U Fly Quiet UFQ-A6 User manual
------------------------------------------------------------------ ------------------------------------------------------------------
-
1
-
U Fly Quiet
Aviation Headset UFQ-A6
Good bye noise! Enjoy clear communication & music!!
------------------------------------------------------------------ ------------------------------------------------------------------
-
2
-
Contents of the UFQ-A6 ackage
Carry case
User manual
Micro USB cable for battery charge
Power ada ter
Auxiliary in ut/Cell hone link cable for iPhone and Samsun and
ect on
Features
Advanced reverse noise canceling technology, reduce 90%
background noise.
Noise canceling s ecial use 40mm drive, whole ieces forming
corona dia hragm, for crystal clearly high quality voice.
Built-in rechargeable high ca acity lithium battery.
O eration mode o tional: ANR mode/common mode.
Full cover ca design, im orted high quality memory foam ，
anti-fatigue for long time wearing.
Fold able design, variety fold method to meets different bags.
------------------------------------------------------------------ ------------------------------------------------------------------
-
3
-
Getting started
Fitting your headset
Fitting your headset is the key to comfortable use and the su erior
Active Noise Reduction(ANR) of UFQ-A6. A solid seal around your
entire ear and a symmetrical fit across the to of your head are
necessary for you to ex erience eak erformance from the ANR
feature.
The following ste s will assist you in achieving the ro er fit:
1. Extend the sliders fully.
2. Place the headset on your head and com ress the sliders slowly
on each side until the head ad rests softly on the to of your head
3. Adjust the ear cu s to ensure the ears are fully inside the ear
seal and there is uniform ressure on your head.
4. Position the micro hone 1/8 inch from your mouth. Remove the
mic windscreen to see these features.
This side of the micro hone should face away from you.
This side of the micro hone should face away from you.
------------------------------------------------------------------ ------------------------------------------------------------------
-
4
-
Understanding Controls for UFQ-6A
A. Cli which is easy on the Shirt or coat
B. Charge Port
C. Power ON/OFF switch
D. Power indicator LED
1) Power on LED shows blue color
2) In charging LED shows red color
3) If ower on LED shows nothing means the battery runs out
then need to recharge the battery
4) While during use the blue color LED turn off also means the
battery runs out, then ANR is not available,need to switch to OFF
------------------------------------------------------------------ ------------------------------------------------------------------
-
5
-
then headsets will still work as PNR.
E. Auxiliary in ut jack
Provides a wired in ut for cell hones and audio devices
Link cable also included
F. Panel volume controls
Sliders adjust anel volume controls inde endently for each ear
Also affect the volume of auxiliary devices
G.
H.Mono/Stereo switch
------------------------------------------------------------------ ------------------------------------------------------------------
-
6
-
Using your UFQ A6 Headset
To ower UFQ A6 Headset,follow these ste s
1) Put on the UFQ A6 Headset and adjust for ro er fit and seal
(see age 3)
2) Switch on the ower, the LED shows blue color, you feel quieter
suddenly
3) If necessary ut the cli on your shirt or coat
Matching Mono/Stereo Setting to an Audio Panel
Choose the setting that matches the signal from your audio anel,
To ex erience the best erformance from a Stereo(dual single)
anel, set the switch to Stereo. To ex erience the best erformance
from a mon ( single signal) anel, set the headset to Mono.
Note: If this switch is set incorrectly,you will hear communications in
only one ear
------------------------------------------------------------------ ------------------------------------------------------------------
-
7
-
Connecting to iPhone or iPad other wired Auxiliary Devices
Usually you just need one cable with cables with 2 4 oles male
3.5mm connectors is OK. See the icture
Link cable Ada ter
Consider iPhone with different connections with other brands
cell hone like Samsung,Nokia and ect on
UFQ A6 also with an ada ter included, use link cable and ada ter
then can work well.
Recharging
Plug the 5 in jack into the side charging ort of the wire controller,
and connect the USB jack to PC/Power bank/5V ower ada tor.
Red light shows on charging, light off if full charging.
------------------------------------------------------------------ ------------------------------------------------------------------
-
8
-
General
Battery ower su ly:3.7V
Weight: 259g ( include ear seals and mic boom)
Panel aircraft: 8-40VDC
Head hone
Transducer:40mm moving coil
Frequency Resonse:20 Hz-20 kHz
Nominal im edance @ 1 kHz
Mono: 300 ohms
Stereo: 600 ohms
Micro hone
Transducer rinci le: Noise-canceling electret
Frequency res onse: 200 Hz-6000 Hz
Maximum SPL (Sound Pressure Level): 114 dB
Terminating im edance: 220-2200 ohms
O erating voltage: 8V-16V DC
------------------------------------------------------------------ ------------------------------------------------------------------
-
9
-
