.tyan.com
2

http://www.tyan.com
3
PREFACE
Copyright
This publication, including all photographs, illustrations, and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any material contained herein, may be
reproduced without written consent of manufacturer.
Copyright 2009 MiTAC International Corporation. All rights reserved.
TYAN® is a registered trademark of MiTAC International Corporation.
Version 1.00
Disclaimer
Information co ntained in th is docume nt is furnis hed b y Mi TAC Computer
Corporation a nd h as be en r eviewed for accuracy a nd r eliability prior to
printing. T YAN® assumes no li ability whatsoever, an d disclaims a ny
express or implied warranty, relating to sale and/or use of T YAN® products
including liability or warranties relating to fitness for a partic ular purpose or
merchantability. T YAN® retains the right to make cha nges to prod uce
descriptions and/or sp ecifications at a ny time, without notice. In no ev ent
will T YAN® b e held li able for any dir ect or indirect, incide ntal or
consequential damage, loss of use, lo ss of data or other malady resulting
from errors or inaccuracies of information contained in this document.
Trademark Recognition
All registered and unregistered trademarks and company names contain-
-ed in this manual are property of their respective owners including, but not
limited to the following.
TYAN® is a trademark of MiTAC Computer Corporation.
Intel® is a trademark of Intel Corporation.
AMI®, AMIBIOS® and combinations thereof are trademarks of AMI
Technologies.
Microsoft®, Windows® are trademarks of Microsoft Corporation.
Winbond® is a trademark of Winbond Electronics Corporation.
Portable Document Format (PDF) is a trademark of Adobe Corporation.

http://www.tyan.com
4
Federal Communication Commission (FCC)
Notice for the USA
Compliance Information Statement (Declaration of
Conformity Procedure) DoC FCC Part 15: This
device complies with part 15 of the FCC Rules
Operation is subject to the following conditions:
1) This device may not cause harmful interference;
2) This device must accept an y interference re ceived i ncluding
interference that may cause undesired operation. If this equipment
does ca use harmful interfer ence to ra dio or televis ion r eception,
which can be determined by turning the equipment off and on, the
user is encouraged to try one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and the receiver.
– Plug the equipment into an outlet on a circuit different from that of
the receiver.
Consult the dealer on an experienced radio/television technician for
help.
Notice for Canada
This apparatus complies with the Class A limits for radio interference as
specified in the Can adian Depar tment of Communic ations Ra dio
Interference R egulations. (Cet appar eil es t conforme au x norms d e
Classe A d’interference radio tel que specifie par le Min istere Canadien
des Communications dans les reglements d’ineteference radio.)
Notice for Europe (CE Mark)
This product is in conformity with the Council
Directive 89/336/EEC, 92/31/EEC (EMC).
CAUTION: Lit hium b attery included with t his bo ard. D o not pu ncture,
mutilate, or dispose of battery in fire. There will be danger of explosion if
battery is incorrectly replaced. Replace only with the same or equivalent
type recommended by manufacturer. Dispose of used battery according
to manufacturer instructions and in accordance with your local regulatio-
-ns.

http://www.tyan.com
5
About this Manual
This manual provides you with instructions on installing your
FT72-B7015. This Manual is intended for experienced users and
integrators with hardware knowledge of personal computers.
This manual is consisted of the following parts:
Chapter1: Provides an introduction to the FT72-B7015 bare-
-bones, standard parts list, describes the external
components, gives a table of key components,
and provides block diagrams of the system.
Chapter2: Covers procedures on installing the CPU, memory
modules, add on card and hard drives.
Chapter3:
Covers removal and replacement procedures for
pre-installed components.
Appendix :
Describes the differences between motherboard
BIOS and system BIOS; introduces how to install
the internal HDD, list the cable connection and
FRU part tables for reference of system setup;
and technical support in case a problem arises
with your system.
For information on the mainboard, please refer to the attached
mainboard user’s manual. You can find the detailed description
about jumper and BIOS settings from the mainboard manual.

http://www.tyan.com
6
SAFETY INFORMATION
Before instal ling and us ing FT 72-B7015, take note of the follo wing
precautions:
·Read all instructions carefully.
·Do not place the unit on an unstable surface, cart, or stand.
·Do not bloc k the slots and ope ning on the unit, which are provid ed for
ventilation.
·Only use the power source indicated on the marking label. If you are not
sure, contact the power company.
·The unit uses a three-wire ground cable, which is equipped with a third pin
to ground the unit and prevent electric shock. Do not defeat the pur-
-pose of this pin. If you outlet does not support this kind of plug, contact
your electrician to replace your obsolete outlet.
·Do not place anything on the power cord. Place the power cord where it will
not be in the way of foot traffic.
·Follow all warnings and cautions in this manual and on the unit case.
·Do not push objects in the ventilation slots as they may touch high volta-
-ge components and result in shock and damage to the components.
·When replacing parts, ensure that you use parts specified by the manuf-
-acturer.
·When service or repairs have been done, perform routine safety checks
to verify that the system is operating correctly.
·Avoid usi ng the s ystem ne ar water, in dir ect sunlig ht, or near a heatin g
device.
·Cover the unit when not in use.

http://www.tyan.com
7
Table of Contents
Chapter 1: Overview......................................................................9
1.1 About the TYAN FT72-B7015 .................................................9
1.2 Product Models......................................................................10
1.3 Feat ures ................................................................................11
1.4 Standard Parts List ................................................................13
1.4.1 Box Contents ..................................................................13
1.4.2 Ac cessories ....................................................................15
1.5 Optional Parts........................................................................16
1.6 About the Product..................................................................17
1.6.1 Sys tem Front View .........................................................17
1.6.2 Sys tem Rear View .......................................................... 17
1.6.3 LED Definitions...............................................................17
1.6.4 Motherboa rd Layout .......................................................19
1.6.5 J umpers & Connectors...................................................20
1.6.6 Sys tem Block Diagram ...................................................25
1.6.7 Inter nal View...................................................................26
Chapter 2: Setting Up..................................................................27
2.0.1 Before you Begin............................................................27
2.0.2 Work Area.......................................................................27
2.0.3 T ools...............................................................................27
2.0.4 Prec autions..................................................................... 28
2.1 Installing Motherboard Components .....................................29
2.1.1 Removing the Chassis Cover.........................................29
2.1.2 Ins talling the CPU and Heatsink.....................................30
2.1.3 Ins talling the Memory .....................................................32
2.1.4 Installing Expansion Cards.............................................35
2.1.5 Ins talling Hard Drives .....................................................37
2.2 Rack Mounting.......................................................................38
2.2.1 Ins talling the Server in a Rack........................................38
2.2.2 Ins talling the inner Rails to the Chassis .........................39
2.2.3 Ins talling the Outer Rails to the Rack .............................40
2.2.4 Rack mounting the Server..............................................40
Chapter 3: Replacing Pre-Installed Components .....................43
3.1 Intr oduction............................................................................43
3.2 Dis assembly Flowchart..........................................................43

http://www.tyan.com
8
3.3 Removing the Cover..............................................................44
3.4 Replaci ng the Power Supply .................................................44
3.4.1 Replac e the power supply ..............................................44
3.4.2 Replacing M7015 Power Distribution Board ..................45
3.4.3 M7015 Power Distribution Board Features ....................46
3.4.4 Replac e the M7015 power backplane ............................47
3.4.5 M7015 power backplane Features .................................48
3.5 Replac ing M7015 I/O Board ..................................................49
3.6 Replac ing the LED Control Board .........................................51
3.6.1 M1008 LED Control Board Features .............................. 52
3.6.2 M1008 LED Control Board Connector Pin Definition .....53
3.7 Replac ing the System Fan ....................................................54
3.8 Removing the Motherboard...................................................56
Appendix I: BIOS Differences.....................................................57
Appendix II: Installing the Internal 3.5”HDD..............................59
Appendix III: Cable Connection Tables .....................................61
Appendix IV: FRU Parts Table....................................................63
Appendix V: Technical Support .................................................65

http://www.tyan.com
9
Chapter1:Overview
1.1 About the TYAN FT72-B7015
Congratulations on your purc hase of the T YAN® FT 72-B7015, a hig hly
optimized rack-mountable 4U barebone system. FT72-B7015 is designed
to support dual Intel® Nehalem-EP/Nehalem-WS 2S processors and up to
6 cha nnels with 18 DD R3 DIMMs, provid ing a rich fe ature set an d
incredible perf ormance. Leverag ing adv anced techno logy from Intel ®,
FT72-B7015 server s ystem is capable of offering scal able 32 and 64-b it
computing, high-bandwidth memory design, and l ightning-fast PCI-E bus
implementation. FT72-B7015 not only enpowers your company in today’s
demanding IT environm ent but also offers a smooth path for future
application usage.
FT72-B7015 uses rack-mountable 4U chassis featuring a robust structure
and a soli d mecha nical encl osure. All of this provi des F T72-B7015 the
power and flexibility to meet the needs of nearly any server application.

http://www.tyan.com
10
1.2 Product Models
Model HDD Bays Power supply
B7015F72V2 Support 2 internal 2.5”
SATAII HDD
2400W(1200W+1200W)
PWR supply

http://www.tyan.com
11
1.3 Features
TYAN FT72B7015 (B7015F72V2)
Form Factor 4U Rackmount
Chassis Model FT72
Dimension (D x W x
H) 27.96" x 17.245" x 6.93" (710 x 438 x 176mm)
Motherboard S7015
Board Dimension 16"x19" (406.4x482.6mm)
System
Gross Weight 32KG
Buttons (1) PWR / (1) RST / (1) NMI / (1) ID
LEDs (1) PWR / (1) HDD / (1) Warning
Front Panel I/O Ports (2) USB ports
Type / QTY (2) 2.5" fixed [ or (1) 3.5" fixed, optional ]
Internal Drive
Bay Supported HDD
Interface SATA-II 3.0Gb/s
System Cooling
Configuration FAN (3) 12cm fans
Type ERP1U
Input Range Full-range AC(100-240V)
Frequency 60 Hertz
Output Watts 2400 Watts(1200W+1200W)
Efficiency PFC
Redundancy 2+1(Optional)
Power Supply
Serviceability Hot-swap
Supported CPU
Series Intel Xeon Processor 5500 Series
Socket Type / QTY LGA1366 / (2)
Thermal Design
Power (TDP) wattage Max up to 130W
Processor
System Bus Up to 4.8/ 5.86/ 6.4GT/s with Intel Quick Path
Interconnect (QPI) support
IOH / ICH Intel (2) 5520 / ICH10R
Super I/O Winbond W83627
Chipset PCI-E Switch PLX PEX8647
Supported DIMM Qty (9)+(9) DIMM slots
DIMM Type / Speed DDR3 800/1066/1333* RDIMM/UDIMM / * limit 1
per channel for 1333MHz speed
Capacity Up to 144GB at launch w/ dual rank RDIMMs
Memory channel 3 Channels per CPU
Memory
Memory voltage 1.5V

http://www.tyan.com
12
Expansion Slots PCI-E (8) PCI-E Gen.2 x16 slots
Port QTY (4)
LAN Controller Intel 82574L
Connector type D-Sub 15-pin
Resolution 1600x1200
Graphic Chipset Aspeed AST2050
USB (2) ports
VGA (1) D-Sub 15-pin port
I/O Ports RJ-45 (4) ports
Chipset Winbond W83793G
Voltage Monitors voltage for CPU, memory, chipset &
power supply
Temperature Monitors temperature for CPU & system
environment
System
Monitoring
LED Fan fail LED indicator / Over temperature
warning indicator
Onboard Chipset Onboard Aspeed AST2050
AST2050 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / BIOS update / USB 2.0 virtual
hub
Server
Management AST2050 iKVM
Feature 24-bit high quality video compression / Dual 10/100 Mb/s MAC interfaces
Brand / ROM size AMI / 4MB
BIOS Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0
/SMBIOS2.3 /PXE boot / ACPI 2.0 power
management /Power on mode after power
recovery / User-configurable H/W monitoring
Operating
System OS supported list Please refer to our OS supported list.
FCC (DoC) Class A
Regulation CE (DoC) Yes
Operating Temp. 0° C ~ 55° C (32° F~ 131° F)
Non-operating
Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment In/Non-operating
Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Complaint Yes
Barebone (1) F72-B7015 Barebone
Manual (1) BB User's manual
Installation CD (1) TYAN installation CD
Package
Contains
Heatsink / Cooler (2) CHSK-0410, 1366-pin CPU heatsinks

http://www.tyan.com
13
Rail kit (1) CRAL-0150, sliding rail kit
Mounting Ear (1) CEAR-0150, mounting ear kit for FT72
Others (1) 2.5" HDD screw pack / (1) 3.5" HDD screw
pack +(1) 3.5" HDD bracket
Package
Contains
Cable/Power Cord
(2) CCBL-0312, US type power cord /
(2) CCBL-0313, EU type power cord
(8) CCBL-146I, 2*4pin PWR cable for GPU card
(8) CCBL-146H,2*3pin PWR cable for GPU card
1.4 Standard Parts List
This section describ es FT72-B7015 package co ntents an d
accessories. Open th e box carefully and ensure that all components
are present and undamaged. The product should arrive packaged as
illustrated below.
1.4.1 Box Contents
Component Description
4U FT72 Chassis
Main Board,S7015-CA
1200W Power Supply

http://www.tyan.com
14
120 x120 x38 MM Fan
M1008
Front LED control Board(R02)
M7015
Rear I/O Board
M7015-PBP
PWR Backplane Board(R01)
M7015-PDB
PWR Distribution board for PCI-E
card(R01)

http://www.tyan.com
15
1.4.2 Accessories
If any items are missing or appear damaged, contract your retailer
or browse to TYAN®’s website for service: http://www.tyan.com.
The Web site also provides information on other TYAN® products,
plus FAQs, compatibility lists, BIOS settings, and more.
1 x TYAN® Motherboard
Drive CD 2 x Heatsink
HDD Screws Po wer Cables
Left to right: Europe, US
Mounti ng Ears & Screws Bareb one Manual
Rail Kit
Rail with Bracket x 2 Screw Sack

http://www.tyan.com
16
1.5 Optional Parts
Item Model
Number Picture Quantity Description
HDD Bracket CHDT-0120 1 3.5" HDD Bracket

http://www.tyan.com
17
1.6 About the Product
The following views show you the product.
1.6.1 System Front View
USB ports ID button Power button (with LED)
Warning LED
NMI button HDD LED
Reset button
1.6.2 System Rear View
Power Supply Expansionslots
LAN Port USB Port
VGA Port ID LED

http://www.tyan.com
18
1.6.3 LED Definitions
Front Panel
LED State Color Description
On Green System is turned on
On Amber System is turned off
Power
LED Off Off Power off
On Green HDD power on
Blinking Green HDD active
On Amber HDD error
Blinking Amber HDD rebuild
HDD LED
Random Green/Amber HDD locate
Warning
LED On Red Fan fail/PSU fail/Over
temperature/Over voltage
Rear I/O LED
LED State Color Description
On Green 10Mb/100Mb/1000Mb linked
Blinking Green 10Mb/100Mb/1000Mb activity
RJ-45 Linkage/
Activity(Left) Off Off No LAN linked
On Amber 1000Mb linked/ activity
On Green 100Mb linked/activity
RJ-45 Linkage/
Activity(Right) Off Off 10Mb mode or No LAN linked
NOTE: “Left” and “Right” are viewed from the rear panel.
ID LED
LED State Color Description
On Blue System identified
ID LED Off Off System not identified
Note:
Press ID button when the system is AC (Alternating Current) on, then ID LED
will show the system is identified with emitting blue light. Users from remote
site could also activate ID LED by input a few commands in IPMI, detailed
software support please visit http://www.tyan.com for latest AST2050 user
guide.

http://www.tyan.com
19
1.6.4 Motherboard Layout
The diagram is representative of the latest board revision available at the time of
publishing. The board you receive may not look exactly like the above diagram.

http://www.tyan.com
20
1.6.5 Jumpers & Connectors
Jumper/Connector Function
CN17/CN20 COM port
CN18 Board-to-Board Receptacle connector
CN19 USB header
CN43 Front Panel header
CN36/CN37/CN40 FAN connector
CN101 Clear CMOS
CN61 System Intrusion header
CN73 NMI button header
CN74 ID button header
