TYAN GT62F-B5630 Quick start guide

GT62F-B5630
Service Engineer’s Manual

PREFACE
Copyright
This publication, including all photographs, illustrations, and software, is
protected under international copyright laws, with all rights reserved.
Neither this manual, nor any material contained herein, may be reproduced without
written consent of manufacturer.
Copyright 2017 MITAC COMPUTING TECHNOLOGY CORPORATION. All rights
reserved. TYAN®is a registered trademark of MITAC COMPUTING TECHNOLOGY
CORPORATION.
Version 1.0b
Disclaimer
Information contained in this document is furnished by MiTAC COMPUTING
TECHNOLOGY CORPORATION and has been reviewed for accuracy and
reliability prior to printing. TYAN®assumes no liability whatsoever, and disclaims
any express or implied warranty, relating to sale and/or use of TYAN®products
including liability or warranties relating to fitness for a particular purpose or
merchantability. TYAN®retains the right to make changes to produce descriptions
and/or specifications at any time, without notice. In no event will TYAN®be held
liable for any direct or indirect, incidental or consequential damage, loss of use, loss
of data or other malady resulting from errors or inaccuracies of information
contained in this document.
Trademark Recognition
All registered and unregistered trademarks and company names contain- -ed in
this manual are property of their respective owners including, but not limited to the
following.
TYAN®is a trademark of MiTAC COMPUTING TECHNOLOGY CORPORATION.
Intel®is a trademark of Intel Corporation.
AMI®, AMIBIOS®and combinations thereof are trademarks of AMI Technologies.
Microsoft®, Windows®are trademarks of Microsoft Corporation.
IBM®, PC®, AT®and PS/2®are trademarks of IBM Corporation.
Winbond®is a trademark of Winbond Electronics Corporation.

FCC Declaration
Notice for the USA
Compliance Information Statement (Declaration of Conformity Procedure) DoC
FCC Part 15: This device complies with part 15 of the FCC Rules
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following conditions:
·This device may not cause harmful interference.
·This device must accept any interference received, including interference that may
cause undesirable operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Notice for Canada
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la Classe A est conforme àla norme NMB-003 du Canada.
Notice for Europe (CE Mark)
This product is in conformity with the Council Directive 2014/30/EU.
Warning

This equipment is compliant with Class A of CISPR 32. In a residential environment
this equipment may cause radio interference.
CAUTION
Lithium battery included with this board. Do not puncture, mutilate, or dispose of
battery in fire. There will be danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by manufacturer.
Dispose of used battery according to manufacturer instructions and in accordance
with your local regulations.
●VCCI-A
この装置は、クラスＡ情報技術装置です。この装置を家庭環境で使用すると電波
妨害を引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう
要求されることがあります。
●Safety: IEC/EN 60950-1
This equipment is compliant with CB/LVD of Safety: IEC/EN 60950-1.

About this Manual
This Manual is intended for experienced users and integrators with
hardware knowledge of personal computers.
It is aimed to provide you with instructions on installing your TYAN
GT62F-B5630.
How this guide is organized
This guide contains the following parts:
Chapter 1: Overview
This chapter give an introduction to theGT62F-B5630 barebones, standard
parts list, and accessories. describes the external components, gives a table of
key
Chapter2: Setting Up
This chapter Covers procedures on installing the CPU, memory modules, add
on card and hard drives. Give an overview about theGT62F-B5630 barebone
from an overall angle.
Chapter 3: Replacing the Pre-installed Components
This chapter covers the removal and replacement procedures for pre-installed
components.
Appendix:
This chapter provides the cable connection table, the FRU parts list for reference of
system setup, and technical support in case a problem arises with your system.

Safety and Compliance Information
Before installing and using TYANGT62F-B5630, take note of the following
precautions:
·Read all instructions carefully.
·Do not place the unit on an unstable surface, cart, or stand.
·Do not block the slots and opening on the unit, which are provided for
ventilation.
·Only use the power source indicated on the marking label. If you are not sure,
contact the power company.
·The unit uses a three-wire ground cable, which is equipped with a third pin to
ground the unit and prevent electric shock. Do not defeat the purpose of this
pin. If your outlet does not support this kind of plug, contact your electrician
to replace your obsolete outlet.
·Do not place anything on the power cord. Place the power cord where it will
not be in the way of foot traffic.
·Follow all warnings and cautions in this manual and on the unit case.
·Do not push objects in the ventilation slots as they may touch high voltage
components and result in shock and damage to the components.
·When replacing parts, ensure that you use parts specified by the
manufacturer.
·When service or repairs have been done, perform routine safety checks to
verify that the system is operating correctly.
·Avoid using the system near water, in direct sunlight, or near a heating
device.
·Cover the unit when not in use.

Safety Information
Retain and follow all product safety and operating instructions provided with your
equipment. In the event of a conflict between the instructions in this guide and the
instructions in equipment documentation, follow the guidelines in the equipment
documentation.
Observe all warnings on the product and in the operating instructions. To
reduce the risk of bodily injury, electric shock, fire and damage to the equipment,
observe all precautions included in this guide.
You must become familiar with the safety information in this guide before you
install, operate, or service TYAN products.
Symbols on Equipment
Caution. This symbol indicates a potential hazard.
The potential for injury exists if cautions are not
observed. Consult equipment documentation for
specific details.
Caution. Slide-mounted equipment is not to be
used as a shelf or a work space.
Warning. This symbol indicates the presence of
hazardous energy circuits or electric shock
hazards. Refer all servicing to qualified personnel.
Warning. This symbol indicates the presence of a
hot surface or hot component. If this surface is
contacted, the potential for injury exists.
To reduce risk of injury from a hot component,
allow the surface to cool before touching.
Warning. Hazardous moving parts keep away
from moving fan blades.
General Precautions
·Follow all caution and warning instructions marked on the equipment and
explained in the accompanying equipment documentation.

Machine Room Environment
·This device is for use only in a machine room or IT room.
 ·Make sure that the area in which you install the system is properly
ventilated and climate-controlled.
·Ensure that the voltage and frequency of your power source match the
voltage and frequency inscribed on the electrical rating label of the
equipment.
·Do not install the system in or near a plenum, air duct, radiator, or heat
register.
·Never use the product in a wet location.
Equipment Chassis
·Do not block or cover the openings to the system.
·Never push objects of any kind through openings in the equipment.
Dangerous voltages might be present.
·Conductive foreign objects can produce a short circuit and cause fire,
electric shock, or damage to your equipment.
·Lift equipment using both hands and with your knees bent.
Equipment Racks
To avoid injury or damage to the equipment:
·Observe local occupational health and safety requirements and guidelines
for manual materials handling.
·Do not attempt to move a rack by yourself; a minimum of two people are
needed to move a rack.
·Do not attempt to move a fully loaded rack. Remove equipment from the
rack before moving it.
·Do not attempt to move a rack on an incline that is greater than 10 degrees
from the horizontal.
·Make sure the rack is properly secured to the floor or ceiling.
·Make sure the stabilizing feet are attached to the rack if it is a single-rack
installation.
·Make sure racks are coupled together if it is a multiple-rack installation.
·Make sure the rack is level and stable before installing an appliance in the

rack.
·Make sure the leveling jacks are extended to the floor.
·Make sure the full weight of the rack rests on the leveling jacks.
·Always load the rack from the bottom up. Load the heaviest component in
the rack first.
·Make sure the rack is level and stable before pulling a component out of the
rack.
·Make sure only one component is extended at a time. A rack might become
unstable if more than one component is extended.
To avoid damage to the equipment:
·The rack width and depth must allow for proper serviceability and cable
management.
·Ensure that there is adequate airflow in the rack. Improper installation or
restricted airflow can damage the equipment.
·The rack cannot have solid or restricted airflow doors. You must use a mesh
door on the front and back of the rack or remove the doors to ensure adequate
air flow to the system.
·If you install the Model in a rack, do not place equipment on top of the unit. It
will cause restricted airflow and might cause damage to the equipment.
·Make sure the product is properly matted with the rails. Products that are
improperly matted with the rails might be unstable.
·Verify that the AC power supply branch circuit that provides power to the rack is
not overloaded. This will reduce the risk of personal injury, fire, or damage to the
equipment. The total rack load should not exceed 80 percent of the branch circuit
rating. Consult the electrical authority having jurisdiction over your facility wiring
and installation requirements.
·Verify that the AC power supply branch circuit that provides power to the rack is
not overloaded. This will reduce the risk of personal injury, fire, or damage to the
equipment. The total rack load should not exceed 80 percent of the branch circuit
rating. Consult the electrical authority having jurisdiction over your facility wiring
and installation requirements.
·Verify that the AC power supply branch circuit that provides power to the rack is
not overloaded. This will reduce the risk of personal injury, fire, or damage to the
equipment. The total rack load should not exceed 80 percent of the branch circuit
rating. Consult the electrical authority having jurisdiction over your facility wiring
and installation requirements.
·When use 100V-127VAC input: The system does not support redundant PSU
operation if the total system load exceeds 20A.

Equipment Power Cords
·Use only the power cords and power supply units provided with your system.
The system might have one or more power cords.
·Plug the power cord into a grounded (earthed) electrical outlet that is easily
accessible at all times.
·In all European electrical environments, you must ground the Green/Yellow tab
on the power cord. If you do not ground the Green/Yellow tab, it can cause an
electrical shock due to high leakage currents.
·Do not place objects on AC power cords or cables. Arrange them so that no one
might accidentally step on or trip over them.
·Do not pull on a cord or cable. When unplugging from the electrical outlet, grasp
the cord by the plug.
·To reduce the risk of electrical shock, disconnect all power cords before
servicing the appliance.
Equipment Batteries
·The system battery contains lithium manganese dioxide. If the battery pack is
not handled properly, there is risk of fire and burns.
·Do not disassemble, crush, puncture, short external contacts, or dispose of the
battery in fire or water.
·Do not expose the battery to temperatures higher than 60°C (140°F).
·The system battery is not replaceable. If the battery is replaced by an incorrect
type, there is danger of explosion. Replace the battery only with a spare
designated for your product.
·Do not attempt to recharge the battery.
·Dispose of used batteries according to the instructions of the manufacturer. Do
not dispose of batteries with the general household waste. To forward them to
recycling or proper disposal, use the public collection system or return them to
TYAN, your authorized TYAN partner, or their agents.
Equipment Modifications
·Do not make mechanical modifications to the system. TYAN is not responsible
for the regulatory compliance of TYAN equipment that has been modified.
Equipment Repairs and Servicing
·The installation of internal options and routine maintenance and service of this
product should be performed by trained service technician/personnel who are

knowledgeable about the procedures, precautions, and hazards associated with
equipment containing hazardous energy levels.
·Do not exceed the level of repair specified in the procedures in the product
documentation. Improper repairs can create a safety hazard.
·Allow the product to cool before removing covers and touching internal
components.
·Remove all watches, rings, or loose jewelry when working before removing
covers and touching internal components.
·Do not use conductive tools that could bridge live parts.
·Use gloves when you remove or replace system components; they can become
hot to the touch.
·If the product sustains damage requiring service, disconnect the product from
the AC electrical outlet and refer servicing to an authorized service provider.
Examples of damage requiring service include:
–The power cord, extension cord, or plug has been damaged.
–Liquid has been spilled on the product or an object has fallen into the product.
–The product has been exposed to rain or water.
–The product has been dropped or damaged.
–The product does not operate normally when you follow the operating
instructions.

Table of Contents
Chapter 1: Overview .....................................................................14
1.1 About the TYAN GT62F-B5630...........................................14
1.2 Product Models....................................................................14
1.3Standard Parts List..............................................................24
1.3.1 Box Contents................................................................24
1.3.2 Accessories ..................................................................25
1.4About the Product................................................................25
1.4.1 System Front View .......................................................25
1.4.2 System Rear View........................................................27
1.4.3 LED Definitions.............................................................27
1.4.4 Internal View.................................................................28
Chapter 2: Setting Up ...................................................................30
2.0.1 Before you Begin..........................................................30
2.0.2 Work Area.....................................................................30
2.0.3 Tools.............................................................................30
2.0.4 Precautions...................................................................30
2.1 Installing Motherboard Components ...................................31
2.1.1 Removing the Chassis Cover.......................................32
2.1.2 Removing the Air Duct..................................................32
2.1.3Installing the CPU and Heat sink..................................33
2.1.4Installing the Memory ...................................................35
2.1.5Installing Hard Drives ...................................................37
2.1.6 Installing the Add-On Card...........................................39
2.2 Rack Mounting.....................................................................41
2.2.1 Installing the Server in a Rack......................................43
2.2.2 Installing the inner Rails to the Chassis .......................43
2.2.3 Installing the Outer Rails to the Rack...........................45
2.2.4 Rack mounting the Server............................................45
Chapter 3: Replacing Pre-Installed Components......................48
3.1 Introduction..........................................................................48
3.2 Disassembly Flowchart........................................................48
3.3 Removing the Cover............................................................48
3.4Replacing the Riser Card ....................................................49
3.5Replacing the System Fan ..................................................49
3.6Replacing the HDD Backplane............................................50
3.6.1 HDD Backplane Features.............................................52
3.6.2 Connector Definition.....................................................53
3.6.3 Connector Definition.....................................................55
3.6.4 HDD BP Board LED Definitions ...................................60
3.7Replacing the Front Panel Board ........................................61
3.7.1 Front Panel Board Features.........................................63

3.7.2 Connector Definition.....................................................64
3.8Replacing the Power Supply ...............................................65
3.9Replacing the Power Distribution Board..............................66
3.9.1 Front Panel Board Features.........................................67
3.9.2 Connector Definitions...................................................68
3.10 Replacing the Motherboard .........................................71
Appendix I: Cable Connection Tables ........................................73
Appendix II: Fan and Temp Sensors...........................................76
Appendix III: FRU Parts Table......................................................79
Appendix IV: Technical Support..................................................81

Chapter 1: Overview
1.1 About the TYAN GT62F-B5630
Congratulations on your purchase of the TYAN®GT62F-B5630, a highly optimized
rack-mountable 1U barebone system.GT62F-B5630 is designed to support single
Intel® Xeon® Scalable Processor Families and Up to 384GB RDIMM/ 768GB
LRDIMM/ 1,536GB RDIMM 3DS/LRDIMM 3DS DDR4 Memory, providing a rich
feature set and incredible performance. Leveraging advanced technology from
Intel®,GT62F-B5630 server system is capable of offering scalable 32 and 64-bit
computing, high-bandwidth memory design, and lightning-fast PCI-E bus
implementation.GT62F-B5630 not only empowers your company in today’s
demanding IT environment but also offers a smooth path for future application
usage.
TYAN®also offers theGT62F-B5630 in a version that can support up to ten 2.5”
Hot-Swap SSDs/HDDs.GT62F-B5630 uses rack-mountable 1U chassis featuring a
robust structure and a solid mechanical enclosure. All of this provides
GT62F-B5630 the power and flexibility to meet the needs of nearly any server
application.
1.2 Product Models
The system board within the Tyan MicroServer blade contains different processors
and chipsets, which are defined by the following models:
 B5630G62FV6E4HR: Intel-based platform
 B5630G62FV2E8HR: Intel-based platform
 B5630G62FV10HR: Intel-based platform


1.3Features
B5630G62FV6E4HR Specifications
System
Form Factor
1U Rackmount
Chassis Model
GT62F
Dimension (D x W x H)
24.6" x 17.2" x 1.72" (625.4 x 436 x
43.6mm)
Motherboard
S5630GMRE
Gross Weight
20 kg (44 lbs)
Net weight
10.5kg (23.5 lbs)
Front Panel
Buttons
(1) PWR, (1) RST, (1) ID
LEDs
(1) PWR, (1) HDD, (1) IPMI/Warning
I/O Ports
(2) USB 3.0 port
External Drive Bay
Type / Q'ty
2.5" Hot-Swap SSD/HDD + NVMe/
(6) + (4)
HDD backplane
support
SAS 12Gb/s, SATA 6Gb/s, NVMe
Supported HDD
Interface
(6) SATA 6Gb/s + (4) NVMe
System Cooling
Configuration
FAN
(5) 4cm fans
Power Supply
Type
ERPS 1U
Input Range
AC 100-240V/8A
Frequency
50-60 Hertz
Output Watts
650 Watts
Efficiency
PFC, 80 plus Platinum
Redundancy
1+1
Processor
Socket Type / Q'ty
LGA3647/ (1)
Supported CPU Series
Intel Xeon Scalable Processor
Family
Thermal Design
Power (TDP) wattage
Max up to 205W
Chipset
PCH
Intel C621
Memory
Supported DIMM
Qty
(12) DIMM slots
DIMM Type / Speed
DDR4 RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 384GB RDIMM/ 768GB
LRDIMM/ 1,536GB RDIMM
3DS/LRDIMM 3DS *Follow latest Intel
DDR4 Memory POR

Memory channel
6 Channels
Memory voltage
1.2V
Expansion Slots
PCI-E
(1) PCI-E Gen3 x16 slots
Others:
(1) PCI-E Gen3 x8 OCP 2.0 slots
(con.A+con.B+con.C)
LAN
Port Q'ty
(1) PHY
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) Mini-SAS HD (8-ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel RSTe)
NVMe
(2) PCI-E x8 SFF-8611
OCuLink connectors for (4)
NVMe ports
sSATA
Connector
(2) 8-pin
SATA/SATA-DOM, (1)
Mini-SAS HD (4-ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
I/O Ports
USB
(2) USB3.0 ports (at rear), (2)
USB3.0 ports (at front), (1) USB3.0
TYPE-A
COM
(1) DB-9 port (COM1) + (1) header
(COM2)
VGA
(1) D-Sub 15-pin port
RJ-45
(1) GbE port dedicated for IPMI
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Over temperature warning
indicator, Fan & PSU fail LED
indicator

Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
Supports storage over IP and remote
platform-flash, USB 2.0 virtual hub
AST2500 IPMI
Feature
24-bit high quality video
compression, 10/100/1000 Mb/s
MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
sleeping states S4,S5, ACPI 6.1
Operating System
OS supported list
Please refer to our AVL support
lists.
Regulation
FCC (DoC)
Class A
CE (DoC)
Class A
VCCI Class A
CB/LVD Yes
RCM Class A
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Package Contains
Manual
(1) Web User's manual, (1) Quick
Installation Guide
Installation CD
(1) TYAN installation CD
Barebone
(1) GT62F-B5630 Barebone
B5630G62FV2E8HR Specifications
System
Form Factor
1U Rackmount
Chassis Model
GT62F
Dimension (D x W x H)
24.6" x 17.2" x 1.72" (625.4 x 436 x
43.6mm)
Motherboard
S5630GMRE

Gross Weight
20 kg (44 lbs)
Net weight
10.5kg (23.5 lbs)
Front Panel
Buttons
(1) PWR, (1) RST, (1) ID
LEDs
(1) PWR, (1) HDD, (1)
IPMI/Warning
I/O Ports
(2) USB 3.0 port
External Drive Bay
Type / Q'ty
2.5" Hot-Swap SSD/HDD + NVMe/
(2) + (8)
HDD backplane
support
SAS 12Gb/s, SATA 6Gb/s, NVMe
Supported HDD
Interface
(2) SATA 6Gb/s + (8) NVMe
System Cooling
Configuration
FAN
(5) 4cm fans
Power Supply
Type
ERPS 1U
Input Range
AC 100-240V/8A
Frequency
50-60 Hertz
Output Watts
650 Watts
Efficiency
PFC, 80 plus Platinum
Redundancy
1+1
Processor
Socket Type / Q'ty
LGA3647/ (1)
Supported CPU Series
Intel Xeon Scalable Processor
Family
Thermal Design
Power (TDP) wattage
Max up to 205W
Chipset
PCH
Intel C621
Memory
Supported DIMM
Qty
(12) DIMM slots
DIMM Type / Speed
DDR4 RDIMM/RDIMM
3DS/LRDIMM/LRDIMM 3DS 2666
Capacity
Up to 384GB RDIMM/ 768GB
LRDIMM/ 1,536GB RDIMM
3DS/LRDIMM 3DS *Follow latest
Intel DDR4 Memory POR
Memory channel
6 Channels
Memory voltage
1.2V
Expansion Slots
Pre-install TYAN
Riser Card
M2091, PCI-E x16 1U riser card
(left)
Others:
(1) PCI-E Gen3 x8 OCP 2.0 slots
(con.A+con.B+con.C)

LAN
Port Q'ty
(1) PHY
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) Mini-SAS HD (8-ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel RSTe)
NVMe
(2) PCI-E x8 SFF-8611 OCuLink
connectors for (4) NVMe ports,
(1) M2093 w/ (2) PCI-E x8
SFF-8611 OCuLink connectors
for (4) NVMe ports
sSATA
Connector
(2) 8-pin SATA/SATA-DOM, (1)
Mini-SAS HD (4-ports)
Controller
Intel C621
Speed
6.0 Gb/s
RAID
RAID 0/1/10/5 (Intel RSTe)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
I/O Ports
USB
(2) USB3.0 ports (at rear), (2)
USB3.0 ports (at front), (1) USB3.0
TYPE-A
COM
(1) DB-9 port (COM1) + (1) header
(COM2)
VGA
(1) D-Sub 15-pin port
RJ-45
(1) GbE port dedicated for IPMI
TPM (Optional)
TPM Support
Please refer to our TPM supported
list.
System Monitoring
Chipset
Aspeed AST2500
Temperature
Monitors temperature for CPU &
memory & system environment
Voltage
Monitors voltage for CPU, memory,
chipset & power supply
LED
Over temperature warning
indicator, Fan & PSU fail LED
indicator
Others
Watchdog timer support
Server Management
Onboard Chipset
Onboard Aspeed AST2500
AST2500 iKVM
Feature
IPMI 2.0 compliant baseboard
management controller (BMC),
Supports storage over IP and

remote platform-flash, USB 2.0
virtual hub
AST2500 IPMI
Feature
24-bit high quality video
compression, 10/100/1000 Mb/s
MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, SMBIOS
3.0/PnP/Wake on LAN, Boot from
USB device/PXE via LAN/Storage,
User Configurable FAN PWM Duty
Cycle, Console Redirection, ACPI
sleeping states S4,S5, ACPI 6.1
Operating System
OS supported list
Please refer to our AVL support
lists.
Regulation
FCC (DoC)
Class A
CE (DoC)
Class A
CCI Class A
CB/LVD Yes
RCM Class A
Operating Environment
Operating Temp.
10°C ~ 35°C (50°F~ 95°F)
Non-operating Temp.
- 40°C ~ 70°C (-40°F ~ 158°F)
In/Non-operating
Humidity
90%, non-condensing at 35°C
RoHS
RoHS 6/6 Compliant
Yes
Package Contains
Manual
(1) Web User's manual, (1) Quick
Installation Guide
Installation CD
(1) TYAN installation CD
Barebone
(1) GT62F-B5630 Barebone
B5630G62FV10HR Specifications
System
Form Factor
1U Rackmount
Chassis Model
GT62F
Dimension (D x W x H)
24.6" x 17.2" x 1.72" (625.4 x 436 x
43.6mm)
Motherboard
S5630GMRE
Gross Weight
20 kg (44 lbs)
Net weight
10.5kg (23.5 lbs)
Front Panel
Buttons
(1) PWR, (1) RST, (1) ID
LEDs
(1) PWR, (1) HDD, (1)
