Ubert FF Series User manual

User Manual
Wall of Flame
FF-Series

Contents Page 3
printed: 06/2020 Subject to change! :FFUserManual.docx
1 Contents
1Contents ................................................................................................................................... 3
2Important References ............................................................................................................... 4
2.1 Basic safety instructions ..................................................................................................... 4
2.2 Warranty and Liability ......................................................................................................... 5
2.3 Explanation of Symbols and notes for the user ................................................................... 5
2.4 Right of origin (Copyright) ................................................................................................... 5
2.5 Special safety notes for the user ......................................................................................... 6
3Product information ................................................................................................................... 8
3.1 Introduction ......................................................................................................................... 8
3.2 Special Features................................................................................................................. 8
3.3 Technical Data ................................................................................................................... 8
4Initial Installation Procedure .................................................................................................... 14
4.1 Unpacking ........................................................................................................................ 14
4.2 Installation ........................................................................................................................ 14
4.3 Electrical connection ......................................................................................................... 15
4.4 Gas connection ................................................................................................................ 15
4.5 Re-adjustment .................................................................................................................. 16
4.6 Waste Water Connection .................................................................................................. 17
4.7 Preparation of Using / Starting up ..................................................................................... 17
5Operation ................................................................................................................................ 18
5.1 Operation elements .......................................................................................................... 18
5.2 Operation / handling ......................................................................................................... 19
6Maintenance ........................................................................................................................... 20
6.1 Cleaning and care ............................................................................................................ 20
6.2 Recommendation for the treatment .................................................................................. 21
6.3 Maintenance of gas technical parts .................................................................................. 22
6.4 Maintenance of the bearing and the drive chain ............................................................... 23
6.5 Changing part ................................................................................................................... 23
6.6 Trouble shooting ............................................................................................................... 24
6.7 Wiring Diagram ................................................................................................................. 25
6.8 Spareparts ........................................................................................................................ 25
6.9 Declaration of Conformity ................................................................................................. 31

Page 4 Important References
printed: 06/2020 Subject to change! :FFUserManual.docx
2 Important References
2.1 Basic safety instructions
2.1.1 Please read advices in the operation manual carefully
• It is important to have knowledge of the basic safety instructions and of your local safety regula-
tions.
• This operation manual contains the most important advices to operate the appliance in the right
safe way.
• We suggest that all operating personnel will follow both, this manual and especially these safety
advices carefully.
• Please follow also the safety instructions issued by your local authorities.
2.1.2 Obligation of the owner/user
The owner/user declares, that he only allows the following personnel to operate the Wall of Flame
Rotisserie:
• People being trained to operate this appliance and do know the regulations about basic safety
instructions and how to prevent possible accidents.
• People who know about the safety chapter and the warnings within this operation manual. They
have to confirm by signing.
These obligations are subject to be checked on a regular basis.
2.1.3 Obligation of the operating personnel
Personnel, being requested to operate this appliance, hereby confirm the following:
• That they know about the basic safety instructions and do know the regulations how to prevent
possible accidents.
• That they have read the safety chapter and warnings in this operation manual and they have
confirmed with their signature having understood all information.
2.1.4 How to use the Rotisseries. Possible risks.
Wall of Flame Rotisseries are built following the latest standard of technic and according to all safety
regulations. However, while operating in case of not following all safety instructions, they may cause
severe risks for the operators and other people’s life. They may also cause possible damages to the
appliance. Therefore, the appliance is only for the use of:
• Operation according to the designed purpose of a rotisserie.
• Being in optimal safe and technical conditions.
All malfunctions, which may affect the safety of the appliance must be repaired immediately.
2.1.5 Operation according to the designed purpose
All Wall of Flame Rotisseries are built for the preparation of food only. Any other use of the unit are
only allowed after consulting UBERT GASTROTECHNIK GMBH. Damages which result out of wrong
use UBERT GASTROTECHNIK GMBH cannot be held responsible. Part of the due use is also:
• the consideration of all references of the operating manual and
• the observance of necessary maintenance and service.
• We recommend a semi-annually maintenance interval.

Important References Page 5
printed: 06/2020 Subject to change! :FFUserManual.docx
2.2 Warranty and Liability
All products from the manufacturer are manufactured to the high nowadays technical standards and
comply with all valid regulations. The manufacturer will grant a warranty to compensate all recog-
nized valid claims. All other Warranty and Liability claims for people and appliances are excluded,
especially if a possible damage is caused:
• In case of any improper use not according to the designed purpose.
• In case of wrong installation, incorrect setting into operation, wrong treatment and maintenance
of the appliance.
• In case of operating the appliance with faulty, missing or not working safety features.
• By disregarding of the operation manual advices especially in the view of transport, storage, in-
stallation, setting into operation, operation and maintenance.
• By changing the appliance without any written permission.
• By changing the power dates without any written permission.
• In the case of non-regular maintenance of any parts being subject to wear and tear.
• In case of nonprofessional service.
• In case of any force majeure.
2.3 Explanation of Symbols and notes for the user
Within this operation manual you will find the following signs and symbols:
This symbol stands for a possible danger for life and health. It also points out to a
possible hazardous situation.
To disregard these symbols may cause severe hazardous effects up to severe inju-
ries. It may also cause severe damages to your appliance!
This symbol will give important notes to the user how to treat the appliance in the right
way.
To disregard these symbols may cause a possible damage to your appliance or to the
environment!
This symbol will give you useful tips and advices.
They will help you in using all functions of the appliance in the best way!
2.4 Right of origin (Copyright)
The copyright on this operation manual remains strictly with the manufacturer. It is only issued for
the owner and his trained personnel. This manual contains regulations and advices which either in
parts or the full brochure may not be:
• duplicated
• circulated or
• used or announced for a different purpose.
Violation may cause criminal prosecution.

Page 6 Important References
printed: 06/2020 Subject to change! :FFUserManual.docx
2.5 Special safety notes for the user
2.5.1 Safety devices (Protection units)
• Before setting the appliance into operation all safety devices and all removable parts
have to be fitted and must operate in working order.
• Safety devices may only be removed after switching off the appliance completely. You
must make sure, that the appliance cannot be switched on again during maintenance
processes.
• All parts and components have to be fitted according to the regulations.
2.5.2 For your information (Informing safety steps)
• These operating instructions should be kept always together with the appliance.
• Supplementing to the operation instructions within this manual all local regulations for
accident prevention and for the protection of the environment are to be considered.
• All stickers for safety and possible hazards on the appliance have to be in a good
readable condition and in a visible position.
2.5.3 Personnel training
• Only trained and instructed personnel is allowed to operate the appliance.
• The responsibilities of the personnel are to be determined clearly for installing, start-
up, operation, assembling, and servicing of the unit.
• Personnel not being trained yet are only allowed to operate the unit under supervision
of a trained and experienced person.
2.5.4 Operating the controls
• Only trained personnel is allowed to operate the controls.
2.5.5 Safety check during operation
• Only operate the appliance if all safety devices are working properly.
• Before switching on, make sure that there is no danger for any person while the ap-
pliance is starting to operate.
• Check appliance at least once per day with regard to visible damages and to the
function of all safety devices.
2.5.6 Possible hazards caused by electric energy
• Repair works on electrical leads and devices must be carried out by qualified electri-
cians only.
• The connection must follow the rules of the local determinations.
• Check the electrical components of the appliance on a regular basis. Wiring being
connected improper or melted cables have to be repaired immediately.
• If there is a need of repair works on life electrical components, always a second per-
son is required to attend and to switch off the main switch in case of emergency.
2.5.7 Special areas of danger
• All removable parts are only to be removed if the Wall of Flame Rotisserie is switched
off and all surfaces and parts are not hot anymore!
• Caution while removing grilled food! All parts may be hot and may cause severe burn-
ings to your skin. Do not reach into the rotisserie while the appliance is hot and oper-
ating. Before removing the waste fat pan take out the waste liquids.

Important References Page 7
printed: 06/2020 Subject to change! :FFUserManual.docx
2.5.8 Maintenance, Trouble Shooting
• All prescribed adjustment-, maintenance- and service works must be carried out by
an authorized service technician on a regular basis.
• Before starting these maintenance- and service works the personnel must be clearly
informed.
• Pull out the plug before maintaining, inspecting and repairing is performed.
• Make sure that all loose screw connections are fixed and secured again.
• Check all safety devices and their proper function carefully at the end of all mainte-
nance-, service and repair works.
2.5.9 Technical amendments to the appliance
• No amendments, changings or reconstructions to the appliance are allowed to be
carried out without the written permission of the manufacturer. Never weld on load-
bearing parts of construction.
• All reconstructions do require a written permission of the manufacturer.
• Improper parts have to be changed immediately.
• Only use original spare parts.
• If you use spare parts of a third party, we cannot take over responsibility of their safe
construction and of any proper use in our appliances. All possible damages caused
by the use of improper parts will not be covered by the manufacturer.
• In case of reconstructions which impair the supply of air for combustion, the function
of the unit has to be examined again.
2.5.10 Cleaning and waste disposal
All matters and materials should be used only in accordance with their purpose. Used
materials, especially those for lubricating and cleaning must be disposed in accordance
with the valid regulations. Only use detergents which are in accordance with the food
hygienic regulations, environmental regulations and the regulations issued by your local
authorities.

Page 8 Product information
printed: 06/2020 Subject to change! :FFUserManual.docx
3 Product information
3.1 Introduction
The most important feature of the FF-series rotisseries is the high functionality with very attractive
optical effects. That guarantees an optimum food processing and presentation, which is the basis
for every selling success.
3.2 Special Features
• Enamelled execution
• Optimum grilling result due to movable spits
• Heat storing cast iron or steel radiators
• Elegant design by metal decoration
• Excellent flame optical effect by glowing glass filaments
• Illumination by halogen light
3.3 Technical Data
3.3.1 Capacity
Depending on the size up to 6 chickens per spit.
3.3.2 Dimensions [mm]
Model W x H x D Number of Spits:
FF - 22: 1120 x 1000 x 675 2
FF - 24: 1120 x 1515 x 675 4
FF - 26: 1120 x 2030 x 675 6
FF - 28: 1120 x 2545 x 675 8
FF - 32: 1450 x 1000 x 675 2
FF - 34: 1450 x 1515 x 675 4
FF - 36: 1450 x 2030 x 675 6
FF - 38: 1450 x 2545 x 675 8
FF - 42: 1780 x 1000 x 675 2
FF - 44: 1780 x 1515 x 675 4
FF - 46: 1780 x 2030 x 675 6
FF - 48: 1780 x 2545 x 675 8
3.3.3 Weight [kg]
Model Net weight:
FF - 22: ca 210kg
FF - 24: ca 290kg
FF - 26: ca 340kg
FF - 28: ca 410kg
FF - 32: ca 280kg
FF - 34: ca 380kg
FF - 36: ca 440kg
FF - 38: ca 510kg
FF - 42: ca 380kg
FF - 44: ca 445kg
FF - 46: ca 495kg
FF - 48: ca 565kg

Product information Page 9
printed: 06/2020 Subject to change! :FFUserManual.docx
3.3.4 Electrical Details, Power Consumption, Noise Emission
Type el. connection [EA] power cons. noise emission
all types 230V, 1/N, 50Hz 0.7 kW < 70 dB (A)
3.3.5 Nozzle table
Model
Kind of gas
Number
of
main
nozzles
=number
of burn-
ers
Size of
main noz-
zles
[mmx100]
Size of minimum
nozzles [mmx100]
Opening of
primary air
[mm]
Size of nozzle
ignition burner
[mmx100]
FF 22
LPG 50mbar
1
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 22
LPG 30mbar
1
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 22
Natural gas H
1
240
50 (adjustable)
open
35 (adjustable)
FF 22
Natural gas L
1
260
50 (adjustable)
open
35 (adjustable)
FF 22
Natural gas E+
1
240
50 (adjustable)
open
35 (adjustable)
FF 24
LPG 50mbar
2
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 24
LPG 30mbar
2
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 24
Natural gas H
2
240
50 (adjustable)
open
35 (adjustable)
FF 24
Natural gas L
2
260
50 (adjustable)
open
35 (adjustable)
FF 24
Natural gas E+
2
240
50 (adjustable)
open
35 (adjustable)
FF 26
LPG 50mbar
3
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 26
LPG 30mbar
3
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 26
Natural gas H
3
240
50 (adjustable)
open
35 (adjustable)
FF 26
Natural gas L
3
260
50 (adjustable)
open
35 (adjustable)
FF 26
Natural gas E+
3
240
50 (adjustable)
open
35 (adjustable)
FF 28
LPG 50mbar
4
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 28
LPG 30mbar
4
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 28
Natural gas H
4
240
50 (adjustable)
open
35 (adjustable)
FF 28
Natural gas L
4
260
50 (adjustable)
open
35 (adjustable)
FF 28
Natural gas E+
4
240
50 (adjustable)
open
35 (adjustable)
FF 32
LPG 50mbar
2
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 32
LPG 30mbar
2
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 32
Natural gas H
2
210
50 (adjustable)
open
35 (adjustable)
FF 32
Natural gas L
2
230
50 (adjustable)
open
35 (adjustable)
FF 32
Natural gas E+
2
210
50 (adjustable)
open
35 (adjustable)
FF 34
LPG 50mbar
4
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 34
LPG 30mbar
4
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 34
Natural gas H
4
210
50 (adjustable)
open
35 (adjustable)
FF 34
Natural gas L
4
230
50 (adjustable)
open
35 (adjustable)
FF 34
Natural gas E+
4
210
50 (adjustable)
open
35 (adjustable)
FF 36
LPG 50mbar
6
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 36
LPG 30mbar
6
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 36
Natural gas H
6
210
50 (adjustable)
open
35 (adjustable)
FF 36
Natural gas L
6
230
50 (adjustable)
open
35 (adjustable)
FF 36
Natural gas E+
6
210
50 (adjustable)
open
35 (adjustable)
FF 38
LPG 50mbar
8
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 38
LPG 30mbar
8
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 38
Natural gas H
8
210
50 (adjustable)
open
35 (adjustable)
FF 38
Natural gas L
8
230
50 (adjustable)
open
35 (adjustable)
FF 38
Natural gas E+
8
210
50 (adjustable)
open
35 (adjustable)

Page 10 Product information
printed: 06/2020 Subject to change! :FFUserManual.docx
Model
Kind of gas
Number
of
main
nozzles
=number
of burn-
ers
Size of
main noz-
zles
[mmx100]
Size of minimum
nozzles [mmx100]
Opening of
primary air
[mm]
Size of nozzle
ignition burner
[mmx100]
FF 42
LPG 50mbar
2
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 42
LPG 30mbar
2
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 42
Natural gas H
2
240
50 (adjustable)
open
35 (adjustable)
FF 42
Natural gas L
2
260
50 (adjustable)
open
35 (adjustable)
FF 42
Natural gas E+
2
240
50 (adjustable)
open
35 (adjustable)
FF 44
LPG 50mbar
4
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 44
LPG 30mbar
4
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 44
Natural gas H
4
240
50 (adjustable)
open
35 (adjustable)
FF 44
Natural gas L
4
260
50 (adjustable)
open
35 (adjustable)
FF 44
Natural gas E+
4
240
50 (adjustable)
open
35 (adjustable)
FF 46
LPG 50mbar
6
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 46
LPG 30mbar
6
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 46
Natural gas H
6
240
50 (adjustable)
open
35 (adjustable)
FF 46
Natural gas L
6
260
50 (adjustable)
open
35 (adjustable)
FF 46
Natural gas E+
6
240
50 (adjustable)
open
35 (adjustable)
FF 48
LPG 50mbar
8
130
80 (screwed tightly)
open
20 (screwed tightly)
FF 48
LPG 30mbar
8
140
90 (screwed tightly)
open
20 (screwed tightly)
FF 48
Natural gas H
8
240
50 (adjustable)
open
35 (adjustable)
FF 48
Natural gas L
8
260
50 (adjustable)
open
35 (adjustable)
FF 48
Natural gas E+
8
240
50 (adjustable)
open
35 (adjustable)
For the Netherlands with connection pressure 25 mbar for natural gas the nozzle size (main noz-
zle) is: 220 [mmx100]

Product information Page 11
printed: 06/2020 Subject to change! :FFUserManual.docx
3.3.6 Indication of consumption
Model
Kind of gas
Max.
Nominal
Heat
Load
[kW]
Min.
Nominal
Heat Load
[kW]
Consumption
flow of LPG on
HuB=12,68
kwh/kg
[kg/h]
Consumption
flow Natural
gas H on
HuB=9,45
kwh/m³
[m³/h]
Consumption
flow Natural
gas L on
HuB=8,125
kwh/m³
[m³/h]
FF 22
LPG
10
3,47
0,79
/
/
FF 22
Natural gas H
10
2,83
/
1,05
/
FF 22
Natural gas L
10
3,04
/
/
1,23
FF 22
Natural gas E+ 20mbar
10
2,83
/
1,05
/
FF 22
Natural gas E+ 25mbar
9
2,33
/
1,05
/
FF 24
LPG
20
6,93
1,58
/
/
FF 24
Natural gas H
20
5,65
/
2,11
/
FF 24
Natural gas L
20
6,08
/
/
2,46
FF 24
Natural gas E+ 20mbar
20
5,65
/
2,11
/
FF 24
Natural gas E+ 25mbar
18
4,67
/
2,11
/
FF 26
LPG
30
10,4
2,37
/
/
FF 26
Natural gas H
30
8,48
/
3,17
/
FF 26
Natural gas L
30
9,12
/
/
3,69
FF 26
Natural gas E+ 20mbar
30
8,48
/
3,17
/
FF 26
Natural gas E+ 25mbar
27
7
/
3,17
/
FF 28
LPG
40
13,87
3,15
/
/
FF 28
Natural gas H
40
11,31
/
4,23
/
FF 28
Natural gas L
40
12,16
/
/
4,93
FF 28
Natural gas E+ 20mbar
40
11,31
/
4,23
/
FF 28
Natural gas E+ 25mbar
36
9,33
/
4,23
/
FF 32
LPG
15
5,2
1,18
/
/
FF 32
Natural gas H
15
4,24
/
1,58
/
FF 32
Natural gas L
15
4,56
/
/
1,85
FF 32
Natural gas E+ 20mbar
15
4,24
/
1,58
/
FF 32
Natural gas E+ 25mbar
13,5
3,5
/
1,58
/
FF 34
LPG
30
10,4
2,37
/
/
FF 34
Natural gas H
30
8,48
/
3,17
/
FF 34
Natural gas L
30
9,12
/
/
3,69
FF 34
Natural gas E+ 20mbar
30
8,48
/
3,17
/
FF 34
Natural gas E+ 25mbar
27
7
/
3,17
/
FF 36
LPG
45
15,6
3,55
/
/
FF 36
Natural gas H
45
12,72
/
4,75
/
FF 36
Natural gas L
45
13,68
/
/
5,54
FF 36
Natural gas E+ 20mbar
45
12,72
/
4,75
/
FF 36
Natural gas E+ 25mbar
40,5
10,5
/
4,75
/
FF 38
LPG
60
20,8
4,73
/
/
FF 38
Natural gas H
60
16,96
/
6,34
/
FF 38
Natural gas L
60
18,24
/
/
7,39
FF 38
Natural gas E+ 20mbar
60
16,96
/
6,34
/
FF 38
Natural gas E+ 25mbar
54
14
/
6,34
/

Page 12 Product information
printed: 06/2020 Subject to change! :FFUserManual.docx
Model
Kind of gas
Max.
Nominal
Heat
Load
[kW]
Min.
Nominal
Heat Load
[kW]
Consumption
flow of LPG on
HuB=12,68
kwh/kg
[kg/h]
Consumption
flow Natural
gas H on
HuB=9,45
kwh/m³
[m³/h]
Consumption
flow Natural
gas L on
HuB=8,125
kwh/m³
[m³/h]
FF 42
LPG
20
6,94
1,58
/
/
FF 42
Natural gas H
20
5,66
/
2,1
/
FF 42
Natural gas L
20
6,08
/
/
2,46
FF 42
Natural gas E+ 20mbar
20
5,66
/
2,1
/
FF 42
Natural gas E+ 25mbar
18
4,66
/
2,1
/
FF 44
LPG
40
13,86
3,16
/
/
FF 44
Natural gas H
40
11,3
/
4,22
/
FF 44
Natural gas L
40
12,16
/
/
4,92
FF 44
Natural gas E+ 20mbar
40
11,3
/
4,22
/
FF 44
Natural gas E+ 25mbar
36
9,34
/
4,22
/
FF 46
LPG
60
20,8
4,74
/
/
FF 46
Natural gas H
60
16,96
/
6,34
/
FF 46
Natural gas L
60
18,24
/
/
7,38
FF 46
Natural gas E+ 20mbar
60
16,96
/
6,34
/
FF 46
Natural gas E+ 25mbar
54
14
/
6,34
/
FF 48
LPG
80
27,74
6,3
/
/
FF 48
Natural gas H
80
22,62
/
8,46
/
FF 48
Natural gas L
80
24,32
/
/
9,86
FF 48
Natural gas E+ 20mbar
80
22,62
/
8,46
/
FF 48
Natural gas E+ 25mbar
72
18,66
/
8,46
/
3.3.7 Valid categories for the use of the Wall of Flame Rotisserie
Country
Country Specification
Category
Pressure
Germany
DE:
II2ELL3B/P
20, 50 mbar
Austria
AT:
II2H3B/P
20, 50 mbar
Italy
IT:
I2H
20 mbar
Portugal
PT:
I2H
20 mbar
Spain
ES:
I2H
20 mbar
Sweden
SE:
II2H3B/P
20, 30 mbar
Switzerland
CH:
II2H3B/P
20, 50 mbar
Netherland
NL:
II2L3P, II2L3B/P
25, 30, 50 mbar
Denmark
DK:
II2H3B/P
20, 30 mbar
Finland
FI:
II2H3B/P
20, 30 mbar
Ireland
IE:
I2H
20 mbar
Great Britain
GB:
I2H
20 mbar
Norway
NO:
II2H3B/P
20, 30 mbar
Belgium
BE:
I2E I3P
20, 50 mbar
France
FR:
II2E+3B/P
20/25, 50 mbar
Iceland
IS
II2H3B/P
20, 30 mbar
Czech Republic
CZ
II2H3B/P
20, 30 mbar

Product information Page 13
printed: 06/2020 Subject to change! :FFUserManual.docx
3.3.8 Name Plate
The installation and operation manual is made for the Ubert Wall of Flame Rotisserie of the model
series FF with the categories of natural gas and LPG mentioned under point 3.3.8. The units corre-
spond to kind of construction "A".
The type plate is fixed on the front side of the unit and bears the following indications:
- Serial number, type
- Order number kind of construction acc. to DIN-EN 203 A B
- Applicable for natural gas H/L and LPG
- Category
- Adjusted for natural gas H 20 mbar
- for natural gas L 20 mbar
- for LPG mbar
- Heat Load kW
- Adjustment pressure / pressure control [mbar]
- Consumption: natural gas H m³/h
- natural gas L [m³/h]
- LPG [kg/h]
- Power [kW]
- Electrical connection.: V N Hz
- 0085
Differing from a.m. indications the type plate will be executed suitable for the following countries:
Netherlands for natural gas L: connection pressure 25 mbar
France and Belgium for natural gas E+: connection pressure 20 resp.. 25 mbar.
3.3.9 Construction of the Wall of Flame Rotisserie und equipment
The unit is a Wall of Flame Rotisserie with atmospheric main burners, pilot flame burner and chicken
spits which are driven by a motor chain gear. The gas connection is at the lower right side of the
unit. The temperature control is made by multiple adjustment valves with thermoelectrical ignition
safety device (fully ignition safe gas armatures) The operation temperature can be adjusted infinitely
variable from the minimum adjustment to the maximum adjustment. Each burner is ignited separately
by a piezo igniter. Motor and illumination are switched on or off by turning cam switches.

Page 14 Initial Installation Procedure
printed: 06/2020 Subject to change! :FFUserManual.docx
4 Initial Installation Procedure
Our Wall of Flame Rotisseries are packed for safe transport, so that they can reach their
destination without any damages. However, we advise an examination of the Wall of
Flame Rotisserie right after delivery.
Attention! Do report visible damages immediately!
4.1 Unpacking
• Open the box and take out the wrapping and filling material carefully.
• Take out all single parts and check whether these are complete (compare with enclosed dispatch
documents).
• Now please remove the cardboard packaging and all wrapping and covering folios from the rotis-
serie.
4.2 Installation
4.2.1 General information
• Install the feet of the unit and set it up at the place as wanted.
• Set up the unit on an even, horizontal surface! Line up the unit horizontal.
• Observe that all slots for air supply and ventilation are held free and are at least 100
mm away from walls or similar things which could block the slots.
• Take care that the area around the rotisserie is free in order to load, unload, clean the
unit or that maintenance works can be done smoothly.
• The unit has to be set up in a way that the surrounding area can be cleaned.
4.2.2 Place of operation
Attention! The device must be placed on a level, solid and fireproof surface in an well
ventilated room under an on-site extraction hood. Depending on the type, the device
can be placed freely, on a temperature-resistant wall or with other devices in a row. A
minimum distance of 100mm from the sidewalls, the rear wall and walls mad of possibly
combustible material must be met. When these distances are too narrow, you have to
take heat conversation measures, e.g. tiling the walls or affixing of a radiation protection.
Before you connect the device, you have to check the type plate, whether the device is
approved for the used gas type. If the kind of gas indicated on the type plate does not
agree with the required kind of gas, the installation of the device is not allowed until the
unit has been adjusted according to the requirements
4.2.3 Statutory orders, technical regulations and directions
The following regulations have to be observed when the unit is set up:
• local statutory orders
• local laws valid for your countries
• technical regulations for LPG
• directions of the local gas supply company
Furthermore, regulations of accident prevention valid for your country have to be ob-
served.
For operating the unit outside Germany, the national laws, technical regulations and di-
rections of the specific country are valid.

Initial Installation Procedure Page 15
printed: 06/2020 Subject to change! :FFUserManual.docx
4.2.3 Special advices regarding the gas exhaust
Attention! The rotisserie has to be set up in sufficiently ventilated rooms and below an
existing ventilation hood. The unit corresponds to kind of construction "A". The installa-
tion to an exhaust gas device (ventilation hood) is necessary in order to lead out the
exhaust gas immediately.
4.2.4 Installation
Before the installation get the approval from your gas supply company. Only approved
technicians are allowed to make the gas connection in compliance with the following
relevant regulations. The devices require regular maintenance by an approved techni-
cian, especially in regard to burner-, controller-, and safety installations. Maintenance,
conversion to another type of gas should only be carried out by a technician, approved
by the responsible gas supply company.
4.3 Electrical connection
Note! Note that also after installation and electrical connection the plug must be acces-
sible. If this is not possible due to structural reasons, or if the unit is connected perma-
nently, the power supply needs to have an interlock switch.
Note! During any servicing, take care that the unit is disconnected from the mains! Not
paying attention may result in injury!
Please learn the electrical and technical data of your unit from the nameplate.
• The unit is ready for plug-in.
• For power supply a shockproof socket is necessary.
• Make sure the supply cable is protected separately with 16 Amps.
The existing connection cable for the electrical connection is positioned at the lower right
rear wall.
Note!
After finishing any installation work, maintenance or repair check whether the ground
wires are connected properly to the casing.
4.4 Gas connection
Please control, if the device is arranged for the present type of gas. Compare the indi-
cated kind of gas on the type plate with the existing kind of gas. If this is not identical,
you have to make adjustments to meet the local conditions. The gas connection de-
pends on the type (external thread right to DIN-ISO 7/1 [DIN 2999 Part 1] ¾ inch). The
connection with the gas supply has to be made with a connection armature (under ob-
servation of DVGW-TRGI resp. TRF and DVGW- worksheet G-634). Only an approved
technician is allowed to do this. After the gas connection has been made, all connection
points and also the device itself must be checked for leaks. This has to be made under
operating pressure by leak detection spray or by brushing with a non-corrosive foam-
forming medium.
4.4.1 Preparation for operation
The units have to be checked on their designed nominal heat load and adjusted accordingly if re-
quired when they are installed the first time or after any maintenance work. This has to be made.
Please learn the necessary values from the table in section 3.3.7.

Page 16 Initial Installation Procedure
printed: 06/2020 Subject to change! :FFUserManual.docx
4.4.2 Control of nominal heat load
Firstly, please check whether the unit is adjusted for the existing kind of gas. For this you have to
check whether the indication on the type plate corresponds to the existing kind of gas. If you adjust
the unit for other gas types please check the indication of the nozzles. The nominal heat load re-
sults from using the right nozzle with connection pressure of
+ 20 mbar with natural gas H and natural gas L (for France E+)
+ 50 mbar with LPG
by taking effect of the corresponding nozzle area.
The permission of operation with the resulting nominal heat load under dependency of the planned
nozzles results from the following connection pressure bounds:
15 to 25 mbar with natural gases)
25 to 35 mbar and 42.5 to 57.5 mbar with LPG
Starting the operation outside these pressure bounds is not permitted.
The connection pressure is measured by a pressure gauge (indication exactness: 0.1 mbar). For
this the sealing screw in the connection pressure measuring socket of the main gas supply has to
be loosened and the pressure gauge has to be connected.
4.4.3 Checking of nominal heat load with LPG
Check whether the indication of used nozzles corresponds to the indications of the manufacturer.
Secure that the existing low-pressure regulator on site does not exceed a maximum output pres-
sure of 50 mbar according to section 4.4.2 (control of type plate or pressure measurement).
4.4.4 Control of function
• Set the unit into operation according to the manual.
• Check the unit for gas leaks.
• Check the correct adjustment of primary air and nozzles (pilot flame device, main nozzles (at
the burner nozzle assembly), minimum adjustment nozzles (at the all gas valve).
• Check the transmission ignition and regularly flames of the burners with minimum and maximum
adjustment.
• A maintenance contract is recommended.
4.5 Re-adjustment
Attention! Before any re-adjustment works at the unit are executed the main gas supply
has to be closed and the unit has to be unplugged firstly.
All units of our production are single examined and are adjusted for the kind of gas required by the
customer. If no indication has been made, the units are principally adjusted for LPG. If the unit is to
be re-adjusted it has to be observed that this is made by an approved technician or by the Ubert
service technicians. The corresponding nozzles sizes are to be find in the nozzle table. For re-ad-
justment the following measures have to be made:
• Replacement of pilot flame nozzles.
• Replacement of main nozzles.
• Replacement of bypass nozzle
• Adjustment of primary air.
• Checking of function and indication of new gas type on the type plate at the front of the unit.
4.5.1 Replacement of pilot flame nozzle (pilot flame device)
• Close the main gas supply and unplug the unit.
• Remove the side walls after unscrewing them.
• Remove the ignition cable from the ignition plug at the pilot flame.
• Unscrew the ignition plug from the pilot flame device.
• Unscrew the gas supply connected to the pilot flame device.
• Remove the thermo feeler.

Initial Installation Procedure Page 17
printed: 06/2020 Subject to change! :FFUserManual.docx
• Unscrew the pilot flame device.
• Unscrew the nozzle after removal of the union and replace it according to the nozzle table.
The assembling is to be made in reversed sequence. Afterwards the function has to be checked.
4.5.2 Replacement of main nozzle
• Close the main gas supply and unplug the unit.
Access from the front side of the unit:
• Remove the spits and fat drawers
• Remove the ribs as follows:
1. Push the rib upwards.
2. Push the lower rib to the rear.
3. Pull the rib downwards.
4. Remove the rib to the front.
Access from the rear side of the unit
• Remove the rear wall after un-
screwing it.
• Remove the burner nozzle assembly from the injector case (cast iron part) after unscrewing the
fixing screw at the injector case and the union of the gas supply from the all gas valve.
• Unscrew the main nozzle from the burner nozzle assembly and replace it according to the noz-
zle table.
The re-assembling is to be made in reversed sequence. Afterwards check the function.
4.5.3 Replacement of bypass- / minimum adjustment nozzle
• Remove the lower fat drawer and the bottom plate.
• Pull off the control knobs from the operation panel.
• Pull off the ignition cable from all piezo ignitors.
• Remove the front/operation panel carefully after unscrewing it.
• The minimum adjustment nozzle is to be find at the upper front side of the all gas valve.
• Unscrew the minimum adjustment nozzle and replace it according to the nozzle table.
The re-assembling is to be made in reversed sequence. Afterwards check the function.
4.5.4 Adjustment of minimum position
For LPG and natural gas please learn the size of minimum adjustment nozzle from the nozzle ta-
ble. The corresponding nozzles have to be turned against the stop.
4.6 Waste Water Connection
The water drain of the fat drawer is at the right front. You should drain the fluids/fat com-
ing out of the food products through the ball valve before you remove fat drawer for
cleaning.
4.7 Preparation of Using / Starting up
Before setting your Rotisserie Wall of Flame into operation, please clean all removable parts with a
fat-solving detergent. After cleaning you may dry all surfaces.
Warning! Do not use any flammable Liquids for cleaning. Neither clean your Compact
Rotisserie with high pressure cleaning devices, nor use steam or water-jet-cleaning! You
will find further detailled information about cleaning and maintenance in the special chap-
ter within this manual.
By cleaning your Rotisserie Wall of Flame before first use you will avoid smells and smoke and you
start using your rotisserie in a hygenic and safe way.

Page 18 Operation
printed: 06/2020 Subject to change! :FFUserManual.docx
5 Operation
5.1 Operation elements
Following you find explanations regarding all important position and function components for the
operation of the unit:
1. Spit for taking up the grill products
2. Fat Drawer catches the meat juice and fat coming out of the grill product
3. Gear chain sets the spit in rotation
4. Spit support used as outer support of spit.
5. Control knob used for adjustment of the gas burner
6. Rotation switch switches on or off the spit gear
7. Light switch switches on or off the illumination as well as the ventilation
8. Ball drain cock used for draining fluids out of the fat drawer

Operation Page 19
printed: 06/2020 Subject to change! :FFUserManual.docx
5.2 Operation / handling
Please observe the following check list for starting the operation of the unit.
Attention! The ignition process takes place principally from downwards to upwards.
• For igniting you have to turn the knob one eighth (1/8) rotation to the left
towards the ignition symbol.
• Then push the knob up to the stop so that the gas flows out.
• For ignition push the key of the piezo igniter.
• After the ignition still push the knob for approx. 15 – 20 seconds.
• For minimum adjustment, you have to turn the knob counter-clockwise.
• Turn the knob on position 0 in order to switch off the main burner.
When you adjust the spit distances please observe that the spits are moved parallel to
the burner in order to achieve an even product result and in order not to overstrain the
spit gear motor.
5.2.1 Optional: Equipped with glass doors
Information: To allow thermal expansion of the glass doors, the hinges are designed with large
tolerances. Because of that, the doors may not be exactly parallel to each other.

Page 20 Maintenance
printed: 06/2020 Subject to change! :FFUserManual.docx
6 Maintenance
Following we give you advices for maintenance, possible trouble shooting and for service cases of
your unit.
6.1 Cleaning and care
6.1.1 Safety advices
• Before you start any cleaning or maintenance work close the main gas supply and
unplug the unit.
• Never use flammable liquids, nor use any sharp or metallic utensils for cleaning your
appliance. Do not use high pressure water or steam appliances! More detailed infor-
mation to follow below.
• Wear acidproof gloves while cleaning the parts to prevent skin irritations.
6.1.2 General Recommendations
• The unit has to be cleaned daily.
• Only use non-poisonous cleaners (neutral or alkaline detergents) which are harm-
less in connection with food, even if there are plain and persistent residues.
• After cleaning with special cleaners, you have to wash all parts with clear water and
dry them afterwards so that there are no residues of the cleaner on these parts.
• It is absolutely necessary to watch out for some fundamental things to keep this
long living high-grade-steel-machine working:
- always keep the high-grade-steel surface clean.
- watch out that there is always enough fresh air on the surface
- never contact the surface with rusty material
• never use bleaching or chlorine cleaners.
• Observe that no residues or waste reaches the burner or thermo element during op-
eration or cleaning, as this can cause damages to the proper control
• of the burner.
6.1.3 Special Recommendations
Control the grease lubrication of the bearings and the chain at least quarterly, more
often if necessary. If the bearings and the chain are not greasy enough, grease them
to ensure a reliable working of the bearing. For lubrication use heat-resistant grease
only. Disregarding follows defect bearings and breakdown of the spit rotation! (Heat-
resistant grease (part no. 412221) and grease guns (part no. 550408) are available at
Ubert.)
6.1.4 Detergents
To make the cleaning fast and easy we have integrated some cleaners in our pro-
gram:
• Stainless steel-cleaner
You have to spray this from a distance of app. 25 cm on the surface and wipe it off
with a dry-cleaning rag. If you want to clean only small parts you have to spray it
directly on the cleaning rag and wipe it off this way. With this method it is possible to
clean the Rotisserie Wall of Flame easily and without stripes.
