TyloHelo 1601-40 User manual

OPERATING INSTRUCTIONS
72-0134 11-26-2019 Rev A
Page 1
WARNING
SECTION 1: GENERAL INFORMATION
Do not take a sauna if using
alcohol, drugs or
medications.
Pregnant women or persons
with poor health should
consult their physician before
using any sauna.
Caution re hazard: Do not
use the sauna room for
drying clothes, bathing suits,
etc. Do not hang towels
above heater or place any
object other than the rocks
supplied on the heater. If any
darkening of the wall around
the heater is noticed
discontinue sauna use
immediately.
Inspect sauna regularly for
required maintenance to
heater, control and benches.
Replace wood surfaces
which show any signs of
deterioration.
The heater gets extremely hot
during operation and should
not be touched or burns may
result.
Minors should be adequately
supervised whenever near a
hot or warming sauna.
Sauna Control Models Pure 2.0
(Type # 1601-40 and 1601-40-1)
Read all instructions carefully before installation. Please leave all
instructions and warranty with the owner.
WARNING
Prolonged exposure to elevated temperatures is capable of inducing
hyperthermia. Hyperthermia occurs when the internal temperature of the
body reaches several degrees above the normal body temperature of
98.6°F. The symptoms of hyperthermia include an increase in the normal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The
effects of the hyperthermia include failure to perceive heat, failure to
recognize the need to exit the room, unawareness of impending hazard,
fetal damage in pregnant women, physical inability to exit the room and
unconsciousness.
WARNING
The use of alcohol, drugs, or medication is capable of greatly increasing
the risk of fatal hyperthermia.
The controls are ETL approved by Intertek for permanent installations and
electrical connections. Refer to the heater or steam generator “Installation
and Operation Instructions” for complete information about the electrical
wiring. All wiring must be performed in accordance with national and local
codes.

OPERATING INSTRUCTIONS
72-0134 11-26-2019 Rev A
Page 2
WARNING
SECTION 2: CONTROL OPERATION
Fire sprinkler systems used
inside any sauna room should
be properly rated for sauna
room temperatures.
Do not pour chlorinated pool
or spa water on heater.
Excessive water use on heater
may cause damage and void
warranty.
Electric Shock Hazard - High
voltage exists within this
equipment. There are no user
serviceable parts in this
equipment. All installation
and service to this equipment
should be performed by
qualied licensed personnel in
accordance with local and
national codes.
Do not construct sauna room
so as to restrict air ow
through the bottom of the
heater.
Packing the rocks too tightly
may cause the heater high
limit switch to trip.
A. On/Off Light switch
B. Indicators - lights for lighting, door switch (n/a), timer and the heater
C. On/Off Sauna Switch and fault alarms
D. Sets the desired value
E. Functions - Temperature, Delay Timer, Sauna Length and Humidity (n/a)
F. Function buttons
CONTROL OPERATION:
TURN ON LIGHT: Press the "light bulb" icon once to turn on the light and
press again to turn off. (Usage of light control is optional)
SAUNA LENGTH:
(Control 1601-40) Select the sauna length function by pressing the buttons
< > (F). Set the desired usage time (0–60 minutes) using the – and +
buttons. (Setting 10 equals 60 minutes)
(Control 1601-40-1) Usage time is 0-24 hours operation (Setting 1 = 2
hours, setting 10 = 24 hours) version has a maximum sauna length of 24
hours and can be used only when a facility has an attendant on duty to
monitor the people in the sauna .
SET TEMPERATURE: Press function button (F). Then you can choose the desired temperature 1–10 using buttons –
and +. (Setting 10 equals highest set point.)
When the desired temperature has been set and the heater is switched on the set temperature indicator light will remain
on and the current temperature indicator LED will ash. When the current temperature reaches the set value the
indicator light will stop ashing.
Version 1 2 3 4 5 6 7 8 9 10
1 hour 6 min 12 min 18 min 24 min 30 min 36 min 42 min 48 min 54 min 60 min
24 hour 2 hr 4 hr 6 hr 8 hr 10 hr 12 hr 14 hr 16 hr 18 hr 24 hr
LED

OPERATING INSTRUCTIONS
72-0134 11-26-2019 Rev A
Page 3
Shower
Sauna (10 - 15 min.)
Shower or swim
Rest (10 - 15 min.)
Relax with juice or water
You liked it?
Do it once again and
you will feel great.
SECTION 3: HOW TO TAKE A SAUNA
SECTION 2: OPERATION, Continued
• When taking a sauna, allow time to relax completely.
• Remove clothing and jewelry...if required, wear a towel loosely.
• After 10 minutes or when perspiration begins, leave sauna and relax in
dressing area...follow with a cool shower.
• Cooling time should equal time spent in sauna. Enter sauna room again
and stay 5 or 10 minutes.
• Repeat the cycle 2 or 3 times; end with a brisk shower...rinse in cool
water.
• Dress when completely dry and perspiration has stopped.
• Some sauna bathers enjoy the soothing effect of steam by splashing
water on the heated sauna rocks. Use only one dipper full (approx. ½
cup) at a time and keep clear of the steam as it rises off the rocks.
• Do not smoke, exercise or drink alcoholic beverages in the sauna room.
• Do not pour chlorinated pool or spa water on the heater or corrosion
damage may result.
FAHRENHEIT or CELSIUS: The temperature will be displayed in Fahrenheit as
default. To change the temperature display, apply power to the system for over 5
minutes and the LED temperature indicator must be glowing. Next, press the <
button for 5 seconds. After 2 seconds the temperature indicator will start ashing,
and a C or F will appear in the temperature display to indicate that the temperature
display has been changed.
START HEAT IMMEDIATELY:
Start the heater on by pressing the On/Off button. The latest temperature and
usage time settings will remain preset. A green indicator light will come on in area
(B) to indicate that the device has been switched on.
You may switch the system off before the usage time ends by pressing the same
button again. The indicator light will go out.
TIME DELAY START TIME: The control may be set to delay start mode to
activate the heater after a preset amount of time. Select the clock symbol using
the function button (F). Use the – and + buttons to select the amount of hours
(1–10 hours) after which the device will switch on. Activate a later start by
pressing the Start button (C).
The timer symbol light will come on (in eld B) and the selected time-lapse
indicator light will start ashing. The ashing indicator measures and indicates
the time leading up to the device being switched on. When the heater starts, the
control panel will automatically show the set temperature.

OPERATING INSTRUCTIONS
72-0134 11-26-2019 Rev A
Page 4
SECTION 4: TROUBLESHOOTING
Control will Run but No Heat - Press the (reset) high limit switch on the bottom of heater.
Slow Heat Time or High Limit Tripping - Check rock placement, they will break down over time and reduce the air
ow in the heater. Refer to Diagram 10 for proper rock installation. Discard all rocks under the size of 2" pieces. Call
the number below to order more rocks if needed.
CAUTION: Use only a contractor approved for 250,000 endurance Cycles / ATTENTION: Utiliser uniquement un
contacteur approuve pour 250,000 cycles de fanctionnement
In the event of a fault occurring in the heater system (control panel, temperature sensor, etc.), this will be signaled
by the LED indicator light on the control panel. The fault indicator light will be displayed on the 1-10 scale of the
control. The fault error code will be displayed with a constant LED light or a ashing LED light. See the list below for
fault codes.
Note: The LED indicators do not turn off, some indicators will glow as long as power is applied to the system.
Constant LED Fault Code (ones marked with “n/a” are not in use):
1 Temperature sensor not connected or shorted
2 n/a
3 Heater circuit board overheated
4 n/a
5 n/a
6 Communication lost between control and circuit board in heater.
7 n/a
8 n/a
9 n/a
10 n/a
Flashing LED Fault Code
1 n/a
2 n/a
3 n/a
4 n/a
5 n/a
6 n/a
7 n/a
8 n/a
9 Door Switch is open for more than 60 seconds while heating or jumper on circuit board in heater is removed.
10 Door Switch is open for more than 60 seconds in “Delay” Mode or jumper on circuit board in heater is removed.
For troubleshooting or service questions call 1-888-780-4427 and ask to speak with service. Prior to calling, please
have the Model and Type number available. You may also email us at techsuppor[email protected]
LED Flashes Red
during a fault
1 - 10 Indicates the
fault code
