U-Line Echelon 2075RF User manual

1. Frost Free Technology
BENEFIT: Eliminates the need to defrost the
2075RF. The 2075RF is the only built-in under the
counter refrigerator/freezer on the market which
utilizes frost free technology.
2. Optional full overlay door capability (panel kit)
using a 3/4 inch thick panel
BENEFIT: Provides a fully integrated appearance
with surrounding cabinets. Overlay panel is easily
attached to the door.
3. A large vertically designed freezer compartment
BENEFIT: A vertical freezer compartment
provides more storage space and easier accessibility
to the products within the freezer compartment. Tall
items can now be easily stored in the freezer area.
4. Three fully encapsulated, contoured, spill proof
shelves
BENEFIT: Upscale appearance that contains
spills to one shelf. Easy to clean. The shelves consist
of two half shelves located on the side of the freezer
compartment and a full stylized etched bottom
crisper shelf.
5. Two adjustable, contoured, self contained, inner
door “pick-off” shelves
BENEFIT: These highly stylized shelves are
adjustable for the storage of a variety of different
bottle, can, and container sizes and shapes thereby
providing optimum space utilization and flexibility.
The self contained shelves can be removed and used
to transport their contents to other cooking areas in
the home or outside patio.
6. Bottom inner door shelf accommodates a two
liter or 750 ml bottle
BENEFIT: Provides greater storage capabilities
and flexibility.
7. Highly styled, removable, clear lower crisper
drawer
BENEFIT: Optimizes the organization of product
stored in the crisper. The crisper may also be used to
transport its contents to a cooking or serving area.
8. Indented or recessed shelf channels support the
encapsulated shelves
BENEFIT: Provides a sleek, clean appearance to
the interior of the cabinet by eliminating protruding
shelf supports. Also provides a more
secure, rigid fit for the encapsulated
shelves.
EXCLUSIVE FEATURES OF ÉCHELON™
Model 2075RF
A FROST FREE 5.7 cubic foot built-in under
the counter refrigerator/freezer
INCHES (CENTIMETERS)
* ON BACK OF UNIT
FULL
EXTEND
HEIGHT
35-1/8
(89.2)
FULL
RETRACT
HEIGHT
34-1/8
(86.7)
23-1/4
(59.1)
23-15/16
(60.6)
5-7/8
(14.9)
2-7/8
(7.3)
3-3/8
(8.6)
21
(53.3)
* POWER CORD
Custom 1/4" Door Panel: 28-5/32" H x 23-1/32" W (71.5 cm x 58.5 cm)
3/4" Full Overlay Panel: 29-7/8" H x 23-3/4" W (75.9 cm x 60.3 cm)
See Overlay Door Panel Preparation Instructions

9. Colder internal freezer temperatures of between -5
and +5 degrees Fahrenheit
BENEFIT: A new evaporator and improved
refrigeration system design plus the use of a spring
loaded freezer door permits colder freezer temperatures.
Such items as ice cream products and Popsicles®can
now be stored and maintained within the freezer
compartment.
10. The freezer has a removable white vinyl coated wire
shelf that divides the compartment in half.
BENEFIT: Products can be placed underneath and on
top of the wire shelf for easy storage. The shelf can also
be placed on the bottom of the freezer compartment or
completely removed in order to store tall items.
SUPERIOR FEATURES OF ÉCHELON™
ADDITIONAL FEATURES
1. Approximately 4.2 cubic feet of refrigeration and 1.5
cubic feet of freezer.
2. Built-in or freestanding.
3. All doors (except stainless steel) accommodate a 1/4 inch
thick custom panel. All doors come standard with a
factory installed black or white flush panel.
4. Door locks optional on black and white units.
Not available on stainless steel.
5. Interior light.
6. Vinyl clad steel cabinet (black/white).
7. Adjustable leveling legs.
8. Available in black, white, stainless steel.
BENEFITS
Provides both refrigeration and freezer capacity.
Provides custom look. No additional clearance around sides,
top, or rear for ventilation. Do not obstruct front grille.
Standard feature to achieve a custom, built-in look by
matching surrounding cabinets.
Door remain field reversible. Locks located in upper middle
portion of the door.
Automatically illuminates when door opens.
Textured rich look. More resistant to scratching, peeling,
flaking. Cabinet sides extend to the floor.
More precise under the counter fit, durable – factory installed.
Blends with all cabinet colors.
2075RF
EXCLUSIVE FEATURES OF ÉCHELON™
1. Self closing door hinges are engaged when door is
open approximately 8-10 inches
BENEFIT: Ensures a positive door seal and prevents
door bounce back.
2. “L” shaped door hinges
BENEFIT: This hinge design provides greater door
support thereby permitting larger and heavier door
panels and full overlay doors to be utilized.
3. A slightly contoured, across the top, integrated door
handle design for black and white units
BENEFIT: The contoured shape maintains the stylized
shape of the Échelon™ series plus permits full door field
reversibility on black and white units.
4. Flat, recessed, front grille with “warmer/colder”
control settings
BENEFIT: Greater toe kick space. Easy to read
molded temperature control settings. The grille design
shields the interior motor compartment and all electrical
components from view.
5. New condenser design
BENEFIT: Optimizes product performance and energy
efficiency while providing reductions in noise levels.
6. New style condenser fan motor located farther away
from the condenser
BENEFIT: Further reduces the noise level with the
utilization of the new condenser that permits the use of a
lower speed condenser fan.
7. Easier service accessibility to components if needed
BENEFIT: Evaporator and evaporator fan motor are
accessible from the front without removing the freezer
housing. The temperature control and defrost timer are
also more easily accessible.
8. All stainless steel units have a seamless full wrap
stainless steel cabinet and door with sculpted,
contoured handle.
BENEFIT: This seamless full wrap stainless steel door
with sculpted stainless handle distinguishes the Échelon™
stainless steel units from other heavier “commercial”
looks. All stainless steel units have a full wrap stainless
cabinet, stainless hinges, and black grille. All stainless
units must be ordered either right or left hand hinged and
are not field reversible.
9. The 2075RF stainless unit is deemed suitable for
outdoor use by UL.
BENEFIT: For those outdoor applications that require
products that are deemed suitable for outdoor use by UL,
the 2075RF stainless steel unit meets these requirements.
10. Highest energy efficient compressor in its class
BENEFIT: Reduces energy consumption.
11. Field reversible doors (except stainless steel).
BENEFIT: Greater flexibility where the unit can be
installed and allows for side-by-side applications.
