Uconnect 3.0 Configuration guide

Owner’s Manual Supplement
Uconnect®3.0

TABLE OF CONTENTS
SECTION PAGE
1SAFETY GUIDELINES .........................................................3
2INTRODUCTION .............................................................9
3RADIO MODE ...............................................................19
4MEDIA MODE ..............................................................25
5UCONNECT® PHONE .........................................................31
6UCONNECT® 3.0 VOICE RECOGNITION QUICK TIPS ..............................37
1
2
3
4
5
6

SAFETY GUIDELINES
CONTENTS
䡵SAFETY GUIDELINES .....................4
1

SAFETY GUIDELINES
WARNING!
ALWAYS drive safely with your hands on the
steering wheel. You have full responsibility and
assume all risks related to the use of the
Uconnect® features and applications in this ve-
hicle. Only use Uconnect® when it is safe to do so.
Failure to do so may result in an accident involv-
ing serious injury or death.
All persons should read this manual carefully before
using the radio system. It contains instructions on how to
use the system in a safe and effective manner.
Please read and follow these safety precautions. Failure
to do so may result in injury or property damage.
•Glance at the screen only when safe to do so. If
prolonged viewing of the screen is necessary, park in a
safe location and set the parking brake.
•Stop use immediately if a problem occurs. Failure to
do so may cause injury or damage to the product.
Return it to your authorized dealer to repair.
•Make certain that the volume level of the system is set
to a level that still allows you to hear outside traffic
and emergency vehicles.
4 SAFETY GUIDELINES

Safe Usage Of The Uconnect® System
•Read all instructions in this manual carefully before
using your system to ensure proper usage!
•Your system is a sophisticated electronic device. Do
not let young children use your system.
•Permanent hearing loss may occur if you play your
music or the system at loud volumes. Exercise caution
when setting the volume on your system.
•Keep drinks, rain, and other sources of moisture away
from your system. Besides damage to your system,
moisture can cause electric shocks as with any elec-
tronic device.
Touchscreen
•Do not touch the screen with any hard or sharp objects
(pen, USB stick, jewelry, etc.) which could scratch the
touchscreen surface!
•Do not spray any liquid or caustic chemicals directly
on the screen! Use a clean and dry micro fiber lens
cleaning cloth in order to clean the touchscreen.
•If necessary, use a lint-free cloth dampened with a
cleaning solution, such as isopropyl alcohol or an
isopropyl alcohol and water solution ratio of 50:50.
Be sure to follow the solvent manufacturer’s precau-
tions and directions.
1
SAFETY GUIDELINES 5

Disc Drive
•Do not insert any damaged, warped, scratched or dirty
Discs into the Disc Player.
•Discs that have been modified with an adhesive label
should not be used in the Disc Player.
•Do not insert more than one Disc at a time into the
drive slot.
FCC Declaration
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2)
this device must accept any interference received, includ-
ing interference that may cause undesired operation.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harm-
ful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
6 SAFETY GUIDELINES

If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
•Increase the separation between the equipment and
receiver.
•Consult the dealer or an experienced radio technician
for help.
Safety Information
Exposure to Radio Frequency Radiation
The radiated output power of the this internal wireless
radio is far below the FCC radio frequency exposure
limits. Nevertheless, the wireless radio shall be used in
such a manner that the radio is 20 cm (200 mm) or further
from the human body.
The internal wireless radio operates within guidelines
found in radio frequency safety standards and recom-
mendations, which reflect the consensus of the scientific
community.
The radio manufacturer believes the internal wireless
radio is safe for use by consumers. The level of energy
emitted is far less than the electromagnetic energy emit-
ted by wireless devices such as mobile phones. However,
the use of wireless radios may be restricted in some
situations or environments, such as aboard airplanes.
If you are unsure of restrictions, you are encouraged to
ask for authorization before turning on the wireless
radio.
1
SAFETY GUIDELINES 7

INTRODUCTION
CONTENTS
䡵Uconnect® 3.0 SYSTEM ...................10 䡵Uconnect® 3.0 SYSTEM VOICE COMMAND ....14
2

Uconnect® 3.0 SYSTEM
WARNING!
ALWAYS drive safely with your hands on the steer-
ing wheel. You have full responsibility and assume
all risks related to the use of the Uconnect® fea-
tures and applications in this vehicle. Only use
Uconnect® when it is safe to do so. Failure to do so
may result in an accident involving serious injury or
death.
10 INTRODUCTION

2
INTRODUCTION 11

1 — RADIO
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM and
SXM (if equipped) can be selected by pushing the RADIO
button on the faceplate until the desired tuner mode is
displayed.
2 — INFO
Push the INFO button on the faceplate for a RBDS station
(one with call letters displayed). The radio will return a
Radio Text message broadcast from an FM station (FM
mode only).
3 — AUDIO
Push the AUDIO button on the faceplate to adjust the
Bass, Mid Range, Treble, Balance or Fade.
4 — MENU
Push the MENU button on the faceplate to scroll between
the setting sub-menus.
5 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
6— PRESETS 1–6
These buttons on the faceplate tune the radio to the
stations that you commit to memory AM (A, B, C), FM
(A, B, C) and Satellite (A, B, C) — 18 AM, 18 FM and 18
SAT stations.
12 INTRODUCTION

7 — BACK
Push the BACK button on the faceplate to return to a
previous menu or screen.
8 — SEEK UP
Push the SEEK UP button on the faceplate to tune the
radio to the next listenable station or channel.
9 — SEEK DOWN
Push the SEEK DOWN button on the faceplate to tune
the radio to the previous listenable station or channel.
10 — PLAY/PAUSE/MUTE
Push to Play, Pause or Mute the music.
11 — ON/VOLUME
Push the ON/VOLUME control knob to turn on the
radio. Push the ON/VOLUME control knob a second
time to turn off the radio.
The electronic volume control turns continuously (360
degrees) in either direction without stopping. Turning the
ON/VOLUME control knob to the right increases the
volume and to the left decreases it.
12 — A-B-C
Push the A-B-C button on the faceplate to select the A, B
or C preset list.
13 — MEDIA
Pushing the MEDIA button on the faceplate will allow
you to switch from AM/FM/SXM modes to Media mode
(CD – if equipped, USB/iPOD®, AUX).
2
INTRODUCTION 13

Uconnect® 3.0 SYSTEM VOICE COMMAND
WARNING!
ALWAYS drive safely with your hands on the steer-
ing wheel. You have full responsibility and assume
all risks related to the use of the Uconnect® fea-
tures and applications in this vehicle. Only use
Uconnect® when it is safe to do so. Failure to do so
may result in an accident involving serious injury or
death.
14 INTRODUCTION

2
INTRODUCTION 15

1 — RADIO
Push the RADIO button on the faceplate to enter the
Radio Mode. The different tuner modes; AM, FM and
SXM (if equipped) can be selected by pushing the RADIO
button on the faceplate until the desired tuner mode is
displayed.
2 — PHONE PICK UP
Push the PHONE PICK UP button to initiate or answer a
phone call, send or receive a text.
3 — PHONE HANG UP
Push the PHONE HANG UP button to end a call.
4 — A-B-C
Push the A-B-C button on the faceplate to select the A, B
or C preset list.
5 — PRESETS 1–5
These buttons on the faceplate tune the radio to the
stations that you commit to memory AM (A, B, C), FM
(A, B, C) and Satellite (A, B, C) — 18 AM, 18 FM and
18 SAT stations.
6 — ENTER/BROWSE & TUNE/SCROLL
Push the ENTER/BROWSE button to accept a high-
lighted selection on the screen. Rotate the TUNE/
SCROLL rotary knob to scroll through a list or tune a
radio station.
7 — SEEK UP
Push the SEEK UP button on the faceplate to tune the
radio to the next listenable station or channel.
16 INTRODUCTION

8 — BACK
Push the BACK button on the faceplate to return to a
previous menu or screen.
9 — MENU
Push the MENU button on the faceplate to scroll between
the setting sub-menus.
10 — INFO
Push the INFO button on the faceplate for a RBDS station
(one with call letters displayed). The radio will return a
Radio Text message broadcast from an FM station (FM
mode only).
11 — PLAY/PAUSE/MUTE
Push to Play, Pause or Mute music or Mute an active
phone call.
12 — SEEK DOWN
Push the SEEK DOWN button on the faceplate to tune
the radio to the previous listenable station or channel.
13 — ON/VOLUME
Push the ON/VOLUME control knob to turn on the
radio. Push the ON/VOLUME control knob a second
time to turn off the radio.
The electronic volume control turns continuously (360
degrees) in either direction without stopping. Turning the
ON/VOLUME control knob to the right increases the
volume and to the left decreases it.
14 — MEDIA
Pushing the MEDIA button on the faceplate will allow
you to switch from AM/FM/SXM modes to Media mode
(CD – if equipped, USB/iPOD®, AUX).
2
INTRODUCTION 17

RADIO MODE
CONTENTS
䡵OPERATING RADIO MODE................20
▫ON/OFF Volume Control.................20
▫
ENTER/BROWSE & TUNE/SCROLL Control . . .20
▫Seek Functions ........................20
▫Setting Presets.........................21
▫
SiriusXM Satellite Radio Mode — If Equipped . . .21
▫Audio ..............................22
▫Clock Setting .........................23
3
