Tyco electronics 00007-1856 User manual

CONTENTS

Vehicle

Transmitter

7.2V Battery Pack

7.2V Charger

9V Battery

CHASSIS

Refer to label on transmitter and vehicle

for frequency. Do not race vehicles with

the same frequency.

Keep these instructions for future reference: they contain important information.

IMPORTANT: Please read all “Consumer Information” (last page) before operating your vehicle.

7.2V R/C

CAUTION:

Surfaces may become hot and cause burns if

electronics get wet. Do not operate vehicle through water or snow.

FORWARD REVERSE LEFT RIGHT

VEHICLE OPERATION

NOT RECOMMENDED

FORCHILDRENUNDER

8 YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS,PRECAUTIONS SHOULD BE

OBSERVED DURING HANDLING AND USE TO PREVENT ELECTRIC SHOCK.

CAUTION-ELECTRIC TOY:



00007-1856

qSteering Adjuster

wBattery Door

eBattery Latch

rON/OFF/SOUND Switch

*Switch Positions:

= OFF

= ON (no engine sounds)

= ON (engine sounds)

INPUT: 120VAC, 60Hz, 12VA. OUTPUT: 8.5VDC, 420mA, 3.6W.

POWER SYSTEMS

Please follow the specific instructions on the next page for

detailed information regarding NiCd vehicle battery charging

and safety.

VEHICLE BATTERY INSTALLATION

1. Rotate battery latch to open position. Open battery door.

2. Insert battery pack into battery compartment as shown.

3. Plug wire connector securely into battery compartment as

shown.

4. Close battery door. Rotate battery latch to locked position.

5. To remove battery pack: turn latch, open battery door, unplug

wire connector and lift battery out.

*The battery door is designed to be removable. If it comes off

the hinges, simply reattach it.

9Vd.c.

TRANSMITTER BATTERY INSTALLATION

Your transmiter uses a 9v/6LR61 battery. It’s equipped with a special

automatic-on battery-saving feature. Just turn your vehicle ON.

Then push either control and you will be able to run and control

your vehicle.

1. Open battery door as shown.

2. Install one 9V battery with polarity (+/-) as shown inside battery

compartment.

3. Close battery door.

7.2V d.c.

Please follow these instructions regarding

NiCd vehicle battery charging and safety.

Use charger only under adult supervision.

BATTERY CHARGING/CARE –

7.2V TURBO®BATTERY

1. Plug wall pack charger into standard

110/120 volt outlet.

2. Connect the wires leading from the

battery pack to the wall pack charger

connector. Make certain the two con-

nectors are tightly snapped together.

3. To disconnect wires, push down on the

connector clip and pull apart.

4. Your battery pack consists of new parts

and materials; therefore, you should

charge the battery pack for 51/2 hours

the first two times you charge the bat-

tery. Subsequent charges will require

only 4 hours.

5. After charging for 4 hours, the battery

will feel warm. This condition is normal

for fully charged batteries.

6. Charging the battery pack for more

than 4 hours will not give you a longer

running time. 4 hours is all that is

required for a fully charged battery

pack.

7. Unlike alkaline batteries, where the

power loss is gradual, a NiCd (nickel-

cadmium) battery will run for its normal

running time, depending on your partic-

ular vehicle, and then lose most of its

power at once. It is time to recharge

the battery pack. Running time will

vary, depending upon which R/C vehi-

cle you have.

8. After use, the battery pack will be hot!

Wait at least 20 minutes until the bat-

tery pack cools before recharging.

Recharging a warm or hot battery pack

will greatly reduce the number of times

your battery pack can be recharged.

RECHARGEABLE BATTERY INFORMATION:

 DO NOT RECHARGE BATTERY PACK

IF IT’S HOT. ALLOW IT TO COOL

BEFORE RECHARGING.

 DO NOT RECHARGE A BATTERY PACK

THAT SHOWS LEAKAGE OR CORRO-

SION.

 DO NOT DISASSEMBLE THE BAT-

TERY PACK. THE BATTERY PACK IS A

SEALED RECHARGEABLE NICKEL-

CADMIUM BATTERY.

 DO NOT DISPOSE OF THE BATTERY

PACK IN FIRE.

 EXERCISE CAUTION IN HANDLING A

HOT BATTERY PACK.

 IF BATTERY PACK AND/OR CHARGER

ARE WET, THOROUGHLY DRY BEFORE

CHARGING.

 DO NOT RECHARGE NON-

RECHARGEABLE BATTERIES.

Note to Adults:

• Remove rechargeable batteries before

recharging. Recharge batteries only

under adult supervision.

• Regularly examine for damage to the

plug, enclosure and other parts. In the

event of any damage, the toy must not

be used with the transformer until the

damage has been repaired.

• This toy is not intended for children

under 8 years old. The transformer is

not a toy.

NiCd BATTERY INFORMATION

THIS PRODUCT USES A NICKEL-CADMIUM RECHARGEABLE BATTERY PACK. BATTERY MUST BE RECYCLED OR DISPOSED OF PROPERLY.

FOR FURTHER INFORMATION REGARDING BATTERIES OR THEIR DISPOSAL PLEASE CALL 1-888-557-TYCO.

lCAUTION: Use only the charger

supplied with this toy. Do not use

any other charging source.

IMPORTANT:

Please read before operating your vehicle.

SAFETY INFORMATION

Note to Adults: To ensure that the child’s

play is both safe and fun, please review all

operating instructions and safety rules with

your child.

Safety Tips

• NEVER drive your vehicle on streets!

They’re for real cars!

• DO NOT pick up vehicle while in motion.

• Keep fingers, hair and loose clothing

away from the tires and the wheel hubs

while the vehicle is switched ON.

• Adult supervision is recommended when

this vehicle is being operated.

• To avoid accidental operation, remove all

batteries when not in use.

BATTERY SAFETY INFORMATION

Batteries may leak fluids that can cause a

chemical burn injury or ruin your toy (prod-

uct). To avoid battery leakage:

• Do not mix old and new batteries or batter-

ies of different types: alkaline, standard

(carbon-zinc) or rechargeable (nickel-cad-

mium).

• Insert batteries as indicated inside the bat-

tery compartment.

• Remove batteries during long periods of

non-use. Always remove exhausted batter-

ies from the toy (product). Dispose of bat-

teries safely. Do not dispose of batteries in

a fire. The batteries may explode or leak.

• Never short-circuit the battery terminals.

• Use only batteries of the same or equiva-

lent type, as recommended.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the

toy (product) before charging.

• If removable, rechargeable batteries are

used, they are only to be charged under

adult supervision.

Battery Performance Note:

For best performance use alkaline batteries

(where disposable batteries are called for). If

your vehicle is supplied with standard (carbon-

zinc) batteries for initial use and/or demonstra-

tion purposes, we recommend replacing them

with alkaline batteries when necessary.

Battery life may vary depending on battery

brand.

❶When your vehicle starts

to lose power, it may lose

functions or perform-

ance. It's time for a

recharge). Your vehicle's

running time may change

depending on your driv-

ing style.

❷Radio interference can

make your vehicle run

badly. Interference can

be caused by other R/C

vehicles running on the

same frequency; electri-

cal wires; large buildings;

or CB radios. Try to stay

away from these!

❸ Point your transmitter

antenna up - not down

toward your vehicle. If

your vehicle gets too far

away, it won't work prop-

erly.

❺Don’t store your vehicle

near heat or in direct sun-

light. Always turn switch-

es OFF and remove all

batteries for storage.

❹Don’t drive your vehicle in

sand or through water or

snow.

QUICK TIPS

SYMPTOM

Vehicle runs slowly or will not run.

Power indicator light on transmitter does not light.

Erratic operation or only short range possible.

Vehicle doesn’t work after going through water or snow.

• PROBABLE CAUSE

• Loose battery connection or vehicle switch not ON.

• Weak or uncharged rechargeable NiCd battery.

• Weak transmitter battery.

• Transmitter battery weak or not connected.

• Radio interference likely.

• Water in the electronics area.

• CORRECTION

• Check battery connector and vehicle switch.

• Charge battery or replace.

• Replace with fresh alkaline battery.

• Check connections and replace battery if required.

• Change location - see Point 2, “Quick Tips.”

• Vehicle will take several hours to dry. Allow to dry thor-

oughly overnight before trying again.

• Avoid driving in water or snow.

TROUBLESHOOTING - PROBLEM? - SOLUTIONS

CONSUMER INFORMATION:

marks of Mattel, Inc.

Retain this address for future reference: Mattel U.K. Ltd.,

Vanwall Business Park, Maidenhead SL6 4UB. Helpline

01628500303. Mattel Australia Pty Ltd., Richmond, Victoria

3121 - Consumer Advisory Service: 1300 135 312. Mattel

East Asia Ltd, Room 1106, South Tower, World Finance

Centre, Harbour City, Tsimshatsui, HK, China. Diimport &

Diedarkan Oleh: Mattel SEA Ptd Ltd. (993532-P) Lot 13.5,

Menara Lien Hoe, Persiaran Tropicana Golf Country Resort,

47410 PJ. Tel: 03-78803817, Fax: 03-78803867.

COMPLIANCE WITH FCC REGULATIONS (VALID IN U.S. ONLY - VAL-

ABLE AUX É.-U. SEULEMENT)

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause unde-

sired operation.

This device generates and uses radio frequency energy and if not

used properly may cause interference to radio and television

reception. It has been tested and found to comply with the limits

set by the FCC which are designed to provide reasonable protec-

tion against such interference.

NOTE: Changes or modifications not expressively approved by the

manufacturer responsible for compliance could void the user’s

authority to operate the equipment.

❺❹❶❷❸

90-DAY LIMITED WARRANTY – TYCO® R/C PRODUCTS

Mattel, Inc. warrants to the original consumer purchaser that this product will be free of defects in material and workmanship for ninety (90) days (unless specified in alter-

nate warranties) from the date of purchase. Mattel will replace the product in the event of such a defect within the warranty period.

In the event of a defect covered under this warranty, first call the toll-free number listed below. Many problems can be solved in this manner. If necessary, you will be

instructed to return the product, postage prepaid and insured, to the address below. Enclose your name, address, dated sales receipt, and a brief explanation of the defect.

Replacement and return shipment will be free of charge.

This warranty does not cover damage resulting from unauthorized modification, accident, misuse or abuse. If the product is returned without a dated sales receipt the prod-

uct may be excluded from coverage under this warranty.

Mattel’s liability for defects in material and workmanship under this warranty shall be limited to replacement, and in no event shall we be responsible for incidental, conse-

quential, or contingent damages (except in those states that do not allow this exclusion or limitation). This warranty is exclusive, and is made in lieu of any express or

implied warranty. Valid only in U.S.A. This warranty gives you specific legal rights and you may have other rights, which vary from state to state. Some states do not allow

the exclusion of incidental or consequential damages, so the above exclusions or limitations may not apply to you.

TOLL-FREE NUMBER: 1-888-557-TYCO (8926) (valid only in U.S.A.)Hours: 8:00 A.M. - 5:00 P.M. Eastern Time; Monday - Friday. Expect some delay in January following the holi-
