Ubiquiti UniFi UVC-G3-Flex User manual

1080p Indoor/Outdoor IP Camera with
Infrared and 802.3af Support
Model: UVC-G3-Flex

Package Contents
G3 Flex Camera Base Mount Pole/Wall
Mount
Outdoor
Cover
Security Screw
(Qty. 1)
Screws
(Qty. 3)
Screw Anchors
(Qty. 3)
Zip Ties
(Qty. 2)
Installation Requirements
• Phillips screwdriver
• Drill and 6 mm (1/4") bit for drywall anchors and 3 mm (1/8")
for screws)
• Category 5e (or above) Ethernet cable
Note: When using the Outdoor Cover, use an Ethernetcable
without a strain-relief boot on the connector. This willprevent
unnecessary tension on the cable ends during installation.
Cable without a strain-relief boot Cable with a strain-relief boot

Outdoor Installation Requirements
IMPORTANT: When installed outdoors, the camera must be
installed in the upright postion only.
• Mount the camera in the upright position only. Please see
diagram below.
• Shielded Category 5e (or above) cabling with drain wire
should be used for all outdoor wired Ethernet connections
and should be grounded through the AC ground of the PoE.
We recommend that you protect your networks from
harmful outdoor environments and destructive ESD events
with industrial‑grade, shielded Ethernet cable from Ubiquiti
Networks. For more details, visit ui.com/toughcable
• Surge protection should be used for all outdoor installations.
We recommend that you use two Ethernet Surge Protectors,
model ETH‑SP‑G2, one near the UVC‑G3‑Flex and the other
at the entry point to the building. The ETH‑SP‑G2 will absorb
power surges and safely discharge them into the ground.
To LAN
ETH-SP-G2
ETH-SP-G2
US-8-150W
UVC-G3-Flex
Diagram Showing Use of Ethernet Surge Protectors

Before You Begin
The UVC G3 Flex camera is designed to work with Ubiquiti's
new integrated management system, UniFi Protect.
UniFi Protect is a flexible and powerful IP video surveillance
system that can manage UniFi Protect cameras and the UniFi
Protect mobile app. The software is free from all hosting and
licensing fees and comes pre‑installed on UniFi's Cloud Key Gen2
Plus, model UCK‑G2‑PLUS.
UniFi Cloud Key Gen2 Plus, model UCK-G2-PLUS
For more information on UniFi Protect, visit us on the web at:
unifi-protect.ui.com
Note: The UVC G3 Flex camera will also work with the
UniFi Video®3 controller software.
UniFi Video may be hosted on any of the following:
• UniFi Application Server, model UAS‑XG
• UniFi NVR, model UVC‑NVR‑2TB
• A Linux or Windows computer
UniFi Application Server, model UAS-XG UniFi NVR, model UVC-NVR-2TB
Note: The latest UniFi Video 3 software, for Linux‑ or
Windows‑based computers, is available for free
download at: ui.com/download/unifivideo

Hardware Overview
Microphone
Camera Lens
Light Sensor
LED
Swivel Base
Microphone Microphone for recording audio
Camera Lens Lens for viewing/recording video
Light Sensor Sensor for ambient light detection
LED Status indicator for the following:
LED State Status
Alternating
White/Blue
Device is busy; do not touch or unplug it.
This usually indicates that a process such
as a firmware upgrade is taking place.
Steady Blue Connected to Controller;
Reset Button Pressed
Flashing Green Disconnected from Controller
Steady White Awaiting adoption
Swivel Base Allows you to change the viewing angle of the
camera by adjusting left or right. Useful if mounted on a wall
or other permanent surface.

Bottom View
Ethernet Port Reset Button
Ethernet Port The Ethernet Port is a 10/100 Mbps port used
to supply power from a PoE 802.3af‑compliant switch to the
camera. The switch should be connected to a LAN running
DHCP services and the UniFi Video Controller software.
Reset Button The Reset Button is used to reset the camera to
factory defaults. Press and hold the Reset Button for more than
10 seconds while the camera is powered on.
Mounting Options
Use the Base Mount by itself to install the G3 Flex
camera on a desktop or tabletop. Out of the box,
this mount comes preinstalled on the camera.
Use the Base Mount with two screws to install the
G3 Flex camera on a wall (vertically).
Use the Base Mount with two screws to install
the G3 Flex camera on a solid horizontal surface
or ceiling.
Use the Pole Mount with two screws and the
Outdoor Cover to install the G3 Flex camera on a
wall or at surface outdoors. The Outdoor Cover is
not required for indoor installations.
Use the Pole Mount with two plastic zip ties and
the Outdoor Cover to install the G3 Flex camera
on an outdoor pole. The Outdoor Cover is not
required for indoor pole installations.

Additional Mounts Available
There are two additional mounts available for the G3 Flex: a
Ceiling Mount and a Pendant Mount. Each is sold separately.
Use the optional Ceiling Mount, Screw Kit, and
Mount Cover to install the G3 Flex camera on a
solid horizontal surface or ceiling.
Use the optional Ceiling Mount, Mount Cover, and
Back Plate Assembly to install the G3 Flex camera
on a drop tile ceiling or horizontal surface
where the interior side of the Ceiling Mount is
accessible.
Use the Pendant Mount to install the G3 Flex
camera onto a tted 3/4" or 1.5" conduit mount
or ceiling pipe.

Installation
The UVC G3 Flex can be installed using one of the following
methods:
• Desktop For installing on a flat surface such as a desktop
or table/shelf; could be set up for temporary installations.
• Wall/Ceiling For installing in a secure location; used more
for stationary or permanent installations.
• Pole For installing on a pole (indoor or outdoor).
Proceed to the appropriate section for your installation.
Note: The viewing angle or surveillance coverage of the
G3 Flex camera can be changed at any time.
• Tilt the lens up or down for vertical adjustment
• Turn the base left or right for horizontal adjustment

Desktop
1. Remove the Base Mount from the base of the camera.
2. Insert one end of the RJ‑45 cable into the Ethernet Port and the
other end into a PoE 802.3af‑compliant switch.
3. Attach the camera to the Base Mount by lining up the
notches with the slots in the base of the camera. Press
firmly together until the camera is secure.
Note: Ensure the Ethernet cable is seated in the notch
between the Base Mount and base of the camera.

4. Place the camera on a desk or table in its upright position.
5. Adjust the viewing angle or surveillance coverage as
needed by following these steps:
• Tilt the lens up or down to adjust the angle vertically
• Turn the camera body left or right to adjust the angle
horizontally
Installation complete.
Desktop / Table Install

Wall/Ceiling
1. If the Ethernet cable is coming from the inside of a wall:
a. Drill or cut a hole in the wall and feed the Ethernet
cable through the opening.
b. Pull the Ethernet cable forward and slide it through the
opening in the mount.
2. Use the Screws and Screw Anchors to secure the Base Mount
to the wall.
Top Side Down Mounting
or
Vertical Upright Mounting
3. Connect the Ethernet cable to the Ethernet Port in the base
of the camera.

4. Attach the camera to the Base Mount by lining up the
notches with the slots in the base of the camera. Press
firmly together until the camera is secure.
Vertical mounting on ceiling
or
Vertical mounting on a wall
Installation complete.
Horizozntal Surface / Ceiling with Base Mount
Indoor Wall with Base Mount

Pole
Note: If you are mounting the camera outdoors, it must
be installed in the upright position to prevent water
from getting into the base of the camera. Use the
OutdoorCover for additional protection from moisture.
1. Attach the Pole Mount to a pole using the included Zip Ties.
2. Insert and pull an Ethernet cable through the back port
opening of the Outdoor Cover.
Note: When using the Outdoor Cover, use an Ethernet
cable without strain‑relief boots on the connector. This
will prevent unnecessary tension on the cable ends.
3. Connect the Ethernet cable to the Ethernet Port on the
G3 Flex camera.

4. Attach the camera to the Outdoor Cover by lining up the
notches with the slots on the bottom of the camera. Press
firmly until the camera snaps on.
5. Attach the camera to the Pole Mount:
a. Press the camera against the Pole Mount and line up
the notches on the mount with the slots on the
bottom of the camera.
b. Slide the camera down onto the Pole Mount until it
is secure.
Note: When using the Outdoor Cover, use an Ethernet
cable without strain‑relief boots on the connector. This
will prevent unnecessary tension on the cable ends.

6. Use a phillips screwdriver to install the Security Screw
through the Outdoor Cover and into the base of the
camera. This secures the camera to the mount.
7. Adjust the camera to the desired viewing angle by:
• Tilting the lens up or down for vertical adjustment
• Turn the camera body left or right to adjust the angle
horizontally
Installation is complete.
Pole Mount Install

Setting Up UniFi Protect via App
Download and install the UniFi Protect app to configure the
UVC‑G3‑Flex.
Note: When you first launch UniFi Protect, the app will
prompt you to enable Bluetooth and other relevant
features necessary to provide the best user experience
possible. Please allow these features and permissions
to take place for proper app functionality.
1. Launch the UniFi Protect app.

2. Tap the side menu in the upper‑left corner of the app to
access additional options.
3. Tap Add Cameras to add a new camera.
Note: If setting up multiple cameras, UniFi Protect
allows you to add more than one camera during the
setup process.
4. When the Select cameras screen appears, tap each camera
in the list you would like to add to your UniFi Protect
system. Tap Set up cameras to continue.

5. A Name your camera screen appears individually for each
camera you selected in step 4. Enter a name for each
camera and tap Next, repeating this process until all
cameras have been named.
6. If necessary, any camera requiring a firmware upgrade will
update at this time. Once completed, a live view of each
camera will display in the app.
UVCG3 FLEX

Specifications
UVC‑G3‑Flex
Dimensions Ø107.5 x 48 x 48 mm
(Ø 4.23 x 1.89 x 1.89")
Weight 170 g (5.99 oz)
Sensor 1/2.7" 2‑Megapixel HDR Sensor
Lens EFL 4mm / f2.0
Viewing Angle with Lens
Distortion Correction (LDC)
LDC Off
LDC On
87.4° (H), 47° (V), 104° (D)
80° (H), 46° (V), 92° (D)
Night Mode IR LEDs with Mechanical ICR Filter
Video Compression H.264
Resolution 1080p FHD (1920 x 1080)
Maximum Frame Rate 25 FPS
Image Settings Brightness, Contrast, Sharpness, Saturation,
Noise Reduction, 50/60 Hz
Microphone Yes
Management Interface UniFi Protect; UniFi Video
Networking Interface (1) 10/100 Ethernet Port
Max. Power Consumption 4W
Power Method 802.3af PoE
Power Supply 802.3af PoE Switch Port
Mounting Table, Wall (Indoor/Outdoor), Pole
Operating Temperature ‑20 to 50° C
(‑4 to 122° F)
Operating Humidity 20 to 90% Noncondensing

Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Hot Surface. Do not touch.
WARNING: Do not use this product in a location that can
be submerged by water.
WARNING: Avoid using this product during an electrical
storm. There may be a remote risk of electric shock from
lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current
requirements indicated on the manufacturer’s label. Connection to a
different power source than those specified may result in improper
operation, damage to the equipment or pose a fire hazard if the
limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service
should be provided only by a qualified service technician.
