Ubiquiti UVC-G3-BULLET User manual

Camera Cable Gland Screw Anchors (Qty.
2)
Self-Tapping Screws
(Qty. 2)
Pole Mount Bracket Machine Screws (Qty.
2)
Package Contents
Installation Requirements
Shielded Category 5 (or above) cabling should be used for
all wired Ethernet connections and should be grounded
through the AC ground of the PoE.
We recommend that you protect your networks from harmful
outdoor environments and destructive ESD events with
industrial-grade, shielded Ethernet cable from Ubiquiti. For
more details, visit ui.com/toughcable
UVC-G3-BULLET Quick Start Guide

Ethernet Port
Reset Button
Hardware Overview
10/100 RJ45 port connects to an 802.3af PoE switch for
PoE power and data.
To reset to factory defaults, press and hold the Reset button
for more than 10 seconds while the camera is powered on.
Hardware Installation
Wall/Ceiling Mount
1.

2.
3.

4.
5.

OR
6.

7.
8.

9.
Pole Mount
1.
2.

3.
4.

5.
Connecting Power

UniFi Protect App
Launch the UniFi Protect app and follow the on-screen
instructions to complete setup.

UniFi Video App
Note: For UniFi Video 3 deployments, there is a
UniFi Video mobile app available for download in
the App Store® for iOS devices and Google Play™
store for Android-based devices.
For details on using the UniFi Video software, refer to the User
Guide at: ui.com/download/unifi‑video
Adjusting the Camera View
1.
2.
Specifications
UVC-G3-BULLET
Dimensions Ø 75 x 140 mm

(Ø 2.95 x 5.51")
Weight 300 g
(10.58 oz)
Enclosure Injection-Molded Polycarbonate and
Die-Cast Aluminum
Networking Interface (1) 10/100 Ethernet Port
Sensor 1/3" 4-Megapixel HDR Sensor
Lens EFL 3.6 mm, f/1.8
Viewing Angle
Before Lens Correction 85° (H), 44.8° (V), 98.1° (D)
After Lens Correction 72° (H), 42.9° (V), 80.4° (D)
Night Mode IR LEDs with Mechanical IR Cut Filter
Video Compression H.264
Resolution 1080p Full HD (1920 x 1080)
Maximum Frame Rate 30 FPS
Image Settings Brightness, Contrast, Sharpness,
Saturation, Noise Reduction, 50/60 Hz
Processor Ambarella S2L
Memory 512 MB DDR3L
Management Interface UniFi Protect, UniFi Video
Microphone Yes
Max. Power
Consumption
4W
Power Method 802.3af or 24V Passive PoE
Power Supply 802.3af PoE Switch
Buttons Factory Reset Button
Mounting Wall/Ceiling (Kits Included)
Pole (Kit Not Included)
Operating Temperature -20 to 50° C
(-4 to 122° F)

Operating Humidity 20 to 90% Noncondensing
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Hot surface. Do not touch.
WARNING: Do not use this product in location that can be
submerged by water.
WARNING: Avoid using this product during an electrical
storm. There may be a remote risk of electric shock from
lightning.
Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Hot surface. Do not touch.
WARNING: Do not use this product in location that can be
submerged by water.
WARNING: Avoid using this product during an electrical
storm. There may be a remote risk of electric shock from
lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and
current requirements indicated on the manufacturer’s label.

Connection to a different power source than those specified may
result in improper operation, damage to the equipment or pose a fire
hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment.
Service should be provided only by a qualified service technician.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and
current requirements indicated on the manufacturer’s label.
Connection to a different power source than those specified may
result in improper operation, damage to the equipment or pose a fire
hazard if the limitations are not followed.
2. There are no operator serviceable parts inside this equipment.
Service should be provided only by a qualified service technician.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes
on an individual basis, and, where applicable, specify arbitration instead
of jury trials or class actions.
Limited Warranty
ui.com/support/warranty
The limited warranty requires the use of arbitration to resolve disputes
on an individual basis, and, where applicable, specify arbitration instead
of jury trials or class actions.
Compliance
FCC
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions.
1. This device may not cause harmful interference, and

2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operations of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
ISED Canada
CAN ICES-3(A)/NMB-3(A)
Australia and New Zealand
Warning: This equipment is compliant with Class A of CISPR
32. In a residential environment this equipment may cause
radio interference.
CE Marking
CE marking on this product represents the product is in compliance
with all directives that are applicable to it.
WEEE Compliance Statement
Compliance
FCC
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate

the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions.
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operations of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
ISED Canada
CAN ICES-3(A)/NMB-3(A)
Australia and New Zealand
Warning: This equipment is compliant with Class A of CISPR
32. In a residential environment this equipment may cause
radio interference.
CE Marking
CE marking on this product represents the product is in compliance
with all directives that are applicable to it.
WEEE Compliance Statement
Declaration of Conformity

Online Resources
