U-Line 3036BVWC User manual
STAINLESS
FRAME
STAINLESS
FRAME (LOCK)
INTEGRATED
FRAME
INTEGRATED
SOLID
PERFORMANCE
•
123 cans (12 oz) and 31 wine bottles (750 ml)
• Temperature range: Left: 38°F - 65°F / Right: 34°F - 70°F
•
the set temperature
• U-Select®
Beverage: 34°F - 40°F, Deli: 34°F - 40°F, Market: 34°F - 40°F,
Pantry: 34°F - 70°F, Root Cellar: 45°F - 55°F
• U-Select®
Beverage: 34°F - 65°F, Sparkling Wine: 38°F - 50°F,
White Wine: 45°F - 55°F, Red Wine: 55°F - 65°F
• U-Select®Control with digital OLED display is ergonomically
located on top of door
• Maintains temperature to within 1°F of the set point to maximize
preservation
• Independently controlled dual-zones
• Relative humidity inside the unit is approx. 50%
• Rubber mounted compressor virtually eliminates vibration
INTERIOR/EXTERIOR
• Black interior is illuminated with LED theater lighting that
stay on for 3, 6, or 24 hours
• Robust full-extension black vinyl coated wine racks allow for easy
access and prevent bottles from shifting
• Wine racks accommodate a variety of bottle shapes and sizes;
champagne bottles
• Wine racks are designed to accommodate a variety of bottle
shapes and sizes
•
shelves with 11 height positions
• The right compartment features a full-extension, slide-out crisper
drawer that is removable for easy cleaning
•
protection from harmful UV light
• Standard commercial stainless steel handle is interchangeable
with professional handle accessory
INTEGRATION
• Robust, concealed and covered hinges with built-in door stop and
closer
• Adjustable grille can be shifted front-to-back and up-and-down
•
•
supplied by U-Line)
• Four independently adjustable leveling legs; rear legs are
adjustable from the front for ease of installation
MODEL DETAILS
Model Voltage/Hz Door Swing Finish Shipping Weight
U-3036BVWCS-00A 115 / 60 Double Doors Stainless Frame 247 lbs
U-3036BVWCS-13A 115 / 60 Double Doors Stainless Frame (Lock) 247 lbs
U-3036BVWCINT-00A 115 / 60 Double Doors Integrated Frame 230 lbs
U-3036BVWCINT-60A 115 / 60 Double Doors Integrated Solid 226 lbs
ACCESSORIES
Model Description Finish Shipping Weight
23074 Stainless 2 lbs
23073 Stainless 2 lbs
3036BVWC • 36” Beverage Center • Modular 3000 Series
QUICK REFERENCE GUIDE
FEATURES & BENEFITS
Model 3036BVWC
Amps: Running 1.2
Capacity: Bottle (12 oz)
Capacity: Can (12 oz) 123
Capacity: Volume (cu ft) 7.0
Capacity: Wine Bottle (750 ml) 31
Control Type U-Select®
Dimensions: Product Depth
Dimensions: Product Height
Dimensions: Product Width
Energy Consumption: Avg. Per Year 321.5 kWh
ENERGY STAR No
Panel Height
Panel Thickness
Panel Type
Panel Width
Product Weight: Max 221 lbs
Refrigerant Type R600a
Yes
Temperature Range Left: 38°F - 65°F
Right: 34°F - 70°F
allowing ample room for door handle.
No additional clearance around sides, top or rear of
unit is needed for ventilation.
This unit requires a grounded a polarized 115 VAC, 60 Hz, 15 A power
supply (normal household current).
Residential
4"
(102 mm)
7"
(178 mm)
35-7/16"
(900 mm)
33-7/8"
(860 mm)
to
34-7/8"
(886 mm)
Preferred location
for electrical outlet
is in adjacent
cabinet. 5/8"
(16 mm)
24"
(610 mm)
38°-65° 34°-70°
COOLING SYSTEM
35-7/16"
(900 mm)
33-11/16" to
34-11/16"
(856 to
881 mm)
23-7/16" (590 mm)
3-5/8"to 4-5/8"
(92 to
118 mm)
Not Including Handle
Modular 3000 Series • 36” Beverage Center • 3036BVWC
QUICK REFERENCE GUIDE
8900 North 55th Street • Milwaukee, Wisconsin 53223 USA • Phone +1.414.354.0300 • Fax +1.414.354.7905 • u-line.com
DIMENSIONS SPECIFICATIONS
ELECTRICAL REQUIREMENTS
CABINET CUT-OUT
Please visit u-line.com to view this model’s User Guide.
All specications are subject to change without notice.
INSTALLATION NOTES
