U-Line 1175WC Configuration guide

FEATURES
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
117 5 W C
117 5 W C 1000 Se ri e S
• Wine bottle capacity of up to 48 bottles (.75L)
• Touch pad digital control featuring easy view command center and door open alert
• Digital controlled triple temperature zone
• Temperature range 40 to 60°F
• Stable, consistent temperatures provide longer term storage capability
• Sabbath / Blackout mode turns off all lighting and controls display and automatically
resets after 36 hours
• UL residential and commercial listings
• 2winerackswilltlargerdiameterwinebottles,includingChampagnebottles
• Lighted black interior optimizes elegant display of wines and can be manually turned
on for display with door closed; automatically shuts off after four hours
• Solid beech wood trimmed, 3/4 extension black powder coated wine racks
• Standard commercial stainless steel handle is interchangeable with professional
handle option on stainless steel model
• Stainless steel model has stainless steel wrap with black caps on top and bottom to
makethisuniteldreversible
• Blackmodelhasintegratedhandleandiseldreversible
• LowEcoated,argongaslledthermopaneglassdoorprovidesprotectionfrom
harmfulUVraysandaddedinsulatingenergyefciency
• Blackvinylcladtexturedcabinetismoreresistanttoscratching,peelingandaking
• Black and stainless models available with optional door lock*
• Solid beech wood trim on wine racks can be stained to match surrounding cabinetry
• Allowa2-1/2"clearanceonhingedsidefor90˚dooropeningwheninstalledadjacentto
a wall (for stainless steel model)
• Allow 1/4" width overall for proper installation (see backside for details)
• No additional clearance around sides, top or rear of unit is needed for ventilation
• Donotobstructfrontgrilleairow
• Durable,factoryinstalledlevellegsprovideamorepreciseundercountert
• Product note: with left hand hinge installation, allow for 145º door swing to ensure
extension of wine rack
Lock model
Stainless Black
Triple Zone System
featured in 1175WC.
INTEGRATION INTERIOR / EXTERIOR PERFORMANCE
For elegant presentation
of your wine collection,
all U-Line Wine
Captain®Models have
an illuminated interior.
WINE CAPTAIN®MODELS
*Blacklockmodeliseldreversible,stainlesslockmodelmustbeorderedright-handorleft-handhingespecic.

23-15/16"
1175 Refrigerator & 75FB
1175 Stainless Refrigerator
1175 Stainless Wine Captain® & Beverage Center
34-1/8"
3-9/16"
34-1/8"
3-9/16"
34-1/8"
23-1/16"
3-9/16"
23-1/2"
23-1/2"
Not Including Handle
Not Including Handle
23-15/16"
23-15/16"
1175WCS Stainless Model
Please visit www.u-line.com for installation guide.
All specifications are subject to change without notice.
OVERALL DIMENSIONS
8900 NORTH 55TH STREET MILWAUKEE, WISCONSIN 53223 414.354.0300 FAX [phone] U-LINE.COM
117 5 W C
Height 34-1/8" (86.6)
Width 23-15/16" (60.6)
Depth 23-1/2" (59.6)
With stainless steel handle 25-3/8" (64.4)
Shipping weight:
Black model 132 lbs (53 kg)
Stainless model 134 lbs (60 kg)
Running amps 2.4
Maximum start-up amps 9.8
Amps pertain to voltage rating 110/115 volt, 60 Hz
Capacities:
Wine bottle storage (0.75L) Up to 48
*Note:Wheninstallingablackmodel,allowfor145˚doorswing
to ensure wine racks slide out.
4"
7"
24"
24-3/16"
34-1/4"
to
35-1/8"
23-15/16"
1175 Refrigerator & 75FB
1175 Stainless Refrigerator
1175 Stainless Wine Captain® & Beverage Center
34-1/8"
3-9/16"
34-1/8"
3-9/16"
34-1/8"
23-1/16"
3-9/16"
23-1/2"
23-1/2"
Not Including Handle
Not Including Handle
23-15/16"
23-15/16"
1175WC
Stainless U-1175WCS-00
Black U-1175WCB-00
Stainless RH, with lock U-1175WCS-13
Stainless LH, with lock U-1175WCS-15
Black with lock U-1175WCB-13
1175WCB Black Model
DIMENSIONS AND SPECIFICATIONS
WINE CAPTAIN®MODELS
