U-Line FELLOWES SB-99Ci User manual

PAGE 1 OF 5 0818 IH-2607
πH-2607
FELLOWES®SB-99Ci
PAPER SHREDDER
1-800-295-5510
uline.com
Will shred paper, plastic credit cards, CD/DVDs, staples
and small paper clips.
Will not shred adhesive labels, continuous form paper,
transparencies, newspaper, cardboard, large paper
clips, laminates, file folders, X-rays or plastic other than
noted above.
Paper Shred Size
Cross-Cut–5/32 x 1⁄"
Maximum
• Sheets per pass – 18*
• CDs/Cards per pass – 1*
• Paper entry width – 9"
*8⁄ x 11", 20 lb., paper at 120V, 60 Hz, 5 Amps; heavier
paper, humidity or other than rated voltage may
reduce capacity.
Recommended daily usage rates: 1,500 sheets per day,
50 credit cards, 10 CDs. 18 sheets per pass.
Fellowes SafeSense® shredders are designed to
operate in home and office environments ranging
between 50-80º F and at 40-80% relative humidity.
PARTS
CAPABILITIES
REF. DESCRIPTION
1SafeSense®Technology
2Paper entry
3See safety instructions
4 CD/Card safety flap
5Pullout bin
6Casters
7Disconnect power switch
8 Control Panel and LEDs
NOTE: Read these instructions before use.
Do not discard. Keep for future reference.
1
2
3
4
5
6
7
8

PAGE 2 OF 5 0818 IH-2607
SAFETY
CASTER INSTALLATION
• Operation, maintenance and service requirements
are covered in these instructions. Read completely
before operating shredder.
• Keep away from children and pets. Keep hands
away from paper entry. Always set to OFF (O) or
unplug when not in use.
• Keep foreign objects – gloves, jewelry, clothing, hair,
etc. – away from shredder openings. If object enters top
opening, switch to Reverse ( ) to back out object.
• Do not use aerosol products, petroleum-based or
aerosol lubricants on or near shredder. Do not use
canned air or air dusters on shredder. Vapors from
propellants and petroleum-based lubricants may
combust causing serious injury.
• Do not use if damaged or defective. Do not
disassemble shredder. Do not place near or over
heat source or water.
• This shredder has a disconnect power switch that must
be in the ON (I) position to operate the shredder. In
case of emergency, move switch to OFF (O) position.
This action will stop shredder immediately.
• Avoid touching exposed cutting blades under
shredder head.
• Shredder must be plugged into a properly
grounded wall outlet of the voltage and amperage
designated on the label. The grounded outlet or
socket must be installed near the equipment and
easily accessible. Energy convertors, transformers or
extension cords should not be used with this product.
• Fire hazard – do not shred greeting cards with sound
chips or batteries.
• For indoor use only.
• Unplug shredder before cleaning or servicing.
WARNING! Changes or modifications to this
unit not expressly approved by the party
responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can
radiate radio frequency energy and, if not
installed in accordance with the instructions,
may cause harmful interference to radio
communications. However, There is no
guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
1. Locate casters. 2. Lay shredder
on its back.
3. Insert casters
into housing.
4. Flip upright.
18

PAGE 3 OF 5 0818 IH-2607
OPERATING INSTRUCTIONS
Continuous operation up to 30-minute maximum.
NOTE: Shredder runs briefly after each pass to clear entry. Continuous operation
beyond 30 minutes will trigger 40-minute cool down period.
18
1. Plug in and
put disconnect
power switch in
ON (I) position.
2. Press ON ( )
to activate
(blue).
3. Feed paper
straight into
paper entry
and release.
4. To shred CDs
or credit cards,
rotate safety
flap into place.
5. Hold card/CD
at edge. Feed
into center
of entry and
release.
6. When finished
shredding,
set to OFF ( )
position.
PRODUCT FEATURES
JAM-PROOF SYSTEM
Jam-proof system eliminates paper jams and powers through tough jobs.
Advanced jam prevention
electronically measures paper
thickness to prevent paper jams:
Up to RED: Too many
sheets have been inserted.
Remove several sheets until
indicator is below red.
Wait for flashing to stop after
automatic correction is complete.
Regular shredding will resume.
Up to YELLOW: Productivity
is optimized.
Up to GREEN: More
sheets can be added.
All indicators light up
and shredder pauses for
three to six seconds.
If ( ) illuminates after paper has
been reversed, press reverse and
remove paper. Otherwise, regular
shredding will resume.
Continue
Shredding.
123
Stops shredding immediately when hands touch the paper opening.
18
18
18
1. Turn the shredder
ON ( ) to activate
SafeSense® .
2. Touch test area
and look for the
SafeSense®indicator
to illuminate.
3. SafeSense®is
active and
working properly.
4. If hand is held on
SafeSense®area more
than three seconds,
shredder will shut off.
SAFESENSE®TECHNOLOGY
18
18
or

PAGE 4 OF 5 0818 IH-2607
Optimal energy efficiency 100% of the time – in use and out of use.
• Saves energy in four ways: energy efficient electronics, jam prevention,
standby mode and sleep mode.
• Sleep mode shuts down shredder after two minutes of inactivity.
18
1. In sleep mode. 2. To get out of sleep
mode, touch control
panel.
ENERGY SAVINGS SYSTEM
PRODUCT FEATURES CONTINUED
3. Insert paper.
18
or
CLEANING AUTO-START INFRARED SENSORS
Paper detection sensor are for maintenance-free
operation. However, on rare occasions the sensors may
become blocked by paper dust, causing the motor to
run even when there is no paper present.
NOTE: Two paper detection sensors are located
in the center of the paper entry.
18
18
1. Turn off and
unplug shredder.
2. Locate auto-start
infrared sensor.
3. Dip cotton swab
in rubbing alcohol.
4. Using cotton swab, wipe away any
contamination from the paper sensors.
MAINTENANCE
18
1. Apply oil
across entry.
OILING SHREDDER
All cross-cut shredders require oil for peak performance.
If not oiled, a machine may experience diminished
sheet capacity, intrusive noise when shredding and
could ultimately stop running. To avoid these problems,
we recommend oiling shredder each time user empties
waste bin.
CAUTION! Use only a non-aerosol vegetable oil
in long nozzle container, such as S-16094.
Follow oiling procedures below and repeat twice.
2. Press and hold Forward ( )
for two to three seconds.

PAGE 5 OF 5 0818 IH-2607
πCHICAGO • ATLANTA • DALLAS • LOS ANGELES • MINNEAPOLIS • NYC/PHILA • SEATTLE • MEXICO • CANADA
1-800-295-5510
uline.com
TROUBLESHOOTING
OPERATING ISSUE RECOMMENDATIONS
Overheat Indicator When the Overheat Indicator is illuminated:
1. Allow the shredder to cool down.
2. Resume shredding once the Overheat Indicator is no longer
illuminated.
Bin Open When Bin Open is illuminated:
1. Close the bin.
2. Resume shredding.
Bin Full When Bin Full is illuminated:
1. Empty the bin.
2. Resume shredding.
Remove Paper When Remove Paper is illuminated:
1. Press the Reverse button ( ) and remove the paper.
2. Reduce paper quantity to an acceptable amount and
refeed into paper entry.
SafeSense®Indicator When SafeSense®Indicator is illuminated:
1. Remove hands from proximity of the paper entry.
NOTE: If illuminated for more than 3 seconds, the shredder will
automatically turn off. In this case, press the power button on
the control panel to resume shredding.
