11ac Tri-Band 2200Mbps High Power Outdoor Access Point
Model:AP11-Dual-IP67
Description:
AP11-Dual-IP67 is an Qualcomm Solution 11ac high power industrial use Outdoor access point with tri-
band, 2200Mbps Wi-Fi speed (2.4GHz 300Mbps, 5.8GHz 900Mbps, 5.8G 900Mbps), equipped with
Gigabit WAN port, fast Ethernet data rate make 200 end users access into it, to enjoy the seamless HD
movies, streaming, online gaming, wireless security and other bandwidth-intensive tasks, useful in high
density user access environment.
Outdoor shell with Lightning Protection, TemperatureAdaptive
AP11-Dual-IP67 with metal IP67 level waterproof, dust proof and sunscreen shell, PCB board support
Common mode ±6KV Different mode ±2KV lightning protection, which avoid the damage from dust,
thunderstorm weather. Meantime, it adaptive to various environment, the working temperature can be
normal at -30℃to 70℃, Suit for any country and any environment.
High Power design, N connector for external antenna, more range and
stable signal
Designed in Power Amplifier on PCB board, the power can be 300mW high power, N type water proof
connector,can connect with panel/omni outdoor antenna based on request, greatly increase the Wi-Fi
range and supply the stable Wi-Fi signal for users.
Power over Ethernet
AP11-Dual-IP67 has integrated IEEE802.3at Power over Ethernet (PoE), for easy installation and
lower cost. So it can be installed in areas where power outlets are not readily available,
eliminating the mess of altering existing network infrastructure.
MU-MIMO, Wave2.0 Technology
Comply with Wave2.0 Technology, it adopt 256QAM modulation, support MU-MIMO (Multi-User
Multiple-Input Multiple-Output), 8 Spatial Steams, greatly to improved the communication
efficiency

Technical specifications are subject to change without prior notice. Please check www.tyconusa.com for the latest information.
www.tyconusa.com
Beamfrorming, DFS, Airtime Fairness, Band Steering, OFDM support
AP11-Dual-IP67 support many functions like Beamfrorming,DFS(Dynamic Frequency Selection),
Airtime
Fairness, Band Steering ( 5G Prior), OFDM(Orthogonal Frequency Division Multiplexing), RF Power
adjustable to improve the performance and Wi-Fistability.
WLAN Controller Central/Remote Management, Captive Portal support
Work with WLAN controller in wireless AP operation mode,easily realize the central and remote
management, like AP status monitor, change IP address, ESSID, Channel, Password, upgrade firmware,
backup and restore....
Besides that, it support captive portal authentication like Member/SMS/no authentication login, make this
device more professional in Wi-FiProjects.
Comply with IEEE 802.11ac/b/g/n, tri-band, 2200Mbps Data Rate
1*10/100/1000Mbps WAN Port, PoE support, water-proof
300mW high power, can connect with external antenna for strongersignal strength and more
wireless coverage, 32M Flash, 512M DDR3 RAM, more user, more stable
Support IEEE 802.3at PoE standard
Support SSID broadcasting, Multi SSID up to 12 (4 SSID in 2.4GHz, 8 SSID in 5GHz)
Support Gateway (PPPOE, static IP, dynamic IP) , Wireless AP,Repeater, WISP operation mode
Support DDNS, VPN pass through, Port forwarding and DMZ host
Main Features:
11ac Tri-Band 2200Mbps High Power Outdoor Access Point
Model:AP11-Dual-IP67

Technical specifications are subject to change without prior notice. Please check www.tyconusa.com for the latest information.
www.tyconusa.com
ProductSpec.:
Hardware:
Chipset Qualcomm IPQ4019+QCA9886+QCA8075
Standard 802.11ac/b/g/n, MU-MIMO technology
Memory 512MB DDR3 RAM
Flash 32MB
Interface 1 * 10/100 /1000Mbps RJ45 WAN Port
1 * 10/100 / 1000Mbps RJ45 LAN Port (Inside of shell)
1 * Reset button, press 10 seconds to revert to defaultsetting
Antenna 6 * N type connector, can work with omni/panel antennas
Power consumption 48V PoE<30W
Size
RF Data
Frequency
2.4G: 802.11b/g/n: 2.4GHz –2.484GHz
5GHz:802.11a/n/ac MIMO: 5.150GHz～5.850GHz
Modulation OFDM = BPSK,QPSK, 16-QAM, 64-QAM, 128-QAM, 256-QAM
DSSS = DBPSK, DQPSK, CCK
Throughput 2200Mbps
2.4G RF Power
(IPQ4019)
802.11b 11M 23±2dBm 1M 25±2dBm
802.11g 54M 22±2dBm 6M 24±2dBm
802.11n HT20 MCS7 21±2dBm MCS0 23±2dBm
802.11n HT40 MCS7 21±2dBm MCS0 23±2dBm
5G RFPower
（IPQ4019）
802.11a 54M 19±2dBm 6M 21±2dBm
802.11n HT20 MCS7 18±2dBm MCS0 20±2dBm
802.11n HT40 MCS7 18±2dBm MCS0 20±2dBm
802.11acHT80 MCS9 17±2dBm MCS0 19±2dBm
5G RF Power
（QCA9886）
802.11a 54M 19±2dBm 6M 21±2dBm
802.11n HT20 MCS7 18±2dBm MCS0 20±2dBm
802.11nHT40 MCS7 18±2dBm MCS0 20±2dBm
802.11acHT80 MCS9 17±2dBm MCS0 19±2dBm
11ac Tri-Band 2200Mbps High Power Outdoor Access Point
Model:AP11-Dual-IP67

Technical specifications are subject to change without prior notice. Please check www.tyconusa.com for the latest information.
www.tyconusa.com
2.4G Receive
Sensitivity
802.11b 11M -85dBm 1M -94dBm
802.11g 54M -72dBm 6M -90dBm
802.11n HT20 MCS7 -70dBm MCS0 -88dBm
802.11n HT40 MCS7 -68dBm MCS0 -86dBm
5G Receive
Sensitivity
802.11a 54M -72dBm 6M -90dBm
802.11n HT20 MCS7 -70dBm MCS0 -88dBm
802.11n HT40 MCS7 -68dBm MCS0 -86dBm
802.11acHT80 MCS9 -58dBm MCS0 -85dBm
EVM 2.4G EVM: 802.11b: ≤-10 dB; 802.11g: ≤-25 dB; 802.11n: ≤-28dB
5G EVM: 802.11a: ≤-25 dB; 802.11n: ≤-28 dB; 802.11ac: ≤-32dB
PPM ±20ppm
Max Users 256
Firmware Features:
Operation mode Wireless AP, Gateway, WISP, Wi-Fi Repeater
WAN Type Dynamic IP/Static IP/PPPoE/L2TP(Dual Access) /PPTP(DualAccess)
Wireless Security 64/128-bit WPA/ WPA2(PSK/AES)encryption
SSID Multiple SSID (4 SSID for 2.4G, 8 SSID for 5.8G)
Firewall IP Address Filter/MAC Address Filter/DomainFilter
IP and MAC AddressBinding
Protocols IPv4
Others:
Package Contents 2200Mbps Dual Band wireless access point
Ethernet Cable
Quick Installation Guide
SettingAccessory
System
Requirements
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8,
MAC OS, NetWare, UNIX or Linux
Environment Operating Temperature: -20~55 ℃
Limit working temperature: -30~70 ℃
Storage Temperature: -40~70 ℃
Humidity: 5%~95% non-condensing
Management Firmware GUI , Remote Management, WLAN Controller, Cloud Management
System
