WINE CAPTAIN®DRAWER
MODEL 2275DWRW
Capacity: Stores up to 43 wine bottles (0.75L)
Defrost Type: Automatic (cycle) Defrost
Colors: Stainless Steel and Custom Overlay Frame
Feature Benefit
Independently temperature
controlled drawers
Temperature in each drawer can be set independently
between 40-60°F, providing different storage options.
Touch Control Digital
Technology
• Full-featured, easy-view command center - right at your
fingertips
• Easy to set and see the temperature in each Wine Captain
Drawer
• Manages key model functions and provided user alerts
Black interior Elegant visual appearance
Adjustable on/off interior light • Automatically illuminates when the drawer is opened
• May be manually turned on when drawer is closed for
viewing wines
• Auto shut-off after four hours
• Recessed so as not to interfere with access to wine
Open drawer alarm Audible alert when drawer is left open
Full extension slide-out vinyl-
coated wine racks
Allow for easy access to all wine bottles and prevents bottles
from slipping
Contoured maple-trimmed wine
racks
Wood can be stained or replaced with a solid surface
material to match surrounding décor.
Wine Caddy in bottom drawer Holds 3 bottles, accessible from either side and allows for
convenient transportation of wine
Tinted, thermal glass drawer
fronts
Protects wine from potentially harmful ultraviolet light rays
Stainless steel model • Offers two seamless stainless steel-trimmed glass drawers
with a sculpted stainless steel handle, stainless-like grille
and black cabinet
• Optional bold commercial-style stainless steel handles
available for purchase
Overlay model • A custom overlay frame can be installed to match the
surrounding decor.
• If a custom frame is not installed, a black sculpted handle
must be ordered.
• Black cabinet and grille
Black vinyl-clad cabinet Textured look, more resistant to scratching, peeling or
flaking
Built-in • Product designed for built-in look
• No additional clearance around sides, top or rear of unit
for ventilation. Do not obstruct front grille.
Leveling legs More precise undercounter fit - durable - factory installed
Sabbath or “Black Out” mode Easily turns off all lights and control displays
Contemporary grille design Integrates seamlessly with surrounding cabinets

D
imensions Specifications
&
8900 North 55th Street • Milwaukee, Wisconsin 53223
Phone: [phone] • Fax: [phone] • www.u-line.com
03/23/07 © 2007 U-Line Corporation Printed In U.S.A.
Wine Captain®Drawer Model 2275DWRW
Specifications Capacities
(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.
Anchoring device included and is required for all installations.
To prevent potential interior liner damage, please consult the Installation Guide if you choose to stain the wood trim on the
wine racks.
Please visit www.U-Line.com for Installation Guide.
All specifications subject to change without notice.
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
35-1/8
(89.2)
FULL
EXTEND
HEIGHT
2-7/8
(7.3)
5-7/8
(14.9)
23-15/16
(60.8) 21
(53.3)
22-15/16
(58.3)
25-15/32
(64.7)
21
(53.3)
22-15/16
(58.3)
23-11/16
(60.2) WITH 3/4"
OVERLAY FRAME
* ON BACK OF UNIT INCHES (CENTIMETERS)
2275DWRW
* POWER CORD
(Stainless Steel) (Overlay)
Shipping Weight:
Overlay Model
Stainless Steel Model
155 lbs (71 kg)
155 lbs (71 kg)
(1) Running Amps 2.4
(1) Maximum Start-up Amps 5.5
Refrigerator volume N/A
Freezer volume N/A
Approximate daily ice production N/A
Ice storage N/A
Wine bottle storage (0.75 L) Up to 43
